Specifying the Network Settings

This chapter describes the settings and procedures necessary to connect and use the
machine with a TCP/IP network.

TCP/IP Network Setup Procedures

To use a TCP/IP network, it is necessary to perform the following procedures.
Network Cable Connection (See "To Use the Machine as a Network Printer
1
(Network Connection)," in the Set-Up Instructions for Networking and
Printing.)
Connect the network cables in accordance with the Set-Up Instructions for Networking and Printing.
Preparation for Protocol Settings (See "Preparation for Protocol Settings," on
2
p. 2-3.)
Specify the machine's basic protocol settings for communication between the machine and computers using
the machine. To specify the settings, use:
•
The machine's operation panel
•
NetSpot Device Installer (Canon utility software included in the User Software CD)
•
ARP/PING commands
3
Protocol Settings (See "Protocol Settings," on p. 2-10.)
Specify the machine's advanced protocol settings. To specify the settings, use:
•
NetSpot Console (via a web browser) (Canon utility software)
•
A web browser (Remote UI)
Computer Settings for Printing (See "Setting Up a Computer for Printing," on
4
p. 2-15.)
Specify the settings for each computer you use for printing.
IMPORTANT
•
It is recommended that the network manager perform steps 1, 2, and 3 above.
TCP/IP Network Setup Procedures
2
CHAPTER
2-1
