A Nomenclature
B Markings
0598
EN567:2013
ROPE Ø9mm - 12mm
RP229
YYBBBBBBNNNN
C Installation on Harness
A Nomenclature & Markings
1 Main Frame
2 Secondary Attachment Point
3 Cam Safety Catch
4 Main Cam
5 Main Attachment Point
B Markings
1 Manufacturers Identification
2 Body Controlling the Manufacture of PPE
3 Suitable Rope Diameters - (EN1891 A 9-12mm)
4 Serial Number ( Year of Manufacture/ Batch Number/ Individual Number)
5 EN567 : 2013 - Mountaineering Equipment - Rope Clamps
6 Part Number
C Installation on Rope
1 Open cam safety catch and retain on the frame
2 Insert the rope and close the cam fully
3 Pull the Cam Safety Catch away from the frame, allowing the cam to 'clamp' the rope. Whilst in this position, the Cam Safety Catch prevents the rope from coming out of the device. The device should
now slide up the rope. To check that the device is engaged correctly pull the device down the rope sharply.
+44 (0) 1248 363 110 www.iscwales.com sales@iscwales.com
Unit 1, Plot 2, Llandygai Industrial Estate
Bangor, Gwynedd, LL57 4YH, United Kingdom
Company Registered in England & Wales, No. 2999156
RP229 CHEST ASCENDER
User Instruction Manual
D Installation on Rope
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ISC RP229
Summary of Contents for ISC RP229
- Page 1 RP229 CHEST ASCENDER User Instruction Manual A Nomenclature D Installation on Rope B Markings 0598 EN567:2013 ROPE Ø9mm - 12mm RP229 YYBBBBBBNNNN C Installation on Harness A Nomenclature & Markings 1 Main Frame 2 Secondary Attachment Point 3 Cam Safety Catch...
- Page 2 The potential lifetime of ISC products is up to 10 years for plastic or textile products, and indefi nite for metal products. The actual lifetime of a product depends on a variety of factors such as, the intensity of use, the frequency of use, the environment in which it has been used, the competency of the user, and how well it has been maintained and stored etc.
