  • Page 1 Manual Electric Heater Steam Humidifier...
  • Page 2  Copyright HYGROMATIK GmbH; HeaterLine January 2012 Information in this manual is subject to change or alteration without prior notice. Current version of this manual can be found at: www.hygromatik.co.uk Warning, Hazardous Voltage: All work to be performed by trained personnel only.

  • Page 3: Table Of Contents

    1. Introduction ........................5 1.1 Typographic Distinctions ....................5 1.2 Documentation ........................5 1.3 Directions for Use ......................6 2. Safety Notes ........................7 2.1 Overview ........................... 7 2.2 Guidelines for Safe Operation ................... 7 2.3 Disposal after Dismantling ....................8 3.
  • Page 4 6.3.1 Feed from Holding Tank ....................39 6.4 Water Treatment ....................... 39 6.5 Water Discharge ........................ 40 6.6 Checklist ..........................41 7. Electrical Installation ......................42 7.1 Electrical Installation ......................42 7.2 Cable Connections ......................43 7.3 Control Connection ......................43 7.4 Fan Unit ..........................

  • Page 5: Introduction

    They will impress you with their safety, ease of use and econom- ical operation. In order to operate your HygroMatik steam humidifier safely, properly and efficiently, please read these operating instructions. Employ your steam humidifier only in sound condition and as directed.

  • Page 6: Directions For Use

    / condensate water (only for humidifier type HeaterLine, HeaterCompact and HeaterSlim). Warning: HygroMatik steam humidifiers emit steam with a tem- perature of 100° C. The steam may not be inhaled directly. Only qualified and authorised personnel may operate the unit.

  • Page 7: Safety Notes

    2. Safety Notes 2.1 Overview These safety notes are required by law. They promote work- place safety and accident prevention. Warnings and Safety Symbols The safety symbols below identify sections containing warnings about hazards or potential dangers. Please familiarize yourself with these symbols.

  • Page 8: Disposal After Dismantling

    HygroMatik steam humidifiers are IP20-protected. Make sure that the unit is protected from drips in its installed location. Installing a humidifier in a room without water discharge requires safety devices to protect against water leakages. Accident Prevention Regulations Comply with the Accident Prevention Regulation Electrical Sys- tems and Equipment to prevent injury to yourself and others.

  • Page 9: Transport

    HL 27 HL 30 HL 36 HL 45 * Dimensions and weigths can vary insignificantly The heating element humidifiers type HeaterLine 60-90 are double units - they consist of two separate units. HL 60 HL 30 HL 30 (Slave) HL 70...

  • Page 10: Packing

    3.3 Packing Note: Observe the symbols affixed to the box. 3.4 Interim Storage Keep the unit dry and protect from frost. 3.5 Check for Complete and Correct Delivery of Goods Upon receipt of the unit, make sure that:  type and serial number on the name plate match what is in the purchasing and delivery documents, ...

  • Page 11: Operation And Installation

    4. Operation and Installation 4.1 Mode of Action The Imersion Heater Principle One to five heater elements (8) are placed in a closed cylinder and connected to alternating current. The cylinder (9) is filled with tap water, fully demineralized water or partially softened water.
  • Page 12 (“Dry Run”). The cylinder water is periodically flushed out with a heavy-duty blow-down pump (10). Hygromatik’s SUPER FLUSH system effectively assists this operation. The SUPER FLUSH mecha- nism generates a strong whirlpool effect in the strainer basket which aids removal of scale deposits during the blow-down pro- cess.

  • Page 13: Internal Output Setting

    For maintenance the cylinder can be drained by pressing the control switch „Pos.II”. 4.3 Internal Output Setting Continuous control of the HeaterLine Type steam humidifier is achieved by proportional control ( pulse-width modulation) of the heater elements. In this way the humidifier can be proportionally operated across the entire output range of 5% - 100% nominal capacity.

  • Page 14: Mechanical Installation

    5. Mechanical Installation Warning: Installation of this unit should be performed by quali- fied personnel only. Hygromatik accept no liability for damage due to faulty installation. Obey all safety instructions and warnings on the unit. During installation the unit must be disconnected from its power supply.

  • Page 15: Fitting Measures

    5.1.1 Fitting Measures Wall Distance (all dimensions in mm) Note: It is often advantageous to use existing water connections (feed and drain) when selecting the steam humidifier. Wall Mounting Note: To function properly the steam humidifier must be installed vertically. Measures for drills for wall mounting please see table (measures d and e) in chapter „Equipment Dimensions”.If there is no suit- able wall, it is recommended that the equipment is installed on...

  • Page 16: Equipment Dimensions Hl 06-45

    5.1.2 Equipment Dimensions HL 06-45 View from below HL 06-27 HL 30-45 Rear view 56,5 56,5 18,5 18,5 all dimensions in mm View from top Page 16...

  • Page 17: Fan Unit (Option)

    5.2 Fan Unit (option) Note: The fan unit should be positioned to avoid drafts. A mini- mum height of 2 m is generally sufficient.  Install the fan unit directly on a wall. Type Fan Unit HL 6 VG 08 HL 9 VG 17 HL 18 - 30...
  • Page 18 Technical Specifications Fan Unit VG Fan Unit VG08 VG17 VG30 Quantity of Steam [kg/h] Steam Inlet [mm] Condensate Outlet [mm] Airflow Capacity [cbm/h] Nominal Output Nominal voltage Dimensions W [mm] H [mm] D [mm] Weight [kg] Sound Level (1m dis- [dB(A)] tance to the source of noise)

  • Page 19: Absorption Distance Bn

    5.3 Absorption Distance B The "absorption distance" (B ) is defined as the distance from the steam feed to where the steam is completely absorbed in the treated air. Inside the absorption distance, steam is visible as mist in the air stream. Condensation may collect on anything installed inside the absorption distance.
  • Page 20 Length I of the usable steam manifold depends on the dimen- sions of the air duct. The length of the absorption distance can be reduced by using multiple steam manifolds (also see section on the steam manifold). Method: Graphically determine absorption distance B using the absorp- tion distance nomogram (also see Section „Absorption Distance Nomogramm“).

  • Page 21: Absorption Distance Nomogram

    5.3.2 Absorption Distance Nomogram Source: Henne, Erich: Luftbefeuchtung (Air Humidification), 3 Edition 1984 (Page 101), Olden- bourg Industrieverlag, Munich Page 21...

  • Page 22: Steam Manifold

    5.4 Steam Manifold 5.4.1 Notes on Installation These notes are based on a homogeneous Horizontal installation of Standard steam manifold installation: steam manifold Duct Steam Manifold Air flow L1=L2=L3 An even distribution of steam manifolds ensures a uniform steam distribution. Please use the total hight of the duct! Steam Manifold Air flow...
  • Page 23 Air duct Positioning of steam manifolds Sample flat Staggered vertically and laterally Air flow very flat By tilting the steam manifold 30 - 45° very flat duct towards the air flow direction, the mini- mum upper clearance can be reduced to 70mm.
  • Page 24 With high-pressure air-conditioning systems, the unit's drain hose system must be modified depending on the over pressure. When this is the case please consult HygroMatik. • Install the steam manifold as close as possible to the steam humidifier in order to minimize steam loss through condensation.
  • Page 25 2x(2xDN40) 2x(1xDN40) 2x(1xDN12) * For units HL 6 - 12 and HC3-12 HygroMatik delivers one adapter DN40 / 25 (but not for SPA applications).. ** For units HL 36 - 45 HygroMatik delivers one t-connector for separating the steam on two steam manifolds.

  • Page 26: Cover Plate

    5.5 Cover Plate HygroMatik flange plates may be used to neatly complete instal- lation of the steam humidifier in the air duct. Two-piece flange plates are available for the DN25 and DN40 steam manifolds. flange plate DN25 E-2604260 flange plate DN40 E-2604410...

  • Page 27: Drill Pattern

    5.6 Drill Pattern 5.6.1 Drill Pattern DN25 (not to scale) Note: Due to variable print media the dimensions are not to scale. Page 27...

  • Page 28: Drill Pattern Dn40 (Not To Scale)

    5.6.2 Drill Pattern DN40 (not to scale) Note: Due to variable print media the dimensions are not to scale. Page 28...

  • Page 29: Steam Line

    Note: When installing the steam hose, please pay attention to the following: • The steam hose diameter may not be smaller than the steam outlet of the HygroMatik steam humidifier (do not restrict the cross-section, otherwise back pressure will increase). •...

  • Page 30: Types Of Installation

    Types of Installation 5.7.1 Installation type 1 If the steam manifold is positioned higher than 500 mm above the steam humidifier: » Lay the steam hose at a height of at least 400 mm above unit and then connect to the steam manifold with a constant rise or fall.
  • Page 31 Installation type 2 If the steam manifold is positioned lower than 500 mm above the steam humidifier: » Lay steam hose at a height of at least 400 mm above unit and then connect to the steam manifold with a con- stant fall.

  • Page 32: Condensate Hose

    Lead the open end of the condensate hose through the hole in the top of the humidifier’s cabinet. 2.: Note: Depending on the type of HeaterLine humidifier it is necessary to use one or two manifolds / condensate hoses. Therefor there are two type of connecting the condensate hose/ »...
  • Page 33 HL30 - HL45 HL6 -HL27 Connection condensate hose / hoses Lay the condensate hose at an approximate incline of 5-10% to the steam cylinder connection fitting, to allow the condensate to drain freely. Note: It is recommended to form a loop of 200 mm diameter as a vapour trap provided there is enough space.

  • Page 34: Steam Solenoid Valves

    Installation type 2 If the steam manifold is positioned lower than 500 mm above the steam humidifier: » The condensate must be drained separately. » To prevent steam loss, lay a loop at least 200 mm in di- ameter. » To ensure condensate drainage, place the loop (vapor trap) as far away as possible below the steam manifold connection.

  • Page 35: Chimney-Compartment

    5.10 Chimney-compartment Between electrical compartment (right side) and steam produc- tion compartment (left side) the chimney compartment is located. The chimney compartment is used to cool electronic components. For proper function make sure that the three holes in the top side of the housing are not covered - otherwise the heat removal is too low and a thermal cutout could be triggered.

  • Page 36: Water Installation

    When employing demineralized water or purified conden- sate, do not use copper or brass in the supply or drain lines of the HeaterLine unit. These materials can be cor- roded by demineralized water or purified condensate. Instead, use stainless steel or temperature-resistant plas- tic pipes.

  • Page 37: Water Supply (For Operation With Demineralized Water Or Purified Condensate)

    Make sure that a backflow preventer is installed in the water supply line. Note: Shut-off valve (AV), water filter (WF) and backflow pre- venter are not provided by HygroMatik. Install as follows: » Check whether the valve strainer has been inserted in the solenoid valve.

  • Page 38: Water Supply (For Operation With Tap Water Or Partially Softened Water)

    Note: Shut-off valve (SV) and water filter (WF) are not supplied with the unit » HygroMatik provides a water hose (56) with a cap nut at both ends which can be used for water installation. Install as follows: »...

  • Page 39: Feed From Holding Tank

    6.4 Water Treatment For water treatment system specifications, use the following table. The figures below assume that the humidifier has been running for 24 hours at 100% output. HeaterLine Max. Water Consump- tion in over24 h [l] 1242 Page 39...

  • Page 40: Water Discharge

    6.5 Water Discharge Warning: Please pay attention to free and non-pressure drain- age of the water! During blow down up to 0,3L/s is being drained. For water discharge, we recommend installation of a flexible water drain hose. Humidifier and waste water discharge must be on the same pressure level.

  • Page 41: Checklist

    6.6 Checklist Verify correct system installation using the checklist below:  Can flushed-out water drain freely?  Have all screws and clamps been properly tightened?  Is the water supply line properly flushed out?  Has the water installation been performed correctly? Is the drainage system correctly installed? Are the water supply and drain lines free of leaks? Warning: Flush out the water supply line before connecting to...

  • Page 42: Electrical Installation

    7. Electrical Installation Warning, Hazardous Voltage! All work related to electrical installation may be performed by authorized personnel only (electricians or professionals with equivalent training). The cus- tomer is responsible for checking qualifications.Warning, Haz- ardous Voltage! Do not connect the steam humidifier to the power grid until after all installation work has been completed.

  • Page 43: Cable Connections

    2 x (3x63) A HL90 2 x 58,5 A 2 x (3x63) A 7.2 Cable Connections The table below shows the cable connections provided in HeaterLine steam humidifiers: Unit Connection Connection Connection HL6 - 45 Characteristics of metric cable connections:...

  • Page 44: Fan Unit

    7.4 Fan Unit » Connect fan unit as specified in the wiring diagram. The fan unit is activated/deactivated in parallel with humidifica- tion. Note:Terminals 37 und 38 are supplied with the unit only when the fan unit and humidifier are purchased simultaneously. In other cases (i.e.

  • Page 45: Wiring Diagram

    After this check the unit can be switched on. Warning: The unit must be closed and locked (only for humidifer type HeaterLine). This guarantees that the cover is grounded. Note: For initial operation, control, service, malfunctions, and circuit diagrams, consult the operation instructions for the Hygro- Matik-controls or at www.hygromatik.de.

  • Page 46: Commissioning

    8. Commissioning Warning: This unit is only to be started by qualified personnel. Switching off steam humidifier Warning: Before starting up the unit, make sure you know how to switch it off. » Switch off unit by setting control switch to “0” »...

  • Page 47: Maintenance

    Maintenance The HygroMatik steam humidifier is easy to maintain. Neverthe- less, inadequate or improper maintenance can lead to opera- tional malfunctions. Perform regular maintenance to give your unit a long life span. Since steam and condensate hoses are also subject to wear they have to be checked regularly.

  • Page 48: Maintenance For Operation With Demineralized Water / Condensate

    Maintenance for Operation with Demineralized Water / Condensate Instructions for maintenance and cleaning intervals are based exclusively on typical, empirically determined values. Cycle Maintenance Task 4 Weeks after Visual check of electrical and mechanical Initial Operation connections. Visual check of water level control. Visual check of steam cylinder interior.

  • Page 49: Maintenance For Operation With Tap Water Or Partially Softened Water

    Part of this solid build-up is removed through periodic blow-downs and fresh tap water refills with the aid of the HygroMatik SUPER FLUSH flushing system. The SUPER-FLUSH system generates a whirlpool effect in the strainer basket, intensifying removal of calcium particles during blow-down.

  • Page 50: Access To Control Unit

    9.3 Access to Control Unit » Remove cover (or electric compartment cover) and lift display panel (A) out of its guide. » Turn display panel (see drawing) and hang display panel on the humidifier cabinet (B) by placing the two guide pins in the two front guides.
  • Page 51 » Remove cylinder base o-ring (13). » Lift strainer insert (12) out of the base using the two access holes on the side. » Remove all deposits from the coarse strainer. » Keep coarse strainer clean with mechanical utilities. » Check base for deposits and remove if necessary.

  • Page 52: Cleaning Steam Cylinder

    » Switch breaker back on. » Open water supply. » Switch on unit and check for leaks after 15-30 minutes of operation. If leakage occurs, switch off power supply and repair the leaks, following safety instructions for work on live components! 9.5 Cleaning Steam Cylinder Removal »...

  • Page 53: Cleaning Connection Hoses, Cylinder Base And Nozzle

    9.6 Cleaning connection hoses, cylinder base and nozzle All connection hoses should be free of deposits and in good con- ditions. Please check all connections of the cylinder base (11) for depos- its and remove if neccessary. When operating with partially softened water or tap water scale can be discharged with the steam flow and can settle in the noz- zle (3) that is in the steam hose adapter.

  • Page 54: Replacing Thermo Sensor (For Heater Element)

    using retainer clips. » To proceed further, follow the steps described above in section “Cleaning Coarse Strainer Cylinder Base.” 9.8 Replacing Thermo Sensor (for Heater Ele- ment) Removal » Close off water supply. » Drain steam cylinder (9) by setting main switch to Pos »...

  • Page 55: Cleaning Of The Control Cylinder

    O: Thermo Sensor P: Unlocking Button for Thermo Sensor Q: Seal R: Mounting Counternut Warning: Do not bend the capillary tube of the thermo sensor! Installation » Install heater element and thermo sensor. Do not screw the nut in too tightly! »...

  • Page 56: Unlocking Of A Released Thermo Sensor (For Heater Element)

    9.9 Unlocking of a Released Thermo Sensor (for heater element) If a thermo sensor (for heater element) has released due to a too high temperature the blue button (P) is on the same level as the top of its holder. Additional the control reports a failure „thermo sensor activated“.
  • Page 57 specified). » Open water supply. » Switch on unit and check for leaks after 15-30 minutes of operation. If leakage occurs, switch off power supply and repair the leaks, following safety instructions for work on live components! Page 57...

  • Page 58: Removing Inlet Solenoid Valve And Cleaning Fine Mesh Filter

    9.12 Removing Inlet Solenoid Valve and Clean- ing Fine Mesh Filter Removal » Close off water supply. » Drain steam cylinder (9) by setting main switch to Pos » Disconnect power supply and secure against restart (switch off control switch, remove main fuse and control fuse F1).

  • Page 59: Checking Cable Screw Connections, Heater Element Wires

    Installation » Place solenoid valve with seal in the hole in the unit cabinet. » Secure solenoid valve tightly with screws (I). » Attach fresh water connection (L). » Connect elecrical cable to the double solenoid valve. Take care to position correctly. »...

  • Page 60: Ec-Declaration Of Conformity

    10. EC-Declaration of Conformity Page 60...

  • Page 61: Spare Parts

    11. Spare Parts HL6 HL9 HL12 HL18 HL24 HL27 HL30 HL36 HL45 Article No. Description Cabinet B-2129001 Cabinet HL 6-27 B-2129003 Cabinet HL 30-45 E-2124008 Key for safety lock Steam Generation B-2205315 Cylinder compl. incl. 1 heater element 4,5 kW, 1 thermal sensor and terminal B-2205317 Cylinder compl.
  • Page 62 HL6 HL9 HL12 HL18 HL24 HL27 HL30 HL36 HL45 Article No. Description Steam generation with electrical supply 440V B-2205407 Cylinder compl. incl. 1 heater element 4,5 kW, 1 thermal sen sor and terminal B-2205409 Cylinder compl. incl. 1 heater element 6,75 kW , 1 thermal se nsor and teminal B-2205411 Cylinder compl.
  • Page 63 HL6 HL9 HL12 HL18 HL24 HL27 HL30 HL36 HL45 Article No. Description B-2304040 Mounting set for soleno id valve E-2604002 Hose, solenoid valve - cabinet E-2604002 Hose, solenoid valve - SuperFlush E-2604044 Buckling protection for hose, solenoid valve - cylinder base B-2504129 Control cylinder for water le vel, compl.
  • Page 64 HL6 HL9 HL12 HL18 HL24 HL27 HL30 HL36 HL45 Article No. Description Steam generation with electrical supply 600-690V B-2507041 Main conta ctor 20A, DILM17, Coil vo ltage 230VAC B-2507061 Main conta ctor 35A, DILM17, Coil vo ltage 230VAC E-2205130 Solid state relay 75A/690V, without heat sink, singl e phase E-2205100 Protection cap against contact without cutout E-2205102 Protection cap against contact with cutout E-2205116 heat sink (150 x 50) mm...

  • Page 65: Fax Form - Order For Spare Parts

    12. Fax Form - Order for spare parts Fax Form Please copy, fill in and fax to HygroMatik . +49(0)4193/895-31 Lise-Meitner-Str. 3 Fax.No 24558 Henstedt-Ulzburg Tel. +4904193/895-0 Order of spare parts unit type *______________ serial no.* ___________________ commission: ______________ order no.: __________________...

  • Page 66: Technical Specifications

    Net Weight [kg] Operating Weight [kg] Height [mm] Width [mm] Depth [mm] Water Supply HeaterLine Fully Demineralized Water / Cleaned Condensate / Partially Softened Water / Tap Water (different qualities) 1 to 10 bar (100 x 10 to 100 x 10...
  • Page 67 Technical Specifications HeaterLine HL for SPA HL6..-DS - HL45..-DS Type HL12 HL18 HL24 HL27 HL30 HL36 HL45 Steam Output [kg/h] Electrical Supply* 400V/3/N 50-60Hz Power Rating [kW] 13,5 18,0 20,3 22,5 27,0 33,8 Power Consumption [A]*** 11,3 16,9 19,5 29,3...

  • Page 68: Exploded View

    14. Exploded View Page 68...

  • Page 69: View Of Cabinet

    15. View of Cabinet Page 69...
