Rev 06 2021
An Operator's Manual was shipped with the equipment in the
Manual Canister. This Operator's Manual is an integral part
of the safe operation of this machine and must be maintained
with the unit at all times. READ, UNDERSTAND, and FOLLOW
the Safety and Operation Instructions contained in this manual
before operating the equipment. If the Operator's Manual is not
with the equipment, contact your dealer or Servis-Rhino (800-
446-5158) to obtain a Free copy before operating the equipment.
RHINO
®
1020 S. Sangamon Ave.
Gibson City, IL 60936
800-446-5158
Email: parts@servis-rhino.com
PART'S MANUAL
© 2017 Alamo Group Inc.
TW26
ROTARY MOWER
Part No. 00792377P
Advertisement
Table of Contents
Related Manuals for RHINO TW26
Summary of Contents for RHINO TW26
- Page 1 READ, UNDERSTAND, and FOLLOW the Safety and Operation Instructions contained in this manual before operating the equipment. If the Operator's Manual is not with the equipment, contact your dealer or Servis-Rhino (800- 446-5158) to obtain a Free copy before operating the equipment. RHINO ®...
- Page 2 TO THE OWNER/OPERATOR/DEALER All implements with moving parts are potentially hazardous. There is no substitute for a cautious, safe-minded operator who recognizes the potential hazards and follows reasonable safety practices. The manufacturer has designed this implement to be used with all its safety equipment properly attached to minimize the chance of accidents. BEFORE YOU START!! Read the safety messages on the implement and shown in your manual.
- Page 3 PARTS SECTION Parts Section – 1...
- Page 4 Part Number when ordering Replacement Safety Decals. For maximum safety and to guarantee optimum product reliability, always use genuine Servis-Rhino Parts. The use of inferior replacement parts may cause premature or catastrophic failure which could result in serious injury or death.
-
Page 5: Table Of Contents
DEFLECTOR ASSEMBLY ..................................10 DEFLECTOR SIDE ASSEMBLY................................12 DRIVELINE ASSEMBLY - 00789043 CAT3 SLIPCLUTCH........................14 GEARBOX ASSEMBLY - 00791028 -1:1.47 NO-LUBE 540RPM ......................16 SHIELD ASSEMBLY ....................................18 TAILWHEEL & CANISTER ASSEMBLY..............................20 TW26 ©2017 Alamo Group Inc. Parts Section -3... -
Page 6: A-Frame Assembly
00792279 BUSHING, 1.25 X .69 X 2.53 00780869 NUT, FLG 5/8NC SPIRALOCK PL5 00156503 HEXB, 5/8 NC 7 PL5 00792280 BUSHING, SHOULDER 5/8" 00792278 BUSHING, .88 OD X .64 ID X 1.19 TW26 Parts Section -4 ©2017 Alamo Group Inc. - Page 7 00792297 BUSHING, CAT. II QUICK HITCH 00755082 HEXB, 5/8 NC 2-1/2PL8 00780663 FLAT, DRIVELINE STORAGE 00792351 DECK WLDMT 02030700 HHCS 1/2-13NC X 1-1/4 GR5 PL 02971324 NUT LOCK FLG 1/2-13 NC PL TW26 ©2017 Alamo Group Inc. Parts Section -5...
-
Page 8: Blade Carrier Assembly
WDMT, BLADE PAN 21" CTR 00785567 BLADE, FAN CCW, 25-1/2 CTR-TIP 00786548 BLADE BOLT KIT ---------- NUT TOP LOCK 7/8 NF PLC ---------- WASHER 7/8 STRUCTURAL - PLAIN ---------- BLADE BOLT 7/8 DIA X 3 LG TW26 ©2017 Alamo Group Inc. Parts Section -6... -
Page 9: Chainguard Assembly
CHAINGUARD ASSEMBLY ITEM PART NO. QTY. DESCRIPTION 00792371 ASY, FRONT CHAINGUARD- TW26 00792373 ASSY, REAR CHAIN GUARD 4528 NUT, HEX LOCK 3/8-16 FLG WHIZ 000644 CARB-3/8 NCK 1-1/4 PL5 TW26 ©2017 Alamo Group Inc. Parts Section -7... -
Page 10: Decal Placement
DECAL PLACEMENT TW26 ©2017 Alamo Group Inc. Parts Section -8... - Page 11 DECAL, DANGER THROWN OBJECT D388 DECAL, DANGER PTO 00756004 DECAL, DANGER-SHIELD MISSING 00792284 SHEET, DECAL LOGO-TW25 00792307 DECAL, RHINO BLACK 7.5" X 34.5" 00792180 DECAL, FLAG-MADE IN USA 00792376 DECAL, TW26 MODEL ----- DECAL, DANGER/GREASE (D389-814-590) 00760657 DECAL, SAFETY WARNING...
-
Page 12: Deflector Assembly
DEFLECTOR ASSEMBLY TW26 ©2017 Alamo Group Inc. Parts Section -10... - Page 13 ITEM PART NO. QTY. DESCRIPTION 4528 NUT, HEX LOCK 3/8-16 FLG WHIZ 000644 CARB-3/8 NCK 1-1/4 PL5 00792368 PANEL, FRONT RUBBER DEFLECTOR 00792366 FLAT, DEFLECTOR STRAP 00792369 PANEL, REAR RUBBER DEFLECTOR 00792367 BRACKET, REARDEFLECTOR TW26 ©2017 Alamo Group Inc. Parts Section -11...
-
Page 14: Deflector Side Assembly
DEFLECTOR SIDE ASSEMBLY ITEM PART NO. QTY. DESCRIPTION 00792361 STRAP, SIDE SKIRT DEFLECTOR 00792362 DEFLECTOR,RUBBER SIDE SKIRT 4528 NUT FLG SER 3/8-16 PLB 000644 CARRIAGE BOLT 3/8 NC 1-1/4 PL5 TW26 ©2017 Alamo Group Inc. Parts Section -12... - Page 15 BLANK INTENTIONALLY TW25 ©2017 Alamo Group Inc. Parts Section -13...
-
Page 16: Driveline Assembly - 00789043 Cat3 Slipclutch
DRIVELINE ASSEMBLY - 00789043 CAT3 SLIPCLUTCH TW26 ©2017 Alamo Group Inc. Parts Section -14... - Page 17 ASY,CROSS KIT 00789307 ASY,FRICTION CLUTCH KIT 00789308 SPRING AND BOLT KIT 00789309 CLAMP BOLT/NUT FOR HUB 00768347 FRICTION DISC 00756004 DECAL,DANGER - GUARD MISSING 00756005 DECAL, ROTATING DRIVELINE 00789044 SHIELD,DRIVELINE - COMPLETE TW26 ©2017 Alamo Group Inc. Parts Section -15...
-
Page 18: Gearbox Assembly - 00791028 -1:1.47 No-Lube 540Rpm
GEARBOX ASSEMBLY - 00791027 -1:1.47 NO-LUBE 540RPM TW26 ©2017 Alamo Group Inc. Parts Section -16... - Page 19 00754773 SHIELD, PROTECTIVE - 40.1 X 79.9 X 1 70487 PIN, COTTER M4 X 40 70497 PIN, COTTER M5 X 50 00790985 PLUG, VENT M16-1.5 00790983 SEALING WASHER 4038609 DIPSTICK, OIL- EZ40 TW26 ©2017 Alamo Group Inc. Parts Section -17...
-
Page 20: Shield Assembly
ITEM PART NO. QTY. DESCRIPTION 00785575 SHIELD,BLACK GEARBOX 00785574 RING,GB SHIELD INNER SUPPORT 00791651 HEXB SER FLG M8-20MM 1.25 P 10.9 00695100 NUT, TOPLOCK 5/8 NC PLC 00785946 KIT/ GEARBOX SHIELD & RING TW26 ©2017 Alamo Group Inc. Parts Section -18... - Page 21 BLANK INTENTIONALLY TW25 Parts Section - 19 ©2017 Alamo Group Inc.
-
Page 22: Tailwheel & Canister Assembly
TAILWHEEL & CANISTER ASSEMBLY TW26 ©2017 Alamo Group Inc. Parts Section -20... - Page 23 02845600 HEXB 5/8 NC 3 PL5 00780869 NUT, FLG 5/8NC SPIRALOCK PL5 00792280 BUSHING, SHOULDER 5/8" 00790116 BUSHING, WING AXLE PIVOT 00776031 CANISTER, PARTS MANUAL 00780878 RIVET, 3/16 POP X 15/32" G.R. TW26 ©2017 Alamo Group Inc. Parts Section -21...
- Page 24 WARRANTY 1. LIMITED WARRANTIES 1.01. Servis-Rhino warrants for one year from the purchase date to the original non-commercial, governmental, or municipal purchaser (“Purchaser”) and warrants for six months to the original commercial or industrial purchaser (“Purchaser”) that the goods purchased are free from defects in material or workmanship.
- Page 25 TO THE OWNER/OPERATOR/DEALER The OCCUPATIONAL SAFETY AND HEALTH ACT (1928.51 Subpart C) makes these minimum safety require- ments of tractor operators: REQUIRED OF THE OWNER: 1. Provide a Roll-Over-Protective Structure that meets the requirements of this Standard; and 2. Provide Seatbelts that meet the requirements of this paragraph of this Standard and SAE J4C; and 3.
- Page 26 TW25 Part No. 00792299P Printed U.S.A.
