Elec-Tech International Co., Ltd.
Product Instruction Manual
500W
Product Name: LED Grow Light
Model No.： 55403161
Manufacturer: Elec-Tech International Co., Ltd.
Address: No.1 Jinfeng Road, Tangjiawan Town, Xiangzhou Dist, Zhuhai City, Guangdong Province,
China
Tel：0756-3390990
Fax：0756-3390778
Web：www.etissl.com.cn
Content
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ETI 55403161
Summary of Contents for ETI 55403161
- Page 1 Elec-Tech International Co., Ltd. Product Instruction Manual 500W Product Name: LED Grow Light Model No.： 55403161 Manufacturer: Elec-Tech International Co., Ltd. Address: No.1 Jinfeng Road, Tangjiawan Town, Xiangzhou Dist, Zhuhai City, Guangdong Province, China Tel：0756-3390990 Fax：0756-3390778 Web：www.etissl.com.cn Content...
-
Page 2: Table Of Contents
1. ProductIntroduction‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐3 1.1 ProductDescription ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐3 1.2 SchematicDiagram‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐3 2. ProductFeature‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐2 2.1 Productcharacteristic ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐2 2.2 Specification‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐3 2.3 LightDistribution‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐4 3. Methodofapplication‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐4‐7 4. Function keys Instruction‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐7 5. Controler pairing instruction‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐8‐10 6. MaintenanceInstruction‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐10 7. Environmentalrequirement‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐11 8. Productcarriedstandard‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐11 9. Packageinstruction ‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐‐11 1. Product Introduction... -
Page 3: Productintroduction
1.1. Product Description Out Size： 700x350x138mm； Frame:AL+ABS , Drive box:SPCC Powderspray, lamp cover:Tempered glass built‐in drive drive box 4 Radiating Systim：AL+Air fan Samsung‐LED‐2835；OSRAM‐LED‐3030‐Red；OSRAM‐LED‐3030‐Blue 1.2.Product schematic diagram: 2. Product Featuers: 2.1. Product characteristics ： a. Long lifetime (above 50,000hrs) ； b. -
Page 4: Lightdistribution
Item/ Parameter Electronicratings WRatedPower/W 500W VRatedInputvoltage/V AC120‐277V HzFrequency/Hz 60Hz %RatedPowerefficiency 85% （PF）RatedPowerFactor 0.95 ARatedInputcurrent/A 4.15A RatedI‐THD <20% Photometricratings Samsung‐2835/1W/280PCS LEDtype/Qty. Osram‐3030‐R/3W/84PCS Osram‐3030‐B/3W/60PCS /PPF 800 umol/s Red/Blue/5000K ... - Page 5 Hanging Mount Attached two rope hangers to the ceiling or the structure that can support the weight of grow light plus some extra for power cords and rope hanger,etc. ...
- Page 6 Hold the fixture body by hands, and hang the fixture body by placing one V type hook over each hole on both side of the fixture, adjust the rope hanger to level light. Insert one end of the provided power cord into to back of the fixture, and plug the other end of power cord into an electrical outlet.
-
Page 7: Function Keys Instruction
Operation Instruction for Control Panel Button and Knob on The Fixture 4.1. (Power Switch, “I /O”button, “I”represents power on , “O” represents power off) 4.2. (Spectrum Switch, “I /O/II”button, “I”represents full spectrum, “O”represents “Flower” spectrum, “II”represents “Veg”spectrum) 4.3. ( Timer knob, spin the knob pointing to the desired position, then it starts the timer: “OFF”represents timer ... -
Page 8: Controler Pairing Instruction
5. (Guideline to remote controller) (ON/OFF Button: When light is on press this button, the light will be off; when light is off press ON/OFF button the light will be on.) ( Select ALL button: Press this button, all the light will be on.) (Press Red- button, red light reduces.) ... - Page 9 (Press White+ button, white+ light increases.) (Previous represents select the previous light.) (Next represents select the next light.) (Group1: When a grow light is selected, within 5 seconds press this button in short time, this grow light will be added to group1. The light flash indicates the grow light is added successfully.) (Group2: When a grow light is selected, within 5 seconds press this button in short time, this grow light will be added to group2.
-
Page 10: Maintenanceinstruction
(Timer: Press the button in short time lighting time will switch: 0h, 2h,4h,6h,8h, total five kind of light time. When lighting time is over, the light goes off, and the light on/off cycle is 24 hours.) (Pair the grow light to remote controller: When the fixture is power on within 60s, switch to “remote control” mode , press Paring button, the grow light will flash to indicate the fixture is connected. Grow light is controlled by pressing the -/+ and on/off buttons on the remote controller. -
Page 11: Environmentalrequirement
8． Product carried standard UL-1598/UL8750 9. Package Instruction 9.1 Packing Specification 9.2 Package list Package size Lamp Qty./box 1 PCS Net weight 13.98 Kgs Gross weight 14.5 Kgs Item Qty. Grow lamp Instruction manual Pothook Power Line... - Page 12 FCC STATEMENT 1. This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
