4.0

System Requirements

4.1 Capacity: The FACSS and VLLs covered in this manual, are CSA compliant, with a listed single user capacity, including clothing, tools,
etc., of 59 kg (130 lbs) to no more than 140.6 kg (310 lbs), No more than one VLL may be connected to one anchorage/anchorage
connector at one time.
4.2 Compatibility of Connectors: Connectors are considered to be compatible with connecting elements when they have been designed
to work together in such a way that their sizes and shapes do not cause their gate mechanisms to inadvertently open regardless of how
they become oriented. Contact FallTech if you have any questions about compatibility. Connectors must be compatible with the
anchorage or other system components. Do not use equipment that is not compatible. Non-compatible connectors may unintentionally
disengage. Connectors must be compatible in size, shape, and strength. Self-closing, self-locking snap hooks and carabiners are specified
by OSHA and ANSI.
4.3 Making Connections: Only use self-locking connectors with this equipment. Only use connectors that are suitable to each application.
Ensure all connections are compatible in size, shape, and strength. Do not use equipment that is not compatible. Visually ensure all
connectors are fully closed and locked. Connectors (snap hooks, rebar hooks, and carabiners) are designed for use only as specified in this
manual.
4.4 PFAS Anchorage Strength: An anchorage selected for PFAS must have a strength able to sustain a static load applied in the direction
permitted by the PFAS of at least:
a) Two times the maximum arrest force permitted when certification exists, or
b) 22.2 kN (5,000 lbs) in the absence of certification.
4.5 Rescue: Rescue applications require specialized equipment and is beyond the scope of this manual.
5.0

Installation and Use

DO NOT use any FACSS discussed in this manual until the system has been completely installed, inspected, and approved for use by a
Competent Person.
5.1 Anchorage Location: Select a suitable anchorage point that will support the strength requirement and minimize free fall and swing
hazards. Do not work above the anchorage point.
5.2 Fall Clearance Distance: When working at heights and using a PFAS, it is important to consider the distance between the
walking/working level and the next lower level, or obstruction, to ensure there is sufficient room for the PFAS to arrest a fall. Fall
Clearance Distance is the distance that is required to safely arrest the fall of a user. The Distance may be calculated by adding together the
Length of the Lanyard, the Deceleration Distance, the Height of the Worker, plus a Safety Factor.
CMVLL01 Rev A
Figure 3 - Non -Compatible Connections
041020
A Never connect two active components (snap hooks or carabiners)
to each other.
B Never connect two active components (snap hooks or carabiners)
to a single D-ring at the same time.
C Never connect in a way that would produce a condition of loading
on the gate.
D Never attach to a object in a manner whereby the gate (of the
snap hook or carabiner) would be
prevented from fully closing and locking. Always guard against
false connections by visually inspecting for closure and lock.
E Never attach explicitly to a constituent subcomponent (webbing,
cable or rope) unless specifically provided for by the manufactur-
er's instructions for both subcomponents (snap hook or carabiner
and webbing, cable or rope).
F
Never attach in a manner where an element of the connector
(gate or release lever) may become caught on the anchor thereby
producing additional risk of false engagement.
G
Never attach a spreader snap hook to two side/positioning
D-rings in a manner whereby the D-rings will engage the gates;
the gates on a spreader must always be facing away from the
D-rings during work positioning.
