Three Piece Ball Valve
AC-305MF User Manual
English Version
Use for company in Europe who will place the product on the market, please
amend which necessary.
PREPARED BY
REVIEWED BY
APPROVED BY
KLINGER Denmark A/S | Nyager 12-14 | DK-2605 Broendby | +45 43 64 66 11 | www.klinger.dk
Document No:
Date:
2021/06/22
Version:
AC-305MF Series
PED Category I, II
1.0
DATE
DATE
DATE
Advertisement
Table of Contents
Related Manuals for KLINGER AC-305MF
Summary of Contents for KLINGER AC-305MF
- Page 1 Use for company in Europe who will place the product on the market, please amend which necessary. Document No: Date: 2021/06/22 Version: PREPARED BY DATE REVIEWED BY DATE APPROVED BY DATE KLINGER Denmark A/S | Nyager 12-14 | DK-2605 Broendby | +45 43 64 66 11 | www.klinger.dk...
- Page 2 Page- 4 Delivery Condition and Storage Page- 6 Page- 6~8 Installation and Operation Maintenance Page-9~11 Torque Data Page-11 Troubleshooting Page-12 Page-12 Corrosion Data KLINGER Denmark A/S | Nyager 12-14 | DK-2605 Broendby | +45 43 64 66 11 | www.klinger.dk...
-
Page 3: General Precautions
API-607 approval. Contact to the valve distributor or manufacturer for details. f. Liquids with high fluid velocity: KLINGER Denmark A/S | Nyager 12-14 | DK-2605 Broendby | +45 43 64 66 11 | www.klinger.dk... - Page 4 Declaration of conformity or/and in this user manual. k. Lock design on the handle to avoid the valve operated by non-related people is optional requested by the user. KLINGER Denmark A/S | Nyager 12-14 | DK-2605 Broendby | +45 43 64 66 11 | www.klinger.dk...
-
Page 5: Product Description
No CE Marking Category I Category II DN 8, 10, 15, DN 32, 40, 50, AC-305MF 20, 25 65, 80,100 2.3 Common dimension KLINGER Denmark A/S | Nyager 12-14 | DK-2605 Broendby | +45 43 64 66 11 | www.klinger.dk... -
Page 6: Design Specification
Followings are the general rating charts for non-shock fluid service for floating ball valves distinguished by sizes and seating materials, please refer to section 1, General precaution. KLINGER Denmark A/S | Nyager 12-14 | DK-2605 Broendby | +45 43 64 66 11 | www.klinger.dk... -
Page 7: Flow Characteristics
For cleaning operation, first step is put the valve bore perpendicular to the ground and KLINGER Denmark A/S | Nyager 12-14 | DK-2605 Broendby | +45 43 64 66 11 | www.klinger.dk... - Page 8 Pipe Connector being engaged by the male pipe thread; fully make up pipe joint. (See Figure 1). Complete KLINGER Denmark A/S | Nyager 12-14 | DK-2605 Broendby | +45 43 64 66 11 | www.klinger.dk...
-
Page 9: Operation
Following with the fig., showing how to access the position of ball valve. OPEN CLOSE KLINGER Denmark A/S | Nyager 12-14 | DK-2605 Broendby | +45 43 64 66 11 | www.klinger.dk... -
Page 10: Maintenance
The right position for store the valve is put the open end on to the ground. This procedure is protecting the surface of the ball. KLINGER Denmark A/S | Nyager 12-14 | DK-2605 Broendby | +45 43 64 66 11 | www.klinger.dk... - Page 11 (PTFE or RTFE). The mark from press or fine scrape is happen in an abnormal operation pressure. It KLINGER Denmark A/S | Nyager 12-14 | DK-2605 Broendby | +45 43 64 66 11 | www.klinger.dk...
-
Page 12: Torque Data
8. Torque Data Size DN10 DN15 DN20 DN25 DN 32 DN 40 DN 50 DN 65 DN 80 DN100 Stem Body Bolt 17.5 17.5 KLINGER Denmark A/S | Nyager 12-14 | DK-2605 Broendby | +45 43 64 66 11 | www.klinger.dk... -
Page 13: Troubleshooting
Relaxation of studs evenly in crisscross due to gasket creep manner 10. Corrosion Data The following corrosion data is just for information only. KLINGER Denmark A/S | Nyager 12-14 | DK-2605 Broendby | +45 43 64 66 11 | www.klinger.dk... - Page 14 Corrosion Data Brass Carbon Steel 316Stainless Steel 17-4PH Alloy20 Monel Hastelloy C Viton Heatcom Delrin Kel-F（PCTFE） Grafoil Teflon&Filled Teflon Peek UHMWPE Acetaldehyde Acetamine Acetate Solvents Acetic Acid, aerated Acetic Acid, Air Free Acetic Acid, crude Acetic Acid, glacial Acetic Acid, pure Acetic Acid, 10% Acetic Acid, 80% Acetic Acid Vapors...
- Page 15 Corrosion Data Brass Carbon Steel 316Stainless Steel 17-4PH Alloy20 Monel Hastelloy C Viton Heatcom Delrin Kel-F（PCTFE） Grafoil Teflon&Filled Teflon Peek UHMWPE Alcohol, Methyl Alcohol, Propyl Alumina Aluminum Acetate Aluminum Chloride dry Aluminum Chloride solution Aluminum Fluoride Aluminum Hydroxide Aluminum Nitrate Aluminum Oxalate Alum（Alum.
- Page 16 Corrosion Data Brass Carbon Steel 316Stainless Steel 17-4PH Alloy20 Monel Hastelloy C Viton Heatcom Delrin Kel-F（PCTFE） Grafoil Teflon&Filled Teflon Peek UHMWPE Ammonium Hydroxide Ammonium Monosulfate Ammonium Nitrate Ammonium Oxalate 5% Ammonium Persulfate Ammonium Phosphate Ammonium Phosphate Di-basic Ammonium Phosphate Tri-basic Ammonium Sulfate Ammonium Sulfide Ammonium Sulfite...
- Page 17 Corrosion Data Brass Carbon Steel 316Stainless Steel 17-4PH Alloy20 Monel Hastelloy C Viton Heatcom Delrin Kel-F（PCTFE） Grafoil Teflon&Filled Teflon Peek UHMWPE Barium Hydroxide Barium Nitrate Barium Sulfate Barium Sulfide Beer Beet Sugar Liquors Benzaldehyde Benzene（Benzol） Benzoic Acid Berryllium Sulfate Bleaching Powder wet Blood（Meat Juices）...
- Page 18 Corrosion Data Brass Carbon Steel 316Stainless Steel 17-4PH Alloy20 Monel Hastelloy C Viton Heatcom Delrin Kel-F（PCTFE） Grafoil Teflon&Filled Teflon Peek UHMWPE Butylene Butyric Acid Calcium Bisulfite Calcium Carbonate Calcium Chlorate Calcium Chloride Calcium Hydroxide Calcium Nitrate Calcium Phosphate Calcium Sillicate Calcium Sulfate Caliche Liquor Camphor...
- Page 19 Corrosion Data Brass Carbon Steel 316Stainless Steel 17-4PH Alloy20 Monel Hastelloy C Viton Heatcom Delrin Kel-F（PCTFE） Grafoil Teflon&Filled Teflon Peek UHMWPE Caustic Soda Cellulose Acetate China Wood Oil（Tung） Chlorinated Solvents Chlorinated Water Chlorine Gas, dry Chlorobenzene, dry Chloroform, dry Chlorophyll, dry Chlorosulfonic Acid, dry Chrome Alum Chromic Acid＜50%...
- Page 20 Corrosion Data Brass Carbon Steel 316Stainless Steel 17-4PH Alloy20 Monel Hastelloy C Viton Heatcom Delrin Kel-F（PCTFE） Grafoil Teflon&Filled Teflon Peek UHMWPE Copper Cyanide Copper Nitrate Copper Sulfate Corn Oil Cottonseed Oil Cresol Creosote Oil Cresylic Acid Crude Oil, sour Crude Oil, sweet Coupric Nitrate Cutting Oils, Water Emulsions Cyanide...
- Page 21 Corrosion Data Brass Carbon Steel 316Stainless Steel 17-4PH Alloy20 Monel Hastelloy C Viton Heatcom Delrin Kel-F（PCTFE） Grafoil Teflon&Filled Teflon Peek UHMWPE Dimethyl phthalate Dioxane Dipentane（Pinene） Disoidum Phosphate Dowtherm Drilling Mud Dry Cleaning Fluids Drying Oil Enamel Epsom Salts（MgSo4） Ethane Ethers Ethyl Acetate Ethyl Acrylate Ethyl Benzene...
- Page 22 Corrosion Data Brass Carbon Steel 316Stainless Steel 17-4PH Alloy20 Monel Hastelloy C Viton Heatcom Delrin Kel-F（PCTFE） Grafoil Teflon&Filled Teflon Peek UHMWPE Fatty Acids Ferric Hydroxide Ferric Nitrate Feric Sulfate Ferrous Ammonium Citrate Ferrous Chloride Ferrous Sulfate Ferrous Sulfate, Saturated Fertilizer Solutions Fish Oil Flourine Gas, dry Flue Gases...
- Page 23 Corrosion Data Brass Carbon Steel 316Stainless Steel 17-4PH Alloy20 Monel Hastelloy C Viton Heatcom Delrin Kel-F（PCTFE） Grafoil Teflon&Filled Teflon Peek UHMWPE Fruit Juices Fuel Oil Fumaric Acid Furfural Gallic Acid 5% Gas, Manufactured Gas, Natural Gas, Odorizers Gasoline, Aviation Gasoline, Leaded Gasoline, Motor Gasoline, Refined Gasoline, Sour...
- Page 24 Corrosion Data Brass Carbon Steel 316Stainless Steel 17-4PH Alloy20 Monel Hastelloy C Viton Heatcom Delrin Kel-F（PCTFE） Grafoil Teflon&Filled Teflon Peek UHMWPE Hexanol, Tertiary Hydraulic Oil, Petroleum Base Hydrazine Hydrocyanic Acid Hydrofluosilicic Acid Hydrogen Gas, cold Hydrogen Gas, hot Hydrogen Perixide＞25% Hydrogen Perixide＜25% Hydrogen Sulfide, Dry Hydogen sulfide, Wet...
- Page 25 Corrosion Data Brass Carbon Steel 316Stainless Steel 17-4PH Alloy20 Monel Hastelloy C Viton Heatcom Delrin Kel-F（PCTFE） Grafoil Teflon&Filled Teflon Peek UHMWPE Laquer（and Solvent） Lactic Acid Concentrated Cold Lactic Acid Concentrated Hot Lactic Acid Dilute Cold Lactic Acid dilute Hot Lactose Lard Lard Oil Lead acetate...
- Page 26 Corrosion Data Brass Carbon Steel 316Stainless Steel 17-4PH Alloy20 Monel Hastelloy C Viton Heatcom Delrin Kel-F（PCTFE） Grafoil Teflon&Filled Teflon Peek UHMWPE Maleic Acid Maleic anhydrde Malic acid Malt Beverages Manganese Carbonate Manganese Sulfate Mayonnaise Meat Juices Melamine Resins Mercuric Chloride Mercuric Cyanide Mercurous Nitrate Mercury...
- Page 27 Corrosion Data Brass Carbon Steel 316Stainless Steel 17-4PH Alloy20 Monel Hastelloy C Viton Heatcom Delrin Kel-F（PCTFE） Grafoil Teflon&Filled Teflon Peek UHMWPE Methyl Isobutyle Ketone Milk & Milk Products Mineral Oils Mineral Spirits Mixed Acids（cold） Molasses, crude Molasses, edible Molybdic Acid Monochloro Benzene Dry Morpholine Mustard...
- Page 28 Corrosion Data Brass Carbon Steel 316Stainless Steel 17-4PH Alloy20 Monel Hastelloy C Viton Heatcom Delrin Kel-F（PCTFE） Grafoil Teflon&Filled Teflon Peek UHMWPE Nitrogen Nitrous Acid 10% Nitrous Gases Nitrous Oxide Oils & Fats Oils, Animal Oils, Petroleum Refined Oils, Petroleum Sour Oils, Water Mixture Olaic Acid Oleic Acid...
- Page 29 Corrosion Data Brass Carbon Steel 316Stainless Steel 17-4PH Alloy20 Monel Hastelloy C Viton Heatcom Delrin Kel-F（PCTFE） Grafoil Teflon&Filled Teflon Peek UHMWPE Pentane Perchlore-thylene, Dry Petrolatum（Vaseline Pet. Jelly） Phenol Phosphate Ester Phosphoric Acid 10% Phosphoric Acid 50% Cold Phosphoric Acid 50% Hot Phosphoric Acid 85% Cold Phosphoric Acid 85% Hot Phosphoric Anhydride...
- Page 30 Corrosion Data Brass Carbon Steel 316Stainless Steel 17-4PH Alloy20 Monel Hastelloy C Viton Heatcom Delrin Kel-F（PCTFE） Grafoil Teflon&Filled Teflon Peek UHMWPE Potassium Bromide Potassium Carbonate Potassium Chlorate Potassium Chloride Potassium Chromate Potassium Cyanide Potassium Dichromate Potassium Ferricyanide Potassium Ferrocyanide Potassium Hydroxide Dilute Cold Potassium Hydroxide 70% Cold Potassium Hydroxide Dilute Hot Potassium Hydroxide 70% Hot...
- Page 31 Corrosion Data Brass Carbon Steel 316Stainless Steel 17-4PH Alloy20 Monel Hastelloy C Viton Heatcom Delrin Kel-F（PCTFE） Grafoil Teflon&Filled Teflon Peek UHMWPE Propyl Bromide Propylene Glycol Pyridine Pyrolgallic Acid Quench Oil Quinine, Sulfate, Dry Resins & Rosins Resorcinol Road Tar Roof Pitch Rosin Emulsion R P-1 Fuel Rubber Latex Emulsions...
- Page 32 Corrosion Data Brass Carbon Steel 316Stainless Steel 17-4PH Alloy20 Monel Hastelloy C Viton Heatcom Delrin Kel-F（PCTFE） Grafoil Teflon&Filled Teflon Peek UHMWPE Silver Nitrate 10% Silver Plating Sol. Soap Solutions （Stearates） Sodium Acetate Sodium Aluminate Sodium Benzoate Sodium Bicarbonate Sodium Bichromate Sodium Bisulfate 10% Sodium Bisulfite 10% Sodium Borate...
- Page 33 Corrosion Data Brass Carbon Steel 316Stainless Steel 17-4PH Alloy20 Monel Hastelloy C Viton Heatcom Delrin Kel-F（PCTFE） Grafoil Teflon&Filled Teflon Peek UHMWPE Sodium Hydroxide 70% Hot Sodium Hypochlorite（Bleach） Sodium Hyposulfite Sodium Lactate Sodium Meatap-hosphate Sodium Metasilicate Cold Sodium Metasilicate Hot Sodium Nitrate Sodium Nitrite Sodium Perborate Sodium Peroxide...
- Page 34 Corrosion Data Brass Carbon Steel 316Stainless Steel 17-4PH Alloy20 Monel Hastelloy C Viton Heatcom Delrin Kel-F（PCTFE） Grafoil Teflon&Filled Teflon Peek UHMWPE Steam（212F） Stearic Acid Styrene Sugar Liquids Sugar, Syrups & Jam Sulfate, Black Liquor Sulfate, Green Liquor Sulfate, White Liquor Sulfur Sulfur Chlorides Sulfur Dioxide, Dry...
- Page 35 Corrosion Data Brass Carbon Steel 316Stainless Steel 17-4PH Alloy20 Monel Hastelloy C Viton Heatcom Delrin Kel-F（PCTFE） Grafoil Teflon&Filled Teflon Peek UHMWPE Tolul （Toluene） Tomato Juice Transformer Oil Tributyl Phosphate Trichlo-rethylene Trichloroactetic Acid Triethanolamine Triethylamine Trisodium Phosphate Tung Oil Turpentine Urea Uric Acid Varnish Vegetable Oils...
