Combined Ventilation Controller
TC5-1N5FAB
USER'S MANUAL
FUNCTIONS
SETTINGS

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TC5-1N5FAB and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AP TC5-1N5FAB

Summary of Contents for AP TC5-1N5FAB

  • Page 1 Combined Ventilation Controller TC5-1N5FAB USER'S MANUAL FUNCTIONS SETTINGS...

  • Page 2: Table Of Contents

    Curtain Operating Time Compensation ......46 Manual Operation of the Curtains ........47 HEATER SETTINGS ............48 ALARM SETTINGS ............54 TEST MODE ..............56 TROUBLESHOOTING GUIDE ........57 TECHNICAL SPECIFICATIONS........61 FACTORY SETTINGS ............ 62 FUNCTION SUMMARY........... 64 GLOSSARY ..............68 TC5-1N5FAB rev.06...

  • Page 3: Precautions

    DO NOT SPRAY WATER ON THE CONTROLLER FOR CUSTOMER USE Enter the serial number located on the side of the controller below for future reference. TC5-1N5FAB Model number: Serial number: TC5-1N5FAB rev.06...

  • Page 4: Features

    FEATURES The TC5-1N5FAB is an electronic device used for environmental control in livestock buildings. It allows the user to maintain a specified target tem- perature by controlling the operation of ventilation and heating equipment. One stage of variable speed fans, up to two stages of constant-speed fans, as well as curtains, foggers and heaters can be connected to the controller.
  • Page 5 CONTROL OF AIR INLET MOVEMENT If the TC5-1N5FAB is used in combination with a PF-5B controller, the move- ment of the air inlets can be coordinated with the operation of the fans using a potentiometer located on the panel drive.

  • Page 6: Location Of The Controls

    LOCATION OF THE CONTROLS TC5-1N5FAB rev.06...

  • Page 7: Controller Status Leds

    F L O A T IN G S TA G E 3 D IS A B L E D E N A B L E D R E S E R V E D R E S E R V E D TC5-1N5FAB rev.06...

  • Page 8: Installation

    NC terminal. ALL WIRING MUST BE DONE BY AN AUTHORIZED ELECTRICIAN AND MUST COMPLY WITH APPLICABLE CODES, LAWS AND REGULATIONS. BE SURE POWER IS OFF BEFORE DOING ANY WIRING TO AVOID ELECTRICAL SHOCKS AND EQUIPMENT DAM- WARNING AGE. TC5-1N5FAB rev.06...

  • Page 9: Motor Types

    The currently selected type is dis- played, alternating with the letters "tYP". Use the adjustment knob to adjust the motor type to the desired value. Return to the Stage 1 bandwidth display either by pressing the push- button once again. TC5-1N5FAB rev.06...

  • Page 10: Temperature Probes

    (6.22 and 6.60 mm) (the cable dimensions should not be under 18 AWG) to ensure the cable entry is liquid tight. Do not ground the shielding. It is preferable to solder the cable joint to ensure a proper contact between the two cables. TC5-1N5FAB rev.06...
  • Page 11 If the probe is defective, the let- ters "PR1" are displayed, alter- nating with the state of the probe and the letter "P". TC5-1N5FAB rev.06...

  • Page 12: Stage 3 Operation

    TAGE 3 OPERATION Stage 3 can operate as a heating or cooling stage. ð Set switch # 7 to OFF to use Stage 3 for cooling. ð Set switch # 7 to ON to use Stage 3 for heating. TC5-1N5FAB rev.06...

  • Page 13: Changing The Parameter Settings

    St 2 (ii) If, after about 6 seconds, no action is taken by the user, the absolute temperature value is displayed, alternating with "St 2". In this case, the absolute value is: Set Point + Bandwidth + Differential 2. TC5-1N5FAB rev.06...

  • Page 14: Locking The Parameters Settings

    Stage 1 minimum ventilation speed can be modified (as long as the tem- perature curve and the minimum ventilation speed curve are deactivated respectively). To lock the parameter settings: Set internal switch # 1 to ON. To unlock the parameter settings: Set internal switch # 1 to OFF. TC5-1N5FAB rev.06...

  • Page 15: Temperature Settings

    The controller can display probe temperatures individually. Probes can also be turned on or off to control the temperature in different parts of the building. Set selection knob to ROOM TEMPERATURE / PROBE TEMP. The average room temperature is displayed. TC5-1N5FAB rev.06...
  • Page 16 Turn the adjustment knob clockwise by one notch. The minimum temperature flashes on the display, alternating with the letters "Lo". Turn the adjustment knob clockwise one notch further. The maximum temperature flashes on the display, alternating with the letters "Hi". TC5-1N5FAB rev.06...
  • Page 17 Press the push-button to access the other probes, etc. NOTE : If you let the display flash for more than 10 seconds, the controller resets the minimum and maximum temperatures currently in memory (the display stops flashing to indicate that the reset has been done). TC5-1N5FAB rev.06...

  • Page 18: Temperature Set Point

    Set the selection knob to SET POINT / T° CURVE.The current set point flashes on the display. Use the adjustment knob to adjust the set point to the desired value. NOTE: The temperature set point can be adjusted only if the temperature curve is deactivated (see following section). TC5-1N5FAB rev.06...

  • Page 19: Temperature Curve

    Certain restrictions apply to reduce the risk of errors: − The highest possible day number is 99. − Decreasing day numbers are not allowed. − Increasing temperatures are not allowed. − The temperature variation cannot exceed 3°F (1.6°C) per day. TC5-1N5FAB rev.06...
  • Page 20 Using the adjustment knob, adjust the set point to the desired value. Once the six points of the curve have been specified, activate the curve as explained below. NOTE : Make sure the temperature curve is deactivated before specifying new points (see below). TC5-1N5FAB rev.06...
  • Page 21 Press the push-button to display the points of the curve currently defined until the word OFF appears (thirteen clicks). Turn the adjustment knob clockwise one notch. The word ON flashes on the display, indicating that the temperature curve is now activated. Set the selection knob to ROOM TEMPERATURE. TC5-1N5FAB rev.06...
  • Page 22 Press the push-button to display the points of the curve actually de- fined until the word ON appears (fourteen clicks). Turn the adjustment knob counterclockwise one notch. The word OFF flashes on the display, indicating that the temperature curve is now deactivated. TC5-1N5FAB rev.06...

  • Page 23: Ventilation Settings

    VENTILATION SETTINGS OOLING OPERATION The TC5-1N5FAB controls one stage of variable-speed fans (Stage 1), one stage of constant-speed fans (Stage 2) and one optional stage of constant- speed fans (Stage 3) as well as curtains for natural ventilation. If the floating stage 3 is disabled (internal swich #10 Off), the curtains opererate after the stage 3.
  • Page 24 • At Set Point: stage 1 fans reach minimum speed. • Below the Set Point: stage 1 fans stop operating continuously and operate according to the minimum ventilation cycle at minimum speed. TC5-1N5FAB rev.06...
  • Page 25 • At Set Point + bandwidth 1: stage 1 fans reach full speed. • At Set Point + bandwidth + diff. 2: stage 2 fans start running. TC5-1N5FAB rev.06...
  • Page 26 • At Set Point: stage 1 fans reach minimum speed. • Below the Set Point: stage 1 fans stop operating continuously and operate according to the minimum ventilation cycle at minimum speed. TC5-1N5FAB rev.06...

  • Page 27: Minimum Ventilation Cycle

    2. To stop the fans, set time on to zero and time off to any value. 3. To run the fans intermittently, set time on to the desired running time and time off to the desired off time. TC5-1N5FAB rev.06...
  • Page 28 Use the adjustment knob to adjust time on to the desired value. Press the push-button. The current time off for Stage 1 flashes on the display, alternating with the letters "Off". Use the adjustment knob to adjust time off to the desired value. TC5-1N5FAB rev.06...

  • Page 29: Humidity Compensation

    This feature also applies when the minimum ventilation speed is activated. Note that for the compensation to take place, the compensation feature must be activated by the user. When a compensation is applied to the minimum speed, the compensation pilot light turns on. TC5-1N5FAB rev.06...
  • Page 30 Note that the humidity compensation feature must be activated for this to work. Set the selection knob to STAGE 1 — HUMIDITY CONTROL. The current humidity reading is displayed. TC5-1N5FAB rev.06...
  • Page 31 Set the selection knob to STAGE 1 — HUMIDITY CONTROL. The current humidity reading is displayed. Press the push-button three times. The current on/off state of humidity compensation flashes on the display. Use the adjustment knob to adjust the on/off state to the desired value. TC5-1N5FAB rev.06...

  • Page 32: Minimum Speed Curve

    When the room temperature rises above the set point, the fans will return to the current minimum speed, calculated according to the minimum speed curve. TC5-1N5FAB rev.06...
  • Page 33 EXAMPLE 2 MINIMUM SPEED CURVE TEMPERATURE CURVE Temperature Speed 90.0 °F 10 % POINT 20 % 85.0 °F POINT TC5-1N5FAB rev.06...
  • Page 34 Therefore, if you activate the mini- mum speed curve today, it will effectively be in operation the moment you activate it. In this case, the current minimum speed will be a value between 10% and 20%. TC5-1N5FAB rev.06...
  • Page 35 The minimum speed curve must be deactivated before specifying the points on the curve (see below). ii) All six points of the curve must be specified. If you do not need six different points, repeat your last minimum speed for each unneces- sary point of the curve. TC5-1N5FAB rev.06...
  • Page 36 Press the push-button to display the points of the curve currently defined until the word OFF appears (fourteen clicks). Turn the adjustment knob clockwise by one notch. The word ON flashes on the display, indicating that the minimum speed curve is now activated. TC5-1N5FAB rev.06...
  • Page 37 Press the push-button to display the points of the curve currently defined until the word ON appears (fourteen clicks). Turn the adjustment knob counterclockwise by one notch. The word OFF flashes on the display, indicating that the minimum speed curve is now deactivated. TC5-1N5FAB rev.06...

  • Page 38: Differential Settings

    0.5°F and 20.0°F (0.3°C and 11.1°C). Set the selection knob to STAGE 2/3. The current differential for Stage 2 is displayed, alternating with the letters "St.2" and "dif". Use the adjustment knob to adjust the differential to the desired value. TC5-1N5FAB rev.06...
  • Page 39 2 is displayed, alternating with the letters "St.2" and "dif". Press the push-button. The current differential for Stage 3 is displayed, alternating with the letters "St.3" and "dif". Use the adjustment knob to adjust the differential to the desired value. TC5-1N5FAB rev.06...

  • Page 40: Mist Cooling

    The following diagram sums up the operation of the mist units. Mist units turn on in timer mode Mist units turn off Mist Diff. Room Mist Offset Set Point Temperature TC5-1N5FAB rev.06...
  • Page 41 The current mist time on is displayed, alternating with the word "On". Press the push-button three times. The current differential is displayed, alternating with the letters "diF". Use the adjustment knob to set differential to the desired value. TC5-1N5FAB rev.06...
  • Page 42 The current mist time on is displayed, alternating with the letters "On". Press the push-button four times. The current turn off level is dis- played, alternating with the letters "StP" and "rh". Use the adjustment knob to set the turn off level to the desired value. TC5-1N5FAB rev.06...

  • Page 43: Natural Ventilation

    Note that if Stage 3 is configured for heating, the curtain dead band begins at Bandwidth + Differential 2. The curtains open and close intermittently according to the time on and time off settings: TIME ON OPEN/CLOSE STOP TIME OFF TC5-1N5FAB rev.06...
  • Page 44 PF-5 resumes normal operations (this applies only to users with a PF-5 controller connected to the TC5-1N5FAB). FLOATING STAGE 3 This feature is enabled if the dipswitch #10 is turned on. It allows to operate the curtains after the stage 2 instead of after the stage 3.
  • Page 45 Use the adjustment knob to set time on to the desired value. Press the push-button. The current time off is displayed, alter- nating with the letters "Off". Use the adjustment knob to set time off to the desired value. TC5-1N5FAB rev.06...

  • Page 46: Curtain Operating Time Compensation

    F means a 12% increase). TIME OFF is decreased by the same amount. Compensation Interval Temperature Current Outside Outside Temperature Set Point Note that when the compensated TIME OFF value is less than 10 seconds, it is set to zero. TC5-1N5FAB rev.06...

  • Page 47: Manual Operation Of The Curtains

    Set the selection knob to CURTAINS — MANUAL. The current curtain mode of operation is displayed: Aut — automatic mode; Off — stop the curtains; OPE — open the curtains; CLO — close the curtains. Use the adjustment knob to select the mode. TC5-1N5FAB rev.06...

  • Page 48: Heater Settings

    If the room temperature falls: - at Set Point - Heater 1 Offset - Heater 1 Diff.: Heater 1 turns on. - at Set Point - Heater 1 Offset - Heater 1 Diff. - Heater 2 Diff.: Heater 2 turns on. TC5-1N5FAB rev.06...
  • Page 49 Use the adjustment knob to adjust the differential to the desired value. Press the push-button. The heater differential for Heater 2 is dis- played, alternating with the letters "DIF" and "Ht.2". Use the adjustment knob to adjust the differential to the desired value. TC5-1N5FAB rev.06...
  • Page 50 PROBES 3 & 4 PROBES 1 & 2 NOT USED YOUNG ANIMALS MINIMUM HEAT ate the fans according to the probes of the zone with the highest tempera- ture whenever the temperature difference between zones is greater than a user-defined value. TC5-1N5FAB rev.06...
  • Page 51 If the room temperature falls: - at Set Point - Heater 1 Offset - Diff. 1 (Zone 1) : Heater 1 turns on. - at Set Point - Heater 2 Offset - Diff. 2 (Zone 2) : Heater 2 turns on. TC5-1N5FAB rev.06...
  • Page 52 Use the adjustment knob to adjust the offset to the desired value. Press the push-button. The current heating differential for Heater 2 is displayed, alternating with the letters "DIF" and "Ht.2". Use the adjustment knob to adjust the differential to the desired value. TC5-1N5FAB rev.06...
  • Page 53 1 offset is displayed, alternating with the letters "OFT" and "Ht.1". Press the push-button four times. The maximum temperature differ- ence between zones is displayed, alternating with the letters "Zon dif". Use the adjustment knob to adjust the temperature difference to the desired value. TC5-1N5FAB rev.06...

  • Page 54: Alarm Settings

    F to 40 F. The critical temperature ranges from -40.0°F to 120.0°F (-40.0°C to 48.9°C). Set the selection knob to ALARM — OFFSETS / CRITI- CAL. The current low alarm offset flashes on the display, alternating with the word "LO". TC5-1N5FAB rev.06...
  • Page 55 Use the adjustment knob to set the high alarm offset to the desired value. Press the push-button. The current critical high temperature is dis- played, alternating with the letters "Cri". Use the adjustment knob to set the critical high temperature to the desired value. TC5-1N5FAB rev.06...

  • Page 56: Test Mode

    Turn the selector knob to the ROOM TEMPERATURE position. The current room temperature is displayed. Press and hold the push-button for 5 seconds. NOTE: If no user activity is recorded after 5 minutes in test mode, the controller resumes normal operation. TC5-1N5FAB rev.06...

  • Page 57: Troubleshooting Guide

    There is electrical Do not run probe cables next to temperature. noise near an ex- other power cables. When tended probe cable. crossing other power cables, cross at 90 TC5-1N5FAB rev.06...
  • Page 58 Adjust the minimum speed to a The minimum speed higher value. is too low. The fan motor is Check if motor is defective by defective. connecting it to an alternate power supply. Replace the motor if it still doesn't operate. TC5-1N5FAB rev.06...
  • Page 59 (N for 115V or L2 for 230V) to activate the motor. Also, be sure the stage 1 COMMON is supplied by line L1. Humidity compensation Adjust set point or deactivate is activated and relative compensation as required. humidity exceeds set point. TC5-1N5FAB rev.06...
  • Page 60 If it still is not operating. Listen to see if there is a clicking The controller is sound when the Stage's pilot defective. light turns on. If there is no clicking sound, contact your distributor to repair the control- ler. TC5-1N5FAB rev.06...

  • Page 61: Technical Specifications

    -40.0° to 120.0°F (-40.0° to 48.9°C). Accuracy: 1.8 F (1 C) between 41 F (5 and 35 Enclosure: ABS, moisture and dust-tight. The room temperature where the controller is located MUST ALWAYS REMAIN BETWEEN 32 AND 104 F (0 AND 40 TC5-1N5FAB rev.06...

  • Page 62: Factory Settings

    Out s i d e S e t - 4 0 t o 9 9 . 9 7 0 ° F ( 2 1 ° C ) P o i n t ( - 4 0 t o 3 7 . 7 TC5-1N5FAB rev.06...
  • Page 63 These initial parameter settings will not be retained in the controller's memory. Each new setting will replace the preceding one. ii) If the power supply is cut off, the last parameter settings will be retained in memory until the power is restored. TC5-1N5FAB rev.06...

  • Page 64: Function Summary

    User-adjusted set point. Set point calculated using the temperature steady value curve. SET POINT / T° On / OFF Status of temperature curve. CURVE Day number of the current temperature curve point. Set point of the current temperature curve point. TC5-1N5FAB rev.06...
  • Page 65 Minimum and maximum humidity levels. On / OFF Status of humidity compensation. STAGE 1 - set rH The relative humidity set point. HUMIDITY Minimum Speed Compensation. Time on for Heater 1 timer. Time off for Heater 1 timer. TC5-1N5FAB rev.06...
  • Page 66 CLO - manual close Oft / StP Mist offset (stop temperature). diF / Str Mist differential (start temperature). MIST TIMER/ Time on for mist cycle. OFFSET/ DIFF. Time off for mist cycle. StP rH Humidity turn off level. TC5-1N5FAB rev.06...
  • Page 67 Low alarm offset. ALARM OFFSETS High alarm offset. Cri. Critical temperature. Steady value / Off Outside temperature / probe deactivated OUTSIDE T° flashing value Outside set point SETTINGS ON / OFF On / off state of curtain compensation TC5-1N5FAB rev.06...

  • Page 68: Glossary

    OFFSET: An offset is a temperature difference from the set point that normally defines a cut-off point for a stage operation. For example, a heater offset of 2°F means the heaters will turn off at 2°F below the set point. TC5-1N5FAB rev.06...
  • Page 69 ZONED HEATERS: When zoned heaters are used, heaters in each zone operate according to their own probes rather than the average temperature for the entire room. In this way, heaters across zones are independent of one another. TC5-1N5FAB rev.06...
  • Page 72 M 890-00165 rev. 06 REV. 01...
