INSTALLATION INSTRUCTIONS
HB0063
IP29M SERIES
INTENDED FOR DOMESTIC COOKING ONLY
!
!
READ AND SAVE THESE INSTRUCTIONS
INSTALLER: LEAVE THIS MANUAL WITH HOMEOWNER.
HOMEOWNER: USE AND CARE AND OPERATION INFORMATION ON
PAGES 12 TO 14.
In USA - BEST
P.O. Box 140, Hartford, WI 53027
®
In Canada - BEST
®
550 Lemire Blvd., Drummondville, QC, J2C 7W9
REGISTER YOUR PRODUCT ON LINE AT: www.bestrangehoods.com/register
For additional information — visit www.bestrangehoods.com
V08072 rev. A
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Best IP29M Series
Summary of Contents for Best IP29M Series
- Page 1 INTENDED FOR DOMESTIC COOKING ONLY READ AND SAVE THESE INSTRUCTIONS INSTALLER: LEAVE THIS MANUAL WITH HOMEOWNER. HOMEOWNER: USE AND CARE AND OPERATION INFORMATION ON PAGES 12 TO 14. In USA - BEST P.O. Box 140, Hartford, WI 53027 ® In Canada - BEST ®...
-
Page 2: To Reduce The Risk Of Fire, Electric Shock Or Injury To Persons, Observe The Following
To reduce the risk of fire and electric shock, the Best by Broan IP29M Series hood must be installed with Best by Broan interior blower models P6 or P12; Best by Broan exterior blower models EB6, EB9, EB12 or EB15;... -
Page 3: Range Hood System
IP29M SERIES INTERIOR BLOWERS Model 437 (High capacity roof cap) Model 418 (10” round adjustable elbow) Model 410 (10” round duct—2 ft. sections) Model 427 Model 423 ” x 18 ” ” x 18 ” to to 10” Round, 10” Round - vertical 6”... - Page 4 IP29M SERIES IN-LINE AND EXTERIOR BLOWERS Model 437 (High capacity roof cap) Model 441 Model 643 (10” Round (8” Round wall cap) wall cap) Model ILB6 (600 cfm) in-line blower (includes two 4½” x 18½” to 10’’ round transitions) Model ILB3 (280 cfm) in-line blower (includes one 8”...
- Page 5 1. SELECT BLOWER OPTION AND INSTALLATION TYPE ither an interior or an exterior blower or in-line blower may be used with this hood. The Best by Broan IP29M Series must be installed with blower models P6, P12, ILB3, ILB6, ILB9, ILB11, EB6, EB9, EB12 or EB15 only. Other blowers cannot be substituted.
-
Page 6: Measure Installation
Dimensions for the most common installation are shown beside. The minimum hood distance above cooktop must not be less than 30’’. A maximum of 36” above cooktop is highly recommended for best capture of cooking impurities. Distances over 36” are at the installer and users discretion. - Page 7 4. PREPARE THE BLOWER HOUSING Detach the blower housing from the hood by removing its both retaining screws (A). Keep the screws for further use. Fold up its both flanges (B). The flanges must be perpendicular to the top of the blower housing.
- Page 8 7. BUILD THE FRAMEWORK When building framework, always follow all applicable construction codes and standards. The framework must be sized to support the total weight of the hood. Refer to the table below for total weight of the hood, according to the type of blower chosen.
-
Page 9: Install Blower Housing
8. INSTALL BLOWER HOUSING Use both screws (A) previously removed in step 4 to assemble the blower housing to the mounting brackets. For installation with decorative flue cover AEIWP Series only, place 4 nuts (B) (from flue cover parts bag) on the pem studs, leaving 1/4” for the hood installation. The blower housing must be installed in such a way that its label (C) will be on the same side as the hood control side. -
Page 10: Connect The Wiring
12.CONNECT THE WIRING Risk of electrical shock. Electrical wiring must be done by qualified personnel in accordance with all applicable codes and standards. Before connecting wires, switch power off at service panel and lock service disconnecting means to prevent power to be switched on accidentally. Remove wiring cover from rough-in plate and set aside. -
Page 11: Install The Blower
16.INSTALL THE BLOWER Refer to instructions included with blower. Once the blower is installed, plug the blower cord (A) into the female receptacle and the power supply cord (B) onto the male connector inside the hood. Do not plug the two cords into each other. 17.REINSTALL THE PAN Remove protective plastic film covering pan sides and tape over halogen lamps. -
Page 12: Light Bulbs Replacement
19.LIGHT BULBS REPLACEMENT In order to prevent the risk of personal injury, do not install a lamp identified for use only in enclosed fixtures. This hood must use 120 V, 50 W, MR16 with GU10 base or PAR16 with GU10 base, shielded halogen lamps (included). In order to prevent the risk of personal injury, the halogen lamps must be cooled down before removing them. -
Page 13: Operation
21.OPERATION Always turn ON your hood before you begin cooking in order to establish an air flow in the kitchen. Let the blower run for a few minutes to clear the air after you turn off the range. This will help keep the whole kitchen cleaner and brighter. HC0032 1.Halogen light push-button INSTEON™... -
Page 14: Heat Sentry
To turn off the blower when Heat Sentry is activated, press and hold the blower push-button (item 2 on illustration) for more than 1 second. INSTEON™ Network compatibility Your IP29M Series range hood can be linked to INSTEON network, if installed in your house. For more details, refer to INSTEON devices instruction sheet. - 14 -... -
Page 15: Service Parts
SERVICE PARTS IP29M S ERIES HL0094 PART NO. NUMBER DESCRIPTION V08069 ONTROL V08073 ARTICULATES V13924 V13923 EMALE V08074 ONTROL V16569 V05921 ALOGEN V16967 VOLUTIONARY V16968 VOLUTIONARY V05528 ILTER V07694 ECONDARY V07695 ECONDARY V16794 REASE V16796 REASE V17448 NSIDE V17449 NSIDE V03435 HERMISTOR V08072... -
Page 16: Warranty
In USA: Best ® , P.O. Box 140, Hartford, WI 53027 (1-800-637-1453) In Canada: Best ® , 550 Lemire Blvd., Drummondville, QC J2C 7W9 (1-866-737-7770) www.bestrangehoods.com - 16 -...
