Strand Acclaim LED PLE Quick Start Manual

ACCLAIM LED PLE

OVERVIEW

This document provides basic setup instructions and safety
warnings for the following product(s):
Acclaim LED PLE (black body)
Acclaim LED PLE (white body)

INSTALLATION AND SETUP

MOUNTING

The unit should be mounted via its screw holes on the bracket. Always
ensure that the unit is fi rmly fi xed to avoid vibration and slipping while
operating. Always ensure that the structure to which you are attaching
the unit is secure and is able to support a weight of 10 times of the unit's
weight. Always use a safety cable that can hold up to 12 times the weight
of the unit when installing the fi xture.
The luminaire must be mounted by professionals.

SET UP

QUICK REFERENCE DMX MAPS

8-BIT CHANNEL MODE
D MX
CHA N N E L
1
2
3
4
5
6
64511-003
64511-103
3 5
1 2
4
PA RA ME T ER
Intensity (16-bit high)
Strobe
Red (16-bit high)
Green (16-bit high)
Blue (16-bit high)
Lime (16-bit high)
912400576889
912400576890
NOTE: Lens tube sold separately
1
2
3
4
5
6
6
16-BIT CHANNEL MODE
D MX
C HANNEL
2
3
4
5
6
7
8
9
10
11
1
QUICK START GUIDE

INCLUDED ITEMS

QUICK START
GUIDE
ACCLAIM LED PLE
HANGING
BRACKET
LCD display - shows menu and selected function
Buttons:
MENU - to select programming functions
DOWN - to go forward in selected functions
UP - to go backward in selected functions
ENTER - to confi rm the selected function
POWER IN - connects to power supply
POWER OUT - connects to next fi xture
DMX IN - 5-pin XLR cable to link the DMX
console
DMX OUT - 5-pin XLR cable to link next fi xture
P ARAM ETER
1 Intensity (16-bit high)
Intensity (16-bit low)
Strobe
Red (16-bit high)
Red (16-bit low)
Green (16-bit high)
Green (16-bit low)
Blue (16-bit high)
Blue (16-bit low)
Lime (16-bit high)
Lime (16-bit low)
9850-000840-00
POWER
CONNECTOR
WARRANTY
CARD
CLAMP
