Door phone apartment stations
Hide thumbs
Table of Contents

Advertisement

Quick Links

DOOR PHONE APARTMENT
Buttons function ...........................................................................2
TECHNICAL CHARACTERISTICS ....................................................2
INSTALLATION .................................................................................2
Terminal pins description .............................................................2
CONFIGURATION ............................................................................2
Line terminal settings .......................................................................4
PERFORMANCE ..............................................................................4
Call reception ...............................................................................4
Intercom call forwarding ...............................................................4
Floor call function .........................................................................4
Supplementary ringer ...................................................................4
Door open LED .............................................................................4
OPTIONAL PROGRAMMING ...........................................................5
Intercom function .........................................................................5
CALL TONE PROGRAMMING .........................................................6
Door phone call ring tone .............................................................6
Floor call ring tone ........................................................................6
PROGRAMMING DATA DELETING .................................................6
ACCESSORIES.................................................................................7
Kit for tabletop mounting Ref. 1140/50 ........................................7
Buttons function ...........................................................................8
TECHNICAL CHARACTERISTICS ....................................................8
INSTALLATION .................................................................................8
Terminal pins description .............................................................8
CONFIGURATION ............................................................................9
Line terminal settings .................................................................10
PERFORMANCE ............................................................................10
Call reception .............................................................................10
Intercom call forwarding .............................................................10
OPTIONAL PROGRAMMING .........................................................10
Intercom function .......................................................................10
CALL TONE PROGRAMMING .......................................................11
Door phone call ring tone ...........................................................11
PROGRAMMING DATA DELETING ...............................................11
2 VOICE - Technical Manual
SECTION 4B
STATIONS
Download from www.urmet.com Technical Manuals area.
SECTION CONTENTS
(REV. B)
2
ACCESSORIES...............................................................................11
Kit for tabletop mounting Ref. 1133/50 ......................................11
Buttons function .........................................................................12
TECHNICAL SPECIFICATIONS ......................................................12
INSTALLATION ...............................................................................12
Description of terminals ..............................................................12
CONFIGURATION ..........................................................................12
Line terminal settings .....................................................................14
PERFORMANCE ............................................................................14
Call reception .............................................................................14
Intercom call forwarding .............................................................14
Floor call function .......................................................................14
Additional ringer management ...................................................14
Automatic door lock release .......................................................15
Door open LED / Automatic door lock release ...........................15
OPTIONAL PROGRAMMING .........................................................15
Indoor station intercom function ................................................15
CALL TONE PROGRAMMING .......................................................16
Door phone call ring tone ...........................................................16
8
Floor call ring tone ......................................................................16
PROGRAMMING DATA DELETING ...............................................16
ACCESSORIES...............................................................................17
Kit for tabletop mounting Ref. 1140/51 ......................................17
12
1
sec.4b −−−−

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SIGNO and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for urmet domus SIGNO

Summary of Contents for urmet domus SIGNO

  • Page 1: Table Of Contents

    SECTION CONTENTS SIGNO DOOR PHONE Ref.1183/2 ACCESSORIES................11 Kit for tabletop mounting Ref. 1133/50 ........11 Buttons function ................2 TECHNICAL CHARACTERISTICS ............2 SIGNO HOUSE PHONE WITH 10 ADDITIONAL BUTTONS INSTALLATION .................2 Ref. 1183/3 Terminal pins description .............2 CONFIGURATION ................2 Buttons function .................12 Line terminal settings ...............4...

  • Page 2: Signo Door Phone Ref.1183/2

    3. Configure the programming dip-switches and connect the door phone to the system. 4. Mount again the cover. Signo door phone recalls the style of Signo video door phone. Designed by architect Citterio, Signo door phone has a perfectly flat surface harmonized with the absence of corners.
  • Page 3 USER 35 USER 36 USER 37 USER 38 USER 39 SIGNO DOOR PHONE CONFIGURATION USER 40 USER 41 USER 42 USER 43 USER 44 § Use the CODE dip switches from 2 to 8 (2= most significant bit - 8= least significant bit) to set the required code. Dip switch 1 must be OFF.

  • Page 4: Line Terminal Settings

    USER 85 USER 86 USER 87 USER 88 USER 89 SIGNO DOOR PHONE PERFORMANCE USER 90 USER 91 USER 92 USER 93 USER 94 LINE TERMINAL SETTINGS Line termination USER 95 USER 96 USER 97 USER 98 USER 99 USER 100...

  • Page 5: Optional Programming

    SIGNO DOOR PHONE OPTIONAL PROGRAMMING OPTIONAL PROGRAMMING – Check programmed function: release the handset A and press the programmed button. Check that all indoor stations of user B ring and check audio. The following programming operations are needed after testing the –...

  • Page 6: Call Tone Programming

    SIGNO DOOR PHONE CALL TONE PROGRAMMING - PROGRAMMING DATA DELETING CALL TONE PROGRAMMING PROGRAMMING DATA DELETING In 2VOICE system each user can select the door phone call ring tone To delete all optional programming data (intercom call codes), perform and the floor call ring tone among the 5 available ones.

  • Page 7: Accessories

    SIGNO DOOR PHONE ACCESSORIES ACCESSORIES KIT FOR TABLETOP MOUNTING Ref. 1140/50 Signo door phone can be table-top installed. In this case, buy the suitable support. For installation, follow the procedure below: 1. Remove the door phone cover. 2. Fix the door phone base to the support.

  • Page 8: Atlantico Door Phone Ref.1183/1

    ATLANTICO DOOR PHONE TECHNICAL CHARACTERISTICS - INSTALLATION ATLANTICO DOOR PHONE Ref.1183/1 Atlantico door phone has the following characteristics: • Innovative style, with simple and essential lines designed by Michele De Lucchi. • Plastic finishing (ABS): polished for buttons and embossed for other elements.

  • Page 9: Configuration

    USER 40 USER 41 USER 42 USER 43 ATLANTICO DOOR PHONE USER 44 USER 45 USER 46 USER 47 CONFIGURATION USER 48 USER 49 USER 50 USER 51 CONFIGURATION USER 52 USER 53 USER 54 USER 55 CODE USER 56 USER 57 USER 58 USER 59...

  • Page 10: Line Terminal Settings

    ATLANTICO DOOR PHONE PERFORMANCE - OPTIONAL PROGRAMMING FOR ADDITIONAL FUNCTIONS CODE (1): apartment station code. INTERCOM FUNCTION Set the code according to the following rules: The button on 1183/1 door phones can be programmed for intercom • The indoor station code must be 0 if there is only one station in the calls.

  • Page 11: Call Tone Programming

    ATLANTICO DOOR PHONE CALL TONE PROGRAMMING - PROGRAMMING DATA DELETING ACCESSORIES CALL TONE PROGRAMMING ACCESSORIES In 2VOICE system each user can select the door phone call ring tone KIT FOR TABLETOP MOUNTING Ref. 1133/50 among the 5 available ones. The Mod. Atlantico door phone may be tabletop mounted. For this purpose, purchase a specific white tabletop transformation kit Ref.

  • Page 12: Signo House Phone With 10 Additional Buttons Ref. 1183/3

    Refit the hood. The door phone Ref. 1183/3 has the same aspect and electric characteristics as Signo Ref. 1183/2 door phone, but it is provided with 10 buttons used for additional services and with automatic door lock release function after a call.
  • Page 13 USER 35 USER 36 USER 37 USER 38 USER 39 SIGNO HOUSE PHONE WITH 10 ADDITIONAL BUTTONS CONFIGURATION USER 40 USER 41 USER 42 USER 43 USER 44 same user code. • User codes be consecutive in the same column must.

  • Page 14: Line Terminal Settings

    USER 85 USER 86 USER 87 USER 88 USER 89 SIGNO HOUSE PHONE WITH 10 ADDITIONAL BUTTONS PERFORMANCE USER 90 USER 91 USER 92 USER 93 USER 94 LINE TERMINAL SETTINGS Line termination USER 95 USER 96 USER 97 USER 98...

  • Page 15: Automatic Door Lock Release

    SIGNO HOUSE PHONE WITH 10 ADDITIONAL BUTTONS OPTIONAL PROGRAMMING FOR ADDITIONAL FUNCTIONS OPEN DOOR LED / AUTOMATIC DOOR LOCK indicate that it has been programmed. The indoor stations of user B will ring when this occurs. Ignore this call. RELEASE The door phone is provided with a led that signals open door state or automatic door lock release feature active.

  • Page 16: Call Tone Programming

    SIGNO HOUSE PHONE WITH 10 ADDITIONAL BUTTONS CALL TONE PROGRAMMING - PROGRAMMING DATA DELETION FLOOR CALL TONE – Hold the door opener button pressed. Press and release the button . The indoor station will play a tone. – Hold the door opener button pressed and press the button again to change the tone.

  • Page 17: Accessories

    SIGNO HOUSE PHONE WITH 10 ADDITIONAL BUTTONS ACCESSORIES ACCESSORIES KIT FOR TABLETOP MOUNTING Ref. 1140/51 Signo door phone can be table-top installed. In this case, buy the suitable support. For installation, follow the procedure below: 1. Remove the door phone cover.
  • Page 18 −−−− sec.4b 2 VOICE - Technical Manual...
