CONVERTITORE MINI DISPLAYPORT A VGA CONVERTITORE MINI DISPLAYPORT A VGA Gentile Cliente Grazie per aver acquistato questo prodotto. Per ottenere il massimo delle prestazioni nella salvaguardia della vostra sicurezza, vi consigliamo di leggere con attenzione il presente manuale prima di collegare e mettere in funzione il prodotto. Tenete sempre a disposizione il presente manuale per ulteriori esigenze future.
CONVERTITORE MINI DISPLAYPORT A VGA 2.0 SPECIFICHE Ingresso/Uscita segnale Maximum Single Link Range 1920X1200, 1080P Formato video supportato Max to1920x1200 Frequenza operativa Range di frequenza verticale 50/60 Hz Larghezza di banda video 162MHz Informazioni meccaniche Peso (netto) 28g Informazioni ambientali Temperatura d’esercizio Da 0° a +70° Umidità d’esercizio Da 10% a 85 % RH (senza condensa) Temperatura di stoccaggio Da -10° a +80°...
CONVERTITORE MINI DISPLAYPORT A VGA 5.0 COLLEGAMENTO E FUNZIONAMENTO 1) Collegare il connettore Mini DisplayPort maschio al Mini DisplayPort della sorgente 2) Collegare il connettore VGA femmina allo schermo tramite un cavo VGA maschio/maschio Attenzione: Inserire / Estrarre il cavo con delicatezza. 5.1 SCHEMA DI COLLEGAMENTO DISPLAY CONVERTITORE MINI DISPLAYPORT A VGA...
Contattate le autorità locali competenti per ottenere informazioni in merito allo smaltimento corretto della presente apparecchiatura. Con il marchio CE, Techly garantisce che il prodotto è conforme alle norme e direttive ®...
Page 7
MINI DISPLAYPORT TO VGA CONVERTER USER’S MANUAL TABLE OF CONTENTS 1.0 Introduction ..............................................2.0 Specifications ............................................3.0 Package Contents ......................................... 4.0 Panel Descriptions ....................................... 5.0 Connection and Operation ..............................6.0 Safety Precaution and maintenance ....................
MINI DISPLAYPORT TO VGA CONVERTER MINI DISPLAYPORT TO VGA CONVERTER Dear customer Thank you for purchasing this product. For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. 1.0 INTRODUCTION The Mini DisplayPort to VGA signal format converter seamlessly connect next generation DisplayPort based MacBook, MacBook Pro, or MacBook Air with a Mini DisplayPort to conventional VGA...
MINI DISPLAYPORT TO VGA CONVERTER 2.0 SPECIFICATIONS Signal Inputs/Output Maximum Single Link Range 1920X1200, 1080P Video format supported Max to1920x1200 Operating Frequency Vertical Frequency Range 50/60 Hz Video Amplifier Bandwidth 162MHz Mechanical Weight (net) Environmental Operating Temperature 0° C to +70° C Operating Humidity 10% to 85% RH (no condensation) Storage Temperature -10° C to +80° C Storage Humidity 5% to 95% RH (no condensation) Power Requirement External Power Supply...
MINI DISPLAYPORT TO VGA CONVERTER 5.0 CONNECTION AND OPERATION 1) Connect the Mini DisplayPort male to Mini DisplayPort source device 2) Connect the VGA female to display by VGA M/M cable Attention: Insert / Extract cable gently. 5.1 CONNECTION DIAGRAM DISPLAY MINI DISPLAYPORT TO VGA CONVERTER...
In compliance with EU Directive WEEE this product is marked with this symbol. It means that used electrical and electronic products should not be mixed with general household waste. There is a separate collections system for these products in compliance with WEEE directive, otherwise contaminative and hazardous substances can pollute the environment. With the CE sign, Techly ensures that the product is conformed to the basic European ® standards and directives.
