C-DATA R_GPON SFU Products
4GE/4GE+CATV/1GE+3FE/1GE+3FE+CATV
User Manual
Version：V1.1
1
Company Address: Floor 6, Building F, Songbai Road 1008, Sunshine Community，Xili Street, Nanshan District, Shenzhen(518108)
Factory Address: Bldg B, Wentao Industrial zone, Yingrenshiyongxin Village, Shiyan Street, Baoan district, Shenzhen, Guangdong, China (518055)
Tel: +86-755-26014509/4710/4711 Fax:+86-755-26014506
Website: www.cdatatec.com
Advertisement
Table of Contents
Related Manuals for C-Data GPON SFU
Summary of Contents for C-Data GPON SFU
- Page 1 C-DATA R_GPON SFU Products 4GE/4GE+CATV/1GE+3FE/1GE+3FE+CATV User Manual Version：V1.1 Company Address: Floor 6, Building F, Songbai Road 1008, Sunshine Community，Xili Street, Nanshan District, Shenzhen(518108) Factory Address: Bldg B, Wentao Industrial zone, Yingrenshiyongxin Village, Shiyan Street, Baoan district, Shenzhen, Guangdong, China (518055) Tel: +86-755-26014509/4710/4711 Fax:+86-755-26014506 Website: www.cdatatec.com...
-
Page 2: Table Of Contents
Content 1 Note..............................3 1.1 Installation Precautions......................3 1.2 Precautions for Use....................... 3 2 Brief..............................4 2.1 Product Feature........................5 2.2 Product Specification......................5 2.3 Device Interface Definition....................6 2.4 Device Connection........................ 6 2.5 Applications...........................7 2.6 ONU Instructions........................7 3 Login Web Management Locally....................7 3.1 Physical Connection of ONU and PC...................7 3.2 PC Access the WEB of ONU.................... -
Page 3: Note
1 Note Installation Precautions Do not place the equipment near flammable or conductive items, high temperatures (such as direct sunlight) or in wet conditions, or on a PC chassis, and check that the surrounding appliances are stable. Check the cable for aging. Check and verify that the AC or DC input voltage is within the permissible range of the device and that the polarity of the DC is correct. -
Page 4: Brief
Broadband, integrated transformation of the ideal technology. Realtek New Solution GPON SFU Series Terminals are available with 1-4 10M / 100M / 1000M adaptive interfaces, and the device has been interconnected with the GPON office equipment (OLT) of the industry's leading communications vendors (Huawei / ZTE / FiberHome / Company Address: Floor 6, Building F, Songbai Road 1008, Sunshine Community，Xili Street, Nanshan District, Shenzhen(518108) -
Page 5: Product Feature
Alcatel-Lucent), composed of gigabit systems, to meet the two-in-one video, data services of FTTH / FTTO access needs. Note: This manual is written in the form of 4GE+CATV EPON ONU, and other models ONU can also be referenced. 2.1 Product Feature Single-fiber access, providing broadband, CATV, IPTV service access, and so on. -
Page 6: Device Interface Definition
2.3 Device Interface Definition Indicator Description On: Ethernet connection is normal; Blinking: Data is being transmitted through LAN1-4 LAN Port status the Ethernet port; Off: Ethernet connection is not set up; On: Optical power lower than receiver GPON optical signals sensitivity ;... -
Page 7: Applications
2.5 Applications 2.6 ONU Instructions Realtek GPON SFU ONU is mainly work in the bridge mode, all the configuration of ONU (ONU port vlan, ONU port speed limit, etc.) are basically configured through the OLT, but also through the OLT and EMS network management to manage, It does not need to be configured on the ONU's local WEB. -
Page 8: Pc Access The Web Of Onu
c) Open cmd windows and make sure that PC can ping the management IP (192.168.101.1) of ONU. PC Access the WEB of ONU Make sure you can ping the ONU like #3.1. Open the IE Web broswer (IE, Firefox, Google), copy and paste URL: http: //192.168.101.1, the following pop-up Prompt landin-g page: Company Address: Floor 6, Building F, Songbai Road 1008, Sunshine Community，Xili Street, Nanshan District, Shenzhen(518108) -
Page 9: View Onu System Status
adminisp adminisp Input UserName： Password： Click “Login” button. The product basics page appears, as follows： You can start further configuration. 4 View ONU System Status Company Address: Floor 6, Building F, Songbai Road 1008, Sunshine Community，Xili Street, Nanshan District, Shenzhen(518108) Factory Address: Bldg B, Wentao Industrial zone, Yingrenshiyongxin Village, Shiyan Street, Baoan district, Shenzhen, Guangdong, China (518055) Tel: +86-755-26014509/4710/4711 Fax:+86-755-26014506 Website: www.cdatatec.com... -
Page 10: View Onu Device Information
View ONU Device Information Login ONU WEB. Click Status Device, we can view the Device Name, Uptime, Model ID, Software Version, Hardware Version, Build Information, IP Address, MAC Address and so on. View ONU PON Status Login ONU WEB. Click Status PON, we can view the Register Status, Rx Power and Tx Power and so on. -
Page 11: View Onu Catv Status Information
View ONU CATV Status Information Login ONU WEB. Click Status CATV, we can view the CATV information. Company Address: Floor 6, Building F, Songbai Road 1008, Sunshine Community，Xili Street, Nanshan District, Shenzhen(518108) Factory Address: Bldg B, Wentao Industrial zone, Yingrenshiyongxin Village, Shiyan Street, Baoan district, Shenzhen, Guangdong, China (518055) Tel: +86-755-26014509/4710/4711 Fax:+86-755-26014506 Website: www.cdatatec.com... -
Page 12: View Onu Lan Port Information
View ONU LAN Port Information Login ONU WEB. Click Status LAN Info, we can view onu each port status information. 5 Configure LAN IP Address of ONU Login ONU WEB. Click LAN, we can change IP address and subnet mask of local management. -
Page 13: View Onu Lan Side User Information
6 View ONU LAN Side User Information Login ONU WEB. Click Advance ARP Table, we can view the IP Address and MAC Address of every user that connect to the lan port of ONU. 7 ONU Diagnostic Ping diagnostic of Realtek SFU ONU is mainly used to test connectivity between ONU and client devices Company Address: Floor 6, Building F, Songbai Road 1008, Sunshine Community，Xili Street, Nanshan District, Shenzhen(518108) Factory Address: Bldg B, Wentao Industrial zone, Yingrenshiyongxin Village, Shiyan Street, Baoan district, Shenzhen, Guangdong, China (518055) -
Page 14: Onu System Management
Login ONU WEB. Click Diagnostics Ping, type terminal IP address that connect to the ONU lan port, and click ‘GO’ button to test the connectivity 8 ONU System Management Register LOID of ONU Config The LOID of ONU is mainly used for the authentication of LOID and LOID+Password from OLT. -
Page 15: Onu Vendor Id Settings
configure the LOID. But the way to configure the LOID is as below Login ONU WEB. Click Admin GPON Settings, we can configure the LOID and LOID password, and click ‘Apply Changes’ button to finish the settings. ONU Vendor ID Settings Login ONU WEB. -
Page 16: Catv Settings
8.3 CATV Settings Login ONU WEB. Click Admin CATV Settings, we can enable or diable CATV port and configure other parameters of CATV, and click ‘Apply Changes’ button to finish the settings. Company Address: Floor 6, Building F, Songbai Road 1008, Sunshine Community，Xili Street, Nanshan District, Shenzhen(518108) Factory Address: Bldg B, Wentao Industrial zone, Yingrenshiyongxin Village, Shiyan Street, Baoan district, Shenzhen, Guangdong, China (518055) Tel: +86-755-26014509/4710/4711 Fax:+86-755-26014506 Website: www.cdatatec.com... -
Page 17: Port Isolation Settings
Port Isolation Settings ONU ports isolation is mainly used to the terminal that connect to the ONU can communicate with each other or not. Login ONU WEB. Click Admin Port Isolation Settings, we can enable or disable port Company Address: Floor 6, Building F, Songbai Road 1008, Sunshine Community，Xili Street, Nanshan District, Shenzhen(518108) Factory Address: Bldg B, Wentao Industrial zone, Yingrenshiyongxin Village, Shiyan Street, Baoan district, Shenzhen, Guangdong, China (518055) Tel: +86-755-26014509/4710/4711 Fax:+86-755-26014506 Website: www.cdatatec.com... -
Page 18: Onu Loop Diagnostic
Isolation function in here, and click ‘Apply Changes’ button to finish the settings. ONU Loop Diagnostic Login ONU WEB. Click Diagnostics Loop Detect, we can enable or disable loop detect function of ONU. Note: Configured the loop detect function, we have to pay attention to configuration of this function that configured via OLT. -
Page 19: Reboot Onu
Reboot ONU Login ONU WEB. Click Admin Commit/Reboot, click ‘Commit and Reboot’ button to save the configuration and reboot the ONU. Company Address: Floor 6, Building F, Songbai Road 1008, Sunshine Community，Xili Street, Nanshan District, Shenzhen(518108) Factory Address: Bldg B, Wentao Industrial zone, Yingrenshiyongxin Village, Shiyan Street, Baoan district, Shenzhen, Guangdong, China (518055) Tel: +86-755-26014509/4710/4711 Fax:+86-755-26014506 Website: www.cdatatec.com... -
Page 20: Onu Chinese And English Interface Switch
ONU Chinese and English Interface Switch Login ONU WEB. Click Admin Multi-Language Settings. In here, we can change the language to Chinese or English, click ‘Update selected language’ button to finish the settings. Company Address: Floor 6, Building F, Songbai Road 1008, Sunshine Community，Xili Street, Nanshan District, Shenzhen(518108) Factory Address: Bldg B, Wentao Industrial zone, Yingrenshiyongxin Village, Shiyan Street, Baoan district, Shenzhen, Guangdong, China (518055) Tel: +86-755-26014509/4710/4711 Fax:+86-755-26014506 Website: www.cdatatec.com... -
Page 21: Reset Settings To Default
Reset Settings to Default Login ONU WEB. Click Admin Backup/Restore. In here, we can backup and restore settings, and click ‘Reset’ button to restore the ONU settings to default. Modify the Account and password Default system management account and password are adminisp/adminisp Default system common account and password are admin/admin... -
Page 22: Upgrade The Onu
8.10 Upgrade the ONU Firstly, we have to get a newest firmware from provider. Login ONU WEB. Click Admin Firmware Upgrade. In here, click ‘Choose File’ button to select a upgrade file, and click ‘Upgrade’ button to upgrade the ONU. Note: We needn’t extract Realtek project production’s firmware, just upgrade the .tar file. -
Page 23: Onu Interface Traffic Statistics
9 ONU Interface Traffic Statistics PON Statistics Login ONU WEB. Click Statistics PON Statistics. In here, we can view the information of transmitted and received packets of ONU PON port. Company Address: Floor 6, Building F, Songbai Road 1008, Sunshine Community，Xili Street, Nanshan District, Shenzhen(518108) Factory Address: Bldg B, Wentao Industrial zone, Yingrenshiyongxin Village, Shiyan Street, Baoan district, Shenzhen, Guangdong, China (518055) Tel: +86-755-26014509/4710/4711 Fax:+86-755-26014506 Website: www.cdatatec.com... -
Page 24: Onu Lan Interface Traffic Statistics
ONU LAN Interface Traffic Statistics Login ONU WEB. Click Statistics LAN Statistics. In here, we can view the information of transmitted and received packets of ONU lan ports. Company Address: Floor 6, Building F, Songbai Road 1008, Sunshine Community，Xili Street, Nanshan District, Shenzhen(518108) Factory Address: Bldg B, Wentao Industrial zone, Yingrenshiyongxin Village, Shiyan Street, Baoan district, Shenzhen, Guangdong, China (518055) Tel: +86-755-26014509/4710/4711 Fax:+86-755-26014506 Website: www.cdatatec.com... -
Page 25: Concluding Remarks
Concluding Remarks Thanks for using products of Shenzhen C-Data Technology Co. Ltd. Contact Information: Company Address: Room 601, Floor 6, Building F, Songbai Road 1008, Sunshine Community，Xili Street, Nanshan District, Shenzhen(518108) Factory Address: 1 floor, Building B, Wentao Industrial Park, Yingrenshi Community,...
