Technical Data

Mixing Control 354 Floating
Literature — D 354, A 354, D 001, D 070, Essays
Control — Microprocessor control; This is not a safety (limit) control.
Packaged weight — 2.8 lb. (1300 g), Enclosure A, PVC plastic
Dimensions — 6-5/8" H x 7-9/16" W x 2-13/16" D (170 x 193 x 72 mm)
Approvals — Meets DOC regulations for EMI/RFI.
Ambient conditions — Indoor use only, 30 to 120°F (0 to 50°C), < 95% RH non-
condensing.
Power supply — Class 2, 24 V (ac) ±10% 50/60 Hz 3 VA
Mix Relays — 120 V (ac) 6 A 1/4 hp, pilot duty 240 VA 2 A
Other Relays — 120 V (ac) 10 A 1/3 hp, pilot duty 240 VA 2 A
Sensors — NTC thermistor, 10 kΩ @ 77°F (25°C ±0.2°C) ß=3892
included: Outdoor Sensor 070 and Universal Sensor 071.
optional: Universal Sensor 071, and Indoor Sensor 076 or 2k RTU
Occupied — 35 to 105°F (2 to 41°C)
Unoccupied — 35 to 105°F (2 to 41°C)
Heating Curve — 0.4 to 3.6
Max. Supply — 100 to 190°F, Off (38 to 88°C, Off)
Minimum Boiler Return — Off, 60 to 150°F (Off, 16 to 66°C)
Motor Speed — 30 to 250 seconds
