Rev 02- 8
An Operator's Manual was shipped with the equipment in the
Manual Canister. This Operator's Manual is an integral part
of the safe operation of this machine and must be maintained
with the unit at all times. READ, UNDERSTAND, and FOLLOW
the Safety and Operation Instructions contained in this manual
before operating the equipment. If the Operator's Manual is not
with the equipment, contact your dealer or Servis-Rhino (800-
446-5158) to obtain a Free copy before operating the equipment.
RHINO
®
1020 S. Sangamon Ave.
Gibson City, IL 60936
800-446-5158
Email: parts@servis-rhino.com
PART'S MANUAL
© 2018 Alamo Group Inc.
TW27
ROTARY MOWER
Part No. 00792448P
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for RHINO TW27
Summary of Contents for RHINO TW27
- Page 1 READ, UNDERSTAND, and FOLLOW the Safety and Operation Instructions contained in this manual before operating the equipment. If the Operator's Manual is not with the equipment, contact your dealer or Servis-Rhino (800- 446-5158) to obtain a Free copy before operating the equipment. RHINO ®...
- Page 2 TO THE OWNER/OPERATOR/DEALER All implements with moving parts are potentially hazardous. There is no substitute for a cautious, safe-minded operator who recognizes the potential hazards and follows reasonable safety practices. The manufacturer has designed this implement to be used with all its safety equipment properly attached to minimize the chance of accidents. BEFORE YOU START!! Read the safety messages on the implement and shown in your manual.
- Page 3 PARTS SECTION Parts Section – 1...
- Page 4 Part Number when ordering Replacement Safety Decals. For maximum safety and to guarantee optimum product reliability, always use genuine Servis-Rhino Parts. The use of inferior replacement parts may cause premature or catastrophic failure which could result in serious injury or death.
-
Page 5: Table Of Contents
PART NAME INDEX A-FRAME ASSEMBLY....................................4 BLADE CARRIER ASSEMBLY.................................. 6 CASTER FORK ASSEMBLY..................................7 CHAINGUARD ASSEMBLY..................................9 DECALS - TW27......................................10 DEFLECTOR ASSEMBLY ..................................11 DRIVELINE ASSEMBLY - 00792450............................... 12 DUAL TAILWHEEL ASSEMBLY - OPTIONAL............................. 14 GEARBOX ASSEMBLY 00791057................................16 GEARBOX SHIELD &... -
Page 6: A-Frame Assembly
A-FRAME ASSEMBLY TW27 ©2018 Alamo Group Inc. Parts Section -4... - Page 7 A-FRAME ASSEMBLY Continued... ITEM PART NO. QTY. DESCRIPTION 00792401 WDMT, TW27 DECK 00703200 HHCS 5/8-11 NC 2-3/4 PL5 00780663 FLAT, DRIVELINE STORAGE 00780869 NUT, FLG 5/8NC SPIRALOCK PL5 00792278 BUSHING, .88 OD X .64 ID X 1.19 00792425 ARM, FRONT A-FRAME-LH...
-
Page 8: Blade Carrier Assembly
BLADE CARRIER ASSEMBLY ITEM PART NO. QTY. DESCRIPTION 00792422 WDMT, TW27 BLADE CARRIER 5JRC16140 LOCKNUT TLM 1 NF PL 9216 WASHER, 1 STRUCTURAL 8251 BOLT, BLADE SPECIAL 00780803P BLADE, CCW FAN, 28-1/4" CTR-TIP 00780809 WASHER, 1-9/64" SQ HOLE X 2" OD 8264 KIT, BLADE BOLT (CONTAINS ITEMS 2 &... - Page 9 BLANK INTENTIONALLY TW27 ©2017 Alamo Group Inc.
-
Page 10: Caster Fork Assembly
CASTER FORK ASSEMBLY TW27 ©2018 Alamo Group Inc. Parts Section -7... - Page 11 NUT SPINDLE M24 X 2 00771620 PIN,COTTER 5/32X2-1/2 PL 00772082 NIPPLE, GREASE M8X1 02822500 FLATWASHER 1 PL STD 00780238 ASY,TAILWHEEL HUB (INCLUDES ITEMS 7 & 20) 00785915 KIT,BEARING & SEAL (INCLUDES ITEMS 7-13 & 17) TW27 ©2018 Alamo Group Inc. Parts Section -8...
-
Page 12: Chainguard Assembly
CHAINGUARD ASSEMBLY ITEM PART NO. QTY. DESCRIPTION 00792442 ASY, FRONT CHAINGUARD-TW27 00792444 ASY, REAR CHAINGUARD-TW27 4528 NUT, HEX LOCK 3/8-16 FLG WHIZ 000644 CARB-3/8 NCK 1-1/4 PL5 TW27 ©2018 Alamo Group Inc. Parts Section -9... -
Page 13: Decals - Tw27
DECAL, DANGER THROWN OBJECT D388 DECAL, DANGER PTO 00756004 DECAL, DANGER-SHIELD MISSING 00792284 SHEET, DECAL LOGO-TW27 00792307 DECAL, RHINO BLACK 7.5" X 34.5" 00792180 DECAL, FLAG-MADE IN USA 00792447 DECAL, MODEL TW27 D389-D814-D590 1 DECAL, DANGER/GREASE 00760657 DECAL, SAFETY WARNING... -
Page 14: Deflector Assembly
DEFLECTOR ASSEMBLY ITEM PART NO. QTY. DESCRIPTION 4528 NUT, HEX LOCK 3/8-16 FLG WHIZ 000644 CARB-3/8 NCK 1-1/4 PL5 00792439 DEFLECTOR, RUBBER TW27 00792437 FLAT, DEFLECTOR STRAP 00792440 DEFLECTOR, RUBBER TW27 00792438 BRACKET, REAR DEFLECTOR TW27 ©2018 Alamo Group Inc. - Page 15 BLANK INTENTIONALLY TW27 ©2017 Alamo Group Inc.
-
Page 16: Driveline Assembly - 00792450
DRIVELINE ASSEMBLY - 00792450 TW27 ©2018 Alamo Group Inc. Parts Section -12... - Page 17 BEARING RING 00759217 SCREW 1/2 LG #8 8974 PAN SUPPORT BEARING 1416601 ZERK 00779513 SHIELD KIT COLLAR KIT - (INCLUDES: COLLAR, BALLS, SPRING, AND SNAP RING) 00767954 INNER PROFILE 00792453 OUTER PROFILE 00792454 TW27 ©2018 Alamo Group Inc. Parts Section -13...
-
Page 18: Dual Tailwheel Assembly - Optional
DUAL TAILWHEEL ASSEMBLY - OPTIONAL TW27 ©2018 Alamo Group Inc. Parts Section -14... - Page 19 00792621 WDMT, TAILWHEEL 00792629 PLATE, TAILWHEEL ADJUSTMENT 00792643 PLATE, BOTTOM POSITION 00792644 PLATE, TOP POSITION 00792630 PLATE, RHINO COVER 00776220 ASY, CASTER FORK & WHEEL 00776031 CANISTER, PARTS MANUAL 00792280 BUSHING, SHOULDER 5/8" 00792631 BUSHING, 1.00 X .69 X 1.91 02858200 HHCS, 5/8-11 X 5.5 GR5 ZC...
-
Page 20: Gearbox Assembly 00791057
GEARBOX ASSEMBLY 00791057 TW27 ©2018 Alamo Group Inc. Parts Section -16... - Page 21 PLUG, VENT M16-1.5 2716423 PIN, COTTER M6 X 60 00791093 NUT, CASTLE M30-2.0 4038611 DIPSTICK, OIL -EZ80 329915H8C NUT, HEX-FLANGE-SPIRALOCK 3/4 PL5 (MOUNTING NUT) 02959391 HHCS 3/4 NC 2-1/4 PL5 (MOUNTING BOLT) TW27 ©2018 Alamo Group Inc. Parts Section -17...
-
Page 22: Gearbox Shield & Mounting Hardware
00785575 SHIELD,BLACK GEARBOX 00785574 RING,GB SHIELD INNER SUPPORT 00791651 HEX FLANGE SCREW, M8X1.25 X 20 - 20N 329915H8C NUT, HEX FLANGE-SPIRALOCK 3/4-10 5312316 WASHER, 3/4" HARDENED 02959391 HHCS 3/4" NC 2-1/4 PL5 TW27 ©2018 Alamo Group Inc. Parts Section -18... -
Page 23: Single Tailwheel Assembly
ASY, CASTER FORK & WHEEL 00780869 NUT, FLG 5/8NC SPIRALOCK PL5 00780878 RIVET, 3/16 POP X 15/32" G.R. 00792280 BUSHING, SHOULDER 5/8" 02030700 HHCS 1/2-13NC X 1-1/4 GR5 PL 02971324 NUT LOCK FLG 1/2-13 NC PL TW27 ©2018 Alamo Group Inc. Parts Section -19... -
Page 24: Slipclutch - 00779512
HUB 1 3/4-20 I.C. 00775323 PLATE, THRUST 00775324 SPRING, BELLEVILLE 61064C8 M10X1.5X50 GR.8.8 HEX CAPSCREW 00765961 NUT MET TLE 10MM-P1.5 PL 00772648 NUT,HEX TOP LOCK-M12 X 1.75 61076C8 M12X1.75X65 GR.8.8 HEX CAPSCRE TW27 ©2018 Alamo Group Inc. Parts Section -20... - Page 25 WARRANTY 1. LIMITED WARRANTIES 1.01. Servis-Rhino warrants for one year from the purchase date to the original non-commercial, governmental, or municipal purchaser (“Purchaser”) and warrants for six months to the original commercial or industrial purchaser (“Purchaser”) that the goods purchased are free from defects in material or workmanship.
- Page 26 TO THE OWNER/OPERATOR/DEALER The OCCUPATIONAL SAFETY AND HEALTH ACT (1928.51 Subpart C) makes these minimum safety require- ments of tractor operators: REQUIRED OF THE OWNER: 1. Provide a Roll-Over-Protective Structure that meets the requirements of this Standard; and 2. Provide Seatbelts that meet the requirements of this paragraph of this Standard and SAE J4C; and 3.
- Page 27 TW27 Printed Part No. 00792448P U.S.A.
