Summary of Contents for Jayco Embark 2022

  • Page 1 2022 Owner’s Manual A subsidiary of Thor Industries, Inc. 0311088.2022...
  • Page 3 Change Of Address/Ownership Suggestions For Obtaining Service Obtaining Service For Separately Warranted Items Obtaining Service At Our Customer Service Facility Parts and Accessories 2022 Jayco Motorized Limited Warranty Section 2: Occupant Safety Secondary Means of Escape (Exit Window) Fire Safety Fire Extinguisher...
  • Page 4 Table of Contents Chassis Air Bags Hydraulic Leveling System Emergency Stopping Emergency Towing Front Axle Tire Alignment Wheel Lug Nuts/Wheel Liners Tires Tire Pressure Monitor System (TPMS) Changing A Tire Awnings (if so equipped) Section 5: Slideout Systems Electric Slide Room(s) Section 6: Electrical System The Electrical System In Case Of An Electrical Fire...
  • Page 5 Table of Contents Toilet (if so equipped) Section 9: Heating & Cooling Climate Control System Power Roof Vent (if so equipped) Heating System(s) Fireplace (if so equipped) Section 10: Appliances Microwave Cooking Safety Induction Cooktop (if so equipped) Micro Hood Refrigerator Portable Chest Cooler (if so equipped) Dishwasher (if so equipped)

  • Page 7: Section 1: Warranty & Service

    Section 1: Warranty & Service WARNING: Read all instructions in this manual and compo- nent manufacturer supplied information before using your RV. This manual has been provided by your recreational vehicle manufacturer for the sole pur- pose of providing instructions concerning the operation and maintenance of this recreational vehicle.
  • Page 8 Canada may differ to conform to Canadian Codes. Dealer Responsibility At the time of sale of the new recreation vehicle, your Jayco dealer is expected to: Deliver your recreation vehicle in the best condition possible. Your recreation ve- hicle must pass the dealer’s pre-delivery inspection (PDI), including all systems...
  • Page 9 (or any effect of the alterations) to any of the parts, components, systems or assemblies installed by Jayco. Jayco is not responsible for the safety or quality of design features, materials or workmanship of any alterations by such suppliers.

  • Page 10: Warranty Packet

    Canada. In addition, the club offers a variety of local and regional activities throughout the year. By belonging to the Jayco Travel Club, you will find new ways to enjoy your RV and make friends all across the country.

  • Page 11: Chassis Guide

    Section 1: Warranty & Service Chassis Guide Throughout this manual, frequent reference is made to the vehicle’s Chassis Guide. The Chassis Guide includes the owner’s manual provided by the manufacturer of the chassis on which this motorhome is built, warranty cards and/or registrations. It also includes pertinent information regarding the transmission, tires, etc.

  • Page 12: Reporting Safety Defects

    Section 1: Warranty & Service Indicates a potentially hazardous situation that, if not avoided, may result in death or serious injury. Reporting Safety Defects In the United States: If you believe that your recreation vehicle has an alleged defect which could cause a crash or cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA), in addition to notifying our Cus- tomer Service Department.

  • Page 13: Customer Responsibility

    Section 1: Warranty & Service Customer Responsibility It is important you read and understand all instructions and precautions before operating the recreation vehicle. Even if you are an experienced RV’er we encourage you to thoroughly read this Owner’s Manual, as well as the information contained in your Warranty Packet and Chassis Guide (motorized only).

  • Page 14: Obtaining Service For Separately Warranted Items

    Section 1: Warranty & Service Please be aware that all service shops require notification of any issues with their repairs within a specified time limit. Make sure you are familiar with their repair policies. Obtaining Service For Separately Warranted Items Your selling dealer is responsible for servicing your recreation vehicle before delivery, and has an interest in your continued satisfaction.
  • Page 15 HOME IS TITLED OR REGISTERED IN A BUSINESS NAME OR WHEN THE JAYCO IS SOLD IN CANADA. There is no warranty of any nature made by Jayco beyond that contained in this Limited Warranty. No person has authority to enlarge, amend or modify this Limited Warranty. The dealer is NOT Jayco’s agent.
  • Page 16 Jayco reserves the right to make changes in the design or material of its prod- ucts without incurring any obligation to incorporate such changes in any product previously manufactured.
  • Page 17 (1) you notify Jayco or an authorized dealer within 10 days of your discovery of a defect; AND (2) you deliver the Motor home to Jayco OR an authorized dealership at your cost and expense.
  • Page 18 The written warranty provided by the manufacturer of the component part is the direct and exclusive responsibility of that manufacturer). EVENTS DISCHARGING JAYCO FROM OBLIGATION UNDER WARRANTY: • Any rental, business or commercial use or purchase of the Motor home;...
  • Page 19 Jayco, your Warranty will be registered. The failure to submit this warranty registration to Jayco will not affect your rights under this limited warranty as long as you can present proof of purchase, however, it can cause delays in obtaining the remedies offered by this limited warranty, and it may adversely affect any servicing facility’s ability...
  • Page 20 Section 1: Warranty & Service Notes: Maintenance Record Table of Contents...

  • Page 21: Section 2: Occupant Safety

    Section 2: Occupant Safety Secondary Means of Escape (Exit Window) Your recreation vehicle has been equipped with a window(s) that serves as a secondary means of escape. The window(s) will allow a quick exit from the vehicle during an emer- gency if access to the main entrance door is not available.

  • Page 22: Fire Safety

    Section 2: Occupant Safety Lever style latch Remove the screen by pulling the red tab (upper right arrow). Pull the lever out from the sash clamps. Swing the lever out so it is positioned straight out from the win- dow. Push the lever (and window) out to open and exit the ve- hicle.

  • Page 23: Smoke Alarm

    Section 2: Occupant Safety Do not check the pressure, test or practice using the fire extinguisher by squeezing the trigger, even briefly. The fire extinguisher is not rechargeable or refillable. Once used, it will gradually lose pressure and will not be fully charged for use in an emergency.

  • Page 24: Combination Carbon Monoxide /Propane Alarm

    Section 2: Occupant Safety When the battery becomes weak, the alarm will “beep” about once a minute indicating a low battery. This warning should last for 30 days. You MUST replace the battery once the alarms low battery warning (beep) starts to assure continued protection. When the battery is removed from the alarm, the battery flag will pop up;...
  • Page 25 Section 2: Occupant Safety Do not cover or obstruct the carbon monoxide/propane alarm with any- thing that could prevent gas from entering the alarm. This alarm is not designed to detect smoke, fire or gases other than car- bon monoxide and propane. The carbon monoxide detector installed is intended for use in ordinary indoor locations of recreation vehicles.
  • Page 26 Section 2: Occupant Safety vehicle on a hot day, the chemicals used in its construction may be detected for months after the vehicle was constructed (for more information, refer to Sec. 2, Formaldehyde). What you should do if the alarm sounds Actuation of this detector indicates the presence of carbon monoxide which can kill you.
  • Page 27 Section 2: Occupant Safety Alarm features and functions Includes an 85db audible horn, two LEDs, and a SILENCE/TEST button. Alarm States Normal operation: The Green LED is ON steady. Red LED OFF, Audible horn OFF. Power OFF: Both LEDs and the audible horn will be OFF. Self Test: Green LED OFF, Red LED ON/Flashing, audible horn 4 chirps fol- lowed by constant beeps.

  • Page 28: Extended Or Full Time Usage

    Section 2: Occupant Safety NOTE: The carbon monoxide/propane alarm manufacturer strongly recommends replacement of the detector five years after the date of purchase. Formaldehyde Some components in the recreation vehicle contain formaldehyde-based adhesives that may release formaldehyde fumes into the air for an unknown period of time. Individuals who are allergic to formaldehyde gas fumes may experience irritation to eyes, ears, nose and throat.
  • Page 29 Section 2: Occupant Safety Condensation Condensation may cause dampness, mildew, mold, staining and, if allowed to continue, it may result in damage to the recreation vehicle (damage caused by condensation is not warrantable). It can also lead to mold or mildew issues, which could be a health hazard.
  • Page 30 Section 2: Occupant Safety Notes: Maintenance Record Table of Contents...

  • Page 31: Section 3: Pre-Travel Information

    Section 3: Pre-Travel Information Vehicle Labels Decals and data plates used throughout the motor home aid in its safe and efficient operation; others give service instructions. Read all decals, data and instruction plates before operat- ing your recreation vehicle. Any decal, data or instruction plate painted over, damaged or removed should be replaced.
  • Page 32 Section 3: Pre-Travel Information OCCC Label (Occupant and Cargo Carrying Capacity): The upper portion of this yellow label is federally required and indicates the total combined weight value of occupants and cargo that may be placed in or on your motor home as it was manufac- tured and weighed before leaving the factory.

  • Page 33: Loading Your Motor Home

    Section 3: Pre-Travel Information Loading Your Motor Home Never load the motorhome in excess of the GVWR or the GAWR for either axle. Overloading your motorhome may result in adverse handling characteristics and damage to the chassis. DO NOT EXCEED YOUR GVWR! This means you should weigh your vehicle as loaded for your normal travel to determine the actual weight.

  • Page 34: Weighing Your Motor Home

    Section 3: Pre-Travel Information White Ground Blue Electric Brakes Green Running lights Black House batteries charge line Stop & left turn Brown Stop & right turn Yellow Back up Lights The connector plug may build up corrosion with extended use. It should be cleaned peri- odically to insure good electrical contact.
  • Page 35 Section 3: Pre-Travel Information Dump the gray and black water holding tanks before traveling to avoid carry- ing unnecessary weight. Full tanks can affect your fuel consumption, and de- pending on tank location, can affect your vehicle handling characteristics. If you cannot immediately empty your holding tanks, reduce your vehicle speed until you reach a dumping station.
  • Page 36 Section 3: Pre-Travel Information Notes: Maintenance Record Table of Contents...

  • Page 37: Vehicle Operation

    Section 4: Vehicle Operation Vehicle Operation Your motor home will travel safely and comfortably at highway speed limits. However, it will take longer than a passenger automobile to reach that speed. Allow more time to go around the vehicle you are passing. Avoid situations that might require sudden momentum changes as the length of the motor home affects your ability to quickly cut back into traf- fic.

  • Page 38: Using The Rear Hitch

    Section 4: Vehicle Operation Using The Rear Hitch Do not install a frame equalizing type hitch on your motorhome. Towing will affect vehicle handling, durability and fuel economy. Exceeding any of the listed weight ratings will result in unacceptable overall vehicle performance. Your safety and satisfaction require proper use of correct equipment.
  • Page 39 Section 4: Vehicle Operation In addition, a separate supplemental braking system must be installed if the towed trailer or vehicle meets or exceeds the minimum weight determined by the chassis manufacturer (this minimum weight rating will vary by chassis and chassis manufacturer). Contact your dealer for assistance in determining whether a separate braking system is rec- ommended for your towing and traveling safety.

  • Page 40: Step Well Cover

    Section 4: Vehicle Operation Electric Trailer Brake Wiring Your motor home may also include electric trailer brake wiring to the 7-way trailer connec- tor at the rear of the RV for electric brakes. The customer must supply and install an electric trailer brake controller in the dash area to make use of the electric trailer brake system.

  • Page 41: Entrance Door

    Section 4: Vehicle Operation LOOK BEFORE ENTERING OR EXITING YOUR MOTORHOME! When opening the door from the outside, make sure you are not obstruct- ing the path of the entrance step. Step deployment takes approximately two seconds. Keep hands and fingers clear while extending or retracting. Look before you exit.

  • Page 42: Keyless Entry

    Section 4: Vehicle Operation The entrance screen door may be equipped with a slide panel that allows access to the en- trance door handle and locks. The entrance door may also be equipped with both a regular door lock and a dead bolt lock. Keys Several keys are provided when you purchase your vehicle.
  • Page 43 Section 4: Vehicle Operation Locate the yellow or white wires with spade termi- nals and a label identifying them as the Program Wires. Bend the paperclip, put one end into the spade ter- minal for the white wire, and the other end into the spade terminal for the yellow wire.
  • Page 44 Section 4: Vehicle Operation Secure Operation Enter your 5-digit Access Code, keypad will double beep to indicate secure operation. After entering an Access Code, the keypad is enabled for (5) seconds and the next button pressed will initiate a secure operation. Secure operations are: (1/2) button unlocks entry doors (3/4) button –...

  • Page 45: Seat Belts

    Section 4: Vehicle Operation Seat Belts Seat belts should always be worn by anyone who drives or rides in this vehicle. Never use one seat belt for more than one occupant. Never carry more people in the motor home than there are seat belts. Only seats equipped with seat belts are to be occupied while the vehicle is in motion.
  • Page 46 Section 4: Vehicle Operation ATC: Turns Automatic Traction Control On/Off. • STEERING WHEEL ICON: Activates/deactivates the EZ Drive • system. LAYERS ICON (Pages): Toggles between STANDARD, NAV • and CAMERAS screens on the dash. Tachometer/Speedometer is STANDARD. When pressed, the Tach/Speedo display shrinks, speedometer moves to the left side, tachometer moves to the right side.
  • Page 47 Section 4: Vehicle Operation Selecting Menus and Settings Rotate the knob on the Video Display Controller to bring up different menus. The different settings will appear in the lower left corner of the digital dash in the Selectable Display Area. Rotary Knob: Rotating CW / CCW scrolls for- ward and backward through available selections.
  • Page 48 Section 4: Vehicle Operation Center Panel Blind Spot Warning Indicators Gauges: Left Side Water Temperature Transmission Temp Oil Pressure Fuel Level Speedometer Park Brake Indicator Tachometer Gauges: Right Side Front Brake Air Pressure Rear Brake Air Pressure Fuel Gauge DEF level (Diesel Exhaust Fluid) Selectable Display Area Gear Indicator Right Panel...
  • Page 49 Section 4: Vehicle Operation Passenger Side Console Instrument Panel (top) Passenger Front Day Shade Passenger Side Day Shade USB Charge Ports Passenger Step Well Cover - Extend/Retract Passenger Side Console Instrument Panel (front) Porch Light Ceiling Light - Entrance Door Entrance Door Awning Light Cargo Compartment Lights Patio Awning - EXTEND...
  • Page 50 Section 4: Vehicle Operation Steering Wheel and Column Controls Left Control Pad Radio control buttons (arrows) These buttons cycle radio station tuning up or down. Cruise control function The electronic cruise controls consist of an on/off button, set button, cancel button and resume button. Refer to the Chassis Guide for detailed information on the cruise control operation.
  • Page 51 Section 4: Vehicle Operation Steering Wheel Tilt/Telescope Your motor home will have one of the following steering wheel adjustments: Manual The steering wheel can be adjusted by using the manual lever located on the left side of the steering column. To adjust the tilt of the wheel, pull the lever towards you, then push the wheel toward the dash or pull it toward you.
  • Page 52 Section 4: Vehicle Operation Docking lights stay on if they are activated with the rocker switch. The docking lights also can operated using the key fob (if so equipped) and will time out and turn off after 10 minutes. If your coach is equipped with the Passive Start system, the docking lights can also be turned ON and OFF using a button on the special key fob.

  • Page 53: Outside Rear View Mirrors

    Section 4: Vehicle Operation Outside Rearview Mirrors Adjust the outside rearview mirrors before driving. After adjusting the front driver’s seat, adjust the outside rearview mirrors to your driving preference. Have someone help you adjust the mirrors in the desired direction for maximum rear visibility before driving.
  • Page 54 Section 4: Vehicle Operation Additionally, the camera views can be displayed on any TV in the RV. The cameras double as surveillance cameras when the vehicle is parked. If your motor home has the alternate VDC controller, push the knob up- ward to scroll through the different dash screens.
  • Page 55 Section 4: Vehicle Operation Climate Control System (Dash) Your motor home has been equipped with an integrated heating / air con- ditioning system. It provides windshield defrost, heating and cooling for the front seat occupants only, and is not capable of heating and cooling the entire motor home.

  • Page 56: Campsite Hook-Up

    Section 4: Vehicle Operation A/C ON/OFF: Green button with the star icon next to it. Turns the air condition- ing On and Off. MAX A/C Air is drawn from the passenger compartment (re-circulated air) and discharged through the dash louvers. This position provides maximum cooling.

  • Page 57: Hydraulic Leveling System

    Section 4: Vehicle Operation Driving with partially filled air bags will create an unsafe environment and can damage your motor home. Refer to your Chassis Guide for more information on the air bags. Make sure the chassis air bags are completely filled before driving your motor home.
  • Page 58 Section 4: Vehicle Operation NOTE: The slideout room should be extended (with the air suspen- sion fully aired up) before leveling jacks are deployed. Wheels MUST be straight. When the coach is leveled, air bags are dumped of air which lowers the fenders below the tops of the wheels.
  • Page 59 Section 4: Vehicle Operation Retracting the Jacks: The Equalizer System provides the ability to retract the jacks using the ALL RETRACT button or the UP button for each individual jack. All jacks will automatically retract and return to stowed position when the ALL RETRACT button is pressed and released.
  • Page 60 Section 4: Vehicle Operation Helpful Hints The ALL RETRACT function is a timed event. Pressing ALL RETRACT will cause the pump to run in retract mode for 60 seconds (or 90 seconds, depending on your specific system). Your leveling system is a microprocessor-controlled system. Proper and adequate battery voltage and permanent chassis ground are essential.

  • Page 61: Emergency Stopping

    Section 4: Vehicle Operation Emergency Stopping Always carry road flares or reflective warning signs. Pull off the roadway as far as possible for emergency stopping. Turn ON your vehicle hazard warning flashers. If traveling at night, use three red warning indicators such as flares, reflectors or lanterns as required by the Uniform Vehicle Code and Model Traffic Ordinance as follows: Place the first warning indicator on the traffic side of the recreation vehicle, directed at the nearest approaching traffic.

  • Page 62: Wheel Lug Nuts/Wheel Liners

    Section 4: Vehicle Operation NOTE: Always have the alignment checked and adjusted by a qualified shop with the proper equipment to handle heavy vehicles. NOTE: A road test by the dealer should be included as part of the pre-delivery inspection. The dealer can check for and correct any steering problems before you take delivery.
  • Page 63 Section 4: Vehicle Operation Check and re-torque after the first 10, 25 and 50 miles (16, 40 and 80 kilometers). Thereafter, check and maintain the torque according to the listed torque values. Wheel Lugs If you suspect or notice the wheel stud bolts are cracked or broken, they must be replaced, along with adjacent bolts that have probably also been weakened due to the additional stress placed on them.

  • Page 64: Tire Pressure Monitor System (Tpms)

    Section 4: Vehicle Operation Tire wear should be checked frequently. Once a wear pattern becomes firmly established in a tire it is difficult to stop, even if the underlying cause is cor- rected. Tire pressure Failure to follow proper inflation guidelines may result in tire failure, which, under certain circumstances can cause loss of vehicle control or accidents that may result in property damage, bodily injury and/or death.

  • Page 65: Changing A Tire

    Section 4: Vehicle Operation TPMS sensors are installed and pre-programmed from the factory. TPMS Display The TPMS fault sensor is located in the lower left corner of the digital dash just above the selectable display area. The TPMS menu is located on the selectable display, which is accessed with the VDC con- troller.

  • Page 66: Awnings (If So Equipped)

    Section 4: Vehicle Operation Make sure the road service technician reads and is familiar with the Chassis Guide informa- tion regarding changing the tires. Make sure the wheel lug nuts have been tightened to the proper torque as outlined in your Chassis Guide. Awnings (if so equipped) Awning Care Keep your awnings clean and in good condition to prevent costly repairs.

  • Page 67: Section 5: Slideout Systems

    Section 5: Slideout Systems Electric Slide Room(s) The mechanical components of the slide out room(s) are gear driven and designed to work on 12 volts DC. Make sure the interior slideout room path and the slideout room itself is clear of people and objects before operating.
  • Page 68 Section 5: Slideout Systems If the slideout rooms will not extend or retract, contact Customer Service or a reputable dealer service facility. Do not attempt to service the slideout system yourself. Maintenance Record Table of Contents...

  • Page 69: Section 6: Electrical System

    Section 6: Electrical System The Electrical System The RV electrical system is comprised of two independent electrical systems. One operates off of 12-volt DC power and the other off of 120-volt 60hz AC power. All installations have been made in compliance with industry standards applicable on the date of manufacture. Because the electrical equipment and associated circuitry are engineered into a dedicated system specific to your RV, do not make unauthorized changes or add fixed appliances to it.

  • Page 70: Controls And Switches

    Section 6: Electrical System Controls and Switches Your motor home is equipped with various switches and controls that allow you to operate and monitor the systems in your motor home. Information on these controls and their location will be provided throughout this manual. Additional information on the various components can be found in the component manu- facturer’s user guide.
  • Page 71 Section 6: Electrical System NOTE: The touchscreen system may require periodic updates and/or downloads. The age of your device or hardware configuration changes may prevent your device from accepting or installing a new system update. If you receive notification that an upgrade is available, please contact Fire Fly Integrations for further information (http://www.fireflyint.com).

  • Page 72: Testing The Campsite Power Connection

    Section 6: Electrical System and 30A service. The status window illuminates each of the appliances that it controls. If the indicator is not lit, that means the PCS system has temporarily removed power to prevent the circuit breaker from tripping. The system has the ability to turn off the following electrical items: Electric Water Heater.
  • Page 73 Section 6: Electrical System Connecting the Power Cord Always test the external power source (i.e., the campsite power receptacle or electrical box) with a ground monitor before connecting your power cord to it. If the ground monitor indi- cates ‘reverse polarity’ or an ‘open ground’ DO NOT connect the power cord. To help prevent power surges from damaging the connected loads, please follow these in- structions when hooking up to the external power source: Turn off the load center main 120-volt circuit breaker.
  • Page 74 Section 6: Electrical System Inverter/Charger Your motor home may have multiple 12-volt DC to 120-volt AC inverter/charger(s) installed that are designed to temporarily run selected 120-volt appliances from house auxiliary bat- tery power. The inverter/charger(s) is located between the chassis frame rails in the cargo storage area, the controls are operated from the touchscreen.

  • Page 75: Volt Dc System

    Section 6: Electrical System NOTE: Leaving the inverter/charger in the “on” position when the motor home is in prolonged storage (no 120-volt AC shore power connected) will drain the auxiliary batteries even though all 120-volt AC appliances are turned off. Inverter/Charger fault conditions Certain fault conditions will cause the inverter to shut down.
  • Page 76 Section 6: Electrical System 12-Volt Fuse Panel Replacement fuses must be of the same voltage, amperage rating and type. Never use a higher rated replacement fuse; doing so may cause a fire by overheating the RV wiring. The 12-volt fuse panel is labeled to indicate fuse sizes, positions and the components pow- ered.
  • Page 77 Section 6: Electrical System Batteries Do not store anything inside the battery compartment(s) or near the batteries that could touch the battery or battery cable terminals. Contact with the battery or battery cable terminals could cause an electrical short circuit, discharge the batteries, or start an electrical fire. Keep sparks, cigarettes and flames away from the batteries as the hydrogen gas they create may explode.
  • Page 78 Section 6: Electrical System of time, they will become deeply discharged. Permanent battery damage will occur after repeated deep discharge cycles. Battery Reserve Capacity Typically, a four battery bank of 6-volt CG-2 deep cycle batteries connected in a series/ parallel arrangement to create 12-volts, has a 75 amp discharge rate reserve capacity (RC) rating of around 420 minutes.
  • Page 79 Section 6: Electrical System electrical system service. Certain models will not include the “HOUSE” power switch. NOTE: The combination carbon monoxide/propane alarm is connected to a constant 12-volt power source. The carbon monoxide/propane alarm remains operational when the battery disconnect solenoid switch, or “main power switch,”...

  • Page 80: Volt Circuit Breakers

    Section 6: Electrical System multi-stage battery charger to charge the house auxiliary and chassis batteries. Refer to and follow safety information found in the manufacturer’s troubleshooting guide found in your warranty packet. NOTE: The generator (diesel or gas powered) requires 12-volt power from the house auxiliary batteries to start, and draws (diesel or gas) fuel to operate from the chassis fuel tank.

  • Page 81: Approximate Electrical Load Ratings

    Section 6: Electrical System Approximate Electrical Load Ratings 12 VOLT SYSTEM Exterior Entertainment Center 5-7 AMPS 1.5 AMPS Furnace 12.0 AMPS Generator Start 95.0 AMPS* Illuminated Switch .125 AMP Inverter variable Leveling System 95.0 AMPS* LP Detector .125 AMP Light; LED 1.7 AMPS Light;...
  • Page 82 Section 6: Electrical System 120-Volt 50 AMP AC Electric System (if so equipped) The 50 amp 120-volt 60hz AC electrical system can be powered by an outside 120/240-volt 60hz utility service like those commonly found in campgrounds or by 120/240-volt 60hz generator power.
  • Page 83 Section 6: Electrical System The shore power cord is designed to continuously carry the 50-amp current flow required to power each leg of the electrical system. It also creates a critical ground connection between the vehicle electrical system and the campground shore power receptacle. Always test the external power source (i.e., the campsite power receptacle or electrical box) with a ground monitor before connecting your power cord to it.
  • Page 84 Section 6: Electrical System CARBON MONOXIDE IS DEADLY! Do not run the generator when your motor home is indoors or in a confined space. DO NOT use the AGS AUTO ON or QUIET ON modes (if so equipped) when your motor home is indoors or in a confined space. Asphyxiation or carbon monoxide poisoning hazards exist whenever genera- tor exhaust gasses can accumulate.

  • Page 85: Starting The Generator

    Section 6: Electrical System Excessive usage can overheat and damage the generator starter motor. Do not engage the starter motor for more than 20 seconds at a time. If the generator does not start after the first attempt, wait at least two minutes before beginning another start sequence.
  • Page 86 Section 6: Electrical System or factory pre-selected parameters. The AGS Start section or the Touch Screen User Guide (in your warranty packet) will give detailed instructions about Automatic Generator Start depending on your model. Generator Slide Tray The generator is mounted on a manual slide tray below the windshield at the front of the motor home.

  • Page 87: Replacing Light Bulbs

    Section 6: Electrical System Maintenance Clean the solar panel upper surface regularly using a soft cloth or sponge with water and a mild detergent. Do not use harsh chemicals or abrasive brushes that might damage the panels’ upper translucent surface. Solar Panel Battery Monitor The solar panel battery monitor is typically located in the pas- senger side overhead entry door control panel.
  • Page 88 Section 6: Electrical System Notes: Maintenance Record Table of Contents...
  • Page 89 Section 7: Fuel & Propane System Diesel Fuel and Fill It is critical to understand the danger associated with fuel. Take time to become educated about the properties of fuel and use it safely. Automotive fuels can cause serious injury or death if misused or mishandled. If you have further questions, consult your dealer or Customer Service for assistance.

  • Page 90: Fuel Safety

    Section 7: Fuel & Propane System NOTE: If your motor home is equipped with an Aqua Hot Heating sys- tem, it may be fueled the chassis diesel tank(s). If fueled from the chassis diesel tank(s) the fuel consumption of this system should be considered when planning your fuel supply to insure you will have adequate fuel to run your system.

  • Page 91: Exhaust Gas Fumes

    Section 7: Fuel & Propane System Remove the fuel fill cap by slowly turning it counter- clockwise, waiting for any “hiss” noise to stop, and then unscrew the cap all the way. To close the fuel fill cap, securely turn the cap clockwise until you hear clicking sounds.
  • Page 92 Section 7: Fuel & Propane System Propane cylinders should not be placed or stored inside the vehicle. LP-gas cylinders are equipped with safety devices that relieve pressure by discharging gas into the atmosphere. The propane fuel system is comprised of numerous components such as the propane con- tainer, hoses, propane gas regulator, piping and copper tubing to each appliance.
  • Page 93 Section 7: Fuel & Propane System NOTE: Tanks are to be installed, fueled and maintained in accordance to State and Local codes, rules, regulations or laws. Propane expands 1½ percent for every ten degrees of increase in temperature. It is im- perative to leave sufficient space inside the container to allow for natural expansion of gas during warmer weather.
  • Page 94 Section 7: Fuel & Propane System Refer to your Warranty Packet for more information on the LP gas system components. Propane Regulator Propane regulators must always be installed with the regulator vent facing downward. Regulators that are not located in baggage compartments have been equipped with a protective cover.

  • Page 95: Propane Use And Safety

    Section 7: Fuel & Propane System Propane Use and Safety Propane is a colorless and odorless gas that, in the lique- fied state, resembles water. An odorant (usually a sulfur compound) is added as a warning agent. If you smell propane within the vehicle, quickly and carefully per- form the procedure listed on the propane system label.
  • Page 96 Section 7: Fuel & Propane System tally exhausted. Using one cylinder until it is empty and then using the second cylinder will allow you to fill the empty cylinder at your convenience without running out of propane. Cooking With Propane Gas Do not turn gas range burner controls to ON and allow gas to escape before lighting.
  • Page 97 Section 7: Fuel & Propane System Traveling With Propane NOTE: Some states prohibit propane appliance operation during travel, especially in underground tunnels. Know the laws for the areas where you travel. Use care when fueling your motor fuel tanks and/or propane containers.
  • Page 98 Section 7: Fuel & Propane System Notes: Maintenance Record Table of Contents...

  • Page 99: Plumbing System

    Section 8: Plumbing System Plumbing System There are two different water systems in your recreation vehicle: The fresh water system consists of the fresh water holding tank, faucets and con- nections, water pump, outside shower assembly (if so equipped), water heater, tub/ shower, and water purification system (if so equipped).

  • Page 100: Fresh Water System

    Section 8: Plumbing System Fresh Water System All water contains contaminant and mineral particles that can cause fresh water system odors. Untreated well water is a major source of water system odors. The fresh water (po- table water) system needs periodic sanitization to take care of all the components in the plumbing system to discourage the growth of bacteria and other organisms that can con- taminate the water supply.
  • Page 101 Section 8: Plumbing System To fill the fresh water tank using the “fresh water inlet” (located in the utility center). Make sure the water tank drain, and hot & cold water lines (faucets) are closed. Remove the fresh water connection inlet plug and connect the short hose on the utility center to the fresh water connection inlet.
  • Page 102 Section 8: Plumbing System NOTE: This method of filling the water tank is NOT recommended if filtered water is required. However, if you fill the tank with unfiltered water, all water from the fresh water tank goes through the whole house canister filter.
  • Page 103 Section 8: Plumbing System Do not allow water in the canister housing to freeze. Remove the cartridge filter before using anti-freeze to winterize the sys- tem or chlorine solution to sanitize the system. Flush filter canister thoroughly before it is put back into service after winterizing or sanitizing.
  • Page 104 Section 8: Plumbing System rification system manufacturer has supplied a (reusable) plastic bypass hose with fittings on either end that is designed to replace the water filter cartridge when the motor home is being winterized or sanitized. Store the hose when it is not in use. Do not allow water to freeze in the filter.
  • Page 105 Section 8: Plumbing System Exterior Docking Center When using the fresh water system, always use a non-toxic drinking water hose dedicated only to supplying fresh water. To prevent contamination, keep the drinking water hose from coming into contact with the ground. Install the city water connection inlet cap when the fresh water connection is not being used.
  • Page 106 Section 8: Plumbing System Never leave the motor home unattended while filling the fresh water system. Canister water filter Outside shower and quick disconnect hose City Water / Tank Fill Valve Pump Switch Macerator ON/OFF switch Black Tank Flush inlet (See Black Tank Flush) Fresh Water Connection inlet Macerator hose and dump connector Fresh Water Connections...
  • Page 107 Section 8: Plumbing System Sanitizing the Plumbing System When to sanitize: When your motor home is new. At the beginning and end of each season. When the water system becomes contaminated or every three months of use. How to sanitize: Level the motor home and drain the fresh water system (see Draining the Fresh Water System).
  • Page 108 Section 8: Plumbing System When the water tank is full: Method 1: Remove the water hose and replace the cap on the water tank. Method 2: Shut off pressurized water source, disconnect water source, and remove the hose from the City Water inlet. Turn off power to the water heater.
  • Page 109 Section 8: Plumbing System Re-flush the system with the vinegar solution through the faucets (steps 11 to 13) until chlo- rine smell is gone. Then flush the system again with fresh water. ONLY after the vinegar solution has been flushed out of the lines with fresh water, replace the water filter and set the water heater bypass valves back to the normal position (hot &...
  • Page 110 Section 8: Plumbing System Winterizing with antifreeze This method adds antifreeze to the water lines for freeze protection for temperatures 32°F (0°C) and below. A second person will make this job easier. Close all the faucets in the coach (including outside shower). Attach the shower hose to the outside shower quick connector.
  • Page 111 Section 8: Plumbing System 13. Wipe the antifreeze out of the sinks, shower, and toilet using a soft, dry cloth. To De-Winterize the Fresh Water System Close the fresh water drain valve. Fill the fresh water tank with fresh water and rinse the RV antifreeze from each faucet or appliance that was protected with the RV antifreeze.

  • Page 112: Water Heater

    Section 8: Plumbing System • A pressurized water source must be connected to the RV and turned ON. • Check the tank monitor to see how much fresh water is in the tank. • Turn the lever on the Shower Miser to bypass the showerhead (OFF). •...
  • Page 113 Section 8: Plumbing System NOTE: Water heaters in certain models will ONLY have a single LP Gas water heater switch. These units will not heat water electrically. Water Heater Bypass Use the factory installed water heater bypass, available in most floor plans, to avoid filling the entire water heater with RV antifreeze.

  • Page 114: Bathroom Tub / Shower

    Section 8: Plumbing System drained to prevent damage from freezing. Damage to the water heater caused by freezing is not warrantable. It is recommended the water heater be drained and bypassed during the winterization process, particularly if introducing RV antifreeze into the plumbing sys- tem.

  • Page 115: Black/Grey Water System And Tanks

    Section 8: Plumbing System The shower faucet may include a vacuum breaker for the shower. There are two purposes for this breaker: To prevent siphoning water through the hose from another fixture. To prevent water from being retained in the hose. The showerhead DOES NOT have a complete shut-off valve (the complete shut-off is at the faucet).
  • Page 116 Section 8: Plumbing System On some models, the vent pipe may be part of the drainage system referred to as a “wet vent” where water flows downward as air flows upward in the same pipe. Some models are equipped with a side vent system. On these models this label will be next to the termi- nation valve.
  • Page 117 Section 8: Plumbing System Macerator Pump System Your motor home is equipped with a macerator pump system used to discharge waste from the gray and black waste tank. The system has a 1-1/2-inch diameter flexible hose that runs from the pump and attaches to a separate compartment on the exterior of the motor home. Not all models are equipped with an external storage compartment.
  • Page 118 Section 8: Plumbing System When tank is empty, turn the macerator power switch OFF. Close the gray tank drain valve. Unhook the dump connector, rinse it out and replace the hose and connector back into the storage compartment. The black tank flush inlet can also be used with this system (refer to the Black Tank Flush section).

  • Page 119: Black Tank Flush (If So Equipped)

    Section 8: Plumbing System Black Tank Flush (if so equipped) The black tank flush (no fuss flush) inlet is typically located on the utility center panel (if so equipped) labeled as “Tank Flush”. For models not equipped with a utility center, the inlet is located on the side of the recreation vehicle.
  • Page 120 Section 8: Plumbing System It is important to prevent solid waste buildup. Follow the toilet manu- facturer’s recommended instructions each time after emptying the black water holding tank. To help prevent toilet blockage, always use RV grade single-ply toilet pa- per.

  • Page 121: Toilet (If So Equipped)

    Section 8: Plumbing System Winterizing Use only propylene glycol based, non-toxic antifreeze when storing the toilet dur- ing freezing conditions. Never us automotive antifreeze or windshield washer solvent to winterize. Make sure that both the entire supply and discharge systems are thoroughly win- terized to ensure complete protection for your system.
  • Page 122 Section 8: Plumbing System Notes: Maintenance Record Table of Contents...

  • Page 123: Section 9: Heating & Cooling

    Section 9: Heating & Cooling Climate Control System All controls for the heating/cooling climate control system are incorporated into thetouch screen system. For specific operating instructions for heating/cooling controls, refer to the- touch screen user guide included in your warranty packet or online at http://www.fireflyint.

  • Page 124: Heating System(S)

    Section 9: Heating & Cooling Control pad (if so equipped) The attic fan may be controlled by a control pad. The dome can be raised or lowered with the UP/DOWN buttons, and the speed of the fan is controlled by the ARROW buttons. It is also equipped with a rain sensor that will close the vent automatically when it rains.

  • Page 125: Section 10: Appliances

    Section 10: Appliances Microwave To prevent damage, remove the turntable from the microwave when trav- eling. Make sure you are connected to a 120-volt power source. Never use the microwave cavity for storage. The microwave cavity should always be empty when not in use. For details on operation, cleaning and safety information, refer to the manufacturer’s user guide.
  • Page 126 Section 10: Appliances Cooking With Propane (if so equipped) See the Propane System Section for important safety instructions. Refer to the manufactur- er’s owner’s manual for detailed operating and safety instructions for all propane appliances. Induction Cooktop (if so equipped) Induction cooktops are more efficient than gas or electric cooktops.
  • Page 127 Section 10: Appliances recreational vehicle. Anytime the stove inside the recreational vehicle is being used, this flap MUST be un- snapped and the range hood turned ON to vent fumes outside the vehicle. Refrigerator NOTE: Make sure you are connected to a 120-volt power source. The refrigerator is not intended for quick freezing or cooling.
  • Page 128 Section 10: Appliances Use a vacuum cleaner with a soft brush to clean the grille, the open areas behind the grille and the front surface area of the condenser. Replace the base grille when finished. Cleaning the Exterior Painted metal exteriors: wash with a clean sponge or soft cloth and a mild detergent in warm water.
  • Page 129 Section 10: Appliances Do not allow frost to build up on the inside of the cooler. To defrost, remove the contents of the cooler, switch off the device and leave the cover open. Wipe off any water with a clean cloth. Allow hot food to cool down first before you place it into the cooler.
  • Page 130 Section 10: Appliances Child Lock Disables all buttons and locks the drawer closed. ACTIVATE: press and hold the button with the 5 pointed star (STAR). Hold the STAR but- ton until you hear 2 tones and the lock indicator will light up. DEACTIVATE: (If the drawer is open) Press and hold the STAR button until you hear a tone.
  • Page 131 Section 10: Appliances Central Vacuum System (if so equipped) Central Vacuum System The following is an overview of the central vacuum system operation. For detailed operat- ing and safety instructions, refer to the manufacturer’s user guide. The central vacuum system installed cleans virtually any surface with no electric cords and has a variety of attachments for many cleaning needs.
  • Page 132 Section 10: Appliances Notes: Maintenance Record Table of Contents...
  • Page 133 Section 11: Electronics Antenna/Satellite System(s) Your motor home may be equipped with one or more of the following: Satellite TV Antenna (if so equipped) The stationary and/or in-motion satellite TV antenna enables you to toggle between satel- lites while stationary or in-motion using a remote control (if you subscribe to multi-satellite programming).
  • Page 134 Section 11: Electronics Recovery from Signal Interruption While traveling, the signal will be interrupted when the line of sight to the satellite is blocked. Signal is acquired again after line of sight is restored. If signal is interrupted for more than 15 seconds, the system automatically enters the search routine. The length of time for the TV picture to recover depends on the receiver model you are using.
  • Page 135 Section 11: Electronics Satellite Dish (if so equipped) The following is an overview of the automatic multi satellite TV antenna operation. For detailed operating instructions, including receiver set up, refer to the manufacturer’s user guide. When you press “POWER,” the antenna will automatically begin searching for satellites. The instructions assume that the antenna is already in the stowed position.
  • Page 136 Section 11: Electronics Emergency Power Off The antenna comes with an emergency power off feature. To activate it, press and hold “POWER” and then press “SELECT” while still holding “POWER”. The antenna will stop and turn off. If the emergency power off feature is used, the antenna may not be in a safe position for travel.
  • Page 137 Section 11: Electronics A. On/Off LED: Green LED lights when antenna amplifier is turned on and system is in Antenna Mode. On/Off Button: Used to turn the antenna on and off. When turned ON it is in Antenna Mode and will receive Over-The-Air (OTA) signals.
  • Page 138 Section 11: Electronics Troubleshooting If the readout displays “HS” (in manual mode), the antenna has reached the operational limit and needs to rotate the other direction. Pressing the Search and Counter Clockwise Rotate button at the same time will reset the system.
  • Page 139 Section 11: Electronics You can download the Winegard TV Signal Finder app for your IPhone or Android device from either Google Play Store or Apple App Store. This app will show you all TV signals in your area and the direction to point your antenna to receive the OTA signals.
  • Page 140 Section 11: Electronics User Menu for Manual Operation The interface includes a user menu for some advanced features. The options most com- monly used are the ability to change the dish type, check software/hardware versions, change desired satellite configuration, or manually move the dish. Improper use of the user menu could cause damage to the antenna and/or ve- hicle.

  • Page 141: Exterior Entertainment Center (If So Equipped)

    Section 11: Electronics Exterior Entertainment Center (if so equipped) The exterior entertainment center is located on the curbside of the unit. You can access the entertainment center by opening the exterior cargo door to the stationary open position. Refer to the individual component manufacturer’s information for detailed operating in- structions.
  • Page 142 Section 11: Electronics Notes: Maintenance Record Table of Contents...

  • Page 143: Cleaning The Interior

    Section 12: Interior Cleaning The Interior To keep the value of your recreation vehicle, perform regular maintenance using the proper materials and procedures. Using the wrong cleaner may result in damage to the surfaces in your vehicle. Check with the manufacturer’s information for the recommended cleaning agent.
  • Page 144 Section 12: Interior Fill a spray bottle with water and a tiny amount of soap. Then spray a lint-free towel with the mixture and use the towel to wipe down each slat. While cleaning, try not to bend the slats. They can also be soaked in a bathtub to loosen up any debris so the slats can be wiped down easily.
  • Page 145 Section 12: Interior NOTE: Oil based soaps and cleaners are not recommended. No abrasive cleaners or alcohol cleansers should be used. If other cleaner solutions are used, first try on a spot in an inconspicuous area. Sofa and Dinette Always use seatbelts if sitting in the sofa or dinette while the motor home is in transit Your motor home may be equipped with one of the following sofa styles.

  • Page 146: Pantry Or Hutch (If So Equipped)

    Section 12: Interior Hold the table top at an angle (A). Push the table top back toward the wall. Bracket should latch, put the table top to a level position. Free Standing Dinette Chairs (if so equipped) Two free standing chairs and two folding chairs are included in the free standing table/chair package.
  • Page 147 Section 12: Interior to the countertop manufacturer’s user guide. Laminate Countertops (if so equipped) Glass rings, food spills, water spots and smudges usually wipe off with a damp sponge. Stubborn stains can be removed with a general-purpose spray cleaner. Some stains can be removed by squeezing fresh lemon juice over the stain and allowing the juice to soak for ap- proximately forty-five minutes.

  • Page 148: Ceiling Fabric

    Section 12: Interior Flooring Carpet Vacuum your carpet regularly. It is important to remove loose soil and debris while it is on the surface. Heavily traveled areas (i.e., walkways, areas in front of the furniture) may be protected with small throw rugs to prolong the life of the carpet. Prompt attention to spots and spills is essential.

  • Page 149: Bed Storage

    Section 12: Interior Power Window Shades (if so equipped) Power day shades have been installed for the windshield area of your motor home. To extend the shades, locate the appropriate switch and momentarily press the down arrow on the switch. To retract the shade, momentarily press the up arrow of the switch. Pressing the down or up arrow on the switch a second time will stop shade operation.
  • Page 150 Section 12: Interior Put the end of the rod in the bracket under the bed platform. To lower the platform, release the prop rod from the bracket under the bed plat- form, re-attach the prop rod to the holder on the bed base, Lower the platform slowly until closed.
  • Page 151 Section 12: Interior There should be no people, pets or objects on or below the bunk while raising or lowering it Never ride on the bunk while the vehicle is in motion. Exercise extreme care when entering or exiting the bunk bed and using the ladder Do not allow horseplay on the bed and prohibit jumping on the bed.
  • Page 152 Section 12: Interior Bathroom Water Heater Switches Maintenance Record Table of Contents...
  • Page 153 Section 13: Exterior Cleaning The Diamond Shield Surface Your motor home is equipped with a protective Diamond Shield surface located on the front lower cap area, hood edges, generator door, under the entry door grab handle and door lock. When cleaning the surface, do not use harsh or abrasive cleaners or detergents. The manu- facturer of the Diamond Shield surface does not recommend the use of any of the dry wash types of cleaners as they are intended for non-porous surfaces, and paint protection films are a porous material.
  • Page 154 Section 13: Exterior Engine and Generator Compartment Access Do not operate the motor home unless the engine hood, engine access cover, and generator compartment hood are securely closed and locked. Keep people and pets clear of the rear of the coach while operating the engine compartment door.
  • Page 155 Section 13: Exterior Sealants To check the exterior sidewall sealants, use a stepladder placed safely along- side the vehicle. Do not prop a ladder against the body of the RV as it may damage the exterior finish. Sealants perform a very important function and should be inspected closely and regularly maintained.
  • Page 156 Section 13: Exterior Notes: Maintenance Record Table of Contents...

  • Page 157: Section 14: Travel/Camping/Storage Checklists

    Section 14: Travel/Camping/Storage Checklists Travel Checklist Following is a preliminary list of items that need to be checked before leaving your home or campsite. This is a general list, which you may want to customize as you determine your own needs. Refer to your Chassis Guide for information on chassis pre-trip inspections and maintenance.

  • Page 158: Motor Home Storage

    Section 14: Travel/Camping/Storage Checklists Before leaving the campsite: Check the area under the motor home after overnight parking and look for fuel, water, oil or other fluid leaks. If leaks are detected, find the cause and correct it immediately. Turn off propane tanks (if so equipped). Empty black and gray holding tank, rinse as needed.
  • Page 159 Section 14: Travel/Camping/Storage Checklists Drain and flush all holding tanks (fresh water, gray water, black water and/or hot water tanks). Adding fuel stabilizer to the generator will aid in preventing condensation and fuel varnishing. Turn OFF the motor home 12-volt battery disconnect switch. Turn OFF the inverter mode at remote.
  • Page 160 Section 14: Travel/Camping/Storage Checklists Zone 2 • Middle A/C on “cool” Middle heat pump on heat “electric” In-floor heat, on heat “gas” Zone 3 • Rear A/C on “cool” Rear heat pump on heat “electric” Heat exchangers – at rear wall and under lavatory sink on heat “gas” Basement –...

  • Page 161: Featured Components Quick Reference Chart

    Your recreation vehicle may be equipped with some of the items listed below. This is a partial listing and it is not intended to cover all components. All information is the latest available at the time of publication. Jayco reserves the right to change any of the following information without notice.
  • Page 162 Section 15: Additional Information www.airxcel.com/coleman- Thermostat Coleman-Mach mach Toilet Thetford Corp. www.thetford.com Water Heater, Tank DSI Atwood Greenbrier www.atwoodmobile.com Water Heater, Tankless Girard Systems www.greenrvproducts.com Water Pump, 12V Shurflo East www.shurflo.com Maintenance Record Table of Contents...

  • Page 163: Vehicle Maintenance Record

    Section 15: Additional Information Vehicle Maintenance Record Make: Model: Model Year: Vehicle Serial#: Engine: Engine Serial#: Serv i ce P e r f o r m e d Mileage Work Performed Notes Date Maintenance Record Table of Contents...
  • Page 164 Section 15: Additional Information Notes: Maintenance Record Table of Contents...
  • Page 165 Section 15: Additional Information Jayco Ownership Notification Fax Form To: (800) 825-7876 ATTENTION! Federal record keeping laws require that we maintain a file of owners of our product. Your cooperation in filling out this from will be appreciated. □ Change of Owner □Transfer of Limited Warranty...

Table of Contents
