TOOLS REQUIRED
• Adjustable wrench
• 3/8" socket ratchet/driver
• 8mm Socket Wrench
• PSD#2 screwdriver
• 7 mm hex socket wrench
• Phillips head screwdriver
• Flat-Head Screwdriver
• 5/32", 3/32", 1/8", 1/4" Allen wrenches
• 1/8" Drill bit and electric or hand drill
• Tape measure
• Pencil
• Wire cutters
• 1/4" Nut driver
• Level
• Torx T20, T25
WARNING
Plug into a grounded 3-prong outlet. Do not remove the ground prong. Do not use an adapter. Do not use an
extension cord. Failure to follow these instructions can result in death, fire, or electrical shock.
Do not, under any circumstances, cut or remove the third (ground) prong from the power cord. For personal
safety, this appliance must be properly grounded.
The power cord of this appliance is equipped with a
3-prong (grounding) plug which mates with a standard
3-prong (grounding) wall outlet to minimize the possibility
of electric shock hazard from this appliance.
Have the wall outlet and circuit checked by a qualified
electrician to make sure the outlet is properly grounded.
Where a standard 2-prong wall outlet is encountered, it
is your personal responsibility and obligation to have it
replaced with a properly grounded 3-prong wall outlet.
Do not use an adapter.
The refrigerator should always be plugged into its own
individual electrical outlet which has a voltage rating that
matches the rating plate.
AVERTISSEMENT
Branchez l'appareil dans une prise triple avec terre. Ne retirez pas la broche de terre. N'utilisez pas d'adaptateur.
cordon de rallonge. Le non-respect de ces instructions peut entraîner des risques d'incendies, des chocs électriques ou la mort.
ADVERTENCIA
Enchufe en un tomacorriente con conexión a tierra de 3 cables. No elimine el cable de conexión a tierra. No use un adaptador.
No use un prolongador. Si no se siguen estas instrucciones, se podrá producir la muerte, incendios o descargas eléctricas.
31-1000602 Rev. 0

Installation Instructions

ELECTRICAL SHOCK HAZARD
RISQUE DE CHOC ÉLECTRIQUE
RIESGO DE DESCARGAS ELÉCTRICAS
MATERIALS REQUIRED
• 1/4" O.D. compression nut and 2 ferrules (sleeves)
™
OR SmartConnect Refrigerator Tubing Kits
REFRIGERATOR LOCATION
• Do not install the refrigerator where the temperature will
go below 55°F (13°C). It will not run often enough to
maintain proper temperatures.
• Do not install the refrigerator where temperatures will
go above 100°F (37°C) . Iit will not perform properly.
• Do not install the refrigerator in a location exposed to
water (rain, etc.) or direct sunlight.
• Install it on a floor strong enough to support it fully
loaded.
A 115 Volt AC, 60 Hz, 15- or 20-amp fused, grounded
electrical supply is required. This provides the best
performance and also prevents overloading house wiring
circuits which could cause a fire hazard from overheated
wires.
Never unplug your refrigerator by pulling on the power
cord. Always grip plug firmly and pull straight out from
the outlet.
Immediately discontinue use of a damaged supply cord.
If the supply cord is damaged, it must be replaced by a
qualified service professional with an authorized service
part from the manufacturer.
When moving the refrigerator away from the wall, be
careful not to roll over or damage the power cord.
N'utilisez pas un
