Best U102I Specification Sheet

U102I SERIES
RANGE HOODS
Slim-line design provides strong, effective ventilation
and cooktop lighting unobtrusively.
FEATURES
•
Italian design
•
Cabinet mount
•
Finish: 304 Stainless Steel #4 Brushed, White & Black
•
Black Glass Control Panel
•
Width: 30" & 36"
•
8" round duct connector/backdraft damper
•
Halogen lighting (2 x 20 watt, Type JC 12V 20W G4
Base - bulbs included) with multilevels from bright
cooktop illumination to a low nighttime setting
•
Advanced, electronic push-button controls
•
Quiet, variable-speed centrifugal blower with high-
efficiency motor produces 500 cfm of exhaust
•
Four-speed motor controls
•
Delay timer control automatically shuts off range hood
after ten minutes
•
Special control indicates when it's time to clean the filter
•
Can be ducted to the outside or non-ducted for indoor
recirculation (purchase recirculation kit separately)
•
Dishwasher-safe filter features a quick-release latch and
decorative cover plate
•
TM
Heat Sentry - automatically turns blower to high
speed when excess cooking heat is detected
•
Pull out visor with clear glass panel
OPTIONS
•
Replacement grease filters available
•
Non-ducted recirculation kit (Model ANKUIO)
•
Replacement charcoal filters available (Model ROUND
FILTER)
•
Exterior blower (U102E Series) available, providing
600, 900, 1200, or 1500 cfm exhaust
•
Replacement bulb (Part No. SB02300891)
REFERENCE QTY.
BEST BY BROAN, P.O. BOX 140 HARTFORD, WISCONSIN 53027
REMARKS
SPECIFICATION SHEET
SPECIFICATIONS
VOLTS AMPS CFM
120 3.13 500
HVI-2100 CERTIFIED RATINGS comply with new
testing technologies and procedures prescribed by
the Home Ventilating Institute, for off-the-shelf
products, as they are available to consumers.
Product performance is rated at 0.1 in. static
pressure, based on tests conducted in AMCA's
state-of-the-art test laboratory. Sones are a measure
of humanly-perceived loudness, based on laboratory
measurements.
"
1 / 2
1 0 -
7 - 7 / 8 "
/ 8 "
4 - 1
2 "
3 0 " ,
3 6 "
Mount range hood so bottom
is 22-1/2" (minimum) above
cooking surface.
Project
Location
Architect
Engineer
Contractor
Submitted by
50K
SONES DUCT
10.0 8" round
2 6 " , 3 2
"
d i a .
1 - 1 / 8 "
2 "
8 "
5 /
"
/ 8
- 3
4 "
1 1
3 /
.
5 -
.
N
A X
.
" M
X
M
1 6 A
1 / M
6 "
" - 1
1 6 / 1
1 2
- 7
5 /
1 8
1 -
Date
99043481B
