- Page 1 Utility Amplifier GA6A Model Installation and Use Manual © 2004 Bogen Communications, Inc. All rights reserved. Specifications subject to change without notice. 54-5757-03B 0406...
-
Page 2: Important Safety Information
Every effort was made to ensure that the information in this manual was complete and accurate at the time of printing. However, information is subject to change. Important Safety Information WARNING: To Reduce The Risk of Fire Or Electric Shock, Do Not Expose This Apparatus To Rain Or Moisture. -
Page 3: Package Contents
Description The GA6A is a rugged six-watt, dual-input audio amplifier with a wide variety of smaller applications including background music, relaying communication from one room to another, or sound reinforcement. The GA6A delivers rated power at not more than 1% total harmonic distortion from 75-15,000 Hz into transformer-coupled or direct low-impedance loads. -
Page 4: Panel Descriptions
1. Speaker Output Barrier Strip - Output terminal strip provides for 8-ohm, 25V, and 70V speaker outputs. 2. Shorting Link - Used when 25V or 70V speakers are to be connected to the GA6A. Must be removed if 8-ohm speakers are to be connected to the GA6A. - Page 5 Make sure that the total wattage of all the connected speakers is less than 6 watts. Note: Do not use both the 25V and 70V terminals at the same time. Use only one type of speaker (25V or 70V) for all speakers connected to the GA6A.
-
Page 6: Microphone Input
Note: Condenser microphones will not work with the GA6A because the GA6A does not supply phantom power, which is required for these microphones to operate. Use two-conductor shielded cable for a balanced input and connect the shield to the ground terminal. -
Page 7: Operation
Overload Protection The amplifier output is protected against overload and shorted speaker lines by a thermostat enclosed in the power transformer. If the breaker opens, the amplifier will have no output. Set the Power switch to OFF and wait a reasonable time for the breaker to reset. -
Page 8: Specifications
Warranty The GA6A is warranted to be free from defects in material or workmanship for two (2) years from the date of sale to the original purchaser. Any part of the product covered by this warranty that, with normal installation and use, becomes defective will be repaired or replaced by Bogen, at our option, provided the product is shipped insured and prepaid to: Bogen Factory Service Department, 50 Spring Street, Ramsey, NJ 07446, USA.
