Bogen PM3000 Specifications

ProMatrix
Digitally Matrixed
Pre-Amplifier
Model PM3000
Bogen's ProMatrix™ Digitally Matrixed Pre-Amplifier,
Model PM3000, is the ideal solution for restaurant,
Description
lounge/bar, hotel, factory or similar facilities where
multiple audio sources and voice paging inputs need to
be distributed to separate areas and automatically
switched based on input priorities.
The PM3000 provides up to 4 unbalanced aux inputs
and 2 mic inputs that can be individually assigned to
each of 3 output channels (one of the mic inputs can
be programmed for telephone paging applications).
Each input can be assigned a particular priority level
for each output channel; the PM3000 will then auto-
matically switch inputs based on input activity.
• 3 Independent audio channels
• 3 Pre-amp level outputs, both balanced and unbal-
anced
Features
• 4 High-impedance, unbalanced auxiliary inputs
• 2 Microphone inputs; one input can be pro-
grammed to accept a telephone line for paging
• 6 User-assigned priority levels
• Inputs assigned to each output channel auto-switch
based on priority levels assigned
• Each input can be assigned different priority levels
for each of the 3 output channels
• Auxiliary trim controls accommodate a wide range
of auxiliary input signal levels
• Digital interface for quick setup
• Tamper-proof system settings for consistent, fool-
proof operation
• Preset power-up levels of each input for volume,
treble, and bass
• Password-protected programming
™
Microphones can be assigned to priority level 1 or 2
and aux sources to levels 3, 4, 5, or 6. For example, a
paging microphone can be assigned priority level 1, a
jukebox to level 3 and a tuner to level 4. In this con-
figuration, the tuner will play until the jukebox
becomes active; when the page microphone is activat-
ed, it will override both of the other inputs.
With tremendous flexibility for audio control and dis-
tribution in a single unit, the PM3000 is the preferred
solution for multi-zone, multi-input sound manage-
ment.
• Two modes of operation: user and programming
• Program using control panel or wireless infrared
• Output level metering
• Automatic fade-in of audio source after a mic page
• Automatic level control for microphones (selec-
• Choice of microphone page (VOX, N.O., or N.C.
• Phantom power for microphones (selectable)
• Variable music mute levels during mic or tel page
• Rack mountable with kit (RPK79)
• Detachable front panel can be mounted up to 25
• Easy to understand and operate
remote control unit (included)
or when switching to a lower priority
table)
switch)
feet away from main unit using accessory cable
shipped with unit or 250 feet using RMPWMK3
adapter with 22 AWG wire run
Specifications subject to change without notice.
© 2001 Bogen Communications, Inc.
Part No. 54-7883-01R2 Printed in U.S.A. 0109
