The 864 Cleanface GSR2 has several new features and characteristics that require special attention

during installation and set-up. Refer to the owner's manual for full details.

Accessing the Firebox

You will need to remove the screen on this fireplace to access the glass frame and firebox. Remove and

discard the two nuts used to secure the screen during shipping (see illustration below). Next, remove the

concealment cover and screen to access the glass frame.

Page 1 of 2

864 Cleanface GSR2 - Cheat Sheet

HINT FOR REPLACING THE SCREEN: Hold the screen at an

angle and insert the bottom slots first. Then pivot the screen

forward to engage the top hooks.

Remove and discard the two

nuts used to secure the

screen during shipping.

11/32" Wrench

Lift the screen up, pivot the top

forward, and remove from the

fireplace.

Remove the concealment

cover.

17601834

Printed 11/22/16
