Installation Manual
®
Omnivore
2 HP Grinder Pumps
XLSG and XLSGX-Series
Models
XLSG200-Series
Single-Stage
XLSGX200-Series
2-Stage High Head
Certified to CSA, UL,
and FM standards
7000 Apple Tree Avenue
Bergen, NY 14416
ph: 800-543-2550
fax: 585-494-1839
www.LibertyPumps.com
Explosion-Proof
Approved for Hazardous Locations
Class I, Division 1, Groups C and D T4
Class I, Zone 1, Groups IIA and IIB T4
Keep this manual handy for future reference.
For replacement manual, visit LibertyPumps.com,
or contact Liberty Pumps at 800-543-2550.
Retain dated sales receipt for warranty.
Copyright © Liberty Pumps, Inc. 2020 All rights reserved.
Installer: Manual must remain with owner or
operator/maintainer.
Prior to installation, record information
from pump nameplate for future reference:
Model:
Serial:
Mfg Date:
Install Date:
6850000C
