C-DATA R_EPON HGU Products
4FE+WIFI+CATV/4FE+WIFI/1GE+WIFI/1GE
+WIFI+CATV/4GE+WIFI+CATV/4GE+WIFI
User Manual
Version：V1.1
Company Address: Room 601, Floor 6, Building F, Songbai Road 1008, Sunshine Community，Xili Street, Nanshan District, Shenzhen(518108)
Factory Address: Fl1, Bldg B, Wentao Industrial zone, Yingrenshiyongxin Village, Shiyan Street, Baoan district, Shenzhen, Guangdong, China (518055)
Tel: +86-755-26014509/4710/4711 Fax:+86-755-26014506
Website: www.cdatatec.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for C-Data EPON HGU
Summary of Contents for C-Data EPON HGU
- Page 1 C-DATA R_EPON HGU Products 4FE+WIFI+CATV/4FE+WIFI/1GE+WIFI/1GE +WIFI+CATV/4GE+WIFI+CATV/4GE+WIFI User Manual Version：V1.1 Company Address: Room 601, Floor 6, Building F, Songbai Road 1008, Sunshine Community，Xili Street, Nanshan District, Shenzhen(518108) Factory Address: Fl1, Bldg B, Wentao Industrial zone, Yingrenshiyongxin Village, Shiyan Street, Baoan district, Shenzhen, Guangdong, China (518055) Tel: +86-755-26014509/4710/4711 Fax:+86-755-26014506 Website: www.cdatatec.com...
-
Page 2: Table Of Contents
Content Note............................. 1 Installation Precautions....................1 Precautions for Use......................1 Brief.............................3 Product Features......................3 Product Specifications....................4 Device Interface Definition.................... 4 LED Description......................5 Device Connection......................5 Applications........................6 Login Web Management Locally....................6 Physical Connection of ONU and PC................6 PC Access the WEB of ONU..................7 ONU Register Information Config..................... - Page 3 11.2 Restore Default Setting....................26 11.3 Firmware Upgrade......................26 11.4 Device Reboot.......................27 Concluding Remarks.........................27 Company Address: Room 601, Floor 6, Building F, Songbai Road 1008, Sunshine Community，Xili Street, Nanshan District, Shenzhen(518108) Factory Address: Fl1, Bldg B, Wentao Industrial zone, Yingrenshiyongxin Village, Shiyan Street, Baoan district, Shenzhen, Guangdong, China (518055) Tel: +86-755-26014509/4710/4711 Fax:+86-755-26014506 Website: www.cdatatec.com...
-
Page 4: Note
1 Note 1.1 Installation Precautions Do not place the equipment near flammable or conductive items, high temperatures (such as direct sunlight) or in wet conditions, or on a PC chassis, and check that the surrounding appliances are stable. Check the cable for aging. Check and verify that the AC or DC input voltage is within the permissible range of the device and that the polarity of the DC is correct. - Page 5 To ensure safety, do not open the enclosure of the device, especially when the device is powered up. Unplug the power supply before cleaning the equipment. Use a soft dry cloth to clean the equipment to avoid the use of liquids or sprays. ...
-
Page 6: Brief
Realtek EPON HGU (HomeGateway ONU) series products can be integrated wireless capabilities, fully in accordance with 802.11 n/b/g wireless standard protocols, built-in high gain... -
Page 7: Product Specifications
Support AES - 128, support for key generation and switch Support technology based on the DBA and priority of dual management model, to ensure that the user specified minimum bandwidth requirements Support CATV business remotely shut off function ... -
Page 8: Led Description
2.4 LED Description Indicator Description On: The ONU is power on; Power status Off: The ONU is Power off; On：CATV optical normal（>-9dBm） CATV CATV port status Off：The CATV signals are not received （<-9dBm） Blinking：Data is being transmitted WIFI WIFI On：Wi-Fi function Opens On: Ethernet connection is normal;... -
Page 9: Applications
Connect the AC adapter: Plug the AC / DC adapter into the AC wall jack and the ONU 12V DC power jack. 2.6 Applications 3 Login Web Management Locally 3.1 Physical Connection of ONU and PC a) Local NIC of PC connects to LAN port or ETH port of ONU via wires. b) Set the IP address of PC’s local NIC as 192.168.101.X (X：2-254). -
Page 10: Pc Access The Web Of Onu
3.2 PC Access the WEB of ONU Make sure you can ping the ONU like #3.1. Open the IE Web broswer (IE, Firefo x, Google), copy and paste URL: http: //192.168.101.1, the following pop-up Prompt landi n-g page: adminisp adminisp Input UserName：... -
Page 11: Onu Register Information Config
You can start further configuration. 4 ONU Register Information Config 4.1 View ONU Register Status 1. Login ONU WEB, select Status -> Internet Info -> GPON Info, view the ONU register status： 4.2 View ONU Optical Power Information 1. Login ONU WEB, select Status -> Internet Info -> GPON Info, view Rx power and Tx power of ONU：... -
Page 12: Loid Authentication Config
4.3 LOID Authentication Config LOID of ONU is mainly applicable of the authentication mode of LOID and LOID + Password for ONU. By default,EPON ONU registers for the OLT by MAC and rarely uses LOID for register. Normally, we needn’t to configure LOID. But the configuration as follows: 1. - Page 13 【Internet way】Select ‘PPPoE’ 【NAT】 Check ‘NAT’ feature； NAT is mainly used for address translation function of local network and external network. The default is checked enable status. If you do not check this option, maybe you can’t surf the internet. 【Enable Vlan】We can set this option according to your network plan.
- Page 14 2. After configuring the parameters of PPPoE WAN connection as above, click ‘Apply’ to finish the setting： 5.1.2 Configure DHCP WAN Connection for Internet in Route Mode 1．Login ONU WEB, select Internet -> Internet Config -> Internet Config, and then there are some parameters for us to configure as follows: 【WAN Connection name】Select ‘Add WAN Connection’...
- Page 15 do not check this option, maybe you can’t surf the internet. 【Enable Vlan】We can set this option according to your network plan. If there is vlan in the network for internet, we have to check ‘ Enable VLAN ‘ option. If not, we needn’t check this option, which will be VLAN transparent mode.
- Page 16 2.After configuring the parameters of DHCP WAN connection as belows, click ‘Apply’ to finish the setting： Company Address: Room 601, Floor 6, Building F, Songbai Road 1008, Sunshine Community，Xili Street, Nanshan District, Shenzhen(518108) Factory Address: Fl1, Bldg B, Wentao Industrial zone, Yingrenshiyongxin Village, Shiyan Street, Baoan district, Shenzhen, Guangdong, China (518055) Tel: +86-755-26014509/4710/4711 Fax:+86-755-26014506 Website: www.cdatatec.com...
- Page 17 5.1.3 Configure Static IP Address WAN Connection for Internet in Route Mode 1．Login ONU WEB, select Internet -> Internet Config -> Internet Config, and then there are some parameters for us to configure as follows: 【WAN Connection name】Select ‘Add WAN Connection’ 【Mode】Select ‘...
- Page 18 2. After configuring the parameters of Static IP WAN connection as belows, click ‘Apply’ to finish the setting： Company Address: Room 601, Floor 6, Building F, Songbai Road 1008, Sunshine Community，Xili Street, Nanshan District, Shenzhen(518108) Factory Address: Fl1, Bldg B, Wentao Industrial zone, Yingrenshiyongxin Village, Shiyan Street, Baoan district, Shenzhen, Guangdong, China (518055) Tel: +86-755-26014509/4710/4711 Fax:+86-755-26014506 Website: www.cdatatec.com...
-
Page 19: Configure Bridge Wan Connection For Internet
5.2 Configure Bridge WAN Connection for Internet 1．Login ONU WEB, select Internet -> Internet Config -> Internet Config, and then there are some parameter for us to configure as follows: 【WAN Connection name】Select ‘Add WAN Connection’ 【Mode】Select ‘Bridge’ 【 Connection Mode 】 Select ‘Ipv4’; If there is Ipv6 in the network, we can select ‘Ipv4/Ipv6’. -
Page 20: View The Wan Connection Status
2. After configuring the parameter of Bridge WAN connection as above, click ‘Apply’ to finish the setting： 5.3 View the WAN Connection Status 1．Login ONU WEB, select Status -> Internet Info -> IPv4 Status. In here, we can view WAN connection status, check the route WAN connection if it gets an IP address and Bridge WAN connection if it is UP. -
Page 21: Onu Lan Configuration
6 ONU LAN Configuration 6.1 LAN IP Address Configuration 1．Login ONU WEB, select Internet -> DHCP Server -> IPv4 DHCP Server, and then there are some parameters for us to configure as follows: 【 IP address 】 Set local management IP address of ONU. The default IP address is 192.168.101.1 【Subnet mask】Set the mask of local management IP address of ONU 【... -
Page 22: View Lan Client
2．After configuring the parameters of LAN address as above, click ‘Apply’ to finish the setting： 6.2 View LAN Client 1．Login ONU WEB, select Status -> LAN & WLAN -> WLAN Status. View client that access via wireless (WIFI). As follows: 2．Login ONU WEB, select Status ->... -
Page 23: Multicast/Iptv Configuration
7 Multicast/IPTV Configuration 7.1 Multicast/IPTV Service Setting Firstly, configure a bridge WAN connection to carry IGMP/IPTV service according to #6.2 and select ‘Other’ in service mode. After configuring the bridge WAN connection, The configuration, related to other multicast protocols and multicast vlan, can refer to the following # 7.2- # 7.3 configuration. -
Page 24: Igmp Vlan Configuration
disable IGMP Proxy function and click ‘Save’ button to finish the setting as follows: Note: Normally, IGMP Proxy would be used in route mode and carrying Multicast/IPTV service, because the ONU would be acted as multicast agent. There isn’t IGMP Proxy concept in the bridge mode. -
Page 25: Wlan Password Configuration
【Virtual SSID】Click ‘Virtual SSID’ button to enter the virtual SSID config page； 【Band】The default is 2.4GHz（B+G+N）； 【SSID 】Set wireless SSID name. Nowadays, it doesn’t support to set as Chinese SSID name. 【 Bandwidth 】 It is best to select 20MHz, because many PC don’t support 40MHz ； Sometimes, PCs can’t connect to the WIFI if we select 40MHz or 20MHz/40MHz；... -
Page 26: Wlan Virtual Ssid
2．After setting wireless password configuration, click ‘Save/Apply’ button to finish setting. 8.3 WLAN Virtual SSID 1．Login ONU WEB, select Internet->WLAN Config->WLAN Config, and then click ‘Virtual SSID’ button to enter ‘Virtual SSID’ page. We can enable some of virtual SSID, set band and name them: 2．After setting wireless password configuration, click ‘Save/Apply’... -
Page 27: View Catv Information
CATV port and configure the parameters accoding to your requirement. After setting the the parameters, click ‘Apply Changes’ button to finish the setting. 9.2 View CATV Information 1．Login ONU WEB, select Status->Device Info->CATV Info. In this page, we can view the CATV port status and related parameters: 10 TR069 Remote Management ONU TR069 remote management is mainly used for some network that support TR069... -
Page 28: Tr069 Client Configuration
10.2 TR069 Client Configuration Login ONU WEB, select Internet-> Remote Mgmt -> ITMS Server. In this page, we can set ONU’s paremeter of TR069 client (User Name, Password, URL address, Connection request user name and Connection request password). Note: All of parameters of TR069 are offered by ISP. 11 Device Management 11.1 ONU Remote Access Configuration Login the ONU WEB, select Management ->... - Page 29 11.2 Restore Default Setting Login the ONU WEB. Select Management -> Device -> Restore ONU. Click ‘Restore Default Setting’ button. The device will restore the factory defaults after the application. Note:Restore Setting on the ONU WEB is take effect to WIFI information of ONU and LAN port configuration only.
- Page 30 Login the ONU WEB. Select Management ->Device->Device Reboot. Click ‘Save/Restart’. Restart the device immediately after application. Concluding Remarks Thanks for using products of Shenzhen C-Data Technology Co. Ltd. Contact Information: Company Address: Room 601, Floor 6, Building F, Songbai Road 1008, Sunshine Community，Xili Street, Nanshan District, Shenzhen(518108)
- Page 31 Website: www.cdatatec.com www.cdatatec.com.cn Company Address: Room 601, Floor 6, Building F, Songbai Road 1008, Sunshine Community，Xili Street, Nanshan District, Shenzhen(518108) Factory Address: Fl1, Bldg B, Wentao Industrial zone, Yingrenshiyongxin Village, Shiyan Street, Baoan district, Shenzhen, Guangdong, China (518055) Tel: +86-755-26014509/4710/4711 Fax:+86-755-26014506 Website: www.cdatatec.com...
