in the picture.
When the board is powered on, hold the tourney lock button down. The LED will flash a series of green and
red, ending in either green (tourney lock off, or red (tourney lock on).
Tourney
Lock Button

Programming menu

To program the board, first ensure that the tournament lock is off and then turn the marker off. Hold down
the trigger whilst turning the marker on. Continue to hold the trigger while the LED shines white. When the
LED changes to blue, you may release the button and trigger, and proceed to adjust your settings. Click the
trigger if you would like to advance to the next color. When you would like to adjust a setting, hold the
trigger until the LED goes blank. After releasing the trigger, the LED will flash, the number of flashes shows
you the last setting. When the board has finished flashing, pull the trigger the number of times you would
like to input your new setting.
Each setting is color coded. The colors are given below:
LED Color
Blue
Red
White
Green
Setting
De-bounce (1/2ms increments)
Dwell (1ms increments)
Fire mode
Max ROF – capped modes only
Default
10
8
1 (semi)
10 (12.5bps)
