Audrey Wheelbarrow
Assembly Instructions
Thank you for your purchase.
Please follow the instructions below for correct assembly.
A
B
C
bolts
nuts
shaft
x12
x4
x1
E
F
washer
allen key
x2
x1
Hardware Supplied
mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558
D
rim
x2
AGE RECOMMENDATION 12 months +
1
Advertisement
Related Manuals for Mocka Audrey Wheelbarrow
Summary of Contents for Mocka Audrey Wheelbarrow
- Page 1 Audrey Wheelbarrow Assembly Instructions Thank you for your purchase. Please follow the instructions below for correct assembly. bolts nuts shaft washer allen key Hardware Supplied AGE RECOMMENDATION 12 months + mocka.co.nz | mocka.com.au | PO BOX 6171, Maroochydore BC, QLD, 4558...
