ETI 641051 Series Use And Care Manual

nOTE: Keep your receipt and these instructions for proof of purchase
WarninG: Shut off the power at the circuit breaker or fuse panel before removing the old fixture, ballast, or fluorescent tubes.
If you are unfamiliar with electrical installations, we recommend you contact a qualified electrician to do the installation.

INSTALLATION

1. Shut off power at the electrical panel before beginning the installation.
2. Remove existing fluorescent tubes and set aside to recycle in accordance with local requirements.
3. Remove and set aside the ballast cover, if needed.
4. Use the existing shunted sockets if they in good condition. If not, it is recommended that new shunted sockets (not included) are installed.

ReTROfIT LumINAIRe wITh 1 LAmP

INSTANT START
PROGRAM START OR RAPID START

WarninG:

• Risk of fire or electric shock. LED Retrofit Kit installation requires knowledge of luminaires electrical systems. If not qualified, do not attempt installation. Contact a qualified
electrician.
• Risk of fire or electric shock. Install this kit only in the luminaires that have the construction features and dimensions shown in the photographs and/or drawings and where the
input rating of the retrofit kit does not exceed the input rating of the luminaire.
• Do not make or alter any open holes in an enclosure of wiring or electrical components during kit installation.
• To prevent wiring damage or abrasion, do not expose wiring to edges of sheet metal or other sharp objects.
CaUTiOn: Not for emergency lighting.
WarninG: THIS RETROFIT KIT IS ACCEPTED AS A COMPONENT OF A LUMINAIRE WHERE THE SUITABILITY OF THE COMBINATION SHALL BE DETERMINED BY AUTHORITIES HAVING
JURISDICTION. • Installers should not disconnect existing wires from lampholder terminals to make new connections at lampholder terminals. Instead installers should cut existing
lampholder leads away from the lampholder and make new electrical connections to lampholder lead wires by employing applicable connectors. • THERE ARE LED TUBE, OPERATION
INSTRUCTION AND FIELD APPLIED LABEL IN THIS RETROFIT KIT.
The units covered by this report were intended to be retrofit surface mounted. Type IC and non-IC recessed mounted fluorescent luminaires use a maximum of six lamps, the minimum
lamp compartment dimensions are below:
nOTiCE: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device
must accept any interference received, including interference that may cause undesired operation. These limits are designed to provide reasonable protection against harmful interference
in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio
or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
Reorient or relocate the receiving antenna, increase the separation between the equipment and the receiver, connect the equipment into an outlet on a circuit different from that to which
the receiver is connected, and consult the dealer or an experienced radio/TV. Changes or modifications not expressly approved by the party responsible for compliance could void the
user's authority to operate the equipment.
See website for Warranty, Troubleshooting or Care and Cleaning details at www.ETiSSL.com.
Questions, problems, missing parts? Call ETiSSL Customer Service 8 a.m. - 5 p.m., CST, Monday - Friday
UsE anD CarE GUiDE
T5 LED BaLLasT ByPass TUBE
Electronic
Ballast
45 3/4"
Fluorescent lamp
Electronic
Ballast
Fluorescent lamp
model minimum Lamp Compartment Dimensions
Number
641051XX
1-855-eTI-SSLI (1-855-384-7754) www.eTiSSL.com
3/4"
[Length x width x height] [in]
46 x 15.7 x 3.5
Part # T5BP-4-35-850-MV-DE
Certification # 64105161
LED Tube
LED Tube
maximum Lamp
Quantity
6
Ordering # 64105161
