  • Page 1 Manual Orangery hexagonal glass, 7,2 m² 18-12-2020...
  • Page 2 Orangery Assembly Instructions —— For Single Hinged Door Walk-in Greenhouse...
  • Page 3: Safety Warning

    Thank you for purchasing your new greenhouse. We recommend you familiarize yourself with the instructions and read all safety information before you commence assembly. These instructions are divided into sections: Base, Part lists, Preparation, Side wall, Rear wall, Front wall, Roof, Vent, Door, PVC capping bar, Polycarbonate or Glass, Down pipes, Optional Turbine Vent, Anchoring greenhouse to slab or base etc.
  • Page 4: Additional Considerations

    Important Before assembling your new greenhouse, please check that all parts in the provided list are included. Please take each bundle out of the packaging in order to identify the parts better. Most parts are num- bered and can be identified by a stamped number or removable label. Alternatively, the components can be identified by lengths detailed in the packing list (see diagram below).
  • Page 5 Base We cannot emphasis how important it is to have a proper base for your Greenhouse to be erected upon. It is essential that the BASE IS FLAT, LEVEL AND SUBSTANTIAL enough to take the weight of the greenhouse including its polycarbonate panels or heavy glass. Give yourself enough room around your base to allow for fitting the polycarbonate panel or glass and any ongoing maintenance / cleaning.
  • Page 6 Base IMPORTANT Before assembling aluminium base, the end trough centers of seven legs should match both end trough centers of side sills and front & rear sills at the same time. Please match six legs troughs together at the same time...
  • Page 7: Parts List

    Parts List Package 1 7901 7607 7905 7906 7910 7911 Size 1922 1922 1520 1520 2033 1450 M6x10 M6x15 Package 2 7022 7902 7904 7906 7607 7530 7531 7910 7911 7913 Size 1462 1462 1520 1520 1922 1922 1922 2033 1450 M6x10 Rubber...
  • Page 8 Parts List Package 5 7520 7521 7522 7526 7527 7529 Φ3.5x19 M6x25 Size 1909 1909 M6x10 M6x8 S1/S2 LOCK Size 1 SET 1 SET Package 7 Φ3.5x13 Size 1400...
  • Page 9 BASE Base dimensions and recommendations. Ensure that your base is level as this will make assembly of the building, especially the glazing of the roof much more straight forward. PARTS LIST Most components should have a code punched into their metal surface. Identify and separate all like for like components prior to assembly.
  • Page 10 Join 3 short roof glazing bars #7917 between the hexagonal roof bracket #7992 and the center of vent hinge beam #7921. Please note: #7917 overlap bracket by distance of 24 mm at the one end, and con- nected vent hinge beam by joining plate #m3 at the another end. Join 3 roof glazing bars #7916 between the hexagonal roof bracket #7992 and the center of eave .
  • Page 11 In Package 1 & Package 2 Side wall 7901 7607 7022 7905 7906 7910 7911 Size 1922 1922 1462 1519 1519 2033 1450 M6x10 M6x15           Package 1  Package 2 7906 7905 7910...
  • Page 12 Side wall 7910 7607 7911 7901 7911 7911 7901 7910 7911 7911 7911 7906 7906 7607 7901 7910 7906 7905 7906 7905 7910 7910 7901...
  • Page 13 In Package 2 Rear wall —— Join Side wall together 7022 7906 7607 7910 7911 Size 1462 1519 1922 2033 1450 M6x10 M6x15 7906 7022 a3/a2 7022 7906 a1/a2...
  • Page 14 Rear wall 7906 7607 7910 7910 7911 7022 7906 7906 7901 7911 7911 7910 7607 7901 7607 7910 7607 7910 7910 7911 7911 a3/a2 7022...
  • Page 15: Front Wall

    In Package 2 Front wall —— Join Side wall together 7904 7902 7530 7531 7913 Rubber Size 1519 1462 1922 1922 M6x10 M6x15 M6x8 7904 a1/a2 7904 a3/a2 7902 7902...
  • Page 16 Front wall Rubber 7530 7530 7530 7530 a19/a2 a19/a2 a19/a2 7904 7913 7913 7530 7531 7902 7904 7901 7531 a3/a2 7913 7531 7913 7531 7902...
  • Page 17 In Package 3 Roof 7914 7916 7917 7918 7921 7991 7992 7993 7994 Size 1534 1352 Size M6x10 M6x110 M6-L 7992 7914 7914 7914 7914 7914 7914 7914 7992 7992 7914 7914...
  • Page 18 Roof 7918 7918 7914 7921 7914 7917 7916 7916 7914 7914 7917 7917 7918 7918 7921 7921 7918 7918 7916 7914 7914 7992 7992 7916 7916 7917 7916 7921 7921 7918 7918 7914...
  • Page 19 Roof 7994 7991 7993 7992 7914 close open...
  • Page 20 In Package 4 Vent 7950 7951 7952 7924 7953 7067 Φ3.9x8 M4x8 Size M6x10 7950 7918 7918 7067 7950 7950 7918 7951 7951 7924 7924 7924...
  • Page 21 Vent 7952 7951 7057 7924 7952 7924 7057 7952 7952 7924 p3/a4...
  • Page 22 In Package 5 Door 7520 7521 7522 7526 7527 7529 Φ3.5x19 M6x25 Size 1909 1909 M6x10 M6x8 S1/S2 LOCK Size 1 SET 1 SET 7521 7526 7526 7527 7522 Φ3.5x19 M4x28 7522 M4x40 7520...
  • Page 23 Door a11/a2 7527 7520 7520 7529 7526/ 7527 7527 7521 a19/a2 7522 a19/a2 7527 7527 7520 a19/a2...
  • Page 24 Door 7531 a19/a2 a9/a2...
  • Page 25 PVC Capping Bar Step6 Step1 Step3 Step4 Step2 Step5 Note: PVC capping bars were pushed in place from both top and bottom in diagonal direction to- gether. If you assemble it from one side by one side, you will fell space is too tight to assemble an- other PVC capping bar.
  • Page 26 Silicone Waterproof Alu. Foil tape 100mm x 6pc...
  • Page 27 4mm Glass...
  • Page 28 4mm Glass six corners same six corners same c-1512 c-1512 c-688 c-777 c-777 c-688...
  • Page 29 4mm Glass Length HEX10 Size HEX10 1921 700 x 1919 Side Wall 586 x 609 1512 341 x 1919 1352 592 x 439 592 x 195 700 x 0 / 1397 Roof 372 x 0 / 744 394 (77) x 634 5 meter 19 roll Silicone...
  • Page 30 Downpipe Half edge trimmed firstly Waterproof Alu. Foil tape 100mm x 6pc Φ3.5x13 1400...
  • Page 31 The list of parts Description Side wall Rear & Front wall Roof Vent Door PVC capping bar Downpipe Polycarbonate panels Tools Assembly Instruction...
