HygroMatik DG 8 Quick Start Manual

Hide thumbs Also See for DG 8:

1. Electric motor

2. Atomizer disc

3. Ba e grid

4. Water feed cone

5a. Mechanical oat - only DG 4

6. Water solenoid valve for operating level

7. Mechanical over ow

8. Atomized droplet spray

9. Terminal box

10. Fan impeller

11. Carrier air ow

Nur bei DG8:

13. Mechanical level oat and microswitch for electrical safety

over ow/guard

14. Water solenoid valve for electrical - safety over ow guard

15. drain connection

Table of Contents

Need help?

Do you have a question about the DG 8 and is the answer not in the manual?

Page 1 1. Electric motor 2. Atomizer disc 3. Ba e grid 4. Water feed cone 5a. Mechanical oat - only DG 4 6. Water solenoid valve for operating level 7. Mechanical over ow 8. Atomized droplet spray 9. Terminal box 10. Fan impeller 11.
Page 2 Cabinet E-8101001 Motor hood with dust cover E-8101002 Motor hood E-8101023 Air guidance hood E-8101006 Air guidance hood E-8101024 Fan impeller E-8101025 Guard grille for fan impeller E-8101011 Guard grille for fan impeller, compl. with xing screws B-8101026 Water pan with safety over ow 1/2" B-8101014 Water pan with safety over ow 1/2"...
Page 3 Water feed and atomizer components E-8401009 Water feed cone E-8401002 Water feed cone E-8401003 Water feed cone E-8401010 Atomizer disc E-8401004 Atomizer disc E-8401012 Ba e grid E-8401007 Ba e grid E-8401011 Nuts and washers for xing atomizer disc E-8401006 Nuts and washers for xing atomizer disc E-8401014 U-washer d=8,4 mm E-8401013 U-washer d=13 mm Mechanical parts, hoses, screws, seals...

Dg 4
