INSTALLATION INSTRUCTIONS
HB0061
UP27I and UP27E SERIES
INTENDED FOR DOMESTIC COOKING ONLY
!
!
READ AND SAVE THESE INSTRUCTIONS
INSTALLER: LEAVE THIS MANUAL WITH HOMEOWNER.
HOMEOWNER: USE AND CARE AND OPERATION INFORMATION ON
PAGES 13 AND 14.
In USA - BEST BY BROAN
P.O. Box 140, Hartford, WI 53027
®
In Canada - BEST BY BROAN
®
550 Lemire Blvd., Drummondville, QC, J2C 7W9
REGISTER YOUR PRODUCT ON LINE AT: www.bestbybroan.com/register
For additional information - visit www.bestbybroan.com
V07855 rev. A
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Best UP27I SERIES
Summary of Contents for Best UP27I SERIES
- Page 1 READ AND SAVE THESE INSTRUCTIONS INSTALLER: LEAVE THIS MANUAL WITH HOMEOWNER. HOMEOWNER: USE AND CARE AND OPERATION INFORMATION ON PAGES 13 AND 14. In USA - BEST BY BROAN P.O. Box 140, Hartford, WI 53027 ® In Canada - BEST BY BROAN ®...
-
Page 2: To Reduce The Risk Of Fire, Electric Shock Or Injury To Persons, Observe The Following
Best by Broan UP27E Series hoods must be for the size of the surface element. installed with Best by Broan exterior blower models EB6, EB9, EB12 or EB15; or Best by Broan in-line blowers models ILB3, ILB6, ILB9, ILB11. Other blowers cannot be substituted. (Blowers sold separately.) Please read specification label on product for further information and requirements. -
Page 3: Range Hood System
UP27I SERIES RANGE HOOD SYSTEM - INTERIOR BLOWER Model 634 or 644 Model 647 Model 634 or 644 Model 643 (roof cap) (7” Round wall cap) (roof cap) (8” Round wall cap) Model 418 8” round Model 415 Model 459 adjustable (7”... - Page 4 UP27E SERIES RANGE HOOD SYSTEM - IN-LINE AND EXTERIOR BLOWERS Model 441 Model 437 Model ILB9 (800 cfm) (10” Round wall cap) (High capacity roof cap) Model EB12 (1200 cfm) or ILB11 (1100 cfm) or EB15 (1500 cfm) in-line blower exterior blower Model EB6 (600 cfm) (includes two 8”...
- Page 5 Either UP27I or UP27E Series range hoods may be ducted. For a UP27E Series range hood, either an exterior blower or in-line blower may be used. The Best by Broan UP27E Series must be installed with blower models ILB3, ILB6, ILB9, ILB11, EB6, EB9, EB12 or EB15 only.
-
Page 6: Prepare The Installation
Make sure that the following items are included: - Installation manual - Adapter/damper 3¼” x 14” to 3¼” x 10” (exclusively for UP27I Series range hoods, temporarily assembled to pan, behind Evolutionary™ hybrid baffle filters) - Adapter/damper 3¼” x 14” (exclusively for UP27I Series range hoods, temporarily assembled to pan, behind Evolutionary™... -
Page 7: Prepare The Cabinet
5. REMOVE THE GREASE DRIP RAIL Remove tape on grease drip rail. Lift out grease drip rail and set aside. HD0212 6. REMOVE THE PAN Using a Phillips no. 2 screwdriver, remove the screws retaining the pan (shaded parts on illustration below) to the hood. Remove the pan and set aside. -
Page 8: Prepare The Hood
Cut-out the openings for CABINET BOTTOM CABINET BOTTOM duct (A) and house wiring (120 V AC)(B) according to the direction of discharge chosen. See figures beside. 13” 14” NOTE: For all UP27I Series (internal blower) Ø 1¼” 3¾” 3¾” range hoods, 2” ¾”... - Page 9 ISCHARGE UCTED INSTALLATION ONLY The UP27I Series range hoods are factory set to exhaust vertically. If the horizontal discharge is chosen, remove the metal shut-off plate from the back of the hood, by removing its 3 screws. Set aside the screws. Discard both left and right flow deviators assembled to the metal shut-off plate.
-
Page 10: Connect Wiring
8. PREPARE THE HOOD (CONT’D) 8.1 UP27I S ’ ERIES RANGE HOOD INTERNAL BLOWER CONT ’ ORIZONTAL ISCHARGE UCTED INSTALLATION ONLY CONT OP OF HOOD Using 3 no. 8 x 3/8” screws provided with hood, secure the adapter/damper on the back of the hood. Remove tape from damper flap. DAPTER AMPER CREW... -
Page 11: Install The Hood
Place the hood under the cabinet and slide it in position. Make sure the adapter/damper enters the ducting and the damper opens freely (UP27I Series range hood only), or ensure ducting connects to rough-in plate (UP27E Series range hood only). -
Page 12: Light Bulbs Replacement
13.REINSTALL GREASE DRIP RAIL AND BAFFLE FILTERS Reinstall the grease drip rail. HD0214 CAUTION Remove protective plastic film covering Evolutionary™ hybrid baffle filters before installing them. 13.1 D UCTED NSTALLATION Reinstall Evolutionary™ hybrid baffle filters on the hood. 13.2 N UCTED NSTALLATION Slide out and discard the secondary micromesh filters from the back of the baffle filters. -
Page 13: Operation
15.USE AND CARE Evolutionary™ Hybrid Baffle Filters The Evolutionary™ hybrid baffle filters should be cleaned frequently. Use a warm detergent solution. Wash more often if your cooking style generates greater grease—like frying foods or wok cooking. Remove Evolutionary™ hybrid baffle filters by pushing them towards the front of hood and rotating filters downward. Slide out the secondary micromesh filter from the back of each hybrid baffle filter before cleaning. -
Page 14: Heat Sentry
The HEAT SENTRY can start the blower even if the hood is turned OFF. In this case, it is impossible to turn the blower OFF with blower switch. To stop the blower on UP27I series, the main power switch located behind the baffle filters must be in the “OFF”... -
Page 15: Service Parts
SERVICE PARTS UP27I MODEL HL0088 PART QTY (HOOD WIDTH) NO. NUMBER DESCRIPTION 30’’ 36’’ 42’’ V14971 3¼” 14” DAPTER DAMPER T461 3¼” 14” 3¼” 10” DAPTER DAMPER V03435 HERMISTOR ENTRY V07834 OTARY ONTROL V07689 OGGLE WITCH V16966 ’ LASTIC ONTROL RAME AND V07688 V16569... - Page 16 SERVICE PARTS UP27E MODEL HL0089 PART QTY (HOOD WIDTH) NO. NUMBER DESCRIPTION 30’’ 36’’ 42’’ 48’’ V13923 EMALE ONNECTOR V13924 ONNECTOR V03435 HERMISTOR ENTRY V07688 V16966 ’ LASTIC ONTROL RAME AND V07689 OGGLE WITCH V07834 OTARY ONTROL V16569 ’ HELL OCKET AND V05921 (50 W, 120 V, PAR16, GU-10)
