Operating Instructions
Troubleshooting: TCRU/ORU
For safe and correct use, be sure to read Safety Information before using
the machine.

Advertisement

Table of Contents
loading

Related Manuals for Ricoh TCRU/ORU

Summary of Contents for Ricoh TCRU/ORU

  • Page 1 Operating Instructions Troubleshooting: TCRU/ORU For safe and correct use, be sure to read Safety Information before using the machine.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS Introduction................................. 5 How to Read This Manual..........................6 Symbols................................6 Disclaimer................................6 Notes................................6 Notes for TCRU/ORU Users......................... 7 1. Before You Begin About This Manual............................. 9 Names of Components............................10 About the Display for Options.........................11 Before You Change a Setting..........................12 About Printing Surfaces............................13...
  • Page 4 Vertical White Streaks (1)........................... 45 Bands.................................47 Banding: General............................47 Banding: 63 mm (2.4 inches) Intervals...................... 49 Banding: 189 mm (7.5 inches) Intervals....................51 Banding: Horizontal White Bands (S mode)..................... 51 6. Image Quality Problem: Spots Spots..................................53 Black (color) Spots (1)..........................53 Medaka (White Spots)..........................56 7.
  • Page 5 If (J129) Appears............................90 Troubleshooting Image Quality Problems......................91 Paper Skew..............................91 Wrong Detection of Skew...........................91 Double Feeding............................92 Wrong Detection of Double Feeding......................93 Paper Misfeeding............................95 Paper Feed Problems Affecting Image Quality....................98 The Image Is Positioned Incorrectly......................98 Image Scaling Error on the Side 1 of Paper....................98 Image Scaling Error on the Side 2 of Paper....................99 Scratches, Streaks, or Vertical Creases Appear on the Image..............99 Cleaning the Paper Feed Path........................
  • Page 6 Folded Sheets Are Not Stacked Properly....................146 Ring Binding..............................148 SC756-48 Appears..........................148 Buffer Pass Unit...............................149 The Fan Is Noisy............................149 High Capacity Stacker..........................150 Delivered Sheets Are Severely Curled....................150 Delivered Sheets Are Not Aligned......................152 The Machine Wrongly Detects That the Tray Is Full................154 The Paper Press Leaves an Impression on the Paper................

  • Page 7: Introduction

    Introduction This manual contains detailed instructions and notes on the operation and use of this machine. For your safety and benefit, read this manual carefully before using the machine. Keep this manual in a handy place for quick reference.

  • Page 8: How To Read This Manual

    How to Read This Manual Symbols This manual uses the following symbols: Indicates points to pay attention to when using the machine, and explanations of likely causes of paper misfeeds, damage to originals, or loss of data. Be sure to read these explanations. Indicates supplementary explanations of the machine’s functions, and instructions on resolving user errors.

  • Page 9: Notes For Tcru/Oru Users

    Click [Knowledge Base]. Select [Pro C7200/X, Pro C7210/X] or [Pro C7200S/SX, Pro C7210S/SX] from [Production Print (Cutsheet)]. Click [TCRU/ORU Special Menu] at the upper right corner of the screen. Enter the user name and password as follows: • User name Enter "c7200"...

  • Page 11: Before You Begin

    1. Before You Begin About This Manual If the machine will not print, does not print as expected, or exhibits any other problem, find the problem in this manual and troubleshoot accordingly. • Before you replace any unit: • To prevent electrical shock, turn off the color controller on the machine control panel, switch off the main power switch then the AC power switch, and then disconnect the machine from the power supply.

  • Page 12: Names Of Components

    1. Before You Begin Names of Components • Do not remove any covers or screws other than those explicitly mentioned in this manual. Inside this machine are high voltage components that are an electric shock hazard. Contact your sales or service representative if any of the machine's internal components require maintenance, adjustment, or repair.

  • Page 13: About The Display For Options

    About the Display for Options About the Display for Options This machine displays all of the adjustment items in the Adjustment Settings for Operators menu and advanced settings for custom paper regardless of whether or not the items are for options. Note that any modifications to the option settings do not take effect unless the applicable options are installed on this machine.

  • Page 14: Before You Change A Setting

    1. Before You Begin Before You Change a Setting • If the problem persists despite the setting being changed, restore the value you made a note of. • Operating the machine with the changed setting may cause problems such as reduced print quality.

  • Page 15: About Printing Surfaces

    About Printing Surfaces About Printing Surfaces Side 1 is the surface of the paper printed during one-sided printing, or the surface of the first print during duplex printing. Side 2 is the surface of the paper printed after side 1 has been printed during duplex printing. Single-sided printing: Printed side face down DFP406 A.
  • Page 16 1. Before You Begin Single-sided printing: Printed side face up DFP408 A. Side 1 B. Paper feed direction of Side 1 Duplex printing: Printed side face up DFP409 A. Side 1 B. Paper feed direction of Side 1 C. Side 2 D.

  • Page 17: Note About Vertical And Horizontal Directions

    Note about Vertical and Horizontal Directions Note about Vertical and Horizontal Directions In this manual, with regard to the paper feed direction, the vertical and horizontal directions are as shown below: DFP311 1. Paper feed direction 2. Horizontal 3. Vertical...
  • Page 18 1. Before You Begin...

  • Page 19: Troubleshooting Service Call Problems (Sc Codes)

    2. Troubleshooting Service Call Problems (SC Codes) What Are SC Codes? If an error occurs during operation, the machine displays an SC code ("SCnnn", where "nnn" is a three- digit number). The machine stops and cannot be used when an SC code is displayed. If an SC Code Appears: Write down the SC number.
  • Page 20 2. Troubleshooting Service Call Problems (SC Codes)

  • Page 21: Specifying And Checking Paper Settings

    3. Specifying and Checking Paper Settings Adjusting Paper Settings Paper Setting Flowchart Is there a problem you want to solve? Paper Delivery Image quality in fusing and image Image position/density transfer Specify the corresponding settings in Adjustment Settings for Operators and Custom Paper Settings.
  • Page 22 3. Specifying and Checking Paper Settings • To adjust the following settings, pre-register the type of paper in use as a custom paper. For details about registering custom papers, see "Specifying a Custom Paper", Preparation. Solution: Carry out the following sequence of procedures. Terminate the sequence as soon as the problem is resolved.
  • Page 23 Adjusting Paper Settings For details about "Print Speed setting", see "Details of Menu Items in Advanced Settings", Adjustment Item Menu Guide. In [Advanced Settings] for the custom paper you are using, select 1231: [Print Speed], and then decrease the value in the following corresponding settings by one step.

  • Page 24: Improving Transferability

    3. Specifying and Checking Paper Settings • Paper misfeeding • Blisters • Glossy lines • Change of gloss • If one or more of the above side effects occurs, adjust the fusing temperature and process speed by decreasing the fusing temperature and increasing the process speed. •...

  • Page 25: Troubleshooting Image Quality Problems

    4. Troubleshooting Image Quality Problems Image Index Large Classification: Lines/Streaks Line/streaks thinner than 1mm in width that appear either as a result of contamination or incomplete toner transfer. DFP701 Middle classification: Lines/Streaks A smudge or a white area inside an image, in a linear shape with 1mm or smaller width. DFP755...
  • Page 26 4. Troubleshooting Image Quality Problems Small classification Sample image Description Vertical black (color) streaks • See page 42 "Vertical Black Streaks". Black (color) streaks appearing in the paper feed direction. • See page 43 "Vertical Black (color) Streaks (2)". • See page 44 "Vertical Black (color) Streaks (3)".
  • Page 27 Image Index Small classification Sample image Description Vertical glossy streaks Glossy streaks appearing in the paper feed direction. DFP706 Horizontal white streaks Glossy streaks appearing in the direction perpendicular to the paper feed direction. DFP707 Image scratches Stains in the shape of vertical streaks which seem to result from being scratched by the guide plate ribs or other parts.
  • Page 28 4. Troubleshooting Image Quality Problems Small classification Sample image Description Jitter Blurred area visible as bands in the direction perpendicular to the paper feed direction DFP709 Banding Banding at regular intervals in the direction perpendicular to the paper feed direction. (Gear eyes: Color unevenness in the same interval as the pitch of the gear.) DFP710...

  • Page 29: Large Classification: Spots

    Image Index Small classification Sample image Description Vertical black (color) bands Black (color) bands appearing in the paper feed direction. DFP713 Horizontal black (color) bands Black (color) bands appearing in the direction perpendicular to the paper feed direction. DFP714 Fuzzy lines Blurred images in the shape of slightly winding bands in the paper feed direction.
  • Page 30 4. Troubleshooting Image Quality Problems White spots and Fireflies are considered different issues as the former does not consist a core in the center of the unprinted spot. DFP757 Middle classification: Spot White spots seen in solid image areas or black/color spots seen where there should be nothing printed. The description "white spots"...

  • Page 31: Large Classification: Full Page

    Image Index Small classification Sample image Description White spots White spots are visible inside solid image or halftone image area because of missing toner. DFP718 Spots with toner Toner aggregated inside the machine has been transferred to paper. DFP702 White spots with toner cores White spots with pieces of aggregated toner in the center visible in solid color area.
  • Page 32 4. Troubleshooting Image Quality Problems DFP758 Middle classification: Full page Image/text does not appear on the printout. DFP721 Small classification Sample image Description All black Copied paper is all black. DFP721 Blank No image is reproduced. DFP722...
  • Page 33 Image Index Middle classification: Unprinted Parts of the developed images and letters are not reproduced. DFP759 Small classification Sample image Description White zone Part of a solid image or halftone is missing. DFP723 Wormholes The outline of a letter (or a line) is reproduced but the inside of it is missing.
  • Page 34 4. Troubleshooting Image Quality Problems Small classification Sample image Description Negative residual image Previously copied image is reproduced with its black and white reversed on the same page or the next page. DFP726 Positive residual image Previously copied image is reproduced on the same page or the next page.
  • Page 35 Image Index DFP760 Small classification Sample image Description High density Image density higher than configured. DFP730 Low density Image density lower than configured. DFP731 Uneven density • See page 59 "Uneven Density: 189 mm (7.5 inches) Image density is uneven within the Pitch".
  • Page 36 4. Troubleshooting Image Quality Problems Small classification Sample image Description Unevenness in indefinite shape Image density unevenness in indefinite shapes. DFP733 Uneven glossiness • See page 69 "Uneven Gloss". The glossiness is uneven inside a • See page 75 "Uneven Gloss: dark solid image.
  • Page 37 Image Index Small classification Sample image Description Rough image • See page 64 "Mottling". Color is uneven and small white spots are visible inside a solid image. With color copiers, white spots may not appear when two colors are overlapped. DFP737 Earthworm shape White area in a shape similar to an...
  • Page 38 4. Troubleshooting Image Quality Problems DFP743 Small classification Sample image Description Background stains Granular stains are visible in unprinted areas of the paper. DFP741 Backside stains Granular stains are visible on the backside of the paper. DFP742 Toner scattered Toner scattered around a letter. DFP743...
  • Page 39 Image Index Small classification Sample image Description Edge stains • See page 76 "Stained Paper Edges". The side edges of paper are stained. • See page 76 "Stained Paper Edges (1)". • See page 77 "Stained Paper Edges (2)". DFP744 •...
  • Page 40 4. Troubleshooting Image Quality Problems Small classification Sample image Description Image expansion • See page 79 "Stretched Image". Image expanded abnormally in comparison with the original. DFP746 Image contraction • See page 80 "Shrunken Image". Image contracted abnormally in comparison with the original DFP747 Skew •...
  • Page 41 Image Index Small classification Sample image Description Claw marks Stains of toner that got on the paper when it came into contact with drum/ fuser pawls. DFP749 Middle classification: Shifted image Registration shift causes the images to appear longer or wider than the original. DFP751 Small classification Sample image...
  • Page 42 4. Troubleshooting Image Quality Problems Small classification Sample image Description Vertical color shift Color shifted in the paper feed direction where colors should be overlaid. DFP752 Horizontal color shift Color shifted in the direction perpendicular to the paper feed direction where colors should be overlaid.

  • Page 43: Image Quality Problem: Lines

    5. Image Quality Problem: Lines Streaks Horizontal White Streaks White streaks of 1 to 8 mm (0.04 to 0.3 inches) long and perpendicular to the paper feed direction appear. CEZ604 Cause: One of the charge rollers is stained. Solution: To identify the affected color, print three full-page, solid-fill A3 or DLT sheets for each of white and black, and three full-page, halftone A3 or DLT sheets for each of cyan, magenta, and yellow.

  • Page 44: Vertical Black Streaks

    5. Image Quality Problem: Lines • If white streaks appear at 189 or 40 mm (7.5 or 1.6 inches) intervals, carry out the procedure in see page 53 "Black (color) Spots (1)". • After performing the solution, it is recommended to perform the color calibration of the external controller.

  • Page 45: Vertical Black (Color) Streaks (2)

    Streaks Solution: In [Advanced Settings] for the custom paper you are using, select [Fuser] in 1341: [Motor Speed]. Check the present value. Is it higher than +2.5%? No further improvement is likely. Contact your service representative. Increase the value by 0.5 percentage points. Print the image.

  • Page 46: Vertical Black (Color) Streaks (3)

    5. Image Quality Problem: Lines Check whether the problem occurs at the front or back of the paper. <If the problem affects multiple colors at the front of the paper> If the problem persists even if you replace the ITB cleaning unit, contact your service representative.

  • Page 47: Vertical White Streaks (1)

    Streaks Vertical White Streaks (1) A white streak appears from the leading edge to trailing edge of the paper in parallel to the paper feed direction. bzs415 Cause: The photoconductor unit is stained. Solution: To identify the affected color, print three full-page, solid-fill A3 or DLT sheets for each of cyan, magenta, black, and green and three full-page, halftone A3 or DLT sheets for each of cyan, magenta, and yellow.
  • Page 48 5. Image Quality Problem: Lines • For details about replacing the photoconductor unit, see Replacement Guide.

  • Page 49: Bands

    Bands Bands Banding: General Density fluctuation occurs periodically in the vertical direction to the paper feed direction. CWH407 Cause: Density fluctuation occurs when the pitch phase between the charge roller, developing roller, paper transfer roller, and photoreceptor is different. Solution: The solution depends on the length of intervals whereby the density fluctuation occurs.
  • Page 50 5. Image Quality Problem: Lines Go to the next step. Print a full-page, half-tone A3 sheet for each of cyan, magenta, yellow, and black, and then measure by a ruler, etc., the intervals between the spots affected by density fluctuation. Perform the following solution.

  • Page 51: Banding: 63 Mm (2.4 Inches) Intervals

    Bands Banding: 63 mm (2.4 inches) Intervals Density fluctuation occurs at intervals of 63 mm (2.4 inches). 63 mm 63 mm 63 mm (2.4 in.) (2.4 in.) (2.4 in.) DFP352 Cause: Caused by difference in roller speed The speed of the paper transfer is higher than that of transfer timing roller. This may occur if: •...
  • Page 52 5. Image Quality Problem: Lines Solutions: (a) Caused by difference in roller speed In [Advanced Settings] for the custom paper you are using, select 1341: [Motor Speed], and then check the present value in [Paper Transfer Roller]. Is it lower than -0.5%? Contact your service representative.

  • Page 53: Banding: 189 Mm (7.5 Inches) Intervals

    Bands appears after performing the Banding 63 mm intervals solution, restore the original Paper Transfer Roller value. Banding: 189 mm (7.5 inches) Intervals Density fluctuation occurs at intervals of 189 mm (7.5 inches). 189 mm (7.5 in.) DFP395 Cause: This may occur if: •...
  • Page 54 5. Image Quality Problem: Lines DXT813 Cause: Transfer blur occurs due to speed fluctuation of the intermediate transfer belt. This may occur if S mode is used. • To adjust the following settings, pre-register the type of paper in use as a custom paper. For details about registering custom papers, see "Specifying a Custom Paper", Preparation.

  • Page 55: Image Quality Problem: Spots

    6. Image Quality Problem: Spots Spots Black (color) Spots (1) Colored spots appear at 189 mm or 40 mm (7.5 inches or 1.6 inches) intervals. 189 mm (7.5 in.) 40 mm (1.6 in.) CEZ539 Cause: (a) Colored spots appear at 189 mm (7.5 inches) intervals The drum is scratched or stained.
  • Page 56 6. Image Quality Problem: Spots Perform a test print. Determine the color in which color dots appear. No / Not Certain Do color dots appear at regular intervals? Contact your service representative. Approx. 40 mm How long is the regular interval at which the problem occurs? Approx.
  • Page 57 Spots (b) Colored spots appear at 40 mm (1.6 inches) intervals Does it occur at low temperature? Turn on the paper tray heater and ITB heater. Perform a test print. Detach the charge roller Has the problem been resolved? unit of the affected color and check the roller surface.

  • Page 58: Medaka (White Spots)

    6. Image Quality Problem: Spots • Do not use ethanol or any other organic solvent to clean the charge roller. Otherwise it may cause damage to the charge roller. CEZ522 • For details about replacing the charge unit, see Replacement Guide. •...
  • Page 59 Spots Solution: To identify the affected color, print three full-page, solid-fill A3 or DLT sheets for each of cyan, magenta, black, and green, and three full-page, halftone A3 or DLT sheets for each of cyan, magenta, and yellow. Because it is difficult to identify white spots on yellow, green is used instead of yellow. Detach the photoconductor unit of the affected color and check the drum surface.
  • Page 60 6. Image Quality Problem: Spots...

  • Page 61: Image Quality Problem: Full Page

    7. Image Quality Problem: Full Page Uneven Density Uneven Density: 189 mm (7.5 inches) Pitch Density fluctuation occurs at intervals of 189 mm (7.5 inches). 189 mm (7.5 in.) 189 mm (7.5 in.) CNT002 Cause: If the machine is left unattended for a long period in an environment where temperature and humidity are high, corona products on the photoconductor unit absorb moisture to prevent a buildup or removal of static electricity on the photoconductor unit.

  • Page 62: Uneven Density (Textured Paper)

    7. Image Quality Problem: Full Page • After performing the solution, it is recommended to perform the color calibration of the external controller. Uneven Density (Textured Paper) White spots on an embossed surface This is because the voltage of the applied paper transfer roller is too low. CXM001 Dense printing on an embossed surface This is because the voltage of the applied paper transfer roller is too high.
  • Page 63 Uneven Density • To adjust the following settings, pre-register the type of paper in use as a custom paper. For details about registering custom papers, see "Specifying a Custom Paper", Preparation. Solution: (a) Adjust the textured paper mode In [Advanced Settings] for the custom paper you are using, select 1218: [Paper Transfer Output: Textured Paper Mode], and then set [Setting] to [On].
  • Page 64 7. Image Quality Problem: Full Page (b) If white spots appear on an embossed surface In [Advanced Settings] for the custom paper you are using, select 1218: [Paper Transfer Output: Textured Paper Mode], and then increase the value in the following corresponding settings by one step.
  • Page 65 Uneven Density Print the image. Has the problem been resolved? Go to next step. Repeat Step 1 to 2. Do white spots appear? Contact your service representative. Finished! (d) Adjust the paper transfer setting In [Advanced Settings] for the custom paper you are using, select 1214: [Paper Transfer Output], and then adjust the value in the following corresponding settings.

  • Page 66: Mottling

    7. Image Quality Problem: Full Page Print the image. Has the problem been resolved? Finished! Contact your service representative. (f) Adjust the maximum image density In [Advanced Settings] for the custom paper you are using, select 1201: [Max Image Density], and then increase the value for the specified color. Print the image.
  • Page 67 Uneven Density Cause: This may occur if: • Using paper with a rough surface • Documents with a small image area are printed continuously. • Printing in a low humidity environment • Printing in a high humidity environment • To adjust the following settings, pre-register the type of paper in use as a custom paper. For details about registering custom papers, see "Specifying a Custom Paper", Preparation.
  • Page 68 7. Image Quality Problem: Full Page (c) Adjust the transfer settings What type of paper are you using? Textured paper Proceed to Step 6. Low resistance paper Use the paper sealed completely in the plastic bag to prevent it from absorbing moisture from the air.
  • Page 69 Uneven Density Print the image. Has the problem been resolved? Finished! Go to next step. Are you using paper between Paper Weight 4 – 8? Go to next step. Proceed to "(d) Execute developer refreshing". In [Advanced Settings] for the custom paper you are using, set 1218: [Paper Transfer Output: Textured Paper Mode] to [On].
  • Page 70 7. Image Quality Problem: Full Page [Side 1], [Side 2] • [FCS] [Side 1], [Side 2] • [S] [Side 1: Clear/Special], [Side 1: White], [Side 2: Clear/Special], [Side 2: White] Print the image. Has the problem been resolved? Finished! Go to next step. Select 1214: [Paper Transfer Output], and then adjust the value in the following corresponding settings by 1 step.

  • Page 71: Uneven Gloss

    Uneven Density Is it OK to change the paper type? Change the paper to paper that has a high degree of smoothness or has not been moisture conditioned. Proceed to "(e) Adjust maximum image density". Print the image. Has the problem been resolved? Finished! Proceed to "(e) Adjust maximum image density".
  • Page 72 7. Image Quality Problem: Full Page 278 mm (10.9 in.) 278 mm (10.9 in.) DXT815 Cause: This occurs if the toner wax remaining on the fusing belt is uneven. This may occur if: • Paper with a thickness equivalent to Paper Weight 7 or 8 is used, so that the required temperature is high •...
  • Page 73 Uneven Density (b) Adjust the print speed setting Decrease the line speed. This will decrease the throughput, but is it OK? Go to the next step. Proceed to "(e) Decrease the heat roller temperature". In [Advanced Settings] for the custom paper you are using, select 1231: [Print Speed], and then decrease the value in the following corresponding settings by one level.
  • Page 74 7. Image Quality Problem: Full Page [Heat Roller Temp: Clr/Sp], [Heat Roller Temp: White] • [BW/FC/FCS: Fuser Setting HQ] [Heat Roller Temp] • [FCS: Fuser Setting HQ] [Heat Roller Temp: Clr/Sp], [Heat Roller Temp: White] • [S: Fuser Setting HQ] [Heat Roller Temp: Clr/Sp], [Heat Roller Temp: White] Print 10 or more A3 sheets.
  • Page 75 Uneven Density [Corct Temp: Init Fd: Clr/Sp], [Corct Temp: Init Fd: White] • [S] [Corct Temp: Init Fd: Clr/Sp], [Corct Temp: Init Fd: White] • [BW/FC/FCS: Fuser Setting HQ] [Corct Temp: Initial Feed] • [FCS: Fuser Setting HQ] [Corct Temp: Init Fd: Clr/Sp], [Corct Temp: Init Fd: White] •...
  • Page 76 7. Image Quality Problem: Full Page (e) Decrease the heat roller temperature In [Advanced Settings] for the custom paper you are using, select 1232: [Fusing Temperature], and then decrease the value in the following corresponding settings by 5°C. • [BW/FC/FCS] [Heat Roller Temp] •...

  • Page 77: Uneven Gloss: Partly

    Uneven Density Uneven Gloss: Partly Uneven glossiness occurs partly. 251 mm (10 in.) 251 mm (10 in.) DFP421 Cause: The fusing belt is stained by the toner wax. Solution: In the [Machine: Maintenance] group on the [Adjustment Settings for Operators] menu, select 0508: [Manually Smooth Fusing Belt].

  • Page 78: Dirtied Printouts

    7. Image Quality Problem: Full Page Dirtied Printouts Stained Paper Edges Solution: If the paper edges are stained, carry out the procedure in page 76 "Stained Paper Edges (1)", page 77 "Stained Paper Edges (2)", page 77 "Stained Paper Edges (4)", or page 78 "Stained Paper Edges (5)".

  • Page 79: Stained Paper Edges (2)

    Dirtied Printouts Stained Paper Edges (2) CNT012 Cause: The antistatic brushes in the exit transport and invert transport of the drawer are stained or the anti-static brushes in Finisher SR5050/SR5060 are stained. Solution: For details about cleaning, see page 101 "Cleaning the Paper Feed Path". Stained Paper Edges (4) 14 mm 14 mm...

  • Page 80: Stained Paper Edges (5)

    7. Image Quality Problem: Full Page Stained Paper Edges (5) 13 mm 13 mm 67 mm (0.5 in.) (0.5 in.) (2.6 in.) DFP393 Cause: When a particularly dense image is printed, the paper feed rollers may become stained with toner and the paper edges may in turn be stained by the toner on the paper feed rollers.

  • Page 81: Disturbed Image

    Disturbed Image Disturbed Image Stretched Image The leading edge margin is too wide and the image has stretched lengthwise. Original Output Paper feed direction CEZ530 Cause: The paper feed speed of the transfer timing roller is too low. • To adjust the following settings, pre-register the type of paper in use as a custom paper. For details about registering custom papers, see "Specifying a Custom Paper", Preparation.

  • Page 82: Shrunken Image

    7. Image Quality Problem: Full Page Shrunken Image The leading edge margin is too narrow and the image has shrunk lengthwise. Original Output Paper feed direction CEZ528 The paper has creased and no print appears where the crease has occurred. Original Output Paper feed direction...

  • Page 83: Image Skew

    Disturbed Image Print the image. Has the problem been resolved? Finished! Keep decreasing the value by 0.1% until the problem is resolved. If the problem persists even though you have decreased the value by 1.0%, contact your service representative. Image Skew DFP437 For details, see page 91 "Paper Skew".
  • Page 84 7. Image Quality Problem: Full Page...

  • Page 85: Troubleshooting Paper Delivery Problems

    8. Troubleshooting Paper Delivery Problems Frequent Paper Misfeeds Depending on the cause of the problem, do one of the following: Have you ruffled the paper sufficiently? Double feeding may result if the paper is not ruffled properly. Remove the paper, ruffle it, and reload it. For details about ruffling the paper, see "Fanning the Paper", Preparation.
  • Page 86 8. Troubleshooting Paper Delivery Problems For details about how many sheets can be loaded in the paper trays, see "Recommended Paper Sizes and Types", Preparation. The edges of the sheets are rough. Turn the sheets the other way up or smooth the edges before loading. Sheets are curled or wavy.

  • Page 87: Messages Reporting Paper Misfeeds

    Messages Reporting Paper Misfeeds Messages Reporting Paper Misfeeds Paper misfeeds are reported by messages prefixed with problem codes. Resolve the problem according to the code. CWH406 If (J033/J034/J083) Appears Cause: If a solid fill image is printed, the paper may stick to the fusing belt when the paper is separated at the fusing nip exit.
  • Page 88 8. Troubleshooting Paper Delivery Problems In [Advanced Settings] for the custom paper you are using, select 1231: [Print Speed], and then decrease the value in the following corresponding settings by one level. If the present value is [High], select [Middle]. If it is [Middle], select [Low]. •...
  • Page 89 Messages Reporting Paper Misfeeds • [S: Fuser Setting HQ] [Heat Roller Temp: Clr/Sp], [Heat Roller Temp: White] Print 10 or more A4 sheets. Has the problem been resolved? Finished! Proceed to "(a) Adjust the print speed setting". (c) If [Print Speed] is set to [Low] In [Advanced Settings] for the custom paper you are using, select 1232: [Fusing Temperature], and then decrease the value in the following corresponding settings by 20°C.
  • Page 90 8. Troubleshooting Paper Delivery Problems • [FCS: Fuser Setting HQ] [Corct Temp: Init Fd: Clr/Sp], [Corct Temp: Init Fd: White] • [S: Fuser Setting HQ] [Corct Temp: Init Fd: Clr/Sp], [Corct Temp: Init Fd: White] Select 1232: [Fusing Temperature], and then set the value in the following corresponding settings to "5°C".

  • Page 91: If (J097) Appears

    Messages Reporting Paper Misfeeds • [FCS] [Heat Roller Temp: Clr/Sp], [Heat Roller Temp: White] • [S] [Heat Roller Temp: Clr/Sp], [Heat Roller Temp: White] • [BW/FC/FCS: Fuser Setting HQ] [Heat Roller Temp] • [FCS: Fuser Setting HQ] [Heat Roller Temp: Clr/Sp], [Heat Roller Temp: White] •...

  • Page 92: If (J099) Appears

    8. Troubleshooting Paper Delivery Problems If (J099) Appears Cause: This may occur if: • Double feeding has occurred. For details, see page 92 "Double Feeding". • Double feeding may be wrongly detected. For details, see page 93 "Wrong Detection of Double Feeding".

  • Page 93: Troubleshooting Image Quality Problems

    Troubleshooting Image Quality Problems Troubleshooting Image Quality Problems Paper Skew Depending on the cause of the problem, do one of the following: The side fences in the paper tray are too far apart. If the side fences are too far apart, the paper may be skewed. Adjust the side fences to match the paper width.

  • Page 94: Double Feeding

    8. Troubleshooting Paper Delivery Problems An envelope is used. If an envelope flap at the trailing edge is oblique, a skew may be wrongly detected when the envelope is transferred with its flap open. Disable skew detection function. <If custom paper is used> In [Advanced Settings] for the custom paper you are using, set 014: [Skew Detection] to [Off].

  • Page 95: Wrong Detection Of Double Feeding

    Troubleshooting Image Quality Problems The factory-set airflow of the wide LCT may not be strong enough to separate the sheets. Increase the airflow. <If custom paper is used> 1. In [Advanced Settings] for the custom paper you are using, set 108: [Wide LCT Fan Setting] to [On] 2.
  • Page 96 8. Troubleshooting Paper Delivery Problems Preprinted paper is being used The machine may wrongly detect double feeding when the sensor detects a printed part. Disable the double feeding detection function. <If custom paper is used> In [Advanced Settings] for the custom paper you are using, select 1331: [Jam Detection] and then set [Detect JAM099] of [JAM080/097/098/099] to [Off].

  • Page 97: Paper Misfeeding

    Troubleshooting Image Quality Problems <If custom paper is not used> In the [Machine: Paper Feed/ Output] group on the [Adjustment Settings for Operators] menu, set 0305: [Detect JAM099] to [Off]. Thin paper is being used When using paper of high transparency, the machine may wrongly detect double feeding. Disable the double feeding detection function.
  • Page 98 8. Troubleshooting Paper Delivery Problems Have you ruffled the paper sufficiently? Double feeding may result if the paper is not ruffled properly. Remove the paper, ruffle it, and reload it. For details about ruffling the paper, see "Fanning the Paper", Preparation. The side fences in the paper tray are too close together.
  • Page 99 Troubleshooting Image Quality Problems An envelope is used. Depending on the type of envelope, air trapped inside may be squeezed out when the paper feed roller picks up the envelope and cause slippage leading to a misfeed. • Have you flattened the envelope? Flatten the envelope and all its edges to eliminate air before loading.

  • Page 100: Paper Feed Problems Affecting Image Quality

    8. Troubleshooting Paper Delivery Problems Paper Feed Problems Affecting Image Quality The Image Is Positioned Incorrectly Original Output Paper feed direction CEZ523 Cause: Depending on the paper thickness, floppiness, edge roughness, and curl, the image may become mispositioned. Solution: See, page 163 "Adjusting the Image Position of the Either Side of the Paper". Image Scaling Error on the Side 1 of Paper Original Output...

  • Page 101: Image Scaling Error On The Side 2 Of Paper

    Paper Feed Problems Affecting Image Quality Solution: See, page 163 "Adjusting the Image Position of the Either Side of the Paper". Image Scaling Error on the Side 2 of Paper Original Output Side 1 Side 2 Paper feed direction CEZ525 Cause: An image scaling error on the side 2 of the paper may occur because the paper expands or contracts after the image on the side 1 of the paper has been fused.
  • Page 102 8. Troubleshooting Paper Delivery Problems 1. In [Advanced Settings] for the custom paper you are using, adjust the paper feed speed for delivery. Depending on the type of printing, specify one of the following: • For one-sided printing, reduce the value in [Paper Output] of 1341: [Motor Speed] by 0.1.

  • Page 103: Cleaning The Paper Feed Path

    Cleaning the Paper Feed Path Cleaning the Paper Feed Path Paper dust sticking to the paper transfer guide board, roller, paper feed roller, or sensor may cause white spots, paper jam, or double feeding. Clean the paper feed path from the paper tray to the paper exit in the drawer.

  • Page 104: Cleaning Paper Trays 1/2

    8. Troubleshooting Paper Delivery Problems CZC350 Sensor Remove dust with a blower brush. CZC347 Antistatic Brush Remove dust with a blower brush. CZC351 Cleaning Paper Trays 1/2 Remove the paper tray.

  • Page 105: Cleaning The Paper Feed Path For Paper Trays 1/2

    Cleaning the Paper Feed Path Clean the sensor. CZC316 • For details about detaching and reattaching the parts, see the Replacement Guide. Cleaning the Paper Feed Path for Paper Trays 1/2 Open the front covers. DFP001 Pull down the lever A1. DFP330...
  • Page 106 8. Troubleshooting Paper Delivery Problems Pull up the plate. DFP331 Clean the rollers, sensors, and guide boards. DFP332 Pull down the plate. Pull up the lever A1. DFP333...

  • Page 107: Cleaning The Paper Feed Path In The Drawer

    Cleaning the Paper Feed Path Close the front covers. DFP002 Cleaning the Paper Feed Path in the Drawer Left drawer unit Open the front covers. DFP001 Pull down the lever C1. DFP009...
  • Page 108 8. Troubleshooting Paper Delivery Problems Pull the drawer out completely until it stops. DFP010 Use a dry cloth to clean the transport belt unit. To clean the sensor, use a blower brush. Be careful to avoid the paper transport belt sensor when you do this. DFP104 Pull up and open the cover D2.
  • Page 109 Cleaning the Paper Feed Path Use a dry cloth to clean the stripper plate on the fusing belt. DFP300 Clean the sensors. DFP301 Close the cover D2. Pull up and open the cover D3. DXT816...
  • Page 110 8. Troubleshooting Paper Delivery Problems Turn the knob D7 and clean the rollers. DXT817 Clean the sensors. DXT818 Close the cover D3. Pull up and open the cover D4. DXT819...
  • Page 111 Cleaning the Paper Feed Path Turn the knob D7 while using a dry cloth on the invert exit rollers. DXT820 Turn the knob D1 while using a dry cloth on the invert exit rollers. DXT821 Clean the sensors. DXT822...
  • Page 112 8. Troubleshooting Paper Delivery Problems Close the cover D4. DXT823 Pull down and open the cover D5. DFP334 Turn the knob D1 and clean the roller. DFP335...
  • Page 113 Cleaning the Paper Feed Path Clean the roller. DXT824 Clean the sensors. DXT825 Pull up and close the cover D5. Use a hand vacuum cleaner to clean the anti-static brush near the exit rollers. DFP338...
  • Page 114 8. Troubleshooting Paper Delivery Problems Release and pull down duplex transport path plate (Z3). DFP339 Turn the knob Z1. DFP341 Clean the rollers (as you rotate the knob) and sensors. DFP340...
  • Page 115 Cleaning the Paper Feed Path Close the duplex transport path plate (Z3). DFP342 Remove the fusing unit from the machine. For details about removing the fusing unit, see Replacement Guide. Use a dry cloth to clean the entrance guide plate. CEZ194 Install the fusing unit.
  • Page 116 8. Troubleshooting Paper Delivery Problems Pull up the lever C1. DFP012 Close the front covers. Right drawer unit Open the front covers. DFP001 Pull down the lever B5. DFP005...
  • Page 117 Cleaning the Paper Feed Path Pull out the right drawer until it stops. DFP006 Remove the two black screws on the cover plate, and then remove the cover plate. DXT826 Remove a black screw on the dust catcher, and then remove the dust catcher. DXT827...
  • Page 118 8. Troubleshooting Paper Delivery Problems Use a clean dry cloth to remove any dust remaining in the dust catcher. CEZ199 Turn the knob while using a dry cloth on the transfer timing idle roller. DFP345 Reattach the dust catcher with the black screw. DXT828...
  • Page 119 Cleaning the Paper Feed Path Reattach the cover plate with the two black screws. DXT829 On the right side of the drawer, pull down the lever B1 to release the plates. CEZ263 Hold the dry cloth against the main relay drive rollers (1). CEZ265...
  • Page 120 8. Troubleshooting Paper Delivery Problems CEZ266 Clean the sensors. CEZ267 While turning the knob B3, use a dry cloth on the registration entrance idle rollers. CEZ270...
  • Page 121 Cleaning the Paper Feed Path On the inside of the right drawer, hold a dry cloth against the registration entrance drive rollers while turning the knob B3. CEZ272 Clean the sensors. CEZ271 Open the cover B7 to clean the rollers. CEZ275...
  • Page 122 8. Troubleshooting Paper Delivery Problems Hold a dry cloth between the plates and the rollers to clean the drive rollers as they rotate the knob B3. CEZ276 Clean the sensors. CEZ277 CEZ280...
  • Page 123 Cleaning the Paper Feed Path Remove the black screw on the double-feed sensor bracket and clean the sensors. CEZ284 Reattach the double-feed sensor with the black screw. CEZ285 Turn the knob B4 on the front while using a dry cloth on the registration timing idle rollers. CEZ286...
  • Page 124 8. Troubleshooting Paper Delivery Problems Pull up the lever to close the plates. CEZ264 Use the blower brush on the registration timing sensor. CEZ288 Use the dry cloth to clean the rollers. CEZ291...
  • Page 125 Cleaning the Paper Feed Path Turn the knob B6 while using a dry cloth on the transfer timing idle roller. CEZ299 CEZ300 Use the blower brush on the transfer timing sensor. CEZ301...
  • Page 126 8. Troubleshooting Paper Delivery Problems Lower the duplex transport path plate (Z4) on the front of the right drawer. CEZ302 Rotate the knob Z2. CEZ303 Clean the rollers (as you rotate the knob) and sensors. CEZ304...
  • Page 127 Cleaning the Paper Feed Path Close the duplex transport path plate (Z4). CEZ305 Push the right drawer into the main unit until it stops, and then pull up the lever B5. CEZ122 Close the front covers. Purged Paper Sensor Open the left front cover. If there is any paper in the purge tray, remove it.

  • Page 128: Cleaning The Paper Feed Path In The Wide Lct

    8. Troubleshooting Paper Delivery Problems Cleaning the Paper Feed Path in the Wide LCT Clean the side fences and front guide. CEZ502 Clean the paper feed rollers. Clean the guide board of the paper feed unit. CEZ503 Clean the guide board interior. CZC305 After cleaning, restore the machine so that it resumes operation.

  • Page 129: Cleaning The Paper Feed Path In The Multi Bypass Tray

    Cleaning the Paper Feed Path Cleaning the Paper Feed Path in the Multi Bypass Tray Clean the side fences and front guide. CEZ587 Clean the paper feed rollers. Clean the guide board. CEZ506 After cleaning, restore the machine so that it resumes operation. •...

  • Page 130: Cleaning The Paper Path In The Buffer Pass Unit

    8. Troubleshooting Paper Delivery Problems CEZ507 Clean the paper feed belt and paper feed rollers in the detached paper feed unit. CEZ508 After cleaning, restore the machine so that it resumes operation. Cleaning the Paper Path in the Buffer Pass Unit Clean the paper transport rollers and guide plates in the buffer pass unit.
  • Page 131 Cleaning the Paper Feed Path CNT017 Wipe the guide plates (especially the ridgelines of the bends and the cut-and-bent portions) with a cloth moistened with alcohol. CNT018 Close the guide plates and push the buffer pass unit back into the machine.
  • Page 132 8. Troubleshooting Paper Delivery Problems...

  • Page 133: Post-Processing Option Troubleshooting

    9. Post-Processing Option Troubleshooting Finisher Delivered Sheets Are Not Stacked Properly Solution: Depending on the cause of the problem, do one of the following: Coated paper is being used. In the [Finishing: Finisher] group on the [Adjustment Settings for Operators] menu, set 0617: [Adjust Output Fan Level] to [Increase Air Volume].

  • Page 134: Large Delivered Sheets Are Not Stacked Properly

    9. Post-Processing Option Troubleshooting In the [Machine: Paper Feed/ Output] group on the [Adjustment Settings for Operators] menu, set 0304: [Correct Output Paper Curl] to " Curl Correction Level". To control the level of decurling, select "Weak" if the present setting is "Off" or "Strong" if the present value is "Weak". Large Delivered Sheets Are Not Stacked Properly Cause: When using large-size or coated and paper-to-paper friction is very high, a sheet may push against...
  • Page 135 Finisher Paper exit Output tray Paper feed direction CEZ595 Paper deflection Because of high paper friction, the delivered sheet may arch up and become crimped. Paper exit Output tray Paper feed direction CEZ596 Solution: Depending on the cause of the problem, do one of the following: <Sheet bending>...

  • Page 136: Trailing Edge Of Stapled Sheets Close To The Paper Exit

    9. Post-Processing Option Troubleshooting Coated paper is being used. In the [Finishing: Finisher] group on the [Adjustment Settings for Operators] menu, set 0617: [Output Fan Level] to [Increase Air Volume]. Standard paper is being used. • In the [Finishing: Finisher] group on the [Adjustment Settings for Operators] menu, set 0615: [Output Trail Edge Press Setting] to [On].

  • Page 137: Sheets Cannot Be Stapled Properly

    Finisher Trailing edge too near exit Paper exit Output tray Paper feed direction CEZ593 Solution: Load the sheets the other way up. Print the image. Has the problem been resolved? Finished! Go to the next step. To follow the steps below, attach the decurler unit. In the [Machine: Paper Feed/ Output] group on the [Adjustment Settings for Operators] menu, set 0304: [Correct Output Paper Curl] to "...

  • Page 138: Misfeeding Of Sheets Other Than The Cover Has Occurred

    9. Post-Processing Option Troubleshooting • Coated or other paper producing higher paper-to-paper friction is used. • Thin or other limp paper is used. Solution: Reduce the number of sheets to be stapled. In the [Finishing: Finisher] group on the [Adjustment Settings for Operators] menu, select 0606: [Number of Sheet Align for Stapling], and reduce the number of sheets to be stapled.

  • Page 139: Paper Edges Are Stained

    Finisher Select [Magazine]. Press [OK]. Press [Edit / Color]. Press [Margin Adj.]. Specify left margin on the front side to 5 mm and right margin on the back side to 5 mm. Paper Edges Are Stained Cause: While back curls are removed, the toner adhesion becomes insufficient when the fusing pressure roller is used on the paper, allowing the toner to stain the anti-static brush.

  • Page 140: Multi-Folding Unit

    9. Post-Processing Option Troubleshooting Multi-Folding Unit Inaccurate Folding (Folding Deviation) Cause: Depending on paper hardness, inaccurate folds may result. This is referred to as folding deviation. Solution: Change the folding position by adjusting the position of the paper edge stopper for folding. •...

  • Page 141: Folding Deviation

    Multi-Folding Unit Folding Deviation Cause: Depending on paper hardness, folding deviations (skewed folding) may appear. A deviation may appear if the edge dimensions of the parts between folds are different. For example, in the following illustration, the dimensional difference between the top (L2[2]) and bottom (L2[1]) edges is a deviation.
  • Page 142 9. Post-Processing Option Troubleshooting Adjusting screw Adjusting screw hole Mounting screw CEZ599 Mounting screw Adjusting screw hole Adjusting screw CEZ600 Adjusting screw Mounting screw Adjusting screw hole CEZ601 The screws adjust the folding deviations of the following parts:...
  • Page 143 Multi-Folding Unit Z-fold Paper feed direction CEZ532 Half Fold Paper feed direction CEZ533 Letter Fold-in Paper feed direction CEZ535...
  • Page 144 9. Post-Processing Option Troubleshooting Letter Fold-out Paper feed direction CEZ534 Double Parallel Paper feed direction CEZ536 Gate Fold Paper feed direction CEZ537 mark indicates the leading edge (relative to the paper feed direction), and the mark indicates the trailing edge. <How to adjust the folding deviation>...

  • Page 145: Folds Stained By Multi-Sheet Folding

    Multi-Folding Unit Remove the mounting screw. If the mounting screw is attached to the adjusting screw hole, unfasten it. Turn the adjusting screw to adjust the deviation. • To increase the length at the bottom part of paper, turn the screw clockwise. •...
  • Page 146 9. Post-Processing Option Troubleshooting CEZ571 This will produce paper stain of 1-3 cm (0.4-1.2 inches) in width (equal to the width of the blade) in the fold in the center of paper. Solution: Clean the blade. Open the front cover of the multi-folding unit. Pull the multi-folding unit out.

  • Page 147: Z-Folding Is Not Performed Properly

    Multi-Folding Unit Wipe the tip and top of the blade with a soft dry cloth. Be careful not to damage the blade. CEZ513 After cleaning, restore the machine so that it resumes operation. Apply multi-sheet folding and print 3-5 copies. The paper stain will disappear. Z-Folding is Not Performed Properly Cause: If a sheet is curled and its edge touches the guide board, proper folding may not be possible.

  • Page 148: Folded Sheets Are Not Stacked Properly

    9. Post-Processing Option Troubleshooting Print the image. Has the problem been resolved? Finished! Go to the next step. To follow the steps below, attach the decurler unit. In the [Machine: Paper Feed/ Output] group on the [Adjustment Settings for Operators] menu, set 0304: [Correct Output Paper Curl] to "...
  • Page 149 Multi-Folding Unit CEZ514 As a bundle is delivered, its folded edge may droop and catch on the stacked bundles, causing the delivered bundle to flip over. Solution: Use the Z-fold support tray for multi-folding unit. This will reduce the angle of stacked bundles and prevent bundles flipping over as they are delivered. DFP351 For details about using the Z-fold support tray for multi-folding unit, see "Preparation"...

  • Page 150: Ring Binding

    9. Post-Processing Option Troubleshooting Ring Binding • Be sure not to exit from Energy Saver mode or to switch the machine on when the ring binder door is open and the binding unit is disconnected. Doing so will affect initialization, causing the ring binder function to become unavailable (although other functions will be unaffected).

  • Page 151: Buffer Pass Unit

    Buffer Pass Unit Buffer Pass Unit The Fan Is Noisy You can change the buffer pass unit fan activation setting according to the type of paper and ambient temperature. In the [Machine: Paper Feed/ Output] group on the [Adjustment Settings for Operators] menu, change the value in 0311: [Buffer Pass Unit Fan Activation Setting].

  • Page 152: High Capacity Stacker

    9. Post-Processing Option Troubleshooting High Capacity Stacker Delivered Sheets Are Severely Curled Cause: Sheets with downward curls cause strong friction on the leading edges. This may result in paper misfeeds. Sheets will not be ejected completely and the trailing edges will be left inside the paper exit. If this happens, other sheets may slip under the delivered sheets, so that the delivered sheets may be curled when loaded.
  • Page 153 High Capacity Stacker Paper exit Paddle Stacker shift tray Paper feed direction CEZ575 4. The next sheet to be delivered slips under the sheet still in the paper exit and bends back. Paper exit Paddle Stacker shift tray Paper feed direction CEZ576 Solution: Straighten out the sheet by decurling it upward.

  • Page 154: Delivered Sheets Are Not Aligned

    9. Post-Processing Option Troubleshooting Print the image. Has the problem been resolved? Finished! Contact your service representative. Delivered Sheets Are Not Aligned Cause: When sheets are delivered to the stacker tray, because of paper-to-paper friction, the paddle fails to pull the trailing edge back into the front guide, resulting in misalignment. The paper edge stopper also fails to push back the protruding leading edge.
  • Page 155 High Capacity Stacker 3. The paper edge stopper fails to push back the protruding leading edge and align the sheet as required. Paper exit Paper edge stopper Paddle Stacker shift tray Paper feed direction CEZ579 4. Stacked sheets are not aligned properly. Paper exit Paper edge stopper...

  • Page 156: The Machine Wrongly Detects That The Tray Is Full

    9. Post-Processing Option Troubleshooting Contact your service representative. • The top sheet of each offset bundle of delivered sheets may protrude above the rest of the bundle by about 7 mm. Stacker shift tray Paper feed direction CEZ605 The Machine Wrongly Detects That the Tray Is Full Cause: Depending on the paper size, the machine may detect that the shift tray has reached the maximum number of sheets that can be stacked on it.

  • Page 157: The Paper Press Leaves An Impression On The Paper

    High Capacity Stacker Print the image. Has the problem been resolved? Finished! Go to the next step. Set 0304: [Correct Output Paper Curl] to " Curl Correction Level: Small". Print the image. Has the problem been resolved? Finished! Go to the next step. Set 0304: [Correct Output Paper Curl] to "...

  • Page 158: Paper Pressed Down Insufficiently

    9. Post-Processing Option Troubleshooting Paper Pressed Down Insufficiently Cause: The screws on the handle of the paper cart and the bolts at its bottom are loose. Solution: Tighten the screws on the handle and the bolts at the bottom of the paper cart.

  • Page 159: Other Post- Processing Options

    Other Post- Processing Options Other Post- Processing Options Scratched Images and Stained Paper Edges Scratched images or stained paper edges appear. CNT008 Cause: When a relatively stiff, thick paper is delivered, the entrance guide board for the transfer unit is warped toward the intermediate transfer belt due to the stiffness of the paper.
  • Page 160 9. Post-Processing Option Troubleshooting...

  • Page 161: 10. Improving Throughput

    10. Improving Throughput Improving Throughput when Continuously Performing Black and White and Color Printing When a combination of black-and-white, full-color and special color printing is performed, switching color modes takes time, resulting in insufficient throughput. Optimize the amount of sheets the machine prints in the current color mode before switching to another mode.
  • Page 162 10. Improving Throughput Value Behavior 10 (Maximum) • When black-and-white printing is performed after full color printing, full color mode switches to black-and-white mode after 10 black-and-white sheets are printed in full color mode. • When black-and-white printing is performed after special color printing, special color mode switches to black-and-white mode after 10 black- and-white sheets are printed in special color mode.

  • Page 163: 11. Advanced Instructions

    11. Advanced Instructions Operating Procedure for Color Calibration To improve color reproduction and achieve color output with consistent quality, follow this procedure. It is recommended to perform color calibration for each print job. To improve CMYK image reproduction, adjust image density, and then perform calibration. Also, you can improve mixed color reproduction by adjusting image density and color registration and performing calibration.

  • Page 164: Creating A New Calibration Set

    11. Advanced Instructions If you use this method, calibration updates only the calibration setting that is used to print this job. Creating a new calibration set Creating a new calibration set, create a name for it and click [Next]. Enter a calibration name and an optional comment, and then click [Next]. Select a device, and then click [Print].

  • Page 165: Adjusting The Image Position Of The Either Side Of The Paper

    Adjusting the Image Position of the Either Side of the Paper Adjusting the Image Position of the Either Side of the Paper Adjusting the Image Position on Side 1 <If custom paper is used> Perform the solution described in "(a) Adjust the image skew", "(b) Adjust the image position (If custom paper is used)", "(c) Adjust the magnification (Across feed direction)"...
  • Page 166 11. Advanced Instructions Execute color registration. In executing color registration, the black adjustment will also be applied to cyan, magenta, yellow and special color. For details about color registration, see "Adjusting the Color Registration" in the Maintenance and Management supplied with the machine. •...
  • Page 167 Adjusting the Image Position of the Either Side of the Paper • If it is difficult to check and adjust the image position on the printed sheet, print one side of the format used in page 170 "Aligning the Image Position on Side 2 to That on Side 1 (Using a Template to Align the Image Position on Side 1 and 2)".

  • Page 168: Adjusting The Image Position On Side 2

    11. Advanced Instructions • If it is difficult to check and adjust the image position on the printed sheet, print one side of the format used in page 170 "Aligning the Image Position on Side 2 to That on Side 1 (Using a Template to Align the Image Position on Side 1 and 2)".
  • Page 169 Adjusting the Image Position of the Either Side of the Paper <If custom paper is used> Perform the solution described in "(a) Adjust the image skew", "(b) Adjust the image position (If custom paper is used)", "(c) Adjust the magnification (Across feed direction)" and then "(d) Adjust the magnification (With feed direction)".
  • Page 170 11. Advanced Instructions • In 0105: [Perpendicularity Adjustment], you cannot individually adjust the image position on sides 1 and 2. • You cannot skew paper with 0105: [Perpendicularity Adjustment]. For details about adjusting paper skew, page 91 "Paper Skew". • If it is difficult to check and adjust the image position on the printed sheet, print one side of the format used in page 170 "Aligning the Image Position on Side 2 to That on Side 1 (Using a Template to Align the Image Position on Side 1 and 2)".
  • Page 171 Adjusting the Image Position of the Either Side of the Paper DFP320 In [Advanced Settings] for the custom paper you are using, select 1101: [Image Position] and adjust the value in [Across Feed] of [Image Magnification: Side 2]. Press [+] to increase the scaling and [−] to reduce it. •...

  • Page 172: Aligning The Image Position On Side 2 To That On Side 1 (Using A Template To Align The Image Position On Side 1 And 2)

    11. Advanced Instructions (e) Adjust the image position (If custom paper is not used) Adjust the vertical and horizontal image position so that the center (A) of the leading edge of the image is aligned to the registration mark. DFP492 In the [Machine: Image Position] group on the [Adjustment Settings for Operators] menu, adjust the image position.
  • Page 173 Adjusting the Image Position of the Either Side of the Paper To adjust the image position, the machine administrator privilege is required. Supported paper size and paper type Supported Paper Size A3 , A4 , A4 , B4 , B5 , B5 , DLT , Legal , Letter , Letter , Government LG , 8K , 16K , 16K , 12 ×...
  • Page 174 11. Advanced Instructions Measure the length of specified parts on the 6th sheet among the printed copies of the format. Using the ruler and magnifier, measure the length between each corner of the paper and the top of its adjoining arrow, and the length between the top of arrows with the scale in 0.1 mm. DFP493 1.
  • Page 175 Adjusting the Image Position of the Either Side of the Paper You can enter values from 0.1 to 999.9 mm in 0.1-mm increments. Press [OK]. Press [Exit]. Press [OK]. Press [Overwrite]. Press [Yes]. Press [Exit]. Checking Adjusted Results From the supplied CD, print the file of the format matching the size of the paper requiring image position adjustment.
  • Page 176 11. Advanced Instructions Adjustment Method From the supplied CD, print the file of the format matching the size of the paper requiring image position adjustment. Continuously print the format on both sides of 10 sheets. Use the 6th sheet among the printed copies for adjustment. Through visual inspection of the 4th, 5th, and 6th sheets, check that misregistrations on Side 1 and 2 are almost the same.
  • Page 177 Adjusting the Image Position of the Either Side of the Paper DFP313 <With feed direction> Adjusting the image (A) on the leading edge of the paper on Side 2 to match the corresponding image (B) on Side 1 DFP314 In [Advanced Settings] for the custom paper you are using, select 1101: [Image Position] and adjust the value in [With Feed] of [Image Position: Side 2] Press [+] to shift the image to the left (trailing edge).
  • Page 178 11. Advanced Instructions Adjusting magnification to match the length between the arrows (A) on the leading edge of the paper on Side 2 to the length between the arrows (B) on Side 1 DFP319 In [Advanced Settings] for the custom paper you are using, select 1101: [Image Position] and adjust the value in [Across Feed] of [Image Magnification: Side 2] Press [+] to increase the scaling.
  • Page 179 Adjusting the Image Position of the Either Side of the Paper DFP317 In [Advanced Settings] for the custom paper you are using, select 1101: [Image Position] and adjust the value in [With Feed] of [Image Magnification: Side 2] Press [+] to increase the scaling. Press [−] to reduce the scaling.

  • Page 180: Envelopes

    11. Advanced Instructions Envelopes Creases, Wavy Streaks, or Fusing Error Creases occur when printing on an envelope. Creases or a fusing error occur when printing on an envelope. DFP435 Cause: Creases, wavy streaks Depending on the storage conditions of the envelope or printing environment, the envelope may absorb water, causing the paper rigidity of the envelope to lower.
  • Page 181 Envelopes Repeat Steps 1 to 2. Is the toner fusibility within the permissible range? Finished! Contact your service representative. (b) Fusing error In [Advanced Settings] for the custom paper you are using, check the value in 1244: [Fusing Pressure Roller On Before Fusing]. Is 1244: [Fusing Pressure Roller On Before Fusing] set to [On]? Set 1244: [Fusing Pressure Roller On Before Fusing] to [Off].
  • Page 182 11. Advanced Instructions • The toner does not come off even if it is lightly rubbed by a nail. • The toner does not come off even if it is rubbed by the cloth for cleaning the contact glass. D0AK-7433...
  • Page 184 EN GB EN US EN AU D0AK-7433 © 2018...

Table of Contents
