Digitrax DN163K1a Quick Start Manual

D D
igitrax
Run Your Trains, Not Your Track!
DN163K1a
Fits Kato SD 40 Locomotive
Features:
Digitrax LocoMotion
The Digitrax LocoMotion System makes them run like the real thing, too!
Torque Compensation for smooth as silk silent operation.
128 Speed Step operation (14 or 28 steps can also be used).
Momentum with acceleration and deceleration.
Normal Direction of Travel is user selectable.
Switching Speed feature for easier and faster access to yard speeds.
3 Step Speed Tables set start, mid and max voltage for custom control.
28 Step Speed Tables with 256 level resolution for precise control.
Scalable Speed Stabilization (Back EMF) with simple setup & 256 level
resolution.
SuperSonic motor drive for silent operation.
FX 3 Functions for prototypical lighting effects:
Constant Brightness Lighting with directional or independent control.
Realistic Effects like Ditch lights, Mars lights, strobes, and many more.
Dynamic and Static Qualifiers operate functions based on direction,
F0 on or off, loco direction and F0, and whether loco is moving.
Function Remapping for custom function setup.
Master Light Switch turns off all lights & functions with one keystroke.
Advanced Consist Function Controls
Plug 'N Play design makes installation quick and easy.
Golden-White LEDs for added realism.
Transponder ID Equipped ready for transponding on your Layout
Compatible with digital surround sound systems
All Mode Programming with Operations Mode Read Back-read back CV
values right on the mainline.
Decoder Factory CV Reset with or without speed table initialize.
Motor Isolation Protection helps prevent damage to your loco and decoder.
Basic, Advanced & UniVersal Consisting
2 Digit and 4 Digit Addressing
DCC Compatible
FCC Part 15, Class B RFI compliant
©2004 Digitrax, Inc
C C C C
ommand ontrol
®
System-Your locomotives look like the real thing.
www.digitrax.com
N Scale
Mobile Decoder
DCC Plug 'N Play
1.5 Amp/2.0 Amp Peak
6 FX 3 Functions, 0.5 Amp
1
