C-DATA Z_EPON SFU Products
1GE/1GE+CATV
User Manual
Version：V1.1
Company Address: Room 601, Floor 6, Building F, Songbai Road 1008, Sunshine Community，Xili Street, Nanshan District, Shenzhen(518108)
Factory Address: Fl1, Bldg B, Wentao Industrial zone, Yingrenshiyongxin Village, Shiyan Street, Baoan district, Shenzhen, Guangdong, China (518055)
Tel: +86-755-26014509/4710/4711 Fax:+86-755-26014506
Website: www.cdatatec.com
Advertisement
Table of Contents
Related Manuals for C-Data EPON SFU
Summary of Contents for C-Data EPON SFU
- Page 1 C-DATA Z_EPON SFU Products 1GE/1GE+CATV User Manual Version：V1.1 Company Address: Room 601, Floor 6, Building F, Songbai Road 1008, Sunshine Community，Xili Street, Nanshan District, Shenzhen(518108) Factory Address: Fl1, Bldg B, Wentao Industrial zone, Yingrenshiyongxin Village, Shiyan Street, Baoan district, Shenzhen, Guangdong, China (518055) Tel: +86-755-26014509/4710/4711 Fax:+86-755-26014506 Website: www.cdatatec.com...
-
Page 2: Table Of Contents
Contents Note............................1 1.1 Installation Precautions.......................1 1.2 Precautions for Use......................1 Introduce..........................3 2.1 Product Feature........................3 2.2 Environmental Requirements..................... 4 2.3 Product Interface Definitions....................5 2.4 Product LED Definitions....................5 2.5 Device Connection......................5 2.6 Network Application......................6 ONU Local WEB login......................6 3.1 ONU and PC physical Connection.................. -
Page 3: Note
1 Note 1.1 Installation Precautions Do not near flammable or conductive items, high temperature, direct sunlight or moist environment, or on PC chassis, and check whether other home equipment placed around stability Check the cable line. Test and confirm the ac or dc input voltage in the range of allowable, and direct current (dc) correct polarity. - Page 4 Unplug the power supply before cleaning equipment. Use a soft dry cloth cleaning equipment, do not use the liquid or spray. Do not use this product connected to any electronic products unless got our engineer allow. because any wrong connection may cause electricity or fire danger. Company Address: Room 601, Floor 6, Building F, Songbai Road 1008, Sunshine Community，Xili Street, Nanshan District, Shenzhen(518108) Factory Address: Fl1, Bldg B, Wentao Industrial zone, Yingrenshiyongxin Village, Shiyan Street, Baoan district, Shenzhen, Guangdong, China (518055) Tel: +86-755-26014509/4710/4711 Fax:+86-755-26014506...
-
Page 5: Introduce
2 Introduce ZTE EPON SFU series of terminal equipment is based on EPON technology based on the broadband access market, to meet the broadcaster operators broadband access and FTTH, and design passive optical network terminal products that integrate CATV optical receiver and achieve broadband, CATV dual network integration. -
Page 6: Environmental Requirements
Support PPPoE, DHCP, static IP broadband service access Support NAT, static routing, port forwarding Support data encryption, VLAN transparent, vlan tag, vlan trunk Support up and down traffic limit function Supports port loop detection / port link status detection / power dying gasp alarm ... -
Page 7: Product Interface Definitions
2.3 Product Interface Definitions 2.4 Product LED Definitions Indicator Description On: The ONU is power on Power status Off: The ONU is Power off On: Ethernet connection is normal Blinking: Data is being transmitted through LANn LAN port status theEthernet port Off: Ethernet connection is not set up On: Success to register to OLT ONU Register... -
Page 8: Network Application
of the ONU and the home device, ie, the computer, IPTV set-top box. Connecting the coaxial cable: Connect the coaxial cable to the RF connector of the ONU. Connect the AC adapter: Plug the AC / DC adapter into the AC wall jack and the ... -
Page 9: Computer Access Onu Local Web
192.168.101.1 management ip address 3.2 Computer Access ONU Local WEB In the case # 3.1 computer can communicate with the ONU, open the computer's Web browser (IE, Firefox, google), copy and paste the ONU access URL: http: //192.168.101.1, pop-up as follows ONU prompt landing page: adminisp adminisp Enter the ONU super login user:... -
Page 10: Onu Registration Information Configuration
After entering the main interface of the ONU, the ONU can be set up further. For details, see the following setup guide. 4 ONU Registration Information Configuration 4.1 ONU Registration Status View web login ONU select the Status ->Network interface -> PON inform, you can check whether the ONU registered successfully: 4.2 ONU Optical Power Information View web login ONU select the Status ->... -
Page 11: Onu Registration Loid Configuration
4.3 ONU Registration LOID Configuration The LOID of the ONU is mainly applicable to the authentication mode of LOID and LOID + Password. General EPON ONU authentication method is MAC address, and rarely use the LOID authentication mode, so normal circumstances do not need to configure the LOID. -
Page 12: Internet Basic Configuration
5 Internet Basic Configuration ZTE ONU series of products support route function, Internet can work by route mode or bridge mode, the difference between the two modes are as follows: Routing mode Broadband Internet access: ONU as a home gateway equipment, ONU on route mode can obtained IP address in three ways: DHCP, static IP and PPPoE. - Page 13 internet. 【MTU】The default is 1492 does not need to modify; if you meet can ping DNS but the web browser can not access the site. Modify MTU smaller, such as: 1400. 【Link Type】Select "PPPoE". 【Username】Enter the PPPoE Internet PPPoE account provided by the network operator.
- Page 14 2. After the above configuration, click "create" button to complete the PPPoE broadband Internet access settings. 5.1.2 DHCP broadband Internet access in routing mode 1. web login ONU and select Network -> WAN -> WAN Connection, and then set the following parameters: 【Connection name】Select "Create WAN Connection".
- Page 15 the ONU is SFU (pure data)+ Routing, the ONU either works in SFU mode, or is working in routing mode. 2.After the above configuration, click "create" button to complete the DHCP broadband Internet access settings. 5.1.3 Static IP Broadband Internet Access In Routing Mode 1.web login ONU and select Network ->...
- Page 16 internet. 【MTU】The default is 1492 does not need to modify; if you meet can ping DNS but the web browser can not access the site. Modify MTU smaller, such as: 1400. 【Link Type】Select "IP". 【IP Version】The default is "Ipv4". ONU itself does not support IPV6. 【IP Type】Select "static".
-
Page 17: Broadband Internet Access In Bridge Mode
2.After the above configuration, click "create" button to complete the Static IP broadband Internet access settings. 5.2 Broadband Internet Access In Bridge Mode ZTE solution ONU series products factory default mode in the bridge (pure data SFU), ONU bridge mode Internet does not need to do any configuration in the web interface. -
Page 18: Onu Lan Configuration
6 ONU LAN configuration The LAN side configuration of the ZTE solution ONU is mainly for terminal device when ONU in route mode. 6.1 LAN IP Address Configuration 1.web login ONU and select the Network -> LAN -> DHCP Server, And then set the following parameters: 【LAN IP Address】... -
Page 19: Multicast / Iptv Service Basic Settings
segment as the management IP address of the ONU. 【Assign IspDNS】Enable or Disable the ONU to allocate the upper ISP's DNS to the terminal. 【DNS Server1 IP Address/DNS Server2 IP Address/DNS Server3 IP Address】 The DNS address to be assigned to the terminal, in default ONU use itself ip 192.168.101.1 work as DNS proxy address, can enter according to network planning 【Default Gateway】The default gateway address assigned to the terminal... -
Page 20: Catv Management
8 CATV Management CATV management is mainly applied to ONU products with optical machine, you need to configure the optical machine parameters in ONU web. ZTE solution GPON 4FE + CATV ONU temporarily does not support CATV control function. 8.1 CATV Parameter Configuration web login ONU and select the Administration ->... -
Page 21: Onu Device Management
9 ONU Device Management 9.1 ONU Device Remote Access Settings web login ONU and select the Security -> Service Control -> Service Control. In this page you can set the ONU telnet remote access and WEB remote access: Company Address: Room 601, Floor 6, Building F, Songbai Road 1008, Sunshine Community，Xili Street, Nanshan District, Shenzhen(518108) Factory Address: Fl1, Bldg B, Wentao Industrial zone, Yingrenshiyongxin Village, Shiyan Street, Baoan district, Shenzhen, Guangdong, China (518055) Tel: +86-755-26014509/4710/4711 Fax:+86-755-26014506 Website: www.cdatatec.com... -
Page 22: Restore Default
9.2 Restore Default web login ONU and select the Administration -> System Management -> System Management. Click the "Restore Default" button to restore the ONU factory settings: 9.3 Software Upgrade web login ONU and select the Administration -> System Management -> Software Upgrade. -
Page 23: Reboot Device
9.4 Reboot Device web login ONU and select the Administration -> System Management -> System Management. Click the "Reboot" button to restart the ONU device: Company Address: Room 601, Floor 6, Building F, Songbai Road 1008, Sunshine Community，Xili Street, Nanshan District, Shenzhen(518108) Factory Address: Fl1, Bldg B, Wentao Industrial zone, Yingrenshiyongxin Village, Shiyan Street, Baoan district, Shenzhen, Guangdong, China (518055) Tel: +86-755-26014509/4710/4711 Fax:+86-755-26014506 Website: www.cdatatec.com... -
Page 24: Concluding Remarks
Concluding Remarks Thanks for using products of Shenzhen C-Data Technology Co. Ltd. Contact Information: Company Address: Room 601, Floor 6, Building F, Songbai Road 1008, Sunshine Community，Xili Street, Nanshan District, Shenzhen(518108) Factory Address: 1 floor, Building B, Wentao Industrial Park, Yingrenshi Community,...
