C-Data Z EPON HGU User Manual

4ge+wifi(dual-band) & 4ge+catv+wifi(dual-band)
Hide thumbs
Table of Contents

Advertisement

Quick Links

C-DATA Z_EPON HGU Product
4GE+WIFI(Dual-Band)
4GE+CATV+WIFI(Dual-Band)
User Manual
Version：V1.1
Company Address: Floor 6, Building F, Songbai Road 1008, Sunshine Community，Xili Street, Nanshan District, Shenzhen(518108)
Factory Address: Bldg B, Wentao Industrial zone, Yingrenshiyongxin Village, Shiyan Street, Baoan district, Shenzhen, Guangdong, China (518055)
Tel: +86-755-26014509/4710/4711 Fax:+86-755-26014506
Website: www.cdatatec.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Z EPON HGU and is the answer not in the manual?

Questions and answers

Related Manuals for C-Data Z EPON HGU

Summary of Contents for C-Data Z EPON HGU

  • Page 1 C-DATA Z_EPON HGU Product 4GE+WIFI(Dual-Band) 4GE+CATV+WIFI(Dual-Band) User Manual Version：V1.1 Company Address: Floor 6, Building F, Songbai Road 1008, Sunshine Community，Xili Street, Nanshan District, Shenzhen(518108) Factory Address: Bldg B, Wentao Industrial zone, Yingrenshiyongxin Village, Shiyan Street, Baoan district, Shenzhen, Guangdong, China (518055) Tel: +86-755-26014509/4710/4711 Fax:+86-755-26014506 Website: www.cdatatec.com...

  • Page 2: Table Of Contents

    Contents 1 Note..............................1 1.1 Installation Precaution......................1 1.2 Precaution For Use........................1 2 Brief..............................2 2.1 Product Features........................3 2.2 Product Specifications......................3 2.3 Device Interface Definition....................4 2.4 LED Description........................4 2.5 Device Connection........................ 5 2.6 Applications...........................5 3 Login Web Management Locally.................... 5 3.1 Physical Connection of ONU and PC...................5 3.2 PC Access the WEB of ONU....................
  • Page 3 11 Device Management........................28 11.1 ONU Device Remote Access Settings................28 11.2 Restore Default Setting..................... 29 11.3 Firmware Upgrade......................29 11.4 Device Reboot........................30 Concluding Remarks........................31 Company Address: Floor 6, Building F, Songbai Road 1008, Sunshine Community，Xili Street, Nanshan District, Shenzhen(518108) Factory Address: Bldg B, Wentao Industrial zone, Yingrenshiyongxin Village, Shiyan Street, Baoan district, Shenzhen, Guangdong, China (518055) Tel: +86-755-26014509/4710/4711 Fax:+86-755-26014506 Website: www.cdatatec.com...

  • Page 4: Note

    1 Note 1.1 Installation Precaution Do not place the equipment near flammable or conductive items, high temperatures (such  as direct sunlight) or in wet conditions, or on a PC chassis, and check that the surrounding appliances are stable. Check the cable for aging. Check and verify that the AC or DC input voltage is within the ...

  • Page 5: Brief

    Avoid eye looked at the optical interface directly, so as to avoid the laser beam emitted by  the interface damage the eyes. Please try to wear safety glasses to effectively protect your eyes from damage. It is best to plug in the fiber optic interface jacket when the optical interface is not in use .

  • Page 6: Product Features

    standards and support 2.4G and 5G, and the wireless transmission rate up to 1.2Gbps. It has the characteristics of strong penetrating power and wide coverage. It can provide users with more efficient data transmission security. Note: This manual is written in the form of 4GE+CATV+ WIFI(Dual-Band) ONU, and other models ONU can also be referenced.

  • Page 7: Device Interface Definition

    2.3 Device Interface Definition 2.4 LED Description Indicator Description Blinking：Data is being transmitted WIFI WIFI On：Wi-Fi function Opens Off：Wi-Fi function Close On: Ethernet connection is normal; Blinking: Data is being transmitted LAN1-4 LAN Port status through the Ethernet port; Off: Ethernet connection is not set up; On: Optical power lower than receiver EPON optical signals sensitivity ;...

  • Page 8: Device Connection

    2.5 Device Connection Connect the fiber: Insert the SC fiber connector into the PON connector on the rear  panel of the ONU.  Connect the Ethernet cable: Connect the RJ-45 Ethernet cable to any LAN port and each home device, that is, the computer, IPTV set-top box, and so on. Connect coaxial cable: Connect the coaxial cable to the RF connector of the ONU.

  • Page 9: Pc Access The Web Of Onu

    c) Open the cmd windows and make sure that PC can ping the management IP (192.168.101.1) of ONU. 3.2 PC Access the WEB of ONU Make sure you can ping the ONU like #3.1.Open the IE Web broswer (IE, Firefox, Google), copy and paste URL: http: //192.168.101.1 the following pop-up Prompt landin-g page:...

  • Page 10: Onu Register Information Config

    adminisp adminisp Input UserName： PassWord： Click “Login” button. The product basics page appears, as follows： After entering the main interface of the ONU, the ONU can be further set. For specific setting information, see the following setting instructions. 4 ONU Register Information Config Company Address: Floor 6, Building F, Songbai Road 1008, Sunshine Community，Xili Street, Nanshan District, Shenzhen(518108) Factory Address: Bldg B, Wentao Industrial zone, Yingrenshiyongxin Village, Shiyan Street, Baoan district, Shenzhen, Guangdong, China (518055) Tel: +86-755-26014509/4710/4711 Fax:+86-755-26014506...

  • Page 11: Check The Onu Register Status

    4.1 Check the ONU Register Status 1. Login ONU’s WEB, select Status -> Network Information -> Link information, view the ONU register status： 4.2 View ONU Optical Power Information 1. Login ONU’s WEB, select Status -> Network Information -> Link Information, view Input power and Output power of ONU：...

  • Page 12: Route Mode Configuration

    Route mode：ONT as a home gateway equipment, ONT IP address can be obtained in three ways, which includes DHCP, Static IP Address and PPPoE. The IP address of the device on the user side is obtained through the DHCP address pool of the ONT, or by manually setting;...
  • Page 13 【Service List】 Check “INTERNET”or“VOICE_INTERNET”;The broadband Internet of routing mode is usually check the “INTERNET”,the latter supports voice functions. 【VLAN Type】Configure this option according to our network plan.If the network plans the vlan of broadband Internet, this item needs to choose "tag";If the network has no vlan planning for broadband Internet access, this option is "untag”.

  • Page 14: Configure Dhcp Wan Connection For Internet In Route Mode

    Configure DHCP WAN Connection for Internet in Route Mode 5.1.2 1.Login ONU’s WEB, select Network->WAN->WAN Connection, and then there are some parameters for us to configure as follows: 【IP Version】Select ‘Ipv4’; If there is Ipv6 in the network, we can select ‘Ipv4/Ipv6’. 【Type】Select“DHCP”.
  • Page 15 【 Enable DHCP Server 】 check this option;Normally, Terminal , connected to the HGU ONU, will get an IP address from the ONU’s IP pool. Therefore, we need to check this option to get the IP address. 【 Enable NAT 】 Check ‘NAT’ feature;NAT is mainly used for address translation function of local network and external network.

  • Page 16: Configure Static Ip Address Wan Connection For Internet In Route Mode

    Configure Static IP Address WAN Connection for Internet in Route Mode 5.1.3 1. Login ONU’s WEB, select Network->WAN->WAN Connection, and then there are some parameters for us to configure as follows: 【IP Version】Select ‘Ipv4’; If there is Ipv6 in the network, we can select ‘Ipv4/Ipv6’. 【Type】Select ”Static”.
  • Page 17 【 Enable NAT 】 Check ‘NAT’ feature;NAT is mainly used for address translation function of local network and external network. The default is checked enable status. If you do not check this option, maybe you can’t surf the internet. 【Service List】 Check “INTERNET”or“VOICE_INTERNET”;The broadband Internet of routing mode is usually check the “INTERNET”,the latter supports voice functions.

  • Page 18: Configure Bridge Wan Connection For Internet

    5.2 Configure Bridge WAN Connection for Internet 1.Login ONU’s WEB, select Network->WAN->WAN Connection, and then there are some parameters for us to configure as follows: 【IP Version】Select ‘Ipv4’; If there is Ipv6 in the network, we can select ‘Ipv4/Ipv6’. 【Type】Select“Bridge”. 【Connection Name】Select “Create WAN Connection”.
  • Page 19 could refer to WLAN configuration this chapter. 【 Enable DHCP Server 】 uncheck this option;Normally, the terminal which had connected to the HGU ONU, will get an IP address from the ONU’s IP pool. Therefore, we need uncheck this option to avoid the terminal get an IP from the ONU.

  • Page 20: View The Wan Connection Status

    5.4 View the WAN Connection Status 1.Login ONU WEB, select Status ->Network Information-> IPv4 Connection. In here, we can view the route WAN connection status, check the route WAN connection whether it gets an IP address , As follows: Company Address: Floor 6, Building F, Songbai Road 1008, Sunshine Community，Xili Street, Nanshan District, Shenzhen(518108) Factory Address: Bldg B, Wentao Industrial zone, Yingrenshiyongxin Village, Shiyan Street, Baoan district, Shenzhen, Guangdong, China (518055) Tel: +86-755-26014509/4710/4711 Fax:+86-755-26014506 Website: www.cdatatec.com...

  • Page 21: Delete The Wan Connection

    5.5 Delete the WAN Connection 1. Login ONU’s WEB, select Network->WAN->WAN Connection, select the WAN connection that you want to delete in the “Connection Name”,and then click “Delete” button to finish deleting. 6 ONU LAN Configuration 6.1 DHCP Settings 1.Login onu’s web ,select Network->LAN Address Setting->DHCP Server, and configure the parameters as follows: 【...

  • Page 22: View Lan Client

    【Lease Time】Set the DHCP server allocated ip’s lease time,the configuration is one day. 【DHCP Start/End IP Address】Configure the IP address interval that allocated to the terminal. The address interval must be on the same network segment as the management IP address of the ONU.

  • Page 23: Multicast/Iptv Configuration

    the client that is connected via a LAN port. 7 Multicast/IPTV Configuration 7.1 Multicast/IPTV Service Setting Firstly, configure a bridge WAN connection to carry IGMP/IPTV service according to #5.2 and select ‘Other’ in Service List. After configuring the bridge WAN connection, The configuration, related to other multicast protocols and multicast vlan, can refer to the following # 7.2- # 7.3 configuration.

  • Page 24: Igmp Proxy

    7.3 IGMP Proxy 1. Login ONU WEB, select App -> IGMP Setting -> IGMP Setting. Choose Multicast Mode for Multicast Proxy and click ‘Submit’ button to finish the setting as follows: Note: Normally, IGMP Proxy would be used in route mode and carrying Multicast/IPTV service, because the ONU would be acted as multicast agent.

  • Page 25: Igmp Vlan Configuration

    7.4 IGMP VLAN Configuration 1.Login ONU’s WEB, select App->Daily Application->IPTV, select the corresponding WAN, click ‘Modify Icon’, configure multicast vlan, click ‘Modify’ button. ： 8 WLAN Configuration 8.1 WLAN Basic Configuration 1. Login ONU WEB, select Network->WLAN ->Basic, and then there are some parameters for us to configure as follows: 【Enable Wireless RF】Enable or disable the wireless function;...
  • Page 26 best to select 20MHz, because many PC don’t support 40MHz;Sometimes, can’t connect WIFI select 40MHz 20MHz/40MHz.When choose SSID 5-8, the default is 80MHz; 【 Channel 】 The default is Auto; We can select a channel without glitches by manual according to the surrounding environment; 【SGI Enable】Check by default, the default GI value 800us;...

  • Page 27: Wlan Password Configuration

    8.2 WLAN Password Configuration 1．Login ONU WEB, select Network->WLAN ->Security, then enter this page, user can configure ‘Authentication Type’ , ‘WPA Passphrase’ and “WPA Encryption Algorithm”. 2．After setting wireless password configuration, click ‘Submit’ button to finish setting. 8.3 WLAN Virtual SSID 1．Login ONU WEB, select Network->...

  • Page 28: Catv Configuration

    2．After setting wireless password configuration, click ‘Submit’ button to finish setting. 9 CATV Configuration CATV management is mainly applied to ONU with light machine, we need to configure the ONU optical machine parameters through the ONU WEB. 9.1 Configure CATV Port Parameter Select AdministrationCATV ManagementCATV Config.

  • Page 29: View Catv Information

    9.2 View CATV Information Login ONU WEB, select Status ->CATV ->CATV Status. In this page, we can view the CATV port status: Company Address: Floor 6, Building F, Songbai Road 1008, Sunshine Community，Xili Street, Nanshan District, Shenzhen(518108) Factory Address: Bldg B, Wentao Industrial zone, Yingrenshiyongxin Village, Shiyan Street, Baoan district, Shenzhen, Guangdong, China (518055) Tel: +86-755-26014509/4710/4711 Fax:+86-755-26014506 Website: www.cdatatec.com...

  • Page 30: Tr069 Remote Management

    10 TR069 Remote Management ONU TR069 remote management is mainly used for some network that support TR069 server centralized remote management, the current management is mainly used in many large networks, ONU as TR069 remote management of the client need to do the following settings.

  • Page 31: Device Management

    11 Device Management 11.1 ONU Device Remote Access Settings web login ONU and select the Security -> Service Control. In this page you can set the ONU telnet remote access and WEB remote access: Company Address: Floor 6, Building F, Songbai Road 1008, Sunshine Community，Xili Street, Nanshan District, Shenzhen(518108) Factory Address: Bldg B, Wentao Industrial zone, Yingrenshiyongxin Village, Shiyan Street, Baoan district, Shenzhen, Guangdong, China (518055) Tel: +86-755-26014509/4710/4711 Fax:+86-755-26014506 Website: www.cdatatec.com...

  • Page 32: Restore Default Setting

    11.2 Restore Default Setting Login the ONU’s WEB. Select Administration->System Management -> System Management. Click ‘Factory reset’ button. The device will restore the factory defaults after the application. 11.3 Firmware Upgrade Login the onu’s web by this URL,select Administration->System Managemen t ->Soft Update,click“Browser”...

  • Page 33: Device Reboot

    11.4 Device Reboot Login the ONU’s WEB. Select Administration->System Management -> System Management. Click ‘Reboot’ button. The device will reboot later. Company Address: Floor 6, Building F, Songbai Road 1008, Sunshine Community，Xili Street, Nanshan District, Shenzhen(518108) Factory Address: Bldg B, Wentao Industrial zone, Yingrenshiyongxin Village, Shiyan Street, Baoan district, Shenzhen, Guangdong, China (518055) Tel: +86-755-26014509/4710/4711 Fax:+86-755-26014506 Website: www.cdatatec.com...

  • Page 34: Concluding Remarks

    Concluding Remarks Thanks for using products of Shenzhen C-Data Technology Co. Ltd. Contact Information: Company Address: Room 601, Floor 6, Building F, Songbai Road 1008, Sunshine Community，Xili Street, Nanshan District, Shenzhen(518108) Factory Address: 1 floor, Building B, Wentao Industrial Park, Yingrenshi Community,...
