Installation Overview
ACCESSORIES for NEW Installation
Accessory and model number
Plenum (telescoping)
RAVWPT15
*excluding flange
Architectural Louver
RAVAL3
Access Panel with Return Air
Grille
RAVRG4
Return Air Grille
RAVRG2B
Drain Platform
RAVDPLAT
Wall Thermostat
12
22 ⁄
1
Model Type
Electric Resistance Models
Electric Resistance Models
Heat Pump Models
Heat Pump Models
All Models
*0 wires if powered by a battery, 2 wires if powered by the unit
Appearance
"
22 ⁄
1
2
"
2
Wiring Thermostat Type
5-wire 5-wire
6-wire 6-wire
6-wire 6-wire
7-wire 7-wire
* *
Cutout Dimensions
Cutout
Dimensions:
24"W x 32"H
Architectural Louver designed to fit
the following Plenums:
RAVWP15
Cutout
Dimensions:
Cutout
Dimensions:
Not Applicable
Fan Speed(s) Kit Number
1 RAK149P2
2 RAK149F2
1 RAK149P2
2 RAK149F2
2 RAK180W1
