Select how the Desk Accessories can be accessed. This selection does not appear when SCO Console emulation
is selected. In SCO Console emulation, Ctrl ← is the only access method.
The default allows the desk accessories to be accessed through a menu which appears when Ctrl and the left
arrow key are pressed simultaneously. This brings up a pop-up window; selections for the specific accessory can
be made from that menu by pressing F1-F5. The Sh-Ctrl-Fkeys option, when selected, allows direct access to desk
accessories by pressing Sh-Ctrl-F1 through Sh-Ctrl-F5. Selecting Disabled will inhibit entry to desk accessories.
Once a desk accessory is displayed, any other desk accessory can be accessed by pressing only the function key
associated with it (without pressing Sh-Ctrl).
When using PC-Term emulation, Local Leadin (in the F5 menu) must be on to access desk accessories. Then, to
view the diagnostic menu, for example, press Ctrl-Scroll Lock, Ctrl-←, F5.
ANSI Keyboard
Disconnect: [Disabled, Shift-F5]
Choose to allow the keystroke that will generate a modem disconnect on the ANSI keyboard or to disable the
Disconnect function.
If "F1 to F5 keys" selection is set to Fkey in Setup, the Disconnect function will be remapped to Ctrl-Shift-F5.
F1 to F5 keys: [Local, Fkey]
This selection determines whether the first five keys (labeled F1-F5) serve as local keystrokes (for example, F3
allows access to Setup) or will serve as function keys which are loaded with the default strings. (Only
reprogrammed strings are visible in the text area for a given function or edit key; the default strings are not
visible in Setup).
If Fkey is selected, then the keystroke to enter Setup becomes Ctrl-F3 on the ANSI keyboard.
ANSI Keyboard
With the three remapping selections, keys which are available on a PC keyboard are now available on the ANSI
style keyboard: [ESC] ['~] [ , and .].
These three selections should either be kept in their defaults (as they appear on the keyboard), or all three
should be changed to follow the mapping scheme described here.
'~ Key: [' and ~ or ESC]
Select the characters sent by the tic/tilde key.
<> Key: [< and > or ' and ~]
Select the characters sent by the triangle bracket key in the normal and shifted positions.
,, and .. Keys: [,, and .. or ,< and .>]
Select the characters sent by the comma and period keys in the normal and shifted modes.
Backspace: [BS/DEL, DEL/BS, DEL/CAN]
Choose the codes sent by the key in the normal/shifted positions.
Compose Key: [Meta, Compose, Funct, Scroll-Lock, Alt Key]
Setup
32
