- Page 1 Models: REFRIGERANT R290 PH26C POLOCOOL Portable Room Air Conditioner Operation & Installation Manual Page 1...
- Page 2 Before proceeding with the operation of your new Rinnai Portable Room Air Conditioner, please read this manual thoroughly and gain a full understanding of the requirements, features and operation of your new appliance.
-
Page 3: Table Of Contents
Table of Contents Safety Precautions Important Information ..........................04 Safety Precautions ..........................05 Introduction Introduction ............................13 Specifications ............................14 Installation Instructions Preparation ............................15 Design Notice ............................15 Ambient Temperature Range For Unit Operating ..................15 Exhaust Hose Installation ........................15 Choosing The Right Location ........................16 Energy Rating Information ........................16 Tools Needed ............................16 Accessories ............................16 Window Installation Kit ..........................17... -
Page 4: Important Information
Important Information Important Issues Regarding the Proper Use of this Air Conditioner Please contact your supplier for advice before returning unit Use this air conditioner only as described in this instruction manual. This appliance is fitted with a special safety device. When the compressor switches off or when the appliance is first turned on, this device prevents the compressor from switching on again for at least three minutes. -
Page 5: Safety Precautions
Safety Precautions Read Safety Precautions Before Operation and Installation To prevent death or injury to the user or other people and property damage, the following instructions must be followed. Incorrect operation due to ignoring of instructions may cause death, harm or damage. CAUTION WARNING This symbol indicates the possibility of... - Page 6 In a thunderstorm, the power must be cut off to avoid damage to the machine due to lightning. • Your air conditioner should be used in such a way that it is protected from moisture. • e.g. condensation, splashed water, etc. Do not place or store your air conditioner where it can fall or be pulled into water or any other liquid.
- Page 7 Disconnect the power if strange sounds, smell, or smoke comes from it. • • Do not press the buttons on the control panel with anything other than your fingers. Do not remove any fixed covers. Never use this appliance if it is not working properly, or if it has •...
- Page 8 WARNING for Using R290 Refrigerant Do not use means to accelerate the defrosting process or to clean, other than those recommended by the manufacturer. The appliance shall be stored in a room without continuously operating ignition sources (for example: open flames, an operating gas appliance or an operating electric heater). Do not pierce or burn.
- Page 9 1.Transport of equipment containing flammable refrigerants See transport regulations 2.Marking of equipment using signs See local regulations 3.Disposal of equipment using flammable refrigerants See national regulations. 4.Storage of equipment/appliances The storage of equipment should be in accordance with the manufacturer's instructions. 5.Storage of packed (unsold) equipment Storage package protection should be constructed such that mechanical damage to the equipment inside the package will not cause a leak of the refrigerant charge.
- Page 10 8)Checks to the refrigeration equipment Where electrical components are being changed, they shall be fit for the purpose and to the correct specification. At all times the manufacturer's maintenance and service guidelines shall be followed. If in doubt consult the manufacturer's technical department for assistance. The following checks shall be applied to installations using flammable refrigerants: The charge size is in accordance with the room size within which the refrigerant containing parts are installed;...
- Page 11 9.Cabling Check that cabling will not be subject to wear, corrosion, excessive pressure, vibration, sharp edges or any other adverse environmental effects. The check shall also take into account the effects of aging or continual vibration from sources such as compressors or fans. 10.Detection of flammable refrigerants Under no circumstances shall potential sources of ignition be used in the searching for or detection of refrigerant leaks.
- Page 12 14.Decommissioning Before carrying out this procedure, it is essential that the technician is completely familiar with the equipment and all its detail. It is recommended good practice that all refrigerants are recovered safely. Prior to the task being carried out, an oil and refrigerant sample shall be taken in case analysis is required prior to re-use of reclaimed refrigerant.
-
Page 13: Introduction
Introduction This portable air conditioner can alter the room temperature and humidity. It has multiple functions of cooling dehumidifying (drying) and fan ventilation, and can be moved from room to room and transported from building to building easily. In addition, the desired humidity level can be set between 35-85%. The air conditioner can maintain set room indoor air temperatures between 17°C and 30°C. -
Page 14: Specifications
For safety and warranty purposes, appliances that may be damaged or incorrect MUST NOT be installed or operated under any circumstances. Installation of damaged or incorrect appliances may contravene local government regulations. Rinnai disclaims any liability or responsibility whatsoever in relation to the installation or operation of damaged or incorrect appliances. Page 14... -
Page 15: Installation Instructions
Installation Instructions Preparation NOTE: All the illustrations in the manual are for explanation purpose only. Your machine may be slightly different. The actual shape shall prevail. The unit can be controlled by the unit control panel alone or with the remote controller. -
Page 16: Choosing The Right Location
Choosing The Right Location Your installation location should meet the following requirements: -Make sure that you install your unit on an even surface to minimize noise and vibration. -The unit must be installed near a grounded plug, and the Collection Tray Drain (found on the back of the unit) must be accessible. -
Page 17: Window Installation Kit
Shape Qty. Shape Qty. Name of Accessories Name of Accessories Unit Adaptor 1 pc Security Bracket and 2 Screws 1 set(*) Exhaust Hose 1 pc Drain Hose 1 pc Window Slider Adaptor 1 pc(*) Bolt 1 pc(*) Remote Controller and Battery Window Slider A 1 pc(*) 1 set(*) -
Page 18: Installation
Bolt Step Three: Preparing the Adjustable Window Slider Window slider A Window slider B 1. Depending on the size of your window, adjust the size of the window slider. 2. If the length of the window requires two or three Bolts window sliders, use the bolt(s) to fasten the window sliders once they are adjusted to the... - Page 19 Security Bracket Security Bracket 2 Screws 2 Screws 4. If desired, install the security bracket with 2 screws as shown. 5. Insert the window slider adaptor into the hole of the window slider. NOTE: To ensure proper function, DO NOT overextend or bend the hose. Make sure that there is no obstacle around the air outlet of the exhaust hose (in the range of 500mm) in order to the exhaust system works properly.
-
Page 20: Operating Instructions
Operating Instructions Control Panel Features NOTE: The following control panels are for explanation purpose only. The control panel of the unit you purchased may be slightly different according to the models. Your machine may not contain some indicators or buttons. The actual shape shall prevail. Auto Heat Wireless... -
Page 21: Operation Instructions
Operation Instructions COOL operation NOTE: Under AUTO mode, both the AUTO mode and · Press the "MODE" button until the "COOL" indicator the actual operation mode indicator lights illuminate light comes on. for some models. · Press the ADJUST buttons "+" or "-" to select your desired room temperature. - Page 22 thermostat allowing for the precise temperature end of the hose directly over the drain area in your control at its location. To activate the Follow Me/Temp basement floor. Continuous Sensing feature, point the remote control towards the drain hose unit and press the Follow Me/Temp Sensing button. Remove the The remote control will send this signal to the air drain plug...
-
Page 23: Operating From The Remote Control
Operating from the Remote Control Description of the Remote Control DESCRIPTION OF THE REMOTE CONTROL 1. ON/OFF button – press this button to switch the appliance ON/OFF 2. Mode indicator –Press this button to select modes of Auto/Cool/Dry (dehumidify)/ 3. Fan button – Press mode button to select FAN mode. As button is pressed LOW/ HIGH/AUTO fan speeds are selected 4. -
Page 24: Remote Control Functions
Remote Control Functions OPERATING FROM THE REMOTE CONTROL ON / OFF Button Press the ON/OFF orange button to turn the unit ON or OFF. The unit will beep when the remote signal is received. will appear in remote display when the unit is ON. SETTING TEMPERATURE The operating temperature range for the unit is 17-30°C You can increase or decrease the set temperature in 1°C increments... -
Page 25: Setting The Timer
Setting the Timer OPERATING FROM THE REMOTE CONTROL SETTING THE TIMER FUNCTION Your air conditioning unit has two timer-related functions: • TIMER ON - sets the amount of timer after which the unit will automatically turn on. • TIMER OFF - sets the amount of time after which the unit will automatically turn off. - Page 26 OPERATING FROM THE REMOTE CONTROL SETTING BOTH TIMER ON AND TIMER OFF AT THE SAME TIME Keep in mind that the time periods you set for both functions refer to hours after the current time. For example, say that the current time is 1:00 PM, and you want the unit to turn on automatically at 7:00 PM.
-
Page 27: Advanced Functions
Advanced Functions OPERATING FROM THE REMOTE CONTROL HOW TO USE THE ADVANCED FUNCTIONS SLEEP Function The SLEEP function is used to decrease energy use while you sleep (and don’t need the same temperature settings to stay comfortable). This function can only be activated via remote control. -
Page 28: Maintenance
Maintenance Safety Precautions · Always unplug the unit before cleaning or servicing. · DO NOT use flammable liquids or chemicals to clean the unit. · DO NOT wash the unit under running water. Doing so causes electrical danger. · DO NOT operate the machine if the power supply was damaged during cleaning. A damaged power cord must be replaced with a new cord from the manufacturer. -
Page 29: Troubleshooting Tips
Troubleshooting Tips Problem Possible Causes Solution The Water Collection Tray is full. Turn off the P1 Error Code unit, drain the water from the Water Collection Tray and restart the unit. Unit does not turn on when pressing In COOL mode: room ON/OFF button temperature is lower than Reset the temperature... -
Page 30: Terms Of Warranty
Terms of Warranty - Australia Rinnai Australia Pty. Ltd. ABN 74 005 138 769, 100 Atlantic Drive, Keysborough VIC 3173. NOTICE TO CONSUMERS UNDER AUSTRALIAN CONSUMER LAW Our goods and services come with guarantees that cannot be excluded under the Australian Consumer Law. - Page 31 Normal Business Hours by an Authorised Service Representative. Repair by persons other than an Authorised Service Representatives may void the Warranty. 2.4 Alternatively to clause 2.3 above, Rinnai can at its discretion elect to pay you an amount equivalent to the cost of repairing or replacing the Product.
- Page 32 “7 Purchaser’s Responsibilities” on page 33; c) notifies Rinnai within 30 days of a defect occurring or, in the case of a latent defect, becoming apparent, that a claim is being made under this Warranty; and d) provides, in support of the claim made under this Warranty, a Proof of Purchase.
- Page 33 Rinnai to enquire about alternative arrangements. If you wish to make a warranty claim in respect of any fixed Product, please contact Rinnai on the details set out below to make arrangements for an Authorised Service Representative to inspect the product.
- Page 34 NOTES Page 34...
- Page 35 NOTES Page 35...
- Page 36 Monday to Friday, 8.00 am to 5.00 pm EST. *Cost of a local call higher from mobile or public phones. www.mypolo.com.au For further information visit www.rinnai.com.au or email enquiry@rinnai.com.au innai has a Service and Spare Parts network with personnel who are fully trained and equipped to give the best service on your innai appliance.
