- Page 1 MODEL REFRIGERANT PQ10CWF (Whisper) R290 POLOCOOL Portable Room Air Conditioner Operation & Installation Manual Page 1...
- Page 2 POLOCOOL Portable Refrigerated Air Conditioners are imported and distributed throughout Australasia by Rinnai Australia Pty Ltd. For continued safety of this appliance it must be installed and maintained in accordance with the manufacturer’s instructions. Before proceeding with the operation of your...
-
Page 3: Table Of Contents
Table of Contents Safety Precautions Important Information ..........................04 Safety Precautions ..........................05 Introduction Introduction ............................13 Specifications ............................14 Description and Function ........................15 Installation Instructions Preparation ............................16 Window Slider Installation ........................17 Operating Instructions Control Panel Features .........................18 Operation Instructions ...........................19 Operating from the Remote Control Description of the Remote Control .......................20 Remote Control Functions ........................21 Setting the Timer ...........................22... -
Page 4: Important Information
Important Information Important Issues Regarding the Proper Use of this Air Conditioner Please contact your supplier for advice before returning unit Use this air conditioner only as described in this instruction manual. This appliance is fitted with a special safety device. When the compressor switches off or when the appliance is first turned on, this device prevents the compressor from switching on again for at least three minutes. -
Page 5: Safety Precautions
Safety Precautions Read Safety Precautions Before Operation and Installation Read Safety Precautions before Operation and Installation. To prevent death or injury to the user or other people and property damage, the To prevent death or injury to the user or other people and property damage, the following instructions MUST be following instructions must be followed. - Page 6 In a thunderstorm, the power must be cut off to avoid damage to the machine due to lightning. • Your air conditioner should be used in such a way that it is protected from moisture. • e.g. condensation, splashed water, etc. Do not place or store your air conditioner where it can fall or be pulled into water or any other liquid.
- Page 7 Disconnect the power if strange sounds, smell, or smoke comes from it. • • Do not press the buttons on the control panel with anything other than your fingers. Do not remove any fixed covers. Never use this appliance if it is not working properly, or if it has •...
- Page 8 Using R290 Refrigerant WARNING Do not use means to accelerate the defrosting process or to clean, other than those recommended by the manufacturer. The appliance shall be stored in a room without continuously operating ignition sources (for example: open flames, an operating gas appliance or an operating electric heater). Do not pierce or burn.
- Page 9 1.Transport of equipment containing flammable refrigerants See transport regulations 2.Marking of equipment using signs See local regulations 3.Disposal of equipment using flammable refrigerants See national regulations. 4.Storage of equipment/appliances The storage of equipment should be in accordance with the manufacturer's instructions. 5.Storage of packed (unsold) equipment Storage package protection should be constructed such that mechanical damage to the equipment inside the package will not cause a leak of the refrigerant charge.
- Page 10 8)Checks to the refrigeration equipment Where electrical components are being changed, they shall be fit for the purpose and to the correct specification. At all times the manufacturer's maintenance and service guidelines shall be followed. If in doubt consult the manufacturer's technical department for assistance. The following checks shall be applied to installations using flammable refrigerants: The charge size is in accordance with the room size within which the refrigerant containing parts are installed;...
- Page 11 9.Cabling Check that cabling will not be subject to wear, corrosion, excessive pressure, vibration, sharp edges or any other adverse environmental effects. The check shall also take into account the effects of aging or continual vibration from sources such as compressors or fans. 10.Detection of flammable refrigerants Under no circumstances shall potential sources of ignition be used in the searching for or detection of refrigerant leaks.
- Page 12 14.Decommissioning Before carrying out this procedure, it is essential that the technician is completely familiar with the equipment and all its detail. It is recommended good practice that all refrigerants are recovered safely. Prior to the task being carried out, an oil and refrigerant sample shall be taken in case analysis is required prior to re-use of reclaimed refrigerant.
-
Page 13: Introduction
Introduction This portable air conditioner can alter the room temperature and humidity. It has multiple functions of cooling dehumidifying (drying) and fan ventilation, and can be moved from room to room and transported from building to building easily. In addition, the desired humidity level can be set between 35-85%. The air conditioner can maintain set room indoor air temperatures between 17°C and 35°C (Cooling). -
Page 14: Specifications
For safety and warranty purposes, appliances that may be damaged or incorrect MUST NOT be installed or operated under any circumstances. Installation of damaged or incorrect appliances may contravene local government regulations. Rinnai disclaims any liability or responsibility whatsoever in relation to the installation or operation of damaged or incorrect appliances. -
Page 15: Description And Function
Description and Function 1. Control Panel 10. Lower Air Intake 20. Power cord winder bracket Controls the functions of the air Air intake to condenser Pushes into power cord buckle. conditioner Store power cord by winding around 11. Power Plug Socket this bracket 2. -
Page 16: Installation Instructions
Installation Instructions 50cm Preparation SELECTION OF INSTALLATION LOCATION (Fig.3) Fig. 3 Place the portable air conditioner in a flat location where the air inlets and outlets cannot be covered up. Place the unit no less than 50cm away from a wall or other obstacle. In addition a minimum 50cm clearance is required from all faces of the air conditioner including the 50cm clearance rear face. -
Page 17: Window Slider Installation
Window Slider Installation The window slider has been designed to fit most standard “vertical” and “horizontal” window applications. It may be necessary for you to improvise/modify some aspects of the installation procedures for certain types of windows. Some window types may require the use of cardboard or plastic fillers and/or duct tape to install. Additional complete window kits may be purchased from POLO to enable pre-installation in windows in other rooms. -
Page 18: Operating Instructions
Operating Instructions Control Panel Features SWING button Used to initiate the Auto swing feature. When the operation is ON, press the SWING button can stop the louver at the desired angle. FAN BUTTON Control the fan speed. Press to select the fan speed in three steps - LOW, HIGH and AUTO. -
Page 19: Operation Instructions
Operation Instructions Press ON/OFF button to turn appliance on. COOL Operation Press the “MODE” button until the “COOL” indicator light comes on. Press the ADJUST buttons “+” or “-” to select your desired room temperature. The temperature can be set within a range of 17°C~30°C. -
Page 20: Operating From The Remote Control
Operating from the Remote Control Description of the Remote Control DESCRIPTION OF THE REMOTE CONTROL 1. ON/OFF button – press this button to switch the appliance ON/OFF 2. Mode indicator –Press this button to select modes of Auto/Cool/Dry (dehumidify)/ 3. Fan button – Press mode button to select FAN mode. As button is pressed LOW/ HIGH/AUTO fan speeds are selected 4. -
Page 21: Remote Control Functions
Remote Control Functions OPERATING FROM THE REMOTE CONTROL ON / OFF Button Press the ON/OFF orange button to turn the unit ON or OFF. The unit will beep when the remote signal is received. will appear in remote display when the unit is ON. SETTING TEMPERATURE The operating temperature range for the unit is 17-30°C You can increase or decrease the set temperature in 1°C increments... -
Page 22: Setting The Timer
Setting the Timer OPERATING FROM THE REMOTE CONTROL SETTING THE TIMER FUNCTION Your air conditioning unit has two timer-related functions: • TIMER ON - sets the amount of timer after which the unit will automatically turn on. • TIMER OFF - sets the amount of time after which the unit will automatically turn off. - Page 23 OPERATING FROM THE REMOTE CONTROL SETTING BOTH TIMER ON AND TIMER OFF AT THE SAME TIME Keep in mind that the time periods you set for both functions refer to hours after the current time. For example, say that the current time is 1:00 PM, and you want the unit to turn on automatically at 7:00 PM.
-
Page 24: Advanced Functions
Advanced Functions OPERATING FROM THE REMOTE CONTROL HOW TO USE THE ADVANCED FUNCTIONS SLEEP Function The SLEEP function is used to decrease energy use while you sleep (and don’t need the same temperature settings to stay comfortable). This function can only be activated via remote control. -
Page 25: Wireless Operation
Wireless Operation Visit your device app store (iOS or Android) to download the NetHome Plus APP. Once installed follow the procedure below to pair the device with your appliance. Please ensure your mobile device is connected to Wireless router. Also, the Wireless router has already connected to Internet before doing user registration and network configuration. -
Page 26: Maintenance
Maintenance Safety Precautions · Always unplug the unit before cleaning or servicing. · DO NOT use flammable liquids or chemicals to clean the unit. · DO NOT wash the unit under running water. Doing so causes electrical danger. · DO NOT operate the machine if the power supply was damaged during cleaning. A damaged power cord must be replaced with a new cord from the manufacturer. -
Page 27: Self Diagnosis
Self Diagnosis LED display Shows the set temperature in °C or °F and the Auto-timer settings and the humidity settings (only for models with humidity sensor). While on DRY and FAN modes, it shows the room temperature. Shows Error codes and protection code: E1 - Room temperature sensor error. -
Page 28: Water Drainage Method
Water Drainage Method Water Drainage - continuous During dehumidifying modes, remove the upper drain plug from the back of the unit and securely attached the drain hose to the hole so there are no leaks. Remove the upper drain plug Continuous drain hose Water Drainage when bottom tray / tank fill... -
Page 29: Troubleshooting Tips
Troubleshooting Please check the machine according to the following form before asking for maintenance: PROBLEM POSSIBLE CAUSE TROUBLESHOOTING P1 Error Code The Water Collection Tray is full. Turn off the unit, drain the water from the Water Collection Tray and restart the Unit does not turn on unit. -
Page 30: Terms Of Warranty
Terms of Warranty - Australia Rinnai Australia Pty. Ltd. ABN 74 005 138 769, 100 Atlantic Drive, Keysborough VIC 3173. DEFINITIONS The terms listed below shall have the following meanings: “Authorised Service Representative” means an independent service contractor authorised by Rinnai or Rinnai service personnel. - Page 31 Normal Business Hours by an Authorised Service Representative. Repair by persons other than an Authorised Service Representatives may void the Warranty. 2.4 Alternatively to clause 2.3 above, Rinnai can at its discretion elect to pay you an amount equivalent to the cost of repairing or replacing the Product.
- Page 32 7 “Purchaser’s Responsibilities” on page 33; c) notifies Rinnai within 30 days of a defect occurring or, in the case of a latent defect, becoming apparent, that a claim is being made under this Warranty; and d) provides, in support of the claim made under this Warranty, a Proof of Purchase.
- Page 33 Rinnai to enquire about alternative arrangements. If you wish to make a warranty claim in respect of any fixed Product, please contact Rinnai on the details set out below to make arrangements for an Authorised Service Representative to inspect the product.
- Page 34 NOTICE TO CONSUMERS UNDER AUSTRALIAN CONSUMER LAW Our goods and services come with guarantees that cannot be excluded under the Australian Consumer Law. For a major failure with a good, you are entitled to a replacement or refund and compensation for any other reasonable foreseeable loss or damage.
- Page 35 Page 35...
- Page 36 *Cost of a local call higher from mobile or public phones. (National calls from public phones in Australia are free.) www.mypolo.com.au For further information visit www.rinnai.com.au or email enquiry@rinnai.com.au innai has a Service and Spare Parts network with personnel who are fully trained and equipped to give the best service on your innai appliance.
