Summary of Contents for Kongsberg Simrad IS15 Rudder

  • Page 1 Simrad IS15 Rudder A L W A Y S T H E F O R E F R O N T T E C H N O L O G Y...
  • Page 2 Note! Simrad AS makes every effort to ensure that the information contained within this document is correct. However, our equipment is continuously being improved and updated, so we cannot assume liability for any errors which may occur. Warning! The equipment to which this manual applies must only be used for the purpose for which it was designed.
  • Page 3 IS15 as NMEA Repeater This manual is intended as a reference guide for operating and correctly installing the Simrad IS15 Rudder instrument. Please take time to read the manual to get a thorough understanding of the operation and installation. Other documentation material that is provided with your system includes a ‘bridge card’, and Terms of Warranty.

  • Page 4: Table Of Contents

    IS15 Rudder Manual Contents INTRODUCTION ............... 5 Stand alone IS15 Rudder ..........5 Equipment supplied ............ 6 OPERATION OF IS15 RUDDER ........7 General Description ............ 7 Powering Up ............... 8 Display backlighting ........... 9 The Heading Display ..........9 Alarm Sounding ............

  • Page 5: Introduction

    Introduction INTRODUCTION Stand alone IS15 Rudder The IS15 Rudder instrument may be used as a stand-alone rudder indicator shown in Figure 1-1. More instruments (max 3 units with Roblink Power cable) may be added to the system by using single cables in a “daisy chain”. Instructions for installing the rudder feedback unit are found in chapter 4.2.

  • Page 6: Equipment Supplied

    IS15 Rudder Manual Equipment supplied Each IS15 Rudder Instrument is supplied with the following parts: • IS15 Roblink cable 0,3 m • IS15 Roblink Power Cable 2,5 m • IS15 Rudder Manual • IS15 Rudder Quick Reference Guide • Mounting kit •...

  • Page 7: Operation Of Is15 Rudder

    Operation OPERATION OF IS15 RUDDER oraabo PORT STBD Pointer Scale LCD Arrow Legend LOCK Left button Right button LCD display General Description The display is divided into two sections, the scale with pointer, and the LCD. Both are controlled by the two buttons. The Scale The pointer indicates the rudder angle and the scale has markings of “0”...

  • Page 8: Powering Up

    IS15 Rudder Manual • Locked Course/Direction to steer There are two arrows at the top of the LCD indicating what data is being displayed at any one time. The arrow legend is printed on the scale. The right arrow points to LOCK for ‘Locked Course’...

  • Page 9: Display Backlighting

    Operation Display backlighting Press the button and hold for 2 seconds. The display then presents the backlighting level. Repeat pressing until desired backlighting level. Selectable values are 1-7 and off (0). The Heading Display The Heading Display is the first display that is shown after power up.
  • Page 10 IS15 Rudder Manual 2. To select or increase an easterly variation value, apply short presses on the button. The reading will be positive. 3. To select or increase a westerly variation value, apply short presses on the button. The reading will be negative. 4.

  • Page 11: Alarm Sounding

    Operation Press and hold the button for 2 seconds to enter the new setting. The display will stop flashing and the arrow points in the direction to steer, while the digits on the LCD show how much the boat is off the new set course. Alarm Sounding If the IS15 Rudder is integrated in an IS15 Instrument system it will sound and flash a warning message in the event there is an...

  • Page 12: Technical Specifications

    IS15 Rudder Manual TECHNICAL SPECIFICATIONS Rudder Angle Scale Full deflection adjustable for any h.o. angle between ±20° and ±45°. Divisions: Marking per each 1/8 of full deflection. Accuracy: ±2° of full scale deflection. Heading Functions Heading Display (Digital) 0 to 359° Heading Resolution 1°...
  • Page 13 Technical Specifications Inputs Rudder angle: 2-wire p.w.m. (RF300 Feedback Unit) NMEA 0183, RSA Roblink (IS15 system) Compass heading: NMEA 0183, HDG, HDM, HDT Outputs Rudder angle: NMEA 0183, RSA, 5 Hz * Compass heading: NMEA 0183, HDG Other: NMEA 0183 sentences according to IS15 NMEA in/out table in IS15 General Manual.

  • Page 14: Installation

    IS15 Rudder Manual INSTALLATION Mounting of Instrument head Caution Do not install the instrument where moisture at the rear could be present. It can cause damage by entering the breathing hole or by coming into contact with the electrical connectors. The instrument head is fully waterproof from the front and can be installed on deck or below.

  • Page 15: Installing Rf300 Rudder Feedback

    Installation 1. Do not remove the protection film on the display before the installation and set-up is completed. 2. Carefully position the self-adhesive template provided on the surface where the display head is to be mounted. Allow sufficient space for the protection cover as shown on the template when instruments are installed adjacent to each other.
  • Page 16 IS15 Rudder Manual transmission link. The slots enable maximum flexibility to provide the 1:1 mechanical linkage relationship. Note ! Do not try to remove the transmitter arm from the feedback unit. The unit is factory adjusted and need no further adjustment at installation than described below.
  • Page 17 Installation Figure 4-2 RF300 mounting Note ! Due to space limitations, it may be necessary to cut the length of the transmitter rod to move the RF300 closer to the rudder post. Tighten the mounting screws for both the RF300 feedback unit and the transmitter rod ball joint.

  • Page 18: Cabling

    IS15 Rudder Manual Cabling IS15 RUDDER IS15 RUDDER IS15 COMBI ROBLINK SENSOR NMEA ROBLINK SENSOR NMEA ROBLINK SENSOR NMEA ROBLINK ROBLINK ROBLINK IS15 Power Cable Hdg input (NMEA) QUICK CONNECTOR RF300 With code R04 or higher Figure 4-3 Three IS15 instruments supplied via IS15 Power Cable Notes ! 1.
  • Page 19 Installation IS15 RUDDER ROBLINK SENSOR NMEA ROBLINK SENSOR NMEA ROBLINK ROBLINK ROBLINK SENSOR NMEA ROBLINK SENSOR NMEA ROBLINK ROBLINK Hdg (NMEA) (To J3XX TX1+/TX1-) Alternatively to Autopilot J3XX RF+/RF- IS15 TRANSCEIVER RF300 IS15 EXPANDER IS15 POWER SUPPLY Figure 4-4 IS15 Rudder integrated in IS15 system Note ! RF300 to be connected to IS15 Rudder only.
  • Page 20 IS15 Rudder Manual Alternative 1: IS15 Rudder off when autopilot off J3XX IS15 RUDDER IS15 RUDDER MAIN POWER ROBLINK SENSOR NMEA ROBLINK SENSOR NMEA ROBLINK ROBLINK Max. 2 IS15 Power cable IS15 RUDDER SUPPLY 10,8-31,2 RF300 Figure 4-5 Connection to “X”-series autopilots, alternative 1 Note ! Rudder instrument “Sensor”...
  • Page 21 Installation Alternative 2: IS15 Rudder on when autopilot off J3XX IS15 RUDDER IS15 RUDDER POWER MAIN ROBLINK SENSOR NMEA ROBLINK SENSOR NMEA ROBLINK ROBLINK Max. 2 IS15 Power cable Roblink IS15 RUDDER SUPPLY 10,8-31,2 RF300 Figure 4-6 Connection to “X”-series autopilots, alternative 2 Note ! In alternative 2 a slight change in the readout may be observed with the autopilot off.
  • Page 22 IS15 Rudder Manual ADDENDUM TO IS15 RUDDER MANUAL Connection to older revision J3XX Junction Units Figure 4-7 is only valid for J3XX Junction units that contain Main PCB revision D or older (A, B, C). Note ! Connect the optional RI35Mk2 Limiter (P/N 22084990) as shown when: •...

  • Page 23: Setting Up The Rudder Instrument

    IS15 Rudder Manual SETTING UP THE RUDDER INSTRUMENT First time turn on Note ! Turn on the NMEA “listener(s)” and “talker(s)” that are connected to the IS15 Rudder before the first time you turn it on (also when you turn on after a COMMUNICATION RESET or a MASTER RESET).
  • Page 24 Setting-Up Note ! When assigning more than one instrument to a system, allow an interval between each assignment, while/if the display is showing “– – –“. When an instrument is replaced, it is important that a Master Reset has been made on the new one before it is connected to the system.

  • Page 25: Installation And Calibration Menu

    IS15 Rudder Manual Installation and Calibration Menu The installation menu is arranged as follows: Screen Display Screen 1 Screen 2 Screen 3 Screen 4 Digital Shop mode Illumination Heading offset Heading T/M (on/off) bank 10 sec. 0 = no bank 1 = bank 1 2 = bank 2 Screen...
  • Page 26 Setting-Up To enter Installation Menu: 1. Press the button and hold for 10 seconds to access the Installation Menu. 2. Apply a short press on the button to select one of the LCD screens in the Installation Menu. 3. Press the button, hold for 2 seconds and release to access a setting.
  • Page 27 IS15 Rudder Manual Screen 2 HEADING OFFSET [OFFS] The Heading Offset feature allows you to correct for a permanent heading offset. 1. Activate the Heading Offset by pressing and holding the button for 2 seconds. The reading starts flashing. 2. Increase the compass reading using the button or decrease the compass reading using the button.
  • Page 28 Setting-Up Note ! If there is an active ‘talker’ connected to the NMEA port, you will not be able to change this port from ‘IN’ to an ‘OUT’ port unless the ‘talker’ is disconnected. Screen 6 SCALE ADJUST [I This screen is for scale calibration. Any rudder angle between ±20°...
  • Page 29 IS15 Rudder Manual compensates for any drag caused by the shape of the hull and/or the propellers. Alternatively: When dockside, turn the rudder to midship position and perform the adjustment. The IS15 Rudder is now showing the correct rudder midship position. Screen 8 MANUAL RUDDER OFFSET ADJUST [OFFS] If you already have a rudder angle display on the boat and you...
  • Page 30 Setting-Up Screen 11 ROBLINK ON/OFF [robl] Turning Roblink Off and On is local on each instrument. The display reads robl. Press the button and hold for 2 seconds. The LCD display flashes Id:x, ‘x’ being the instrument’s present Roblink Id. number. Press the button to select Roblink OFF.
  • Page 31 IS15 Rudder Manual Screen 14 MASTER RESET [rES] When a MASTER RESET is performed on one of the instruments in a system it becomes system wide and all instruments are reset to default values. Note ! Do not perform a Master Reset unintentionally because it will default settings and calibration values.

  • Page 32: Fault Finding

    Fault Finding FAULT FINDING If the instrument is part of an IS15 instrument system including one of the following: IS15 Transceiver, IS15 Power Supply or IS15 Expander please refer to the IS15 General manual. If it is connected as a stand alone rudder indicator, then perform the fault finding on that instrument.
  • Page 33 IS15 Rudder Manual Roblink test display The Roblink test display monitors the data flow on the Roblink. On the IS15 Rudder the Roblink test monitors rudder data. • Press and hold the button for 10 seconds to enter the installation menu. •...

  • Page 34: Maintenance

    Maintenance MAINTENANCE General Maintenance Caution Do not use any abrasives, chemical cleaners, petrol or diesel to clean the units. The instrument heads will require no maintenance apart from occasional cleaning. Use fresh water and a mild soap solution (not a detergent). Annual Maintenance Check all connections to the instruments and, if necessary, cover with silicone grease or petroleum jelly.

  • Page 35: Local Master Reset

    IS15 Rudder Manual that all connections are secure, and that a correct supply is present at the Roblink/power connector. Should the unit have to be returned to your dealer, adequate packing must be used. Please ensure that your name, telephone number, return address, a clear fault description, and if possible a copy of the proof of purchase are included with any returned equipment.

  • Page 36: Spare Parts List

    IS15 Rudder Manual SPARE PARTS LIST 22094098 IS15 Rudder Instrument 22094429 IS15 Rudder PROM (programmed) V..R.. 20220950 IS15 Rudder Operator’s Quick Reference Guide 22092837 IS15 Mounting kit consisting of: 22084529 Cabinet corners 44165181 Screw 3.5x32 44160232 Screw (for securing the connectors) 22091854 IS15 Protection cover 22092241 IS15 Panel gasket Roblink Cables...
  • Page 37 IS15 Rudder Manual TERMS OF WARRANTY, SIMRAD AS PRODUCTS SIMRAD warrants that every product shall be free of defects in material and workmanship as specified below: CATEGORY “A”: • Autopilots • Radars • Instruments • Navigators • Radiotelephones • Plotters • Gyro compasses incl.
  • Page 38 Manufacturer: Simrad Egersund AS P.O. Box 55 N-4379 Egersund Norway Telephone: +47 51 46 20 00 Telefax: +47 51 46 20 01 www.simrad.com A L W A Y S T H E F O R E F R O N T T E C H N O L O G Y...
