- Page 1 1 Bin Tray BN1040 Machine Code: D574 Field Service Manual Ver 1.0 Latest Release: Nov., 2019 Initial Release: Nov., 2019 Copyright (c) 2019 Ricoh Co.,Ltd.
- Page 3 Adobe Systems Incorporated in the United States and/or other countries. The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by Ricoh Company, Ltd. is under license. Firefox and Thunderbird are registered trademarks of the Mozilla Foundation.
- Page 4 Microsoft® Windows Vista® Business Microsoft® Windows Vista® Home Premium Microsoft® Windows Vista® Home Basic Microsoft® Windows Vista® Enterprise • The product names of Windows 7 are as follows: Microsoft® Windows® 7 Home Premium Microsoft® Windows® 7 Professional Microsoft® Windows® 7 Ultimate Microsoft®...
- Page 5 Microsoft® Windows Server® 2016 R2 Essentials Microsoft® Windows Server® 2016 R2 Standard Other product names used herein are for identification purposes only and might be trademarks of their respective companies. We disclaim any and all rights to those marks. Microsoft product screen shots reprinted with permission from Microsoft Corporation. Symbols and Abbreviations This manual uses several symbols and abbreviations.
-
Page 7: Table Of Contents
Table of Contents Detailed Descriptions ........................2 Overview ............................... 2 Electrical Components .......................... 3 Paper Exit from 1-Bin Tray Unit ......................4 Replacement and Adjustment ......................5 Beforehand ............................5 1-Bin Tray Paper Remaining Sensor ....................6 1-Bin Tray Exit Sensor .......................... 7 1-Bin LED Board ........................... -
Page 8: Detailed Descriptions
1.Detailed Descriptions 1. Detailed Descriptions Overview Callout Item Callout Item Paper Exit Tray Paper Exit Roller 1-Bin Tray Paper Remaining Sensor 1-Bin Tray Exit Sensor 1-Bin LED Board... -
Page 9: Electrical Components
1.Detailed Descriptions Electrical Components Callout Item Callout Item 1-Bin Tray Paper Remaining Sensor 1-Bin LED Board 1-Bin Tray Exit Sensor... -
Page 10: Paper Exit From 1-Bin Tray Unit
1.Detailed Descriptions Paper Exit from 1-Bin Tray Unit The paper from the paper exit section is transported to the 1-bin unit. This uses the same transport path as usual even if duplex is used. The1-bin tray paper remaining sensor [A] detects the fed out paper, and the LED [B] blinks to inform users that there is paper on the 1-bin tray after the end of the job. -
Page 11: Replacement And Adjustment
2.Replacement and Adjustment 2. Replacement and Adjustment Beforehand • Before installing options, please do the following: If there is a fax unit in the machine, print out all messages stored in the memory, the lists of user-programmed items, and the system parameter list. If there are printer jobs in the machine, print out all jobs in the printer buffer. -
Page 12: 1-Bin Tray Paper Remaining Sensor
2.Replacement and Adjustment 1-Bin Tray Paper Remaining Sensor Remove the 1-bin tray unit. (See “1 Bin Tray BN1040” in the mainframe service manual) Remove the 1-bin tray upper cover [A]. Remove the 1-bin tray paper remaining sensor bracket [A]. Remove the 1-bin tray paper remaining sensor [A]. -
Page 13: 1-Bin Tray Exit Sensor
2.Replacement and Adjustment 1-Bin Tray Exit Sensor Remove the 1-bin tray unit. (See “1 Bin Tray BN1040” in the mainframe service manual) Remove the 1-bin tray upper cover. (1-Bin Tray Paper Remaining Sensor) Remove the 1-bin tray exit sensor bracket [A]. ( ×... -
Page 14: 1-Bin Led Board
2.Replacement and Adjustment 1-Bin LED Board Remove the 1-Bin tray unit. (See “1-Bin Tray BN1040” in the mainframe service manual) Remove the 1-bin LED board cover [A]. Remove the 1-bin LED board [A].
