broadband Internet access settings.
5.1.2
1. web login ONU and select Network -> WAN -> WAN Connection, and then set
the following parameters:
【Connection name】Select "Create WAN Connection".
【New Connection name】According to own convenience to specify.
【Link Type】Select "IP".
【IP Version】The default is "Ipv4". ONU itself does not support IPV6.
【IP Type】Select "DHCP".
Company Address: Room 601, Floor 6, Building F, Songbai Road 1008, Sunshine Community，Xili Street, Nanshan District, Shenzhen(518108)
Factory Address: Fl1, Bldg B, Wentao Industrial zone, Yingrenshiyongxin Village, Shiyan Street, Baoan district, Shenzhen, Guangdong, China (518055)
Tel: +86-755-26014509/4710/4711 Fax:+86-755-26014506
Website: www.cdatatec.com
2. After the above configuration, click "create" button to complete the PPPoE
DHCP broadband Internet access in routing mode
【Enable Vlan】This one can be set according to the network planning situation, if
the network planning Internet vlan, this one need to check the
"Enable vlan"; If the network is not planning Internet vlan, this one
does not need to check, then ONU is vlan transparent mode.
【 Vlan ID 】 The same as "Enable Vlan", Setting depending on the network vlan
planning.
【802.1p】Set the priority of vlan, The same as "enable Vlan", depending on the
network vlan planning to configure. The default priority is 0.
【Type】Select "Route".
【 Service List 】 Select internet. route mode access internet are generally select
internet.
【MTU】The default is 1492 does not need to modify; if you meet can ping DNS but
the web browser can not access the site. Modify MTU smaller, such
as: 1400.
【Enable NAT】Check the "Enable NAT" function; NAT function is mainly used for
internal network and external network communication address
translation function, the default is checked enabled state, if not
check the network ONU not get the network.
Note: ZTE solution ONU series of products is no port binding function, because
