Ricoh RT5120 Field Service Manual

Ricoh RT5120 Field Service Manual

Vacuum feed lcit
Hide thumbs
Table of Contents

Advertisement

Quick Links

Vacuum Feed LCIT RT5120
Machine Code: D3EW
Field Service Manual
Ver 1.0
Latest Release: Feb, 2018
Initial Release: Feb, 2018
(c) 2018 Ricoh Co.,Ltd.

Advertisement

Table of Contents
loading

Related Manuals for Ricoh RT5120

Summary of Contents for Ricoh RT5120

  • Page 1 Vacuum Feed LCIT RT5120 Machine Code: D3EW Field Service Manual Ver 1.0 Latest Release: Feb, 2018 Initial Release: Feb, 2018 (c) 2018 Ricoh Co.,Ltd.
  • Page 3 Symbols, Abbreviations This manual uses several symbols and abbreviations. The meaning of those symbols and abbreviations are as follows: Symbol What it means Clip ring Screw Connector Clamp E-ring Flat Flexible Cable Timing Belt Short Edge Feed Long Edge Feed Black Cyan Magenta...

  • Page 5: Table Of Contents

    Table of Contents Replacement and Adjustment ......................4 Exterior Covers ............................4 Right Upper Cover ..........................4 Right Lower Cover ..........................4 Rear Right Cover ..........................5 Rear Left Cover ..........................5 Left Top Cover ............................ 6 Center Top Cover ..........................6 Right Top Cover ..........................
  • Page 6 Tray Upper Limit Sensor ........................48 Side Fences (Front, Rear) ........................ 49 Paper Size Sensors .......................... 58 Side Fan ............................59 Rear Side .............................. 60 Main Board ............................60 Motor Control Board ......................... 60 Tray 1 Pickup Belt Motor ........................62 Tray 1 Grip Motor ..........................
  • Page 7 Jam Removal LED .......................... 105 PSU Box ............................. 108 PSU box ............................108 PSU1, 2, 3 / AC Drive Board ......................109 PSU Cooling Fan 1, 2 ........................115 Interlock Switch ..........................116 Detailed Descriptions ........................117 Overview ............................. 117 Specifications ..........................

  • Page 8: Replacement And Adjustment

    1.Replacement and Adjustment 1. Replacement and Adjustment Do not pull out all the trays while RT5120 is not docked to the main machine. Or the unit may topple. Exterior Covers Right Upper Cover Open paper tray 1 slightly. Remove the right upper cover [A]( Right Lower Cover Open paper trays 1 and 2 slightly.

  • Page 9: Rear Right Cover

    1.Replacement and Adjustment Rear Right Cover Lift the rear right cover [A] slightly and remove it ( x6).  When attaching the rear right cover, hang it on the hook. Rear Left Cover Remove the rear right cover (Rear Right Cover) Lift the rear left cover [A] slightly and remove it ( x10).

  • Page 10: Left Top Cover

    1.Replacement and Adjustment Left Top Cover Cut the cushion at the position [A] along the groove. Remove the screws on the left top cover ( x2). Slide the left top cover [A] in the direction of the blue arrow and remove it. Center Top Cover Remove the left top cover (Left Top...

  • Page 11: Right Top Cover

    1.Replacement and Adjustment Slide the center top cover [A] in the direction of the blue arrow and remove it ( x3). Right Top Cover Remove the left top cover (Left Top Cover) Remove the center top cover (Center Top Cover) Remove the screws to slide the right top cover [A] in the direction of the arrow and remove it.

  • Page 12: Top Cover

    1.Replacement and Adjustment Remove the screws at the bottom of the front corner cover [A] ( x2). Lift the front corner cover [A] and remove it. Top Cover Remove the right top cover (Right Top Cover)
  • Page 13 1.Replacement and Adjustment Remove the screws on the stay [A], and then remove the stay with the top cover. Remove the plate from the top cover.

  • Page 14: Top Cover Interlock Switch

    1.Replacement and Adjustment Top Cover Interlock Switch Remove the rear left cover. (Rear Left Cover) Open the clamps on the left side of the main board to loosen the white/black harness [A], which runs to the interlock switch. Main board location [A]...
  • Page 15 1.Replacement and Adjustment Loosen the white/black harness [A] on the upper side of the board. By loosening the harnesses, you can pull out the bracket of the interlock switch more in the later step, leading to facilitating the removal of the switches. Remove the caps [A].
  • Page 16 1.Replacement and Adjustment Open the top cover. Pull tray 1 out.
  • Page 17 1.Replacement and Adjustment Remove the screws on the interlock switch bracket [A]. Pull the bracket slight to access the backside of it. Then, disconnect the connectors of the switches to remove the bracket. Each of white and black harness connectors is fixed as a pair. This prevents wrong-pair connection.

  • Page 18: Rear Corner Cover

    1.Replacement and Adjustment Rear Corner Cover Remove the left top cover (Left Top Cover) Remove the center top cover (Center Top Cover) Remove the right top cover (Right Top Cover) Remove the rear right and rear left covers (Rear Right Cover,Rear Left Cover).

  • Page 19: Upper Inner Cover

    1.Replacement and Adjustment Lift the front door [A] and remove it. Upper Inner Cover Open the front door. Remove the two levers [A] ( x1 each). Remove the knob [B] ( Raise the paper jam U9 clearing plate and remove the knob [A] ( x2).

  • Page 20: Lower Inner Cover

    1.Replacement and Adjustment Remove the upper inner cover [B] ( Lower Inner Cover Open the front door. Remove the lower inner cover [A] ( Tray Front Cover (Tray 1, 2)  The replacement procedures for the tray front covers of tray 1 and 2 are the same. The following is the procedure for replacing the tray front cover of tray 1.

  • Page 21: Paper Feed Unit (Trays 1, 2)

    1.Replacement and Adjustment Paper Feed Unit (Trays 1, 2)  Parts in paper trays 1 and 2 can be removed using the same procedure. The following are the procedures for replacing the parts in tray 1. Paper Tray Remove the tray front cover (Tray Front Cover (Tray 1, Remove the paper tray [A] ( ...
  • Page 22 1.Replacement and Adjustment Remove the lock of the paper feed belt unit ( x2). Hold the knob of the paper feed belt unit [A] and pull out the paper feed belt unit [A].  The paper feed belt unit must be pulled out horizontally relative to the paper tray, to ensure that the paper feed belt is not damaged by getting caught in the side fences or other parts.
  • Page 23 1.Replacement and Adjustment...
  • Page 24 1.Replacement and Adjustment Installing the paper feed belt unit Attach the paper feed belt unit [A]. Check that there is no gap at the position indicated by the red dotted circle. Then, secure the paper feed belt unit firmly with two screws. If there is a gap, proceed to the following step.

  • Page 25: Paper Feed Belt

    1.Replacement and Adjustment Paper Feed Belt Remove the paper feed belt unit (Paper Feed Belt Unit). Remove the guide plate [A] ( Remove the screws and pull out the chamber [A].
  • Page 26 1.Replacement and Adjustment Remove the bracket [A]. Remove the belt shaft [A] and the paper feed belt.

  • Page 27: Paper End Sensor 1

    1.Replacement and Adjustment  During installation, turn the shaft to correct belt deflection before installing the chamber.  When all parts have been assembled, turn the shaft once more to check for deflection, resistance and other abnormalities before replacing the paper tray. Paper End Sensor 1 Remove the paper feed belt unit (Paper Feed Belt...

  • Page 28: Paper End Sensor 2

    1.Replacement and Adjustment Remove paper end sensor 1 [A]. Paper End Sensor 2 Remove the paper feed belt unit (Paper Feed Belt Unit)
  • Page 29 1.Replacement and Adjustment Remove the center guide plate [A]. Release the connectors and clamps of paper end sensors 1 and 2.

  • Page 30: Suction Fan Shutter Solenoid

    1.Replacement and Adjustment Remove the sensor bracket [A]. Remove paper end sensor 2 from the sensor bracket. Suction Fan Shutter Solenoid Remove the paper feed belt unit (Paper Feed Belt Unit) Remove the guide plate [A] on the duct side. The position of the suction fan shutter solenoid [A]...

  • Page 31: Paper Feed Sensor

    1.Replacement and Adjustment Remove the suction fan shutter solenoid. Paper Feed Sensor  The replacement procedures for the paper feed sensor of trays 1 and 2 are the same. The...
  • Page 32 1.Replacement and Adjustment following is the procedure for replacing the paper feed sensor of tray 1. Pull out the paper tray. Remove the top cover [A] of the transport roller unit ( x2). Remove the paper feed sensor bracket [A] ( Remove the paper feed sensor [A] ( x1,...

  • Page 33: Transport Roller Unit

    1.Replacement and Adjustment Transport Roller Unit Open the front door [A] and pull out the paper tray [B]. Remove the tray left upper cover [A] ( Remove the transport roller unit [A]. Float/Separation/Return Fan Duct Remove the paper tray (Paper Tray)
  • Page 34 1.Replacement and Adjustment Remove the left upper cover [A] of the paper tray. Remove the transport roller unit (Transport Roller Unit) Remove the left rail plate [A]. Remove the plate [A]. Remove the ground wire.
  • Page 35 1.Replacement and Adjustment Release the clamps and disconnect the connectors connected to the fan duct. Remove the screws on the inside of the paper tray and then remove the fan duct. Do not remove the screws that fix the position of the float/separation/return fan duct. The position of the float/separation/return fan duct is fixed in the factory and cannot be adjusted outside the factory.

  • Page 36: Float/Separation/Return Fan Bracket

    1.Replacement and Adjustment When installing the float/separation/return fan duct, make sure that the two position adjustment pins shown below are inserted in the holes in the duct. Float/Separation/Return Fan Bracket Remove the float/separation/return fan duct (Float/Separation/Return Fan Duct) Remove the clip (red arrow) of the float fan shutter solenoid [A] and spring [B].
  • Page 37 1.Replacement and Adjustment Disconnect the connector of the return solenoid [A]. Release the clamp of the float/separation/return fan bracket, remove the screws and then remove the float/separation/return fan brackets. Notes for Installing the Float/Separation/Return Fan Bracket When attaching the float / separation / return fan bracket, insert the covering sponge of the float fan / separation fan all around the duct firmly so that there is no gap.
  • Page 38 1.Replacement and Adjustment Separation Fan Bracket When it is difficult to insert a sponge, firmly push it with moderate force, by using a ruler for example.

  • Page 39: Float Fan

    1.Replacement and Adjustment Float Fan Remove the float/separation/return fan bracket (Float/Separation/Return Fan Bracket) The position of the float fan [A] Release the clamp that fixes the harness of the float fan on the back side of the float/separation/return fan bracket.

  • Page 40: Separation Fan

    1.Replacement and Adjustment Remove the screws and the float fan [A]. Separation Fan Remove the float/separation/return fan duct (Float/Separation/Return Fan Duct) Remove the float/separation/return fan bracket (Float/Separation/Return Fan Bracket) The position of the separation fan [A]...

  • Page 41: Return Fan

    1.Replacement and Adjustment Release the clamp and the harness of the separation fan [A]. Remove the screws and the separation fan. Return Fan Remove the float/separation/return fan duct (Float/Separation/Return Fan Duct) Remove the float/separation/return fan bracket (Float/Separation/Return Fan Bracket) The position of the return fan [A]...
  • Page 42 1.Replacement and Adjustment Release the clamp and the harness of the return fan [A]. Remove the screws and the return fan.

  • Page 43: Float Fan Shutter Solenoid

    1.Replacement and Adjustment Float Fan Shutter Solenoid Remove the float/separation/return fan duct (Float/Separation/Return Fan Duct) The position of the float fan shutter solenoid [A] Remove the clip (red arrow) of the float fan shutter solenoid [A] and spring [B].

  • Page 44: Return Solenoid

    1.Replacement and Adjustment Remove the screws to detach the float fan shutter solenoid. Return Solenoid Remove the float/separation/return fan bracket (Float/Separation/Return Fan Bracket) The position of the return solenoid [A] (attached to the float/separation/return fan duct)

  • Page 45: Paper Upper Limit Sensor 1, 2

    1.Replacement and Adjustment Remove the clip of the return solenoid. Remove the screws to detach the return solenoid. Paper Upper Limit Sensor 1, 2 Remove the float/separation/return fan duct (Float/Separation/Return Fan Duct) The position of the paper upper limit sensor 1 [A], 2 [B]...
  • Page 46 1.Replacement and Adjustment Unscrew the screws on the back side of the float/separation/return fan duct, to remove the duct [A].
  • Page 47 1.Replacement and Adjustment Release the pawls of paper upper limit sensor 1. Remove the connector of paper upper limit sensor 1 [A] from the front side. Release the pawl of paper upper limit sensor 2 from the back side and remove the connector of paper upper limit sensor 2 [A] from the front side.

  • Page 48: Paper Height Middle Sensor

    1.Replacement and Adjustment Paper Height Middle Sensor Open the front door [A] and pull out the paper tray [B]. Remove the tray left upper cover [A] ( Remove the paper height middle sensor bracket [A].

  • Page 49: Paper Lower Limit Sensor

    1.Replacement and Adjustment Remove the paper height middle sensor [A] ( x1, Paper Lower Limit Sensor Remove the paper tray (Paper Tray) Remove the tray left upper cover [A]. Remove the transport roller unit (Transport Roller Unit) Remove the left rail plate [A].
  • Page 50 1.Replacement and Adjustment Remove the plate [A]. The position of the paper lower limit sensor [A] Remove the paper lower limit sensor bracket [A].

  • Page 51: Lcit Paper Length Sensors 1 And 2

    1.Replacement and Adjustment Remove the paper lower limit sensor [A] ( x1, LCIT Paper Length Sensors 1 and 2 Open the paper tray. Hold the side fence lock to open the side fence [A]. Remove the sensor cover [A] ( Remove the sensor bracket [A] ( x3,...

  • Page 52: Tray Upper Limit Sensor

    1.Replacement and Adjustment Remove LCIT paper length sensor 1 [A] ( Remove LCIT paper length sensor 2 [B] ( Tray Upper Limit Sensor Remove the paper tray (Paper Tray) Remove the paper feed belt unit (Paper Feed Belt Unit) Remove the tray upper limit sensor [A] ...

  • Page 53: Side Fences (Front, Rear)

    1.Replacement and Adjustment Remove the pawl of the tray upper limit sensor. Side Fences (Front, Rear) Common Procedure for Removing the Side Fences (Front, Rear) Remove the tray front cover. (Tray Front Cover (Tray 1, Remove the paper tray. (Paper Tray) Remove the plate [A] from the end fence side.
  • Page 54 1.Replacement and Adjustment bottom plate until it becomes visible on the end fence side. When the bottom plate has been raised, insert a screwdriver or similar object in the hole in the sheet metal at the bottom of the wire pick-up roller to prevent the pin [A] from turning. Remove the bottom plate [A] on the front side.
  • Page 55 1.Replacement and Adjustment Remove the side fence guide [A]. The guide is secured by the hook parts [A] that fit on the bottom plate. As the same way in the previous steps, remove the bottom plate on the rear side to remove the side fence guide.
  • Page 56 1.Replacement and Adjustment Remove the plate [A] on the feed side. 10. Fully close the side fences. Side Fence (Front) Remove the side fence shafts [A] and [B] on the front side ( x2). Pull out the shaft in the direction...
  • Page 57 1.Replacement and Adjustment of the arrow. The [B] shaft has a spring. Insert a screwdriver in the opening in the frame and remove the ground connection ( x1). Remove the screws in the side fence ( x4).
  • Page 58 1.Replacement and Adjustment Release the clamp ( x2) Hold down the lock lever [A] and raise the side fence [B]. Remove the connectors from the bottom of the side fence ( x3, x2). Raise the side fence (front) [A] and remove it. Install the spring on the end face shaft as shown in the photo.
  • Page 59 1.Replacement and Adjustment Side Fence (Rear) Remove the bracket [A]. ( Remove the side fence shafts [A] and [B] on the rear side ( x2). Pull out the shaft in the direction...
  • Page 60 1.Replacement and Adjustment of the arrow. The [B] shaft has a spring. Insert a screwdriver in the opening in the frame and remove the ground connection ( x1). Remove the screws in the side fence ( x4).
  • Page 61 1.Replacement and Adjustment Release the clamp ( x2). Hold down the lock lever [A] and raise the side fence [B]. Remove the connectors from the bottom of the side fence ( x4, x2). Lift the side fence (rear) and remove it. Install the spring on the end face shaft as shown in the photo.

  • Page 62: Paper Size Sensors

    1.Replacement and Adjustment Paper Size Sensors Remove the side fence (rear) (Side Fences (Front, Rear)) Remove the sensor bracket [A] ( Remove the paper size sensors [1] to [4] ( x4, x4). The sensors are located in order 1 to 4 on the paper feed side.

  • Page 63: Side Fan

    1.Replacement and Adjustment Side Fan Remove the side fence (Side Fences (Front, Rear)) Remove the fan cover [A] ( Hold down the lock lever [A] and lower the plate [B] in the direction of the arrow. Remove the side fan [A] ( x2, x1)

  • Page 64: Rear Side

    1.Replacement and Adjustment Rear Side Main Board Main Board [A] Location Remove the rear right and left covers (Rear Right Cover,Rear Left Cover). Remove the main board ( x7, hook x1, all connectors and clamps) Motor Control Board The position of the motor control board [A]...
  • Page 65 1.Replacement and Adjustment Remove the rear right and left covers (Rear Right Cover,Rear Left Cover). Disconnect the connectors of the motor control board. Remove the screws to detach the motor control board.

  • Page 66: Tray 1 Pickup Belt Motor

    1.Replacement and Adjustment Tray 1 Pickup Belt Motor Remove the rear right and left covers (Rear Right Cover,Rear Left Cover). Remove the tray 1 grip motor bracket [A]. The number of the socket pins of the tray 1 pickup belt motor and these of the tray 1 grip motor is the same.
  • Page 67 1.Replacement and Adjustment Remove the tray 1 pickup belt motor [A]. Do not remove the damper [A] between the motor and the bracket. This damper is factory installed and cannot be adjusted outside the factory.
  • Page 68 1.Replacement and Adjustment Re-installation Make sure that the motor is correctly placed on the timing belt [A]. Loosen the screw [A] slightly to let the tensioner move, and then rotate the coupling shaft [B] two or three cycles. Tighten the screw [A].

  • Page 69: Tray 1 Grip Motor

    1.Replacement and Adjustment Tray 1 Grip Motor Remove the rear right and left covers (Rear Right Cover, Rear Left Cover). Remove the tray 1 grip motor bracket [A]. Remove the tray 1 grip motor [A]. Do not remove the damper [A] between the motor and the bracket. This damper is factory installed and cannot be adjusted outside the factory.

  • Page 70: Tray 2 Pickup Belt Motor

    1.Replacement and Adjustment Re-installation When installing the grip motor, make sure that the motor is correctly placed on the timing belt [A]. Tray 2 Pickup Belt Motor Remove the rear right and left covers. (Rear Right Cover, Rear Left Cover) Remove the tray 2 grip motor bracket [A].

  • Page 71: Tray 2 Grip Motor

    1.Replacement and Adjustment Remove the tray 2 pickup belt motor [A].  The procedure for removing and installing the tray 2 pickup belt motor is the same as for the tray 1 pickup belt motor. Tray 2 Grip Motor Remove the rear right and left covers. (Rear Right Cover, Rear Left...

  • Page 72: Suction Fan 1, 2 (Tray 1, 2)

    1.Replacement and Adjustment Remove the tray 2 grip motor [A].  The procedure for removing and installing the tray 2 grip motor is the same as for the tray 1 grip motor. Suction Fan 1, 2 (Tray 1, 2)  Suction fans 1, 2 can be removed using the same procedure for each tray.

  • Page 73: Lcit Lift Motor (Tray 1, 2)

    1.Replacement and Adjustment Remove the upper suction fan duct [A] ( Remove suction fan 1 [A] ( x2) Separate suction fan 2 [A], the suction fan duct [B] and the bracket [C]. LCIT Lift Motor (Tray 1, 2)  The LCIT lift motor can be removed using the same procedure for each tray. The following is the procedure for replacing the motor in tray 1.

  • Page 74: Bypass Transport Motor 2

    1.Replacement and Adjustment Remove the lift motor bracket [A] ( Remove the lift motor [A] ( Bypass Transport Motor 2  Bypass transport motor 2 is installed when the optional bypass unit is installed. Remove the rear right and left covers (Rear Right Cover, Rear Left...
  • Page 75 1.Replacement and Adjustment Remove bypass transport motor 2 [A] ( Re-installation When attaching the bracket to the motor, position the bracket so that the opening in the bracket [A] faces the label [B]. When attaching the motor bracket, turn the roller [A] to make sure that the timing belt [B] is correctly installed.

  • Page 76: Transport Motor Cooling Fan

    1.Replacement and Adjustment Transport Motor Cooling Fan Remove the rear right and left covers (Rear Right Cover, Rear Left Cover). Remove the transport motor cooling fan [A] with the bracket ( x2, x2, x1). Remove the transport motor cooling fan [A] ( Re-installation Install the transport motor cooling fan so that its label faces as shown below.
  • Page 77 1.Replacement and Adjustment...

  • Page 78: Vertical Feed Unit

    1.Replacement and Adjustment Vertical Feed Unit  When the LCIT is not docked to the main unit, do not pull out all the trays in the LCIT, because it could fall over. Vertical Feed Unit Remove the upper inner cover (Upper Inner Cover) Remove the lower inner cover...
  • Page 79 1.Replacement and Adjustment Remove the six screws that secure the vertical feed unit [B] to the vacuum feed LCIT ( x6). 10. If linked to the vacuum feed LCIT, remove the horizontal feed unit ( x4). 11. If linked to the vacuum feed LCIT, remove the paper jam processing lever [A] ( x2).

  • Page 80: Tray 1 Vertical Transport Motor 1

    1.Replacement and Adjustment 12. Use both hands to support the vertical feed unit, raise it slightly and pull it towards you. 13. Place the vertical feed unit on the PSU box [A] and pull it out gently. Re-installation When installing the vertical feed unit, place the notches [B] on the right side of the frame of the vertical feed unit on the two shoulder screws [A] on the left side of the LCIT.

  • Page 81: Tray 1 Vertical Transport Motor 2

    1.Replacement and Adjustment Remove the tray 1 vertical transport motor 1 bracket [A] ( Remove tray 1 vertical transport motor 1 [A] (  When installing the motor, refer to re-installation for bypass transport motor 2 (Bypass Transport Motor Tray 1 Vertical Transport Motor 2 Remove the rear right and left covers (Rear Right Cover,...

  • Page 82: Tray 1 Transport Sensor

    1.Replacement and Adjustment Remove tray 1 vertical transport motor 2 [A] (  When installing the motor, refer to re-installation for bypass transport motor 2 (Bypass Transport Motor Tray 1 Transport Sensor Remove the vertical feed unit (Vertical Feed Unit) Remove the shoulder screw [A] Remove the right cover [A] from the vertical feed unit ( x5).

  • Page 83: Tray 2 Vertical Transport Motor 1

    1.Replacement and Adjustment Remove the tray 1 transport sensor bracket [A] ( Remove the tray 1 transport sensor [A] ( x1, Tray 2 Vertical Transport Motor 1 Remove the rear right and left covers (Rear Right Cover, Rear Left Cover). Remove the tray 2 vertical transport motor 1 bracket [A] (...

  • Page 84: Tray 2 Vertical Transport Motor 2

    1.Replacement and Adjustment Remove tray 2 vertical transport motor 1 [A] (  When installing the motor, refer to re-installation for bypass transport motor 2 (Bypass Transport Motor Tray 2 Vertical Transport Motor 2 Remove the rear right and left covers (Rear Right Cover, Rear Left...

  • Page 85: Tray 2 Vertical Transport Sensor

    1.Replacement and Adjustment screw holes [B]. When attaching the motor bracket, turn the roller [A] to make sure that the timing belt [B] is correctly installed. Tray 2 Vertical Transport Sensor Remove the vertical feed unit (Vertical Feed Unit) Remove the right cover [A] from the vertical feed unit ( x5).

  • Page 86: Tray 2 Transport Sensor

    1.Replacement and Adjustment Remove the tray 2 vertical transport sensor bracket [A] ( Remove the tray 2 vertical transport sensor [A] ( x1, Tray 2 Transport Sensor Remove the vertical feed unit (Vertical Feed Unit) Remove the lower cover from the vertical transport unit [A] ( x4).

  • Page 87: Vertical Transport Exit Motor

    1.Replacement and Adjustment Remove the bracket [A] ( Remove the tray 2 transport sensor [A] ( x1, Vertical Transport Exit Motor Remove the rear right and left covers (Rear Right Cover, Rear Left Cover). Remove the vertical transport exit motor bracket [A] ( Remove the vertical transport exit motor [A] ( ...

  • Page 88: Bypass Transport Sensor 2

    1.Replacement and Adjustment Re-installation When attaching the bracket to the motor, install it so that the connector openings [A] face the two screw holes [B]. When attaching the motor bracket, turn the roller [A] to make sure that the timing belt [B] is correctly installed.

  • Page 89: Lcit Exit Motor

    1.Replacement and Adjustment Remove the bypass transport sensor 2 bracket [A] ( Remove bypass transport sensor 2 [A] ( x1, LCIT Exit Motor Remove the rear right and left covers (Rear Right Cover, Rear Left Cover). Remove the LCIT exit motor bracket [A] ( Remove the LCIT exit motor [A] ( ...
  • Page 90 1.Replacement and Adjustment Remove the LCIT exit roller contact motor bracket [A] ( Remove the LCIT exit roller contact motor [A] ( Re-installation When attaching the bracket to the motor, position the bracket so that the opening in the bracket [A] faces the label [B].

  • Page 91: Lcit Exit Sensor

    1.Replacement and Adjustment LCIT Exit Sensor Remove the bracket [A] ( x1, x1) Remove the LCIT exit sensor [A] ( LCIT Exit Roller Contact Sensor Remove the stay [A] from the vertical feed unit ( x2). Remove the bracket [A] ( ...

  • Page 92: Vertical Transport Unit Cooling Fan

    1.Replacement and Adjustment Remove the LCIT exit roller contact sensor [A] ( x1, x1) Vertical Transport Unit Cooling Fan Remove the rear right and rear left covers (Rear Right Cover, Rear Left Cover). Remove the vertical transport unit cooling fan [A] with the bracket ( x2, x1, x1).

  • Page 93: Vertical Transport Entrance Contact Motor

    1.Replacement and Adjustment Remove the vertical transport unit cooling fan [A] ( Vertical Transport Unit Cooling Fan Re-installation Install the cooling fan so that its label faces up Vertical Transport Entrance Contact Motor Remove the vertical feed unit (Vertical Feed Unit) Remove the shoulder screw [A] on the right side of the vertical feed unit.
  • Page 94 1.Replacement and Adjustment Remove the right cover [A] from the vertical feed unit ( x5). Remove the vertical transport entrance contact unit [A]. Release the clamps and connectors, and remove the motor cover [A].

  • Page 95: Tray 2 Vertical Transport Exit Contact Motor

    1.Replacement and Adjustment Remove the vertical transport entrance contact motor [A]. Tray 2 Vertical Transport Exit Contact Motor The position of the contact motors on the left side of the vertical transport unit is shown below. [A]: Tray 1 Vertical Transport Contact Motor...
  • Page 96 1.Replacement and Adjustment [B]: Tray 1 Vertical Transport Exit Contact Motor [C]: Tray 2 Vertical Transport Exit Contact Motor Remove the vertical feed unit (Vertical Feed Unit) Release the clamps and connector, and remove the motor cover [A]. Remove the spring and the motor bracket [A].

  • Page 97: Tray 1 Vertical Transport Exit Contact Motor

    1.Replacement and Adjustment Remove the tray 2 vertical transport exit contact motor [A]. Tray 1 Vertical Transport Exit Contact Motor The position of the contact motors on the left side of the vertical transport unit is shown below. [A]: Tray 1 Vertical Transport Contact Motor [B]: Tray 1 Vertical Transport Exit Contact Motor...
  • Page 98 1.Replacement and Adjustment [C]: Tray 2 Vertical Transport Exit Contact Motor Remove the vertical feed unit (Vertical Feed Unit) Release the clamps and connector, and remove the motor cover [A]. Remove the tray 1 vertical transport exit roller contact motor [A].

  • Page 99: Tray 1 Vertical Transport Contact Motor

    1.Replacement and Adjustment Tray 1 Vertical Transport Contact Motor The position of the contact motors on the left side of the vertical transport unit is shown below. [A]: Tray 1 Vertical Transport Contact Motor [B]: Tray 1 Vertical Transport Exit Contact Motor [C]: Tray 2 Vertical Transport Exit Contact Motor Remove the vertical feed unit (Vertical Feed...
  • Page 100 1.Replacement and Adjustment Release the clamps and connector, and remove the motor cover [A]. Remove the tray 1 vertical transport roller contact motor [A].

  • Page 101: Vertical Transport Entrance Contact Sensor / Vertical Transport Entrance Sensor

    1.Replacement and Adjustment Vertical Transport Entrance Contact Sensor / Vertical Transport Entrance Sensor Remove the vertical feed unit (Vertical Feed Unit) Remove the shoulder screw [A] on the right side of the vertical feed unit. Remove the right cover [A] from the vertical feed unit ( x5).
  • Page 102 1.Replacement and Adjustment Remove the spring and the sensor bracket [A]. Turn over the sensor bracket, release the edge saddle, and disconnect the connectors of the vertical transport entrance contact sensor [A] and vertical transport entrance sensor [B]. Remove the vertical transport entrance contact sensor [A] and vertical transport entrance sensor...

  • Page 103: Tray 2 Vertical Transport Exit Contact Sensor

    1.Replacement and Adjustment [B] from the sensor bracket. Tray 2 Vertical Transport Exit Contact Sensor The position of the contact sensors on the left side of the vertical transport unit is shown below. [A]: Tray 1 Vertical Transport Contact Sensor [B]: Tray 1 Vertical Transport Exit Contact Sensor [C]: Tray 2 Vertical Transport Exit Contact Sensor...
  • Page 104 1.Replacement and Adjustment Remove the vertical feed unit (Vertical Feed Unit) Remove the spring and the sensor bracket [A]. Turn over the sensor bracket, release the edge saddle, and disconnect the connector.

  • Page 105: Tray 1 Vertical Transport Exit Contact Sensor

    1.Replacement and Adjustment Remove the tray 2 vertical transport exit contact sensor from the sensor bracket. Tray 1 Vertical Transport Exit Contact Sensor The position of the contact sensors on the left side of the vertical transport unit is shown below. [A]: Tray 1 Vertical Transport Contact Sensor [B]: Tray 1 Vertical Transport Exit Contact Sensor [C]: Tray 2 Vertical Transport Exit Contact Sensor...
  • Page 106 1.Replacement and Adjustment Remove the vertical feed unit (Vertical Feed Unit) Remove the spring and the sensor bracket [A]. Turn over the sensor bracket, release the edge saddle, and disconnect the connector of the sensor.

  • Page 107: Tray 1 Vertical Transport Contact Sensor

    1.Replacement and Adjustment Remove the tray 1 vertical transport exit contact sensor from the sensor bracket. Tray 1 Vertical Transport Contact Sensor The position of the contact sensors on the left side of the vertical transport unit is shown below. [A]: Tray 1 Vertical Transport Contact Sensor [B]: Tray 1 Vertical Transport Exit Contact Sensor [C]: Tray 2 Vertical Transport Exit Contact Sensor...
  • Page 108 1.Replacement and Adjustment Remove the spring and the sensor bracket [A]. Turn over the sensor bracket, release the edge saddle, and disconnect the connector of the sensor.

  • Page 109: Jam Removal Led

    1.Replacement and Adjustment Remove the tray 1 vertical transport contact sensor from the sensor bracket. Jam Removal LED Remove the upper inner cover. (Upper Inner Cover) The position of the jam removal LEDs [A]: Tray 1 Vertical Transport Lever LED [B]: LCIT Exit Knob LED [C]: Horizontal Transport Lever LED [D]: Tray 2 Vertical Transport Lever LED...
  • Page 110 1.Replacement and Adjustment Disconnect the connector of the jam removal LED [A].
  • Page 111 1.Replacement and Adjustment Remove the jam removal LED. The same procedure is applicable to all the jam LEDs . Replace the other jam LEDs in the same way.

  • Page 112: Psu Box

    1.Replacement and Adjustment PSU Box PSU box Remove the rear right and left covers (Rear Right Cover, Rear Left Cover). Disconnect the connectors [A] and open the clamps. Pull out the PSU box [A].

  • Page 113: Psu1, 2, 3 / Ac Drive Board

    1.Replacement and Adjustment PSU1, 2, 3 / AC Drive Board The PSU has residual charge even some time after the power turns off. NEVER touch the areas outlined in red in the photo below, to prevent electric shock caused by residual charge. After the removal, never place the board on an electrically-conductive surface, such as metal.
  • Page 114 1.Replacement and Adjustment open the clamps to release the harness. Remove the screws on the top and side of the PSU left cover [A]. Lay down the PSU box [A] to remove the screws on the lower side.
  • Page 115 1.Replacement and Adjustment Open the clamp [A] to release the harness, and then remove the PSU left cover. PSU1, 2, 3 / AC Drive Board Location [A]: PSU 1 [B]: PSU 2 [C]: PSU 3 (Rear) [D]: AC Drive Board (Front) To replace PSU 2 or 3, you need to remove the PSU(s) to the right of the one to replace.
  • Page 116 1.Replacement and Adjustment corner of the bracket to detach PSU 1 with its bracket. Detach the board from the bracket. Pull out the connector and remove the screws on PSU 2 [A], and then open the clamp at the rear corner of the bracket to detach PSU 2 with its bracket.
  • Page 117 1.Replacement and Adjustment 10. Detach the board from the bracket. 11. Pull out the connectors and then remove the screws on PSU 3 [A], to detach PSU 3. 12. Remove the AC drive board.
  • Page 118 1.Replacement and Adjustment Replaceable fuses on PSU 1, 2, and 3 Fuse FU3: 10A, 250V FU4: 10A, 250V FU5: 10A, 250V...

  • Page 119: Psu Cooling Fan 1, 2

    1.Replacement and Adjustment Replaceable fuses on the AC drive board Fuse FU101: 10A, 250V FU102: 10A, 250V FU103: 10A, 250V PSU Cooling Fan 1, 2 Remove the PSU box (PSU box) Remove PSU cooling fan 1 [A] and PSU cooling fan 2 [B].

  • Page 120: Interlock Switch

    1.Replacement and Adjustment Interlock Switch Open the front door. Remove the lower inner cover (Lower Inner Cover) Remove the bracket [A] ( Remove the interlock switch [A] ( x1,...

  • Page 121: Detailed Descriptions

    2.Detailed Descriptions 2. Detailed Descriptions Overview Specifications Item Specifications Configuration Console, attached to the right side of the main machine Paper weight Tray 1: 40.0 to 470.0g/m Tray 2: 40.0 to 470.0g/m Paper size 13 × 19.2" SEF, 13 × 19"SEF, 12.6 × 19.2"SEF, 12.6 × 18.5" ,13 × 18" SEF, SRA3 SEF, 12 ×...
  • Page 122 2.Detailed Descriptions Item Description Detection detected and displayed on the operation panel (in four stages). Paper end detection Two photosensors mounted in the paper feed belt unit detect when paper has run out Anti-condensation One anti-condensation heater as standard equipment (100V 18W) Heater Mechanical Component Layout Front...
  • Page 123 2.Detailed Descriptions Motor Layout Name Name Bypass Transport Motor * Tray 2 Vertical Transport Motor 1 Tray 1 Vertical Transport Motor 1 Vertical Transport Entrance Contact Motor Tray 1 Grip Motor Tray 2 Vertical Transport Motor 2 Tray 1 Pickup belt Motor Vertical Transport Exit Motor Tray 1 LCIT Lift Motor Tray 2 Vertical Transport Exit Contact Motor...
  • Page 124 2.Detailed Descriptions Electrical Components Paper Tray Name Name Paper Size Sensor 1 Separation Fan Paper Size Sensor 2 Return Solenoid Paper Size Sensor 3 Float Fan Paper Size Sensor 4 Feed Sensor LCIT Paper Length Sensor 2 Paper Upper Limit Sensor 2 LCIT Paper Length Sensor 1 Paper Upper Limit Sensor 1 Side Fan (Front)
  • Page 125 2.Detailed Descriptions Feed Transport Name Name Suction Fan Shutter Solenoid Paper End Sensor 2 Paper End Sensor 1 Paper Feed...
  • Page 126 2.Detailed Descriptions Name Name Pickup Belt Motor Suction Fan 2 Grip Motor LCIT Lift Motor Suction Fan 1 Transport Motor Cooling Fan Tray Upper Limit Sensor Paper Transport Name Name LCIT Exit Sensor Vertical Transport Unit Cooling Fan LCIT Exit Roller Contact Sensor Tray 2 Vertical Transport Motor 1 Tray 1 Vertical Transport Contact Vertical Transport Entrance Contact Motor...
  • Page 127 2.Detailed Descriptions Name Name LCIT Exit Motor Horizontal Transport Lever LED Tray 2 Vertical Transport Sensor Tray 2 Vertical Transport Exit LCIT Exit Knob LED LCIT Exit Roller Contact Motor Contact Motor Cooling Fan Tray 2 Vertical Transport Motor 2 Tray 1 Vertical Transport Lever LEDV This component is provided with the Multi Bypass Tray Connection Kit.
  • Page 128 2.Detailed Descriptions Horizontal Transport Unit This unit is provided with the bridge unit. When attaching the bridge unit BU5010 to this machine, this component will be installed. Name Name Horizontal Transport Exit Sensor Horizontal Transport Entrance Motor Horizontal Transport Middle Sensor Cooling Fan Horizontal Transport Exit Motor PCB Motor Control Board...
  • Page 129 2.Detailed Descriptions Drive Layout Name Name Tray 1 Vertical Transport Motor 2 Tray 2 Vertical Transport Motor 1 Bypass Transport Motor * Vertical Transport Entrance Contact Motor Tray 1 Vertical Transport Motor 1 Tray 2 Vertical Transport Motor 2 Tray 1 Grip Motor Tray 2 Vertical Transport Exit Contact Motor Tray 1 Pickup Belt Motor Tray 1 Vertical Transport Exit Contact Motor...
  • Page 130 2.Detailed Descriptions *2 These motors are provided with the bridge unit. When attaching the bridge unit BU5010 to this machine, they will be installed. Paper Paths Name Name Bridge A3 LCIT Transport Tray 1 Feed Tray Transport Bypass Tray Transport Tray 2 Feed Tray Transport...
  • Page 131 2.Detailed Descriptions Sensor Layout Name Name Tray 1 Paper Feed Sensor Tray 2 Transport Sensor Tray 1 Paper Lower Limit Sensor Vertical Transport Entrance Sensor Tray 1 Paper Height Middle Sensor Vertical Transport Entrance Contact Sensor Tray 1 Paper End Sensor 2 Tray 2 Vertical Transport Exit Contact Sensor Tray 1 Paper End Sensor 1 Tray 2 Vertical Transport Exit Sensor...
  • Page 132 2.Detailed Descriptions Name Name Tray 2 Paper Height Middle Sensor Tray 1 Transport Sensor Tray 2 Paper Feed Sensor Bypass Vertical Transport Sensor These sensors are provided with the bridge unit. When attaching the bridge unit BU5010 to this machine, they will be installed.

  • Page 133: Details

    2.Detailed Descriptions Details Air Paper Feed Mechanism The air paper feed mechanism uses the air produced by the seven fans (float fan / separation fan / side fan (front/rear) / return fan / suction fan 1, 2) to handle and lift up and separate paper during the process of feeding paper.
  • Page 134 2.Detailed Descriptions transport roller [E] by the paper feed belt [D], and then fed to the vertical transport unit. Air blown from the separation fan and float fan is switched on/off by the shutter [F]. The air blown from the side air nozzles assist float and suction of the next sheet of paper. Also, it prevents double feed.
  • Page 135 2.Detailed Descriptions The three feed belts are installed at the same level. This improves the suction power and the feed quality for long paper. Fan Shutter Mechanism There is no shutters for the side fan, so air from the side fan (side air) always blows through while paper is transported.
  • Page 136 2.Detailed Descriptions *Air Shutter Name Shutter State 1: Float/separation Air Float/separation Fan Shutter Open 2: Side Air None Open 3: Return Air Return Fan Shutter Closed 4: Suction Air Suction Fan Shutter Open *The numbers in this column refer to the numbers in the diagram above. Feed starts After feed starts, the float/separation fan shutter and side fan shutter are closed, and the return fan shutter is open.
  • Page 137 2.Detailed Descriptions When the feed sensor turns on, the count starts to determine when the trailing edge passes the float/separation fan shutter opening position [C]. *Air Shutter Name Shutter State 1: Float/separation Air Float/separation Fan Shutter Closed 2: Side Air None Open 3: Return Air...
  • Page 138 2.Detailed Descriptions *The numbers in this column refer to the numbers in the diagram above. Arrives at the suction fan shutter opening position When the trailing edge of the paper arrives at the suction fan shutter opening position [A], the suction fan shutter opens. The feed belt [B] is stopped.
  • Page 139 2.Detailed Descriptions Name Name Paper Size Sensor 1 (for detecting width) Paper Size Sensor 4 (for detecting width) Paper Size Sensor 2 (for detecting width) LCIT Paper Length Sensor 1 Paper Size Sensor 3 (for detecting width) LCIT Paper Length Sensor 2 Relationship between Sensor State &...
  • Page 140 2.Detailed Descriptions Paper size Paper Width Sensor LCIT Paper Length Sensor Detection Method Half Letter N.C. N.C. Half Letter N.C. Postcard N.C. 1 means sensor shielded, 0 means sensor transmitted and N.C means No Check (regardless of 1 or 0) : Can detect paper size automatically via the width and length detection sensors.
  • Page 141 2.Detailed Descriptions Remaining Paper Detection The paper remaining is detected by counting pulses of the LCIT lift motor [A], and is shown in a four- stage display on the operation panel. When the bottom plate is lower than the paper height middle sensor [B], the remaining indicator is affected by the pulse count that starts when the plate passes the lower limit sensor [C].
  • Page 142 2.Detailed Descriptions Relationship between Sensor State and Paper Remaining  When the upper limit is detected and the lower limit sensor detects, the output pulses of the LCIT lift motor are not counted and the remaining amount is determined as 100 %. ...
  • Page 143 2.Detailed Descriptions Amount of Paper LCIT Lift Motor Displays Paper Stack Pulse Count Lower Paper Paper Amount on the Remaining Height Limit Height operation Lower- Middle- [mm] Sensor Middle Sensor Paper panel limit- passing Sensor passing to paper middle- entering 247.0 Detected 2470...
  • Page 144 2.Detailed Descriptions Amount of Paper LCIT Lift Motor Displays Paper Stack Pulse Count Lower Paper Paper Amount on the Remaining Height Limit Height operation Lower- Middle- [mm] Sensor Middle Sensor Paper panel limit- passing Sensor passing to paper middle- entering 97.6 1739 detected...
  • Page 145 2.Detailed Descriptions Exit Roller Contact Mechanism This LCIT unit has a new roller contact mechanism (pair of four rollers contacts/separates) to release rollers that grip the trailing edge of paper when the SWIFT unit corrects the position of the paper in the main machine (Pro C9200/C9210 models only).
  • Page 146 2.Detailed Descriptions The contact operation of the rollers is the same way of the LCIT exit roller contact mechanism that is previously employed. As an example, the contact mechanism of the LCIT exit rollers is explained as follows. When the LCIT exit roller contact motor [A] is ON, it turns the cam [C] on the driveshaft via the belt [B]. The roller contact arm [D] moves up/down in conjunction with the cam, and this mechanism separates the slave exit roller [E] from the drive exit roller [F].
  • Page 147 2.Detailed Descriptions Jam LEDs The vertical transport has jam LEDs to indicate where jams occur, which prevents jammed paper from being torn when you handle it.
  • Page 148 2.Detailed Descriptions Jam LED Layout Name Name Tray 1 Vertical Transport Lever LED Horizontal Transport Lever LED LCIT Exit Knob LED Tray 2 Vertical Transport Lever LED Jam Sensors and Jam LEDs  When a jam (including a jam detected during initialization) occurs, a jam sensor detects it, and then the corresponding LED blinks.
  • Page 149 2.Detailed Descriptions Jam Sensor Jam LED Transport 1 Sensor Feed 2 Sensor Vertical Transport 2 LED Transport 2 Sensor Bypass Vertical Transport Sensor Vertical Transport 1 Sensor Vertical Transport 1 Exit Sensor Vertical Transport 2 Exit Sensor LCIT Exit Sensor LCIT Exit LED Horizontal Transport Entrance Sensor Horizontal Transport Middle Sensor...
