Conceptronic CM3S Firmware Upgrade Instructions

Hide thumbs Also See for CM3S:

A. Upgrade information

The Conceptronic CM3S is equipped with an upgradeable firmware chip. This function makes it possible to

improve the device and to add new features.

Note:

The firmware upgrade procedure is at your own risk. Even though a firmware upgrade can

improve the device and add new features, there's a small possibility of an upgrade failure

which makes the device unusable.

B. Upgrade procedure

1.1 If you have downloaded the firmware upgrade from www.conceptronic.net, you have a ZIP file

containing a folder named 'Firmware' and three documentation files.

1.2 Connect the CM3S to your computer with the USB cable.

1.3 Copy the 'Firmware' folder including all its content to the hard disk of the CM3S.

1.4 Remove the CM3S from your computer with the 'Safely remove hardware' option.

1.5 Disconnect the USB cable of the CM3S and turn it off with the switch on the back side.

for firmware version 1.58D

www.conceptronic.net

Page 1 of 3

Table of Contents

Need help?

Do you have a question about the CM3S and is the answer not in the manual?

Page 1 1.3 Copy the ‘Firmware’ folder including all its content to the hard disk of the CM3S. 1.4 Remove the CM3S from your computer with the ‘Safely remove hardware’ option. 1.5 Disconnect the USB cable of the CM3S and turn it off with the switch on the back side. ®...
Page 2 ‘Firmware’ folder is selected on your TV or monitor. 3.3 Remove the CM3S from your computer with the ‘Safely remove hardware’ option. 3.4 Disconnect the USB cable from the CM3S and turn it off with the switch on the back side. 4. Checking the current firmware version 4.1 Make sure the CM3S is connected to a TV or monitor.
Page 3 When the amount of files in a folder exceeds 99, the total amount is displayed as “Á” in stead of the actual number. Improved: Boot time. 1.57B July 7, 2008 Initial release. ® Copyright 2009 by Conceptronic – All rights reserved www.conceptronic.net Page 3 of 3...
