Rev 11 7
An Operator's Manual was shipped with the equipment in the
Manual Canister. This Operator's Manual is an integral part
of the safe operation of this machine and must be maintained
with the unit at all times. READ, UNDERSTAND, and FOLLOW
the Safety and Operation Instructions contained in this manual
before operating the equipment. If the Operator's Manual is not
with the equipment, contact your dealer or Servis-Rhino (800-
446-5158) to obtain a Free copy before operating the equipment.
RHINO
®
1020 S. Sangamon Ave.
Gibson City, IL 60936
800-446-5158
Email: parts@servis-rhino.com
PART'S MANUAL
© 2017 Alamo Group Inc.
TW25
ROTARY MOWER
Part No. 00792299P

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TW25 and is the answer not in the manual?

Questions and answers

Summary of Contents for RHINO TW25

  • Page 1 READ, UNDERSTAND, and FOLLOW the Safety and Operation Instructions contained in this manual before operating the equipment. If the Operator's Manual is not with the equipment, contact your dealer or Servis-Rhino (800- 446-5158) to obtain a Free copy before operating the equipment. RHINO ®...
  • Page 2 TO THE OWNER/OPERATOR/DEALER All implements with moving parts are potentially hazardous. There is no substitute for a cautious, safe-minded operator who recognizes the potential hazards and follows reasonable safety practices. The manufacturer has designed this implement to be used with all its safety equipment properly attached to minimize the chance of accidents. BEFORE YOU START!! Read the safety messages on the implement and shown in your manual.
  • Page 3 PARTS SECTION Parts Section – 1...
  • Page 4 Part Number when ordering Replacement Safety Decals. For maximum safety and to guarantee optimum product reliability, always use genuine Servis-Rhino Parts. The use of inferior replacement parts may cause premature or catastrophic failure which could result in serious injury or death.
  • Page 5: Table Of Contents

    DECAL PLACEMENT....................................8 DEFLECTOR ASSEMBLY ..................................10 DRIVELINE ASSEMBLY - 00789043 CAT3 SLIPCLUTCH........................11 GEARBOX ASSEMBLY - 00791028 1:1.69 1-3/8 6SPL 540RPM......................13 SHIELD ASSEMBLY ....................................15 TAILWHEEL & CANISTER ASSEMBLY..............................16 TW25 ©2017 Alamo Group Inc. Parts Section -3...
  • Page 6: A-Frame Assembly

    A-FRAME ASSEMBLY ITEM PART NO. QTY. DESCRIPTION 00792273 ARM, FRONT A-FRAME-RH 00792272 ARM, FRONT A-FRAME-LH 00792277 BAR, BRACE TW25/35 00792274 WDMT, TOGGLE LINK 00792298 BUSHING, 1.00 X .78 X 2.38 00792279 BUSHING, 1.25 X .656 X 2.53 00780869 NUT, FLG 5/8NC SPIRALOCK PL5...
  • Page 7 BUSHING, CAT. II QUICK HITCH 00755082 HEXB 5/8 NC 2-1/2PL8 00780663 FLAT, DRIVELINE STORAGE 00792251 WDMT, TW25 DECK 02030700 HHCS 1/2-13NC X 1-1/4 GR5 PL 02971324 NUT LOCK FLG 1/2-13 NC PL TW25 ©2017 Alamo Group Inc. Parts Section -5...
  • Page 8: Blade Carrier Assembly

    DESCRIPTION 00792309 WDMT, BLADE PAN 27" CTR 00781320 BLADE BOLT 7/8 DIA X 3 LG 00761535 WASHER,7/8" STRUCTURAL - PLAIN 00750226 NUT TOPLOCK 7/8 NF PLC 00781343 BLADE, FAN CCW, 16-1/2 CTR-TIP TW25 ©2017 Alamo Group Inc. Parts Section -6...
  • Page 9: Chainguard Assembly

    CHAINGUARD ASSEMBLY ITEM PART NO. QTY. DESCRIPTION 00792292 ASY, FRONT CHAINGUARD- TW25 00792294 ASSY, REAR CHAIN GUARD 4528 NUT, HEX LOCK 3/8-16 FLG WHIZ 000644 CARB-3/8 NCK 1-1/4 PL5 TW25 ©2017 Alamo Group Inc. Parts Section -7...
  • Page 10: Decal Placement

    DECAL PLACEMENT TW25 ©2017 Alamo Group Inc. Parts Section -8...
  • Page 11 DECAL, DANGER THROWN OBJECT D388 DECAL, DANGER PTO 00756004 DECAL, DANGER-SHIELD MISSING 00792284 SHEET, DECAL LOGO-TW25 00792307 DECAL, RHINO BLACK 7.5" X 34.5" 00792180 DECAL, FLAG-MADE IN USA 00792306 DECAL, TW25 MODEL ----- DECAL, DANGER/GREASE (D389-814-590) 00760657 DECAL, SAFETY WARNING...
  • Page 12: Deflector Assembly

    ITEM PART NO. QTY. DESCRIPTION 4528 NUT, HEX LOCK 3/8-16 FLG WHIZ 000644 CARB-3/8 NCK 1-1/4 PL5 00792289 PANEL, FRONT RUBBER DEFLECTOR 00792287 FLAT, DEFLECTOR STRAP 00792290 DEFLECTOR, RUBBER TW25 00792288 BRACKET,DEFLECTOR,REAR TW25 ©2017 Alamo Group Inc. Parts Section -10...
  • Page 13 BLANK INTENTIONALLY TW25 ©2017 Alamo Group Inc.
  • Page 14: Driveline Assembly - 00789043 Cat3 Slipclutch

    DRIVELINE ASSEMBLY - 00789043 CAT3 SLIPCLUTCH TW25 ©2017 Alamo Group Inc. Parts Section -11...
  • Page 15 ASY,FRICTION CLUTCH KIT 00789308 SPRING AND BOLT KIT 00789309 CLAMP BOLT/NUT FOR HUB 00768347 FRICTION DISC 00756004 DECAL,DANGER - GUARD MISSING 00756005 DECAL, ROTATING DRIVELINE 00789044 SHIELD,DRIVELINE - COMPLETE 00789305 ASY, COLLAR KIT TW25 ©2017 Alamo Group Inc. Parts Section -12...
  • Page 16: Gearbox Assembly - 00791028 1:1.69 1-3/8 6Spl 540Rpm

    GEARBOX ASSEMBLY - 00791028 1:1.69 1-3/8 6SPL 540RPM TW25 ©2017 Alamo Group Inc. Parts Section -13...
  • Page 17 00754773 SHIELD, PROTECTIVE - 40.1 X 79.9 X 1 70487 PIN, COTTER M4 X 40 70497 PIN, COTTER M5 X 50 00790985 PLUG, VENT M16-1.5 00790983 SEALING WASHER 4038609 DIPSTICK, OIL- EZ40 TW25 ©2017 Alamo Group Inc. Parts Section -14...
  • Page 18: Shield Assembly

    ITEM PART NO. QTY. DESCRIPTION 00785575 SHIELD,BLACK GEARBOX 00785574 RING,GB SHIELD INNER SUPPORT 00791651 HEXB SER FLG M8-20MM 1.25 P 10.9 00695100 NUT, TOPLOCK 5/8 NC PLC 00785946 KIT/ GEARBOX SHIELD & RING TW25 ©2017 Alamo Group Inc. Parts Section -15...
  • Page 19 BLANK INTENTIONALLY TW25 ©2017 Alamo Group Inc.
  • Page 20: Tailwheel & Canister Assembly

    TAILWHEEL & CANISTER ASSEMBLY TW25 ©2017 Alamo Group Inc. Parts Section -16...
  • Page 21 TAILWHEEL & CANISTER ASSEMBLY Continued... ITEM PART NO. QTY. DESCRIPTION 00792262 WDMT, TW25/26/35 TAILWHEEL 00776210 AG SE CASTER FORK WHEEL ASSY 00792271 PLATE, TAILWHEEL VERTICAL 02971324 NUT LOCK FLG 1/2-13 NC PL 02030700 HHCS 1/2-13NC X 1-1/4 GR5 PL 02845600...
  • Page 22 WARRANTY 1. LIMITED WARRANTIES 1.01. Servis-Rhino warrants for one year from the purchase date to the original non-commercial, governmental, or municipal purchaser (“Purchaser”) and warrants for six months to the original commercial or industrial purchaser (“Purchaser”) that the goods purchased are free from defects in material or workmanship.
  • Page 23 TO THE OWNER/OPERATOR/DEALER The OCCUPATIONAL SAFETY AND HEALTH ACT (1928.51 Subpart C) makes these minimum safety require- ments of tractor operators: REQUIRED OF THE OWNER: 1. Provide a Roll-Over-Protective Structure that meets the requirements of this Standard; and 2. Provide Seatbelts that meet the requirements of this paragraph of this Standard and SAE J4C; and 3.
  • Page 24 TW25 Part No. 00792299P Printed U.S.A.
