- Page 1 Chain drive ELTRAL KS 30/40 RADIO CONTROL Installation and Operating instructions...
-
Page 2: Table Of Contents
Installation and Operating instructions ELTRAL KS30/40 RADIO CONTROL Chain drive Contents Essential information General safety advice Intended use Product description Technical data (1 motor) Preparing to install Calculating the opening and closing force Mounting the device Electrical installation Operation Components and accessories Maintenance and care Trouble-shooting Disassembly and disposal... -
Page 3: Essential Information
Essential information These instructions are an important delivery component and are intended for the persons who will install, operate or service the product. These instructions provide information about the product and using it safely. Please read the instructions thoroughly and pay particular attention to the advisory notes concerning safety. -
Page 4: Intended Use
Our General Terms and Conditions apply. Product description The ELTRAL KS 30/40 RADIO CONTROL chain drive is designed for use in dry rooms at a maximum permissible ambient temperature of -5° C to +65° C. It can be installed either horizontally or vertically. -
Page 5: Technical Data (1 Motor)
Technical data (1 motor) Model 110 V / 230 V Push* / pull force * (See force-displacement curve) / max. 300 N Travel (adjustable) 100, 200, 300, 400 mm Nominal voltage 110 V / 230 V~ 50/60 Hz Current consumption at nominal load 0.16 A Power consumption at nominal load ~28 W... - Page 6 Installation and Operating instructions ELTRAL KS30/40 RADIO CONTROL Chain drive Dimensioned drawing For the suitable sash heights of the various installation options, refer to the following table or the diagrams in chapter Page 18. Min. sash height Travel Travel Travel Travel Installation method 100 mm...
-
Page 7: Preparing To Install
Preparing to install Incorrect use may cause injury to people and damage to DANGER property Using the type label on the motor and the data listed in chapter "5 Technical data (1 motor)" on page 5, make sure that you have the right motor for your installation situation. -
Page 8: Calculating The Opening And Closing Force
Installation and Operating instructions ELTRAL KS30/40 RADIO CONTROL Chain drive Calculating the opening and closing force With the formulae indicated below it is possible to determine the NOTE approximate force required to open or close a window. The windows are assumed to be smooth-running. Possible snow loads are also to be considered. -
Page 9: Mounting The Device
Mounting the device Risk of inappropriate assembly ATTENTION The device must be assembled by trained and qualifi ed persons only. After mounting the hardware, make sure it is working correctly. Carefully follow the enclosed installation drawings. Risk of crushing During the automatic opening and closing of the window, push and pull forces of up to 300 N occur. -
Page 10: Electrical Installation
Installation and Operating instructions ELTRAL KS30/40 RADIO CONTROL Chain drive Electrical installation Risk of electric shock Only approved electricians are permitted to carry out electrical installation DANGER work on site. For electrical installation on site, observe the VDE regulations (German Electrical Engineers Association) and the requirements of the local electricity supplier. - Page 11 "ON" position Travel 400 mm Handheld radio transmitter The ELTRAL KS 30/40 RADIO CONTROL chain drive is operated exclusively using the KS 30/40 handheld radio transmitter (Order No. K-19046-00-0-0). It cannot be operated using handheld transmitters by other manufacturers.
- Page 12 The programming of the handheld radio transmitter is described in the instructions for the handheld radio transmitter. Saving a handheld radio transmitter DIP switch Display and operating elements of ELTRAL KS 30/40 RADIO CONTROL (under the cover) PRG key NOTE The same button on a handheld radio transmitter cannot be ...
- Page 13 Press the F1, F2 and arrow ▲ buttons one after the other. The window opens. It closes once again after 5 minutes. If the ELTRAL KS 30/40 RADIO CONTROL receives a further remote control command, the ventilation function is aborted.
-
Page 14: Components And Accessories
ELTRAL KS 30/40 RADIO CONTROL K-19042-00-0-* * = colour: 1 = grey (RAL 7047), 6 = black (RAL 9005), 7 = white (RAL 9016) Accessories for ELTRAL KS 30/40 RADIO CONTROL chain drive (see section "17 Application examples" on page 17) Handheld radio transmitter... -
Page 15: Trouble-Shooting
13 Trouble-shooting Installers or end users are not capable of repairing motors professionally and therefore must not do so themselves. Professional repairs can only be carried out by the manufacturer. If you open the motor or manipulate it in any way, this will invalidate the warranty. ... -
Page 16: Guarantee And Aftersales Service
16 Connection diagram Connection of KS30/40 RADIO CONTROL The ELTRAL KS 30/40 RADIO CONTROL chain drive comes with a connection cable which is approx. 2m long. It must be connected to a mains voltage of 110V or 230V~ 50Hz. The opening and closing control commands are issued by the KS 30/40 handheld radio transmitter (Item No. -
Page 17: Application Examples
17 Application examples The application range of the product is recommended by Gretsch-Unitas GmbH Baubeschläge and may vary, depending on which profi le system is used. The product guidelines of the profi le manufacturer, in particular information about construction and assembly, tightness, max. sash weights and material qualities (e.g. linear profi... -
Page 18: Application Diagram
Installation and Operating instructions ELTRAL KS30/40 RADIO CONTROL Chain drive 18 Application diagram 1500 1250 1000 KS 30/40 Flügelbreite / sash width FB [mm] Sash width SW [mm]... -
Page 19: Declaration Of Incorporation
19 Declaration of incorporation 10.2016 | G28706 | Designed in Germany... - Page 20 Editor: Gretsch-Unitas GmbH Baubeschläge Johann-Maus-Str. 3 71254 Ditzingen Germany Tel. + 49 (0) 71 56 3 01-0 Fax + 49 (0) 71 56 3 01-2 93 www.g-u.com...
