  • Page 1 TES3 and TES5 Multi-Standard VBI Processors Hardware User Manual...
  • Page 2 Ross has become well known for the Ross Video Code of Ethics. It guides our interactions and empowers our employees. I hope you enjoy reading it below. If anything at all with your Ross experience does not live up to your expectations be sure to reach out to us at solutions@rossvideo.com.
  • Page 3 © 2015 Ross Video Limited. Ross®, openGear®, and any related marks are trademarks or registered trademarks of Ross Video Ltd. All other trademarks are the property of their respective companies. PATENTS ISSUED and PENDING. All rights reserved. No part of this publication...
  • Page 4 Any changes or modifications not expressly approved by Ross Video could void the user’s authority to operate the equipment.
  • Page 5 Important Safety Notices to Service Personnel Before using this product and nay associated equipment, refer to the section “Important Safety Instructions” listed below to avoid personnel injury and to prevent product damage. Symbol Meanings This symbol identifies a Protective Earth (PE) terminal, which is provided for connection of the supply system’s protective earth (green or green/yellow) conductor.
  • Page 6 Only use attachments/accessories specified by the manufacturer. Warning — Refer all servicing to qualified personnel. Servicing is required when the apparatus has been damaged in any way, such as power-supply cord or plug damage, liquid has been spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or moisture, does not operate normally, or has been dropped.
  • Page 7 The crossed out wheelie bin symbol invites you to use these systems. If you need more information on the collection, reuse, and recycling systems, please contact your local or regional waste administration. You can also contact Ross Video for more information on the environmental performance of our products.
  • Page 8 Company Address Ross Video Limited Ross Video Incorporated 8 John Street P.O. Box 880 Iroquois, Ontario, K0E 1K0 Ogdensburg, New York Canada USA 13669-0880 General Business Office: (+1) 613 • 652 • 4886 Fax: (+1) 613 • 652 • 4425 Technical Support: (+1) 613 •...
  • Page 9: Table Of Contents

    Troubleshooting Replacing a Fuse ........................4-2 Fails to Start ......................... 4-3 Stays in Bypass ........................4-4 Cannot Decode Data Encoded by the TES3 and TES5 ............4-5 Other Operating Difficulties ....................4-6 Specifications Technical Specifications ...................... 5-2 Electrical Specifications ..................5-2 AC Power Specifications..................
  • Page 10 • Contents TES3 and TES5 Hardware User Manual (Iss. 03)
  • Page 11: Introduction

    TES5 are part the Ross Terminal Equipment family of products, backed by Ross Video’s experience in engineering and design expertise since 1974. You will be pleased at how easily your new TES3 and TES5 fits into your overall working environment. Equally pleasing is the product quality, reliability and functionality. Thank you for...
  • Page 12: Overview

    TES3 and TES5 products. The TES3 is a broadcast-quality VBI encoder and decoder unit for analog video. It can insert data in various formats into a program video feed. As well it can decode CEA-608 captioning from both the program input and an auxiliary analog video input.
  • Page 13: Hardware Overview

    Hardware Overview In This Chapter This chapter provides an overview of the hardware. The following topics are discussed: • Before You Begin • Front Panel • Rear Panel TES3 and TES5 Hardware User Manual (Iss. 03) Hardware Overview • 2–1...
  • Page 14: Before You Begin

    Unpacking Unpack each TES3 and TES5 you received from the shipping container and ensure that all items are included. If any items are missing or damaged, contact your sales representative or Ross Video directly.
  • Page 15: Front Panel

    Front Panel Figure 2.1 shows the front panel controls and indicators on the TES3 and TES5. The TES3 is used for illustration, but the controls and indicators are identical on the TES5. TES3 PGM VIDEO STATUS AUX VIDEO PORT A...
  • Page 16: Rear Panel

    This RJ-11 connector is used to connect the internal modem to a telephone line. 10. PORTS A, B, C Connectors These 9 pin male D connectors can be used to connect the TES3 or TES5 to serial RS232 devices. 11. PARALLEL Connector This 9 pin female D connector is intended for general-purpose input or output connections.
  • Page 17: Installation

    Installation In This Chapter This chapter describes how to mount the TES3 or TES5 in the rack and provides a general overview of how to install the TES3 and TES5. The following topics are discussed: • Mounting the TES3 and TES5 in a Rack TES3 and TES5 Hardware User Manual (Iss.
  • Page 18: Mounting The Tes3 And Tes5 In A Rack

    This section describes how to mount the TES3 and TES5 in the rack. In using these instructions, consult Figure 3.1. Note that the TES3 and TES5 should be attached to both the front and rear of the rack; because of the weight of the potentially large number of cables connected to the rear of the TES3 and TES5, rear rack mounting is strongly advised.
  • Page 19 When connecting to a device that is wired as Data Communications Equipment (DCE), such as a modem, you need to use a “straight-through” 9-pin cable instead of the null-modem. This cable is not supplied with the TES3 or TES5, but is readily available from data cable suppliers.
  • Page 20 3–4 • Installation TES3 and TES5 Hardware User Manual (Iss. 03)
  • Page 21: Troubleshooting

    Other error conditions not outlined in this section may depend on the software modules loaded into the TES3 and TES5, and on the application software that provides the data for encoding. Please refer to the manuals for these software packages for additional troubleshooting assistance.
  • Page 22: Replacing A Fuse

    Replacing a Fuse The AC power to the TES3 and TES5 is protected by a 1-ampere fuse; this is located behind a small cover on the rear-panel power entry module. If the power cord is attached to the TES3 and TES5 and plugged into a live AC outlet, and the power switch is in the ON position, yet none of the LEDs on the TES3 and TES5's front panel come on, the fuse has probably blown.
  • Page 23: Fails To Start

    If the indicator is red for more than 1 minute after power-on, turn the unit off for several seconds and then back on. If the indicator is still red after 1 minute, contact Ross Video Technical Support. Note that if this LED occasionally switches between red and green during operation, this does not necessarily indicate a problem.
  • Page 24: Stays In Bypass

    If the bypass LED stays on after the TES has fully powered up, even though all the above conditions are met, please check that the video input is the correct type (analog for the TES3, SMPTE 259M SDI for the TES5). If so, there may be an internal fault in the TES. Contact Ross Video Technical Support.
  • Page 25: Cannot Decode Data Encoded By The Tes3 And Tes5

    Cannot Decode Data Encoded by the TES3 and TES5 If the TES3 and TES5 is out of bypass, and it has been set up to encode VBI services, these services should be injected into the designated lines of the Video Out signal. If you believe that they are not, please check the following: •...
  • Page 26: Other Operating Difficulties

    The operation of the TES is strongly dependent on the software that is installed in it. This manual therefore does not discuss all aspects of operating the TES. If you should experience difficulty in operating the TES, please refer to the TES3 and TES5 Encoder Software User Manual. For additional assistance, please contact Ross Technical Support.
  • Page 27: Specifications

    Specifications In This Chapter This chapter provides the technical specification information for the TES3 and TES5. Note that technical specifications are subject to change without notice. The following topics are discussed: • Technical Specifications TES3 and TES5 Hardware User Manual (Iss. 03)
  • Page 28: Technical Specifications

    Technical Specifications This section provides technical information on the TES3 and TES5. Electrical Specifications Table 5.1 TES3 and TES5 Electrical Specifications Connector Specification RS232, up to 115.2K bits/sec, see Table 5.7 for pinouts PORT A RS232, up to 115.2K bits/sec, see Table 5.7 for pinouts PORT B RS232, up to 115.2K bits/sec, see Table 5.7 for pinouts...
  • Page 29: Environmental Specifications

    < 0.2° Differential Phase Input Return Loss Power > 46 dB to 5 MHz On (multi-burst) Input Return Loss Power > 40 dB to 5 MHz Off or Bypass TES3 and TES5 Hardware User Manual (Iss. 03) Specifications • 5–3...
  • Page 30: Tes5 Program Video Specifications

    > 300 m of type 8281 cable (pathological signal) < 0.08 UI Output jitter > 15 dB to 270 MHz Input return loss (active) > 13 dB to 270 MHz Input return loss (bypass) 5–4 • Specifications TES3 and TES5 Hardware User Manual (Iss. 03)
  • Page 31: Cabling Information

    Not connected Table 5.8 shows the wiring of the null modem cable supplied with the TES3 and TES5. This table can be used to construct a cable to connect PORT A, PORT B or PORT C to a COM port on a PC or other such equipment.
  • Page 32: Remote Connector Pinouts

    LED to pin 3 and the cathode to pin 2. (Figure 5.1) Signal Description Bypass switch Bypass LED + Ground — Figure 5.1 Remote Connector Wiring 5–6 • Specifications TES3 and TES5 Hardware User Manual (Iss. 03)
  • Page 33 Notes:...
  • Page 34 Notes:...
  • Page 35 Notes:...
  • Page 36 Contact Us Contact our friendly and professional support representatives for the following: • Name and address of your local dealer • Product information and pricing • Technical support • Upcoming trade show information Telephone: +1 613 • 652 • 4886 Technical After Hours Emergency: +1 613 •...
