C6BA Series Split System Indoor Cased Coils
INSTALLATION INSTRUCTIONS
IMPORTANT
ATTENTION INSTALLERS:
It is your responsibility to know this product better than your customer. This includes being able to install the
product according to strict safety guidelines and instructing the customer on how to operate and maintain the
equipment for the life of the product. Safety should always be the deciding factor when installing this product
and using common sense plays an important role as well. Pay attention to all safety warnings and any other
special notes highlighted in the manual. Improper installation of the furnace or failure to follow safety warnings
could result in serious injury, death, or property damage.
These instructions are primarily intended to assist qualified individuals experienced in the proper installation
of this appliance. Some local codes require licensed installation/service personnel for this type of equipment.
Please read all instructions carefully before starting the installation. Return these instructions to the customer's
package for future reference.
DO NOT DESTROY. PLEASE READ CAREFULLY & KEEP IN A SAFE PLACE FOR FUTURE REFERENCE.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Nortek C6BA Series
Summary of Contents for Nortek C6BA Series
- Page 1 C6BA Series Split System Indoor Cased Coils INSTALLATION INSTRUCTIONS IMPORTANT ATTENTION INSTALLERS: It is your responsibility to know this product better than your customer. This includes being able to install the product according to strict safety guidelines and instructing the customer on how to operate and maintain the equipment for the life of the product.
-
Page 2: Important Safety Information
IMPORTANT SAFETY INFORMATION WARNING: Please read all instructions before servicing this equipment. Pay attention to all safety warnings and any other special This unit must be installed in accordance with notes highlighted in the manual. Safety markings are used the instructions outlined in this manual during frequently throughout this manual to designate a degree or the installation, service, and operation of this level of seriousness and should not be ignored. -
Page 3: Coil Installation
COIL INSTALLATION lines and drain line where required. Reinstall all inner and outer panels of the furnace/air handler that were previously removed when installing the indoor coil. WARNING: Upflow Installations 1. Disconnect all electrical power to the furnace. ELECTRICAL SHOCK, FIRE OR 2. - Page 4 CAUTION: The knockout must be removed and discarded to ensure proper condensate drainage. Failure to do so may result in structural damage, premature Schrader Liquid Valve equipment failure, or possible personal injury. Line 4. Place the horizontal drain pan on the opposite side of the Suction Line coil.
-
Page 5: Completing The Installation
IMPORTANT NOTE: • Route the lines to a suitable drain, avoiding sharp bends To prevent internal oxidation and scaling from occuring, and pinching of the lines. The drain should maintain a braze all connections with dry nitrogen flowing through minimum horizontal slope in the direction of discharge of the joints. -
Page 6: Top View
FRONT VIEW TOP VIEW Coil Dimensions Figure 2. Thermal Expansion Valve (TXV) Distributor Retaining Door Grommet Liquid Line Stub w/ Screen Accessory Retaining Nut TXV Assembly Figure 3. -
Page 9: Notice D'installation
Serpentins coffrés intérieurs pour système multi-blocs Série C6BA NOTICE D’INSTALLATION IMPORTANT REMARQUE À L’INTENTION DES INSTALLATEURS : Il est de votre responsabilité de mieux connaître ce produit que votre client. Cela inclut la capacité d’installer le produit conformément aux directives de sécurité strictes et d’informer le client sur la façon d’utiliser et de maintenir l’appareil pour assurer la durée de vie du produit. -
Page 10: Renseignements Importants Sur La Sécurité
RENSEIGNEMENTS IMPORTANTS SUR LA AVERTISSEMENT : SÉCURITÉ Veuillez lire toutes les instructions avant d’entretenir cet équipement. Cet appareil doit être installé conformément aux Prêtez attention à tous les avertissements de sécurité et toute instructions contenues dans ce manuel, et ce, pendant autre remarque spéciale donnée dans le manuel. - Page 11 INSTALLATION DU SERPENTIN • Des plaques de fermeture sont disponibles dans certaines trousses de filtration d’air. Consultez la Liste des pièces de rechange pour les numéros de pièces disponibles. Installez les plaques AVERTISSEMENT : de fermeture requises autour des conduites de frigorigène et conduites d’évacuation au besoin.
- Page 12 MISE EN GARDE : L’appareil doit être retiré et mis au rebut pour assurer un drainage approprié de la condensation. Le non- respect de cette instruction peut causer des dommages Valve Conduite structurels, la défaillance prématurée de l’équipement Schrader liquide ou même des blessures.
-
Page 13: Finalisation De L'installation
REMARQUE IMPORTANTE : direction de l’évacuation d’au moins 1 po vertical tous les 10 pi Pour prévenir l’oxydation interne et l’entartrage, brasez tous de conduite horizontale. les branchements en faisant circuler de l’azote sec à travers • Pendant la vérification du système, inspectez la conduite et les les joints. -
Page 14: Vue De Dessus
VUE AVANT VUE DE DESSUS Dimensions du serpentin Figure 2. Détendeur thermostatique (TXV) Distributeur Écrou de retenue du détendeur thermostatique Serrure Passe-fils Embout de la conduite de liquide avec tamis Écrou de retenue d’accessoire Ensemble du détendeur thermostatique Figure 3. - Page 16 O’Fallon, MO, © Nortek Global HVAC LLC 2018. All Rights Reserved. 10250410 Spécifications et illustrations sujettes à changements sans préavis ou sans aucune (Replaces 708823G) obligation. (09/18) O’Fallon, MO, © Nortek Global HVAC LLC 2018. Tous droits réservés. (Remplace 708823G)
