Chapter 3. Acoustic Isolation Installation (FIPA Buffers)
3.
Place the collets on the buffer as shown below.
4.
Repeat the above steps for the other transducer.
This completes the installation of the FIPA buffers and transducers. Refer to the flowmeter Startup Guide or User's
Manual for instructions on obtaining flow rate measurements.
34
Loosen
Using Allen
Wrench
Front View
1 in.
(25 mm)
Collets
Top View
Ring
BWT™ System Installation Guide
