Conceptronic CM3PVR – DVD Playback & AVI Subtitle Instructions

A. DVD Playback Instructions

From firmware version 038, the CM3PVR supports DVD Playback functionality.

To play DVD files from the CM3PVR, follow the instructions below:

1. Create a folder on the CM3PVR hard disk in the 'VIDEO' folder with the name of your DVD movie (for example:

'Movie1').

2. Copy the 'AUDIO_TS' and 'VIDEO_TS' including content from your DVD to the created folder (for example:

'Movie1') on the CM3PVR.

After copying, the structure should be:

- VIDEO

|-> Movie1

|-> AUDIO_TS

|-> VIDEO_TS

for firmware version 038 and later versions

(optional)

(with all the DVD files inside)

www.conceptronic.net

Page 1 of 3

Table of Contents

Need help?

Do you have a question about the CM3PVR and is the answer not in the manual?

Page 1 From firmware version 038, the CM3PVR supports DVD Playback functionality. To play DVD files from the CM3PVR, follow the instructions below: 1. Create a folder on the CM3PVR hard disk in the 'VIDEO' folder with the name of your DVD movie (for example: 'Movie1').
Page 2 7. Select the movie folder and press the 'PLAY/PAUSE' button on your remote control. The DVD playback will now start. Note: If you press 'ENTER' instead of 'PLAY/PAUSE', the CM3PVR will not play the DVD movie, but will open the (movie) folder. Remote Control functions during DVD Playback...
Page 3 B. AVI Subtitle Instructions From firmware 038, the CM3PVR supports the following subtitle files: • • • • To play AVI files with subtitles, you need to assign the same name to the subtitle file as the AVI file. For example: Movie name: My_Movie_With_Sub.AVI...
