Features
•
Select from burst/steady, slow whoop, siren, mechanical bell,
Klaxon, night ringer, double chime, and doorbell tones
•
Select 4 of 8 tones to trigger
•
Momentary and continuous playback modes
•
Screw terminal for 4 external trigger connections
•
Level control
•
Microprocessor-controlled operation
•
4 levels of available priority
•
Can be muted from higher priority modules
•
Can mute lower priority modules
TNG1S
Tone Generator Module
Printed in Taiwan.
© 2002 Bogen Communications, Inc.
54-2080-01R2
Specifications subject to change without notice.
0209
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Bogen TNG1S
Summary of Contents for Bogen TNG1S
- Page 1 Level control • Microprocessor-controlled operation • 4 levels of available priority • Can be muted from higher priority modules • Can mute lower priority modules Printed in Taiwan. 0209 © 2002 Bogen Communications, Inc. 54-2080-01R2 Specifications subject to change without notice.
- Page 2 Priority 4 modules. Priority 4 modules are muted by all higher priority modules. If the TNG1S is muted by a higher priority while it is playing a tone, it will abort that tone play- back. If the trigger is still active when the TNG1S is unmuted, the tone will begin playing from the beginning.
- Page 3 Block Diagram MICROPROCESSOR CONTROLLED TONE GENERATOR A B C D E F G H TONE SELECTION Tel. 201-934-8500; Fax: 201-934-9832; www.bogen.com GAIN 50 Spring Street, Ramsey, NJ 07446, U.S.A. MUTING BUS A ASSIGNMENT BUS B...
