Section 6: Electrical System
multi-stage battery charger to charge the house auxiliary and chassis batteries.
Refer to and follow safety information found in the manufacturer's troubleshooting guide
found in your warranty packet.
NOTE: The generator (diesel or gas powered) requires 12-volt power
from the house auxiliary batteries to start, and draws (diesel or gas) fuel
to operate from the chassis fuel tank. If the fuel level in the chassis fuel
tank drops to or below ¼ full, the generator will automatically shut "off" and
cannot be re-started until the fuel tank is filled to above ¼ full.

120-Volt Circuit Breakers

The 120-volt AC circuit breakers located inside the load center protect all 120-volt wiring
and components from circuit overloads and short circuits. Should a circuit overload or short
circuit occur the circuit breaker protecting the affected circuit will "trip" preventing the flow
of electricity through that circuit.
If a circuit breaker trips, shut off the appliance on that circuit (i.e., power converter, etc.)
and allow the circuit breaker to cool down for a brief period of time. After it cools down,
reset the circuit breaker by moving its lever "off" and then back to the "on" position. If the
circuit breaker re-trips or frequently trips, contact your dealer to have the electrical problem
diagnosed and repaired.
A circuit breaker identification label is permanently attached to the inside surface of the 120-
volt Load Center.
Circuit breakers and fuses will not offer complete protection of the electrical
system in the event of power surge or voltage spike.
Replacement
Only replace circuit breakers with those of the same specified type, voltage, and current rat-
ing. Never replace a circuit breaker with one listed at a higher amperage rating. Please
contact your dealer for repair assistance when replacing circuit breakers.
Maintenance
Replacement circuit breakers must be of the same voltage, amperage rating
and type. Never use a higher rated replacement circuit breaker; doing so may
cause a fire by overheating the RV wiring.
At the beginning of the camping season, inspect the circuit breakers and replace as needed.
Test by turning each circuit breaker "off" and back "on". Circuit breakers are wearable parts
and must be replaced as needed as part of your RV maintenance. If you have any questions,
contact your dealer.
A label is provided to explain the function of every 120-volt circuit breaker. This label is
located on or near the appropriate load center or sub-panel and must remain permanently
affixed to the recreation vehicle.
74
